Overview
Congratulations on purchasing your Kramer VS-88UHDA.
VS-88UHDA is a high-quality 8x8 UHD Matrix Switcher for HDMI signals up to 4K@60Hz
4:2:0 and embedded/de-embedded analog audio. It reclocks and equalizes the signals and
can route any one of eight HDMI, HDCP-compliant sources (selectable) to any or all outputs
simultaneously. The VS-88UHDA offers unmatched audio flexibility where any embedded
digital or analog audio input can be routed to any embedded digital or analog audio output in
addition to 8 ARC sources to produce an equivalent 24x20 audio matrix.
The VS-88UHDA provides exceptional quality, advanced and user-friendly operation, and
flexible control.
Exceptional Quality
Max. data rate –8.91Gbps data rate (2.97Gbps per graphics channel).
Max. resolution –Up to 4K@60Hz UHD (4:2:0).
Step-in over HDMI technology.
HDMI, HDCP and DVI Compliance.
HDMI support –Deep color, 3D, ARC, up to 7.1 uncompressed audio channels.
Kramer reKlocking™ and equalization technology –rebuilds the digital signal to travel
longer distances.
Advanced and User-friendly Operation
Fast switching.
Audio level and balance support.

Kramer Electronics Ltd.
VS-88UHDA - Introduction
3
Embedded pattern generator (480p) –With selectable patterns.
Selectable HDCP per input.
Memory locations –16 presets for quick access to common configurations.
Advanced EDID management per input.
Active source and acceptor detection.
Easy front-panel operation.
Selectable switching speed.
Lock button to prevent tampering.
Kramer protocol 3000 support.
Firmware upgrade via mini USB, Ethernet or the RS-232 port.
Control Options –RS-232 serial commands transmitted by a PC, touch screen system or
other serial controller, Ethernet port via LAN.
7-segment display, indicating the video and audio status and other functions.
Audio breakaway and AFV (audio-follow-video) operation support.
Efficient power-saving features.
Includes non-volatile memory that retains the last settings, after switching the power off
and then on again.
Flexible Connectivity
Supports up to eight analog audio inputs, eight digital audio inputs and 8 ARC inputs.
8x8 switching for HDMI signals, 24x20 switching for audio signals.
Optional ARC from HDMI outputs and analog audio inputs to HDMI inputs 1, 3, 5 and 7.
Supports Step-in function.
Housed in a 19” 1U rack mountable enclosure, with rack ears included, and is fed from a
100-240 VAC universal switching power supply.
Typical Applications
The VS-88UHDA is ideal for the following typical applications:
Presentation and multimedia applications.
Systems that require automatic HDMI routing.
Controlling your VS-88UHDA
Control your VS-88UHDA directly via the front panel push buttons, or:
By RS-232 serial commands transmitted by a touch screen system, PC, or other serial
controller.
Via the Ethernet using built-in user-friendly Web pages.

Kramer Electronics Ltd.
VS-88UHDA - Defining the VS-88UHDA 8x8 UHD Matrix Switcher
4
Defining the VS-88UHDA 8x8 UHD
Matrix Switcher
This section defines the VS-88UHDA.
Figure 1: VS-88UHDA 8x8 UHD Matrix Switcher Front Panel
#
Feature
Function
The behavior of the front panel buttons and the 7-segment display changes along with the operation
modes. For further details see Operating VS-88UHDA via Front Panel Buttons on page 12.
IN (PATTERN)
SELECTOR Buttons
Press to select the input (1 to 8) to switch after selecting an output (also
used for storing machine setups in the STO-RCL modes and for selecting a
pattern in the Pattern mode).
OUT (MUTE) SELECTOR
Buttons
Press to select an output (1 to 8) to which the input is routed. Also used for
storing machine presets.
MUTE/PATTERN Button
Press to view the current pattern status and select the output/s to which a
pattern is routed.
Press to mute audio or video on a selected output when
D-AUDIO/A-AUDIO, and/or VIDEO buttons are pressed (lit).
ALL Button
Press to perform an action on all outputs (for example setting Mute mode,
Pattern mode and so on).
For switching, press ALL and then a specific INPUT button to route the
selected input to all outputs. For example, press ALL and then IN 2 to route
input 2 to all the outputs.
STO and RCL Buttons
Press STO to store the current switching setting to a preset button.
Press RCL to recall the switching setting from a preset button.
A-AUDIO Button
Press to enable analog audio routing. When pressed together with VIDEO,
the analog audio is routed together with the video signal.
D-AUDIO Button
Press to enable digital audio routing. When pressed together with VIDEO,
the digital audio is routed together with the video signal.
VIDEO Button
Press to select video inputs. When pressed together with
D-AUDIO/A-AUDIO, video is switched together with audio.
LOCK Button
Press and hold (for about 3 seconds) to toggle locking/releasing of the front
panel buttons.
Press to save the following setups: HDCP (On/Off), ARC, Fast Switch and
Switch mode.
EDID Button
Press to capture the EDID.
OUTPUT/INPUT
7-segment LED Display
Displays the selected inputs switched to the outputs (marked above each
input).

