Kramer VA-50P User manual

KRAMER ELECTRONICS LTD.
USER MANUAL
MODEL:
VA-50P
Power Supply
P/N: 2900-006012 Rev 4

VA-50P – Contents i
Contents
1Introduction 1
2Getting Started 2
2.1 Achieving the Best Performance 2
3Overview 3
3.1 Defining the VA-50P 3
4Connecting the VA-50P 5
5Technical Specifications 7
Figures
Figure 1: UVA-50PUPower Supply 4
Figure 2: Connecting to the UVA-50PU6

VA-50P - Introduction 1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront the video, audio, presentation, and broadcasting
professional on a daily basis. In recent years, we have redesigned and upgraded
most of our line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix
Switchers; GROUP 3: Control Systems; GROUP 4: Format/Standards Converters;
GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors;
GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and
GROUP 11: Sierra Products.
Congratulations on purchasing your Kramer VA-50P Power Supply, which is ideal
for the following typical applications:
•Any audio/video system using multiple 12V operated products
•As a battery replacement for field/battery operated equipment

2 VA-50P - Getting Started
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
•Review the contents of this user manual
Use Kramer high performance high resolution cables
Use only the power cord that is supplied with this machine
Go to http://www.kramerelectronics.com to check for up-to-date
user manuals, application programs, and to check if firmware
upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
•Use only good quality connection cables to avoid interference, deterioration
in signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
•Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
•Position your Kramer VA-50P away from moisture, excessive sunlight and
dust
i

VA-50P - Overview 3
3 Overview
The VA-50P is a 6-port 12V DC power supply. It replaces up to 6 separate 12 volt
adapters for Kramer TOOLS™ and other models that use 12V DC power
adapters.
In particular, the VA-50P:
•Is an efficient six outlet universal switching power supply that can output 12V
DC with up to 500mA per output (but not exceeding 2A total)
•Is designed to operate Kramer products that normally use an external 12V
DC power transformer
•Can be secured in a rack using the model RK-50RN kit that holds two
VA-50P units and requires two vertical spaces in a standard 19" rack
•Can save valuable space on power strips, by replacing up to six wall
transformers
Make sure that the polarity of the connected unit matches that of the
VA-50P – that is, the center pin is the positive terminal.
3.1 Defining the VA-50P
This section defines the VA-50P.
i

4 VA-50P - Overview
Figure 1: VA-50P Power Supply
# Feature Function
1 POWER Switch Illuminated switch for turning the unit ON or OFF
2 12V DC Power OUTPUTS Connect to the power inlet on a 12V DC unit (from
1 to 6). Maximum 500mA per output, maximum
2000mA total current
3 Power Connector with FUSE Socket for connecting the AC power cord to the
unit

VA-50P - Connecting the VA-50P 5
4 Connecting the VA-50P
Always switch off the power to each device before connecting it to your
VA-50P. After connecting your VA-50P, connect its power and then
switch on the power to each device.
To connect the VA-50P as illustrated in the example in Figure 2:
1. Connect up to 6 power outlets, using DC-to-DC cables, as follows:
Six DC-to-DC cables are supplied with the VA-50P.
Connect the 12V DC OUTPUT 1power outlet to the 12V DC power
inlet, for example, on a Kramer FC-14 RGBHV to Component
Transcoder
Connect the 12V DC OUTPUT 2power outlet to the 12DV DC power
inlet, for example, on a Kramer Tools 810 Color Bar / Audio Generator
Connect the 12V DC OUTPUT 3power outlet to the 12DV DC power
inlet, for example, on a Kramer Pico Tools PT102VN unit
Connect the 12V DC OUTPUT 4power outlet to the 12DV DC power
inlet, for example, on a second Kramer Pico Tools PT102VN unit
Connect the 12V DC OUTPUT 5power outlet to the 12DV DC power
inlet, for example, on a third Kramer Pico Tools PT102VN unit
Connect the 12V DC OUTPUT 6power outlet to the 12DV DC power
inlet, for example, on a Kramer Tools VP-100 unit
2. Connect the power cord to the mains electricity.
i

