Original-Operating manual
High-pressure cleaners
W 11/135
W 13/230
W 15/200
W 19/160
Read and conform safety instructions before use!
Keep instructions in a safe place for later use and
pass them on to any future user.

2
Dear Customer
We would like to congratulate you on your new high pressure cleaner and to thank
you for the purchase.
To ease your introduction to the use of the cleaner, we have provided the following
pages of explanations, tips and hints.
The equipment will assist you professionally in all cleaning tasks, e.g.:
Description
Operating pressure steples-
sly adjustable
Permiss. overpressure
Water output *
Hot water input
High pressure hose
Electrical ratings
Connected load Input
Output
Weight
Dimensions
Sound lever accord.
to DIN 45 635 (rel. to wor-
king place)
with dirtkiller
Recoil at lance
Torque
Vibrations at lance
Order n°:
10 - 135 bar
150 bar
at 1400 rpm
11 l/min
max. 60 °C
10 m
230 V ; 50 Hz ;
14,0 A
P1: 3,3 kW
P2: 2,4 kW
76 kg
710 x 740 x 370
89 dB
84 dB
approx. 25 Nm
26 Nm
2,4 m/s²
41 312
Kränzle
W 11 / 135
Technical
specications
Kränzle
W 19 / 160
Kränzle
W 15 / 200
Kränzle
W 13 / 230
10 - 160 bar
180 bar
at 1400 rpm
19 l/min
max. 60 °C
10 m
400 V ; 50 Hz ;
12 ,5A
P1: 7,5 kW
P2: 5,5 kW
90 kg
710 x 740 x 370
89 dB
93 dB
approx. 22 Nm
24,3 Nm
3,2 m/s²
41 310
10 - 200 bar
220 bar
at 1400 rpm
15 l/min
max. 60 °C
10 m
400 V ; 50 Hz ;
12,5 A
P1: 7,5 kW
P2: 5,5 kW
90 kg
710 x 740 x 370
89 dB
93 dB
approx. 25 Nm
28,8 Nm
3,2 m/s²
41 309
10 - 230 bar
250 bar
at 1400 rpm
13 l/min
max. 60 °C
10 m
400 V ; 50 Hz ;
12,5 A
P1: 7,5 kW
P2: 5,5 kW
90 kg
710 x 740 x 370
89 dB
93 dB
approx. 27 Nm
28,8 Nm
3,2 m/s²
41 308
(Assumed length of lance: 0.9 m)
Permissible tolerance for gures ±5% in accordance with VDMA, uniform sheet 24411
* Min. water quantity to be supplied to the high pressure cleaner!
- Vehicles of all types
- Barrels and containers - Machines etc. - Removingold
paint

3
Preparation for use
Stationary cold water high pressure cleaner
The stationary wall-mounted systems are supplied with a stainless steel housing
and equipped with an AQ pump (W11/135 with APG pump) and 10m steel fabric
heavy duty hose.
Pressure fully adjustable, automatic total-stop feature.
After the gun is closed, the device continues to run for a time and then cuts out. It
restarts when the gun is opened. Incorrect operation by unauthorised persons is
therefore not possible. The factory setting is 30 seconds. The device is connected
to a water supply with advance pressure. Temperatures of up to 60 °C are possib-
le.
Features
Stainless steel housing,
10 m heavy duty hose with gun,
lance 800 mm
control nozzle and HP nozzle.
Preparation for use
Connect to suitable water supply, open the water tap.
Switch on high-pressure cleaner. The pump is running and the pressure is built
up. If the gun remains closed, the cleaner continues to run for another 30 seconds
and then switches automatically into standby.
As soon as you presser the trigger of the gun the high-pressure pump starts.
After closing the gun, it continues to run for approx. 30 seconds, and then
switches back to standby mode.
The device continues to run once the trigger is pressed during the 30 seconds.
1 Water inlet connection
2 High-pressure outlet
3 Press.gaugewithglycerinlling
4 On-/ Off switch
Function
2
1
34
If you use the HP cleaner for the rst time or if you have not worked
with your cleaner for a longer period of time, the machine has to be
deaerated by opening and closing the gun various times.