Kramer Electronics Ltd.
VS-88UHDA - Defining the VS-88UHDA 8x8 UHD Matrix Switcher
5
Figure 2: VS-88UHDA 8x8 UHD Matrix Switcher Rear Panel
#
Feature
Function
AUDIO IN on 3.5 Mini Jack
Connectors
Connect to unbalanced stereo analog audio sources (from 1 to 8).
INPUT HDMI Connector
Connect to the HDMI source (from 1 to 8).
AUDIO OUTPUT on 5-pin
Terminal Block Connectors
Connect to balanced stereo analog audio acceptor (see pinout below),
from 1 to 8.
OUTPUT HDMI Connectors
Connect to HDMI acceptors (from 1 to 8).
PROG Mini USB Port
Use for firmware upgrade or communication (connecting to a PC or a
serial controller).
SETUP DIP-Switches
N/A
5V/2A USB Port
Use to charge a device.
Reset Button
Press and hold while powering the device to reset IP settings to factory
default values.
ETHERNET RJ-45 Port
Connect to your LAN.
OPTIONAL Terminal Block
Connectors
N/A
RS-232 3-pin Terminal
Block Connectors
Connect to a PC or a serial controller.
Mains Power Connector
Connect to the mains power.
Mains Power Fuse
Fuse for protecting the device.
Mains Power Switch
Switch for turning the device on or off.

Kramer Electronics Ltd.
VS-88UHDA - Installing in a Rack
6
Installing in a Rack
This section provides instructions for rack mounting the VS-88UHDA. Before installing in a
rack, verify that the environment is within the recommended range:
Operation temperature –0to 40C (32 to 104F).
Storage temperature –-40to +70C (-40 to +158F).
Humidity –10% to 90%, RHL non-condensing.
When installing on a 19" rack, avoid hazards by taking care that:
It is located within recommended environmental conditions. Operating ambient
temperature of a closed or multi-unit rack assembly may exceed ambient room
temperature.
Once rack mounted, there is enough air still flow around the VS-88UHDA.
The VS-88UHDA is placed upright in the correct horizontal position.
You do not overload the circuit(s). When connecting the VS-88UHDA to the supply
circuit, overloading the circuits may have a detrimental effect on overcurrent protection
and supply wiring. Refer to the appropriate nameplate ratings for information. For
example, for fuse replacement, see the value printed on the product label.
The VS-88UHDA is earthed (grounded) and connected only to an electricity socket with
grounding. Pay particular attention when electricity is supplied indirectly (for example,
when the power cord is not plugged directly into the wall socket but to an extension
cable or power strip). Use only the supplied power cord.
To rack-mount the VS-88UHDA:
1. Attach both ear brackets to the VS-88UHDA:
Remove the screws from each side of the
VS-88UHDA (3 on each side), and replace them
through the ear brackets.
2. Place the ears of the VS-88UHDA against the rack
rails and insert the appropriate screws (not provided)
through each of the four holes in the rack ears.
Some models, may feature built-in rack ears:
Detachable rack ears can be removed for desktop use.
Always mount the VS-88UHDA in the rack before connecting any cables or power.
If you are using a Kramer rack adapter kit (for a machine that is not 19"), see the Rack
Adapters user manual for installation instructions available from our Web site
www.kramerav.com/downloads/VS-88UHDA.