6 VA-50P - Connecting the VA-50P
Figure 2: Connecting to the VA-50P

VA-50P - Technical Specifications 7
5 Technical Specifications
INPUT POWER SOURCE: 100-240V AC, 50/ 60Hz, Pmax. 42VA.
OUTPUTS: 6 x 12V DC outputs, maximum 500mA per output, maximum
2000mA total current
DIMENSIONS: 16.5cm x 12cm x 4.5cm (6.5" x 4.7" x 1.7") W, D, H
WEIGHT: 1kg (2.2lbs) approx.
ACCESSORIES: Power cord, vertical stacking bracket, 6 DC-to-DC cables
OPTIONS: RK-50RN 19" rack adapter
Specifications are subject to change without notice at http://www.kramerelectronics.com

8 VA-50P - Technical Specifications
LIMITED WARRANTY
WHO IS PROTECTED?
WHAT IS COVERED AND WHAT IS NOT COVERED
WHATWE WILLPAYFORANDWHATWE WILLNOT PAY FOR
HOW YOU CAN GET WARRANTY SERVICE
LIMITATION OF IMPLIED WARRANTIES
EXCLUSION OF DAMAGES
CAUTION!
We warrant this product free from defects in material and workmanship under the following terms.
HOW LONG IS THE WARRANTY
Labor and parts are warranted for seven years from the date of the first customer purchase.
Only the first purchase customer may enforce this warranty.
We will pay labor and material expenses for covered items. We will not pay for the following:
The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer
shall not be liable for:
This warranty gives you specific legal rights, and you may also have other rights, which vary from place to place.
: All products returned to Kramer for service must have prior approval. This may be obtained from your dealer.
This equipment has been tested to determine compliance with the requirements of:
EN-50081: "Electromagnetic compatibility (EMC);
generic emission standard.
Residential, commercial and light industry"
EN-50082: "Electromagnetic compatibility (EMC) generic immunity standard.
Part 1: Residential, commercial and light industry environment".
CFR-47: FCC* Rules and Regulations:
Part 15: “Radio frequency devices
Subpart B Unintentional radiators”
Except as below, this warranty covers all defects in material or workmanship in this product. The following are not
covered by the warranty:
1. Any product which is not distributed by us or which is not purchased from an authorized Kramer dealer. If you are
uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site
www.kramerelectronics.com.
2. Any product, on which the serial number has been defaced, modified or removed, or on which the WARRANTY VOID
TAMPERED sticker has been torn,
3. Damage, deterioration or malfunction resulting from:
i) Accident, misuse, abuse, neglect, fire, water, lightning or other acts of nature
ii) Product modification, or failure to follow instructions supplied with the product
iii) Repair or attempted repair by anyone not authorized by Kramer
iv) Any shipment of the product (claims must be presented to the carrier)
v) Removal or installation of the product
vi) Any other cause, which does not relate to a product defect
vii) Cartons, equipment enclosures, cables or accessories used in conjunction with the product
1. Removal or installations charges.
2. Costs of initial technical adjustments (set-up), including adjustment of user controls or programming. These costs are
the responsibility of the Kramer dealer from whom the product was purchased.
3. Shipping charges.
1. To obtain service on you product, you must take or ship it prepaid to any authorized Kramer service center.
2. Whenever warranty service is required, the original dated invoice (or a copy) must be presented as proof of
warranty coverage, and should be included in any shipment of the product. Please also include in any mailing a
contact name, company, address, and a description of the problem(s).
3. For the name of the nearest Kramer authorized service center, consult your authorized dealer.
All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration
to the length of this warranty.
1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the
product, loss of time, commercial loss; or:
2. Any other damages, whether incidental, consequential or otherwise. Some countries may not allow limitations on
how long an implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations and exclusions may not apply to you.
Servicing the machines can only be done by an authorized Kramer technician. Any user who makes changes or
modifications to the unit without the expressed approval of the manufacturer will void user authority to operate the
equipment.
Use the supplied DC power supply to feed power to the machine.
Please use recommended interconnection cables to connect the machine to other components.
IF reattached, removed or otherwise interfered with.
* FCC and CE approved using STP cable (for twisted pair products)
NOTE
Part 1:

         
   
    
        
    


  
   
P/N:
2900- 006012
Rev:
4
!

! 
""