4
Description
Water supply system
The water is fed under pressure (2 - 8 bar) to the HP pump. Then the water is fed
under pressure from the HP pump to the safety spray lance. The high pressure jet
is formed by the nozzle at the end of the lance.
The machine can only be operated when the safety trigger is squeezed.
When the lever is squeezed, the spray gun opens. The liquid is then pumped to
the nozzle.
When the trigger is released, the spray gun closes and any further spraying of
liquid from the lance is stopped and the manometer must show 0 bar.
The increase in pressure when the spray gun is closed causes the unloader
valve-safety valve to open. The pump remains switched on and continues to pump
liquid through the pump at reduced pressure. When the spray gun is opened, the
unloader valve - safety valve closes and the pump ressumes pressure spraying
from the lance.
The spray gun is a safety device. Repairs should only be perfor-
med by qualied persons. Should replacement parts be re-
quired, use only components authorized by the manufacturer.
Lance with spray gun
The unloader valve - safety valve protects the machine from a build up of excess
pressure, and is designed not to permit an excess pressure to be selected for
operation. The limit nut on the handle is sealed with a spray coating.
The operating pressure and spray rate can be steplessly adjusted by turning the
handle.
Replacements, repairs, new adjustments and sealing should only
be performed by qualied persons.
Unloader valve - safety valve
Environmental, refuse disposal and water protection
regulations must be observed !

Description
5
High pressure hose and spraying device
The high pressure hose and spraying device supplied with the machine are made
of high grade material. They are also optimized for the machine and marked as
required by the appropriate regulations.
If replacement parts are required, only such parts that are authorized
by the manufacturer and which bear the markings required by the ap-
propriate regulations may be used. The high pressure hose and spray-
ing device must be connected in a pressure-tight manner.
The high pressure hose may not be driven over, pulled excessively
or twisted. Make sure that the hose is not damaged on sharp edges.
Hose lines are wear parts. Guarantee is accepted only for manufactur-
ing errors, not for external damages.
High pressure hose lines and spraying equipment must not be
repaired, but replaced by a new hose or spraying equipment.
Unloader valve - safety valve
The unloader valve - safety valve protects the machine from a build up of excess
pressure, and is designed not to permit an excess pressure to be selected for
operation. The limit nut on the handle is sealed with a spray coating.
The operating pressure and spray rate can be steplessly adjusted by turning the
handle.
Replacements, repairs, new adjustments and sealing should only
be performed by qualied persons.
Take care that all screw connections are pressure-tight. A leakage
of gun, high-pressure hose or hose drum has to be repaired at once.
Leakages lead to an increased wear and to a possible malfunction
of the delayed motor cut-out.
Operator’s task:
Prior to each usage of this liquid spraying device, the operator is obliged to
check if all safety relevant parts are in perfect working condition.
(e.g. safty valves, high-pressure hose, cables and connections,
spraying devices, etc. )

6
Description
With delayed motor cut-out
Frequent, work-necessitated switching on and off of motors on
machines of this size puts a heavy load on the power network and
causes increased wear on internal electrical parts. That’s why the
motor on the new KRÄNZLE appliances switches itself off 30 seconds after the
trigger is released, and switches itself back on again when the trigger is pressed.
When running your high pressure cleaner with hot water of 60° C
raised temperatures occur. Do not touch the machine without safety
gloves!
CAUTION !
CAUTION !
Never use liquid containing solvents such as paint thinners, petrol, oil
or similar liquid matter. Pay attention to the instructions of the man-
ufacturers of the cleaning agents. The seals in the machine are not
resistant to solvents. The spray of solvents is inammable, explosive
and poisonous.
Setting up
Location
Neither set up and operate the machine in rooms where there is a risk
of re or explosion nor put it into puddles. Do not use the machine
under water.
Replacements and inspection work should only be performed by quali-
ed persons when the machine is disconnected from the power
supply, i.e. the plug is pulled out from the electrical socket.