Kramer Electronics Ltd.
VS-88UHDA - Connecting the VS-88UHDA
7
Connecting the VS-88UHDA
Always switch off the power to each device before connecting it to your VS-88UHDA. After
connecting your VS-88UHDA, connect its power and then switch on the power to each
device.
Although this connecting example shows only several inputs and outputs that are connected,
you can connect all the inputs and outputs simultaneously.
To connect the VS-88UHDA as illustrated in the example in Figure 3, do the following:
1. Connect up to eight video sources to the inputs (from IN1 to IN 8). For example, connect:
A laptop to the IN 1 HDMI connector.
Blu-ray players to the IN 3 and IN 5 HDMI connectors.
2. Connect up to eight analog stereo audio sources (from IN 1 to IN 8). For example,
connect:
The analog audio output of a laptop to the AUDIO IN 1 3.5mm mini jack.
An i-Pod to the AUDIO IN 2 3.5mm jack.
3. Connect the eight video HDMI outputs (from OUTPUT 1 to OUTPUT 8) to up to eight
acceptors. For example, connect the:
OUTPUT 4 HDMI connector to a projector.
OUTPUT 5, OUTPUT 7 and OUTPUT 8 HDMI connectors each to a display.
4. Connect the eight balanced analog output 5-pin terminal block connectors (from
OUTPUT 1 to OUTPUT 8) to up to eight audio acceptors. For example, connect:
OUTPUT 4 to a power amplifier with speakers.
OUTPUT 7 to active speakers.
5. Connect the power cord.
We recommend that you use only the power cord that is supplied with this machine
6. If required, connect:
The 5V/2A USB port to the USB port of another device to charge it.
The ETHERNET port.

Kramer Electronics Ltd.
VS-88UHDA - Connecting the VS-88UHDA
8
Figure 3: Connecting to the VS-88UHDA Rear Panel
Connecting Balanced/Unbalanced Stereo Audio Output
The following are the pinouts for connecting to balanced or unbalanced stereo audio sources:
Figure 4: Connecting the Balanced
Stereo Audio Output
Figure 5: Connecting an Unbalanced Stereo
Audio Acceptor to the Balanced Output
Connecting to VS-88UHDA via RS-232
You can connect to the VS-88UHDA via an RS-232 connection using, for example, a PC.
To connect to the VS-88UHDA via RS-232:
Connect the RS-232 rear panel port on the VS-88UHDA unit via a
9-wire straight cable (only pin 2 to pin 2, pin 3 to pin 3, and pin 5 to pin 5 need to be
connected) to the RS-232 9-pin D-sub port on your PC.
Connecting VS-88UHDA via the ETHERNET Port
You can connect to the VS-88UHDA via Ethernet using either of the following methods:

Kramer Electronics Ltd.
VS-88UHDA - Connecting the VS-88UHDA
9
Directly to the PC using a crossover cable (see Connecting the Ethernet Port Directly to a
PC on page 9).
Via a network hub, switch, or router, using a straight-through cable (see Connecting the
Ethernet Port via a Network Hub or Switch on page 11).
If you want to connect via a router and your IT system is based on IPv6, speak to your IT
department for specific installation instructions
Connecting the Ethernet Port Directly to a PC
You can connect the Ethernet port of the VS-88UHDA directly to the Ethernet port on your PC
using a crossover cable with RJ-45 connectors.
This type of connection is recommended for identifying the VS-88UHDA
with the factory configured default IP address.
After connecting the VS-88UHDA to the Ethernet port, configure your PC as follows:
1. Click Start > Control Panel > Network and Sharing Center.
2. Click Change Adapter Settings.
3. Highlight the network adapter you want to use to connect to the device and click Change
settings of this connection.
The Local Area Connection Properties window for the selected network adapter appears
as shown in Figure 6.
Figure 6: Local Area Connection Properties Window
4. Highlight either Internet Protocol Version 6 (TCP/IPv6) or Internet Protocol Version 4
(TCP/IPv4) depending on the requirements of your IT system.
5. Click Properties.
The Internet Protocol Properties window relevant to your IT system appears as shown in
Figure 7 or Figure 8.

Kramer Electronics Ltd.
VS-88UHDA - Connecting the VS-88UHDA
10
Figure 7: Internet Protocol Version 4 Properties Window
Figure 8: Internet Protocol Version 6 Properties Window
6. Select Use the following IP Address for static IP addressing and fill in the details as
shown in Figure 9.
For TCP/IPv4 you can use any IP address in the range 192.168.1.1 to 192.168.1.255
(excluding 192.168.1.39) that is provided by your IT department.

