Kramer VA-102P512 User manual

KRAMER ELECTRONICS LTD.
USER MANUAL
MODEL:
VA-102P512
Power Supply
P/N: 2900-300201 Rev 1

VA-102P512 – Contents i
Contents
1Introduction 1
2Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 3
2.3 Recycling Kramer Products 3
3Overview 4
3.1 Defining the VA-102P512 Power Supply 4
4Connecting the VA-102P512 5
5Technical Specifications 6
Figures
Figure 1: VA-102P512 Power Supply 4
Figure 2: Connecting the VA-102P512 Power Supply 5

VA-102P512 - Introduction 1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront the video, audio, presentation, and broadcasting
professional on a daily basis. In recent years, we have redesigned and upgraded
most of our line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer VA-102P512 Power Supplythat is
ideal for the following typical applications:
•High-population installations of 5/12V DC devices

2 VA-102P512 - Getting Started
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
•Review the contents of this user manual
Go to http://www.kramerelectronics.com to check for up-to-date
user manuals, application programs, and to check if firmware
upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
•Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
•Do not secure the cables in tight bundles or roll the slack into tight coils
•Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
•Position your Kramer VA-102P512 away from moisture, excessive sunlight
and dust
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
i
!

VA-102P512 - Getting Started 3
2.2 Safety Instructions
Caution: There are no operator serviceable parts inside the unit
Warning: Use only the power cord that is supplied with the unit
Warning: Do not open the unit. High voltages can cause
electrical shock! Servicing by qualified personnel only
Warning: Disconnect the power and unplug the unit from the wall
before installing
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
!

4 VA-102P512 - Overview
3 Overview
The VA-102P512 is a 10-output power supply used for powering 5V DC and 12V
DC powered devices. The VA-102P512 can supply 5V DC to five devices (at 1.8A
max./device for a total of 9A) and 12V DC to five devices (at 1A max./device for a
total of 5A).
The power supply is especially useful in high-population installations for saving
space and eliminating a large number of stand-alone power adapters.
3.1 Defining the VA-102P512 Power Supply
This section defines the VA-102P512.
Figure 1: VA-102P512 Power Supply
# Feature Function
1 Power LED Illuminates when the power is turned on
2 5V DC Output Connectors Supplies 5V DC to up to 5 devices
3 12V DC Output Connectors Supplies 12V DC to up to 5 devices
4 Power Connector, Fuse and Switch Connects to the mains supply and switches
the device on and off

VA-102P512 - Connecting the VA-102P512 5
4 Connecting the VA-102P512
Always switch off the power to each device before connecting it to your
VA-102P512. After connecting your VA-102P512, connect its power
and then switch on the power to each device.
To connect the VA-102P512 as illustrated in the example in Figure 2:
1. Connect the 5V DC outputs to up to five 5V DC devices and the 12V DC
outputs to up to five 12V DC devices.
2. Connect the AC power cord to the AC receptacle and turn ON the power to
the VA-102P512.
Figure 2: Connecting the VA-102P512 Power Supply
i

6 VA-102P512 - Technical Specifications
5 Technical Specifications
OUTPUTS: 5x5V DC @1.8A max. current per output (9A total max.)
5x12V DC @1A max. current per output (5A total max.)
INDICATOR: Power ON LED
POWER CONSUMPTION: 100-240V AC, 2.1A
OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE: -40° to +70°C (-40° to 158°F)
HUMIDITY: 10% to 90%, RHL non-condensing
DIMENSIONS: 21.5cm x 17.4cm x 4.4cm (8.45" x 6.86" 1.72") W, D, H
WEIGHT: 1.1kg (2.4lbs)
ACCESSORIES: 10 DC to DC cables 95cm (3.1ft) per cable, AC power
cord
OPTIONS: RK−1 19” rack adapter
Specifications are subject to change without notice at http://www.kramerelectronics.com

For the latest information on our products and a list of Kramer distributors,
visit our Web site where updates to this user manual may be found.
We welcome your questions, comments, and feedback.
Web site: www.kramerelectronics.com
E-mail: [e-mail]
PN:
2900- 300201
Rev:
1
!
SAFETY WARNING
Disconnect the unit from the power
supply before opening and servicing
