Kramer 104B User manual

Kramer Electronics, Ltd.
USER MANUAL
Model:
104B
1:4 Microphone DA

Contents
i
Contents
1 Introduction 1
2 Getting Started 1
2.1 Quick Start 1
3 Overview 3
4 Your 104B 1:4 Microphone DA 4
5 Using the 104B 1:4 Microphone DA 5
6 Technical Specifications 6
Figures
Figure 1: 104B 1:4 Microphone DA 4
Figure 2: Connecting the 104B 1:4 Microphone DA 5
Tables
Table 1: Features and Functions of the 104B 1:4 Microphone DA 4
Table 2: Technical Specifications of the 104B 1:4 Microphone DA 6

Introduction
1
1 Introduction
Welcome to Kramer Electronics (since 1981): a world of unique, creative and
affordable solutions to the infinite range of problems that confront the video,
audio and presentation professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
500-plus different models now appear in 8 Groups
1
, which are clearly defined
by function.
Congratulations on purchasing your Kramer MultiTOOLS® 104B 1:4
Microphone DA.This product is ideal for:
 Rental and staging applications
 Audio mixing
The package includes the following items:
 104B 1:4 Microphone DA
 Power adapter (12V DC Input)
 This user manual
2
2 Getting Started
We recommend that you:
 Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
 Review the contents of this user manual
 Use Kramer high performance high resolution cables
3
2.1 Quick Start
This Quick start chart summarizes the basic steps when connecting a 104B:
1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:
Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;
GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors
2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2

Overview
3
3 Overview
The high performance 104B 1:4 Microphone DA accepts an input from a
microphone and distributes that signal simultaneously to four outputs. In
particular, the 104B features:
 Audio level control
 A switch for applying phantom power
1
To achieve the best performance:
 Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise-
levels (often associated with low quality cables)
 Avoid interference from neighboring electrical appliances and position
your Kramer 104B away from moisture, excessive sunlight and dust
Caution – No operator-serviceable parts inside unit.
Warning – Use only the Kramer Electronics input power
wall adapter that is provided with this unit
2
.
Warning – Disconnect power and unplug unit from wall
before installing or removing device or servicing unit.
1 This is for applications that require typical condenser microphones to be connected directly to the 104B. To prevent
unnecessary damage, apply phantom power to the Mic only when required
2 For example: model number AD2512C, part number 2535-000251

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your 104B 1:4 Microphone DA
4
4 Your 104B 1:4 Microphone DA
Figure 1 and Table 1 define the 104B 1:4 Microphone DA:
Figure 1: 104B 1:4 Microphone DA
Table 1: Features and Functions of the 104B 1:4 Microphone DA
# Feature Function
1 12V DC +12V DC connector for powering the unit
2 PHANTOM POWER Switch Move to the right to apply phantom power
3 LEVEL Trimmer Adjusts
1
the audio output level
4 OUTPUT 1 XLR Male Connector Connects to audio acceptor
2
1
5 INPUT XLR Female Connector Connects to the microphone
6 ON LED Illuminates when receiving power
7 OUTPUT 2 XLR Male Connector Connects to audio acceptor
2
2
8 OUTPUT 3 XLR Male Connector Connects to audio acceptor
2
3
9 OUTPUT 4 XLR Male Connector Connects to audio acceptor
2
4
1 Insert a screwdriver into the small hole and carefully rotate it to adjust the audio level
2 A mixer

Using the 104B 1:4 Microphone DA
5
5 Using the 104B 1:4 Microphone DA
To connect your 104B 1:4 Microphone DA, as the example in Figure 2
illustrates, do the following:
1. Connect a microphone to the INPUT XLR connector.
2. Connect up to
1
4 OUTPUT XLR connectors to the audio acceptors (for
example, mixers).
3. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity (not shown in Figure 2).
4. If required, adjust the audio signal level.
Figure 2: Connecting the 104B 1:4 Microphone DA
1 You do not have to connect all the outputs

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
6
6 Technical Specifications
Table 2: Technical Specifications
1
of the 104B 1:4 Microphone DA
INPUT: 1 microphone mono balanced on an XLR female connector
OUTPUTS: 4 microphone mono balanced on XLR male connectors
MAX. OUTPUT LEVEL: 5.5Vpp
BANDWIDTH (-3dB): >100kHz
S/N RATIO: 86dB
CONTROLS: –3.2dB to +6.7dB level
COUPLING: DC
AUDIO THD + NOISE: 0.13%
AUDIO 2nd HARMONIC: 0.005%
POWER SOURCE: 12 VDC, 193mA
DIMENSIONS: 16. 2cm x 4.36cm x 10.7cm (6.36" x 1.72" x 4.2") W, D, H
WEIGHT: 0.15kg. (0.55lbs.) approx.
ACCESSORIES: Power supply
1 Specifications are subject to change without notice