Kramer Electronics Ltd.
VS-88UHDA - Connecting the VS-88UHDA
11
Figure 9: Internet Protocol Properties Window
7. Click OK.
8. Click Close.
Connecting the Ethernet Port via a Network Hub or Switch
You can connect the Ethernet port of the VS-88UHDA to the Ethernet port on a network hub or
using a straight-through cable with RJ-45 connectors.
Control Configuration via the Ethernet Port
To control several units via Ethernet, connect the Master unit (Device 1) via the Ethernet port
to the Ethernet port of your PC. Use your PC provide initial configuration of the settings (see
Connecting VS-88UHDA via the ETHERNET Port on page 8).

Kramer Electronics Ltd.
VS-88UHDA - Operating VS-88UHDA via Front Panel Buttons
12
Operating VS-88UHDA via Front
Panel Buttons
Press the power switch to power the device. During the 10-second initialization process,
the:
7-segment display LEDs are on.
All the front panel buttons illuminate.
The FPGA/EPLD version (P), the firmware version (F) and the build version (b) appear in
succession.
Following initialization, the front panel buttons and 7-segment display enter normal operation:
The 7-segment display shows the video IN-OUT status.
The current operation mode button illuminates (VIDEO, by default).
An illuminated IN (PATTERN) button indicates an active signal connected to the input.
An illuminated OUT (MUTE) button indicates that an acceptor is connected to the output.
The VS-88UHDA front panel buttons enable performing the following functions:
Routing the Signals, on page 12.
Storing and Recalling a Setup, on page 24.
Setting the Switching Mode, on page 25.
Setting the Switching Speed, on page 25.
Setting HDCP, on page 26.
Copying the EDID, on page 26.
Routing the Signals
You can switch the video and the audio signals together (AFV) or switch them separately, via
the following switching modes:
Switching the Video Signal, on page 13.
Routing an Audio Input to the Analog Audio Output, on page 13.
Routing an Audio Input to the Digital HDMI Output, on page 15.
Switching the Video and the Audio Signal Simultaneously, on page 17.
Muting/Unmuting an Output, on page 18.
Routing a Pattern, on page 18.
Operating in ARC Mode, on page 19.

Kramer Electronics Ltd.
VS-88UHDA - Operating VS-88UHDA via Front Panel Buttons
13
Switching the Video Signal
The VIDEO button on the VS-88UHDA front panel enables video routing.
To switch a video input to an output:
1. Press VIDEO .
The button illuminates and the 7-segment display shows the current IN-OUT video
status.
On the front panel buttons:
An illuminated input button means that an active signal is detected on that input.
An illuminated output button means that a display is connected to that output.
A flashing output button means that a non-HDCP display is connected to that output.
Note that in the case that an HDCP-encrypted input is routed through the matrix to a
non-HDCP screen, the video will not be presented and the non-HDCP screen will turn
black.
On the 7-segment display:
A digit (from 1 to 8) shows the input number that is currently routed to the output.
“P” under an output number indicates that a pattern is routed to that output.
“0” under an output number indicates that the output is muted.
2. Press an OUT (MUTE) button (1 to 8).
The 7-segment display LED, under the selected output, flashes.
Press ALL (instead of an output button) to route the selected input to all the outputs. All
the 7-segment display LEDs flash.
3. Press an IN (PATTERN) button (1 to 8).
The selected input is switched to the selected output (or to all the outputs if ALL was
pressed instead) and the 7-segment display shows the current status.
Routing an Audio Input to the Analog Audio Output
The A-AUDIO button on the VS-88UHDA front panel enables to route either the analog
audio input signals or the HDMI embedded audio signals to the balanced stereo analog
audio outputs .
Generally, analog routing is enabled by pressing A-AUDIO:
When it is illuminated, the HDMI input embedded audio is the audio source.
When it flashes, the 3.5mm analog audio input is the audio source.