Description
Electrical connection
The machine is supplied with an electrical power cord with plug.
The mains plug must be tted to a standard grounded socket with a
30mA residual current operated device. The socket must be protect-
ed with a 16A delay action fuse on the mains side.
KRÄNZLE W 11-135 = 230 Volt / 50 Hz
KRÄNZLE W 13-230 = 400 Volt / 50 Hz (phase-sequence not signicant)
KRÄNZLE W 15-200 = 400 Volt / 50 Hz (phase-sequence not signicant)
KRÄNZLE W 19-160 = 400 Volt / 50 Hz (phase-sequence not signicant)
When using an extension cable, this must have an earthed lead which is prop-
erly connected to the socket. The conductors in the extension cable must have a
minimum cross section of 1.5 mm². Plug connections must be of a spray-proof
design, and may not be located on a wet oor.
(with extension cables of more than 10 m - 2.5 mm2)
CAUTION !
The use of extension cables which are too long may lead to malfunctions and start
up difculty.
W 13-230;
W 15-200;
W 19-160
400V/50Hz
W 11-135
230V/50Hz
7

8
Description
Brief operating instructions:
1. Connect the high pressure hose with spray gun and machine.
2. Connect to suitable water supply.
3. Flush the air from the pump (open and close the spray gun several times).
4. Make the electrical connection - (400 Volt three-phase current).
5. Switch on the machine and commence cleaning.
6. After having completed the work switch off the tap and completely empty
the pump.
(Switch on the motor for approx. 20 sec. without the water hose and gun).
Afterwards you can roll up the high pressure hose.
- Only use clean water ! - Protect from frost !
CAUTION !
Please pay attention to the regulations of your waterworks company.
In accordance with EN 61 770, the machine may not be directly connected to the
public drinking water supply lines.
A brief connection however is permissible according to DVGW (German Associa-
tion for Gas and Water Affairs) if a tube ventilator with check valve (Kränzle Order-
No. 41.016 4) is built into the water supply.
Also indirect connection to the public drinking water supply lines is permissible by
way of free emission in accordance with EN 61 770; e.g. by using a reservoir with
a oat valve.
Direct connection to a non-drinking water supply line is permissible.

9
Preparation for use
1. Check oil level.
There are two
possibilities for checking the oil level of the pump:
a) Oil must be visible in the viewing window
b) The oil level must be between the two
markings on the oil dipstick.
To check the oil level, loosen the oil cover screw and take out the oil dip stick. The
oil level must be between the two markings.
2. Connect the high pressure lance
or dirtkiller to the spray gun.
4. The machine must be connected to the water line with cold water or up to
60° C warm water (see page 2).
The hose cross section must be at least 3/4“ = 16 mm (free passage).
Itisrecommendedtoinstallawaterlterpriortothecleaner.
(Kränzle order no.: 13.300 3)
3. Unroll hose without kinks and connect with
handgun and pump. Max. extension 20m-HP
hose or 2 x 10m with hose connections.

To shut down the pump:
10
1. Switch off the machine. Switch to „0“ position.
2. Cut off the water supply.
3.Openthespraygunbrieyuntilthepressureisreleased.
4. Apply the safety catch on the spray gun.
5. Remove the water hose and spray gun.
6. Pull the plug from the socket.
7. Winter: store the pump in rooms above 0°C.
8.Cleanthewaterlter.
To shut down the pump:
Frost protection
Normally after operation, there is still some water in the device. Thus, you must take
special measures to protect the device from frost.
-Completely drain the device
For this purpose, separate the device from the water supply. Then, turn on the
main switch and open the gun. Now, the pump presses the remaining water out of
the water tank and the pump. However, do not allow the device to operate without
water for longer than one minute.
- Fill the device with antifreeze agent
If the device is not operated for longer periods, especially over the winter, you
should pump an antifreeze agent through the device. For this purpose, ll the anti-
freeze agent into the water box and turn on the device. Wait with opened gun,
until the agent spurts out of the nozzle.
However, the best way to protect the device from frost is
to store it at a frost-free location.