Kramer Electronics Ltd.
VS-88UHDA - Operating VS-88UHDA via Front Panel Buttons
14
To switch an HDMI audio input to an analog output:
1. Press A-AUDIO .
The button illuminates (HDMI audio input to balanced audio output mode) and the
7-segment display shows the current IN-OUT analog audio status.
On the front panel buttons:
An illuminated input button means that an active signal is detected on that input.
An illuminated output button means that a display that supports audio is detected on
that output.
A dark button means either that the display that is connected does not support audio
or that a display is not connected at all.
On the 7-segment display:
“A” under an output number indicates that an analog audio input is the current audio
source.
“C” under an output number indicates that ARC audio is routed to that output.
“0” under an output number indicates that the analog audio output is muted.
“.” under an output number indicates that the HDMI output port is in ARC mode.
Any digit shows the HDMI audio input switching state.
2. While A-AUDIO is on, select an output button (for example, 7) and then an input button
(for example, 2). HDMI audio input 2 is routed to balanced stereo audio output 7 and on
the 7-segment display, INPUT 2 appears under OUTPUT 7.
When switching you can also press:
An output button (1 to 8) and then OUT (MUTE) to mute the selected output (turns 0).
ALL (instead of an output button) and then an input button to route the selected input
to all the outputs.
All the 7-segment display LEDs flash and then display the selected input.
To switch an analog audio input to an analog output:
1. Press A-AUDIO twice.
The button flashes (analog audio input to balanced audio output mode) and the
7-segment display shows the current IN-OUT analog audio status.
On the front panel buttons:
An illuminated input button means that a cable is connected to the 3.5mm minijack.
An illuminated output button means that a display that supports audio is detected on
that output.
A dark button means either that the display that is connected does not support audio
or that a display is not connected at all.

Kramer Electronics Ltd.
VS-88UHDA - Operating VS-88UHDA via Front Panel Buttons
15
On the 7-segment display:
“d” under an output number indicates that an embedded digital audio is currently
routed to that output.
“C” under an output number indicates that ARC audio is routed to that output.
“0” under an output number indicates that the analog audio output is muted.
“.” under an output number indicates that the HDMI output port is in ARC mode.
Any digit shows the analog audio input switching state.
2. While A-AUDIO flashes, select an output button (for example, 8) and then an input
button (for example, 1). Analog input 1 is routed to balanced stereo audio output 8 and
on the 7-segment display, INPUT 1 appears under OUTPUT 8.
When switching you can also press:
An output button (1 to 8) and then OUT (MUTE) to mute the selected output (turns 0).
ALL (instead of an output button) and then an input button to route the selected input
to all the outputs.
All the 7-segment display LEDs flash and then display the selected input.
Routing an Audio Input to the Digital HDMI Output
The D-AUDIO button on the VS-88UHDA front panel enables to route either the analog
audio input signals or the HDMI embedded audio signals to the HDMI outputs .
Generally, digital routing is enabled by pressing D-AUDIO:
When it is illuminated, the HDMI input embedded audio is the audio source.
When it flashes, the 3.5mm analog audio input is the audio source.
To switch an HDMI audio input to a digital output:
1. Press D-AUDIO .
The button illuminates (HDMI audio input to HDMI output mode) and the 7-segment
display shows the current IN-OUT digital audio status.
On the front panel buttons:
An illuminated input button means that an active digital audio signal is detected on that
input that supports LPCM audio.
A dark input button means that there is no active digital audio source on that input (or
that the source is DVI).
A flashing input button means that a Dobly digital audio, Dobly-TrueHD audio, or AC-3
audio signal from a DVD -player is detected on that input.
An illuminated output button means that a display that supports LPCM audio is
connected to that output.
A dark button means either that the display that is connected does not support audio
or that a display is not connected at all.

Kramer Electronics Ltd.
VS-88UHDA - Operating VS-88UHDA via Front Panel Buttons
16
A flashing output button means that a display is connected that does not support
LPCM.
On the 7-segment display:
“A” under an output number indicates that an analog audio signal is currently routed
to that output.
“0” under an output number indicates that the audio output is muted.
“.” under an output number indicates that the HDMI output port is in ARC mode.
Any digit shows the HDMI audio input switching state.
2. While D-AUDIO is on, select an output button (for example, 6) and then an input button
(for example, 5). HDMI audio input 5 is routed to HDMI audio output 6 and on the
7-segment display, INPUT 5 appears under OUTPUT 6.
When switching you can also press:
An output button (1 to 8) and then OUT (MUTE) to mute the selected output (turns 0).
ALL (instead of an output button) and then an input button to route the selected input
to all the outputs.
All the 7-segment display LEDs flash and then display the selected input.
To switch an analog audio input to a digital output:
1. Press D-AUDIO twice .
The button flashes (analog audio input to HDMI output mode) and the 7-segment display
shows the current IN-OUT digital audio status.
On the front panel buttons:
An illuminated input button means that a cable is connected to the3.5mm mini jack.
An illuminated output button means that a display that supports audio is connected to
that output.
A dark output button means either that the display that is connected does not support
audio or that a display is not connected at all.
On the 7-segment display:
“d” under an output number indicates that a digital audio signal is currently routed to
that output.
“0” under an output number indicates that the audio output is muted.
“.” under an output number indicates that the HDMI output port is in ARC mode.
Any digit shows the analog audio input switching state.
2. While D-AUDIO is on, select an output button (for example, 3) and then an input button
(for example, 1). analog audio input 1 is routed to HDMI audio output 3 and on the
7-segment display, INPUT 1 appears under OUTPUT 3.

Kramer Electronics Ltd.
VS-88UHDA - Operating VS-88UHDA via Front Panel Buttons
17
When switching you can also press:
An output button (1 to 8) and then OUT (MUTE) to mute the selected output (turns 0).
ALL (instead of an output button) and then an input button to route the selected input
to all the outputs.
All the 7-segment display LEDs flash and then display the selected input.
Switching the Video and the Audio Signal Simultaneously
You can select the analog or the digital audio signal to switch to the output together with the
video signal.
To switch the digital audio and video signals together to an output:
1. Press D-AUDIO and VIDEO simultaneously.
The button illuminates and the 7-segment display shows the current IN-OUT video
status.
2. Press an OUT (MUTE) button (1 to 8).
The 7-segment display LED, under the selected output, flashes.
Press ALL (instead of an output button) to route the selected input to all the outputs. All
the 7-segment display LEDs flash.
3. Press an IN (PATTERN) button (1 to 8).
The selected audio input is switched to the selected output (or to all the outputs if ALL
was pressed instead) and the 7-segment display shows the current status.
To switch the analog audio and video signals together to an output:
1. Press A-AUDIO and VIDEO simultaneously.
The buttons illuminate and the 7-segment display shows the current IN-OUT video
status.
2. Press an OUT (MUTE) button (1 to 8).
The 7-segment display LED, under the selected output, flashes.
Press ALL (instead of an output button) to route the selected input to all the outputs. All
the 7-segment display LEDs flash.
3. Press an IN (PATTERN) button (1 to 8).
The selected audio input is switched to the selected output (or to all the outputs if ALL
was pressed instead) and the 7-segment display shows the current status.

Kramer Electronics Ltd.
VS-88UHDA - Operating VS-88UHDA via Front Panel Buttons
18
Muting/Unmuting an Output
You can mute/unmute an audio signal and a video signal separately.
To mute/unmute an audio signal:
1. Press A-AUDIO or D-AUDIO.
The buttons illuminate.
2. Press an OUT (MUTE) button (1 to 8).
Press ALL (instead of an output button) to mute/unmute all the outputs. All the
7-segment display LEDs flash.
3. Press MUTE/PATTERN to mute/unmute the output.
The muted output appears as “0” on the 7-segment display.
To mute/unmute a video signal:
1. Press VIDEO.
The button illuminates and the 7-segment display shows the current IN-OUT video
status.
2. Press an OUT (MUTE) button (1 to 8).
The 7-segment display LED, under the selected output, flashes.
Press ALL (instead of an output button) to mute/unmute all the outputs. All the
7-segment display LEDs flash.
3. Press MUTE/PATTERN to mute/unmute the output.
The muted output appears as “0” on the 7-segment display.
Routing a Pattern to the Output
VS-88UHDA generates 8 embedded patterns. These patterns can be routed at a resolution of
480p to any of the outputs.
Once a pattern is selected, that same pattern is routed to all the selected outputs.
A pattern is selected by pressing inputs 1 to 8 when in the Pattern mode.
1 (Color Bars)
2 (Ramp)
3 (Solid White)
4 (Solid Black)
5 (Solid Red)
6 (Solid Green)
7 (Solid Blue)
8 (Checkboard)
Figure 10: VS-88UHDA Embedded Patterns
