KRESS KG560E Series Installation manual

SAFETY AND OPERATING MANUAL
Cordless Blower KG560E KG560E.X

32
Cordless Blower KG560E KG560E.X
Users can view the electronic instructions at
https://www.kress.com/.
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodied plugs
and matching outlets will reduce risk of electric
shock.
b) Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is
an increased risk of electric shock if your body
is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil,
sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric
shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current
device (RCD) protected supply. Use of an
RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment of
inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes,
hard hat, or hearing protection used for
appropriate conditions will reduce personal
injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your nger on the
switch or energising power tools that have the
switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in unexpected
situations.
f) Dress properly. Do not wear loose clothing
or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving
parts.
g) If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of these devices can reduce dust-
related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at
the rate for which it was designed.
b) Do not use the power tool if the switch
does not turn it on and off. Any power tool
that cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.

Cordless Blower KG560E KG560E.X
32
Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
g) Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations different from those intended could
result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by
the manufacturer. A charger that is suitable
for one type of battery pack may create a risk
of re when used with another battery pack.
b) Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and
re.
c) When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects, that can make a
connection from one terminal to another.
Shorting the battery terminals together may
cause burns or a re.
d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If
contact accidentally occurs, ush with water. If
liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may
cause irritation or burns.
6) Service
a) Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
ADDITIONAL SAFETY
WARNINGS FOR CORD-
LESS BLOWER
WARNING Read all safety
warnings and all instructions. Failure to
follow the warnings and instructions may result in
electric shock, re and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE.
- This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervi-
sion or instruction concerning use of the appliance
by a person responsible for their safety.
- Children should be supervised to ensure that they
do not play with the appliance.
DO NOT EXPOSE THE APPLIANCE OR BATTERY
TO EXCESSIVE TEMPERATURES
1. Rechargeable batteries are to be removed
from the appliance before being charge
2. Different types of batteries or new and used
batteries are not to be mixed;
3. Exhausted batteries are to be removed from
the appliance and safely disposed of;
4. If the appliance is to be stored unused
for a long period, the batteries should be
removed;
5. Do not use non-rechargeable batteries in
place of rechargeable batteries
6. Do not use modified or damaged batteries.
7. WARNING: Use only with KA3713/KA3714
battery charger or additional battery
chargers listed in Operator’s Manual
• The device is designed only for the blowing
of dry leaves in private households and as
a hobby device in the garden. Any other
utilization, which is not explicitly approved in
these directions, can lead to damage to the
device and represent a serious danger to the
user.
• The device is designed for use by adults.
Young people over 16 years may use the device
under supervision only.
• The use of the device in the rain or in a humid
environment is forbidden.
• The manufacturer is not liable for damage
which is caused through inappropriate use or
incorrect operation.
NOTE: Do not employ and low power machines for
heavy work. DO NOT use your device for purposes
for which it has not been designed.
WARNING! To reduce the risk of
injury, user must read and understand
instruction manual.
1) Training
a) Read the instructions carefully. Be familiar
with the controls and the proper use of the
appliance;
b) Never allow children to use the appliance.

54
Cordless Blower KG560E KG560E.X
c) Never allow people unfamiliar with these
instructions to use the appliance. Local
regulations may restrict the age of the operator;
d) Never operate the appliance while people,
especially children, or pets are nearby;
e) The operator or user is responsible for
accidents or hazards occurring to other people
or their property.
2) Preparation
a) While operating the appliance, always wear
substantial footwear and long trousers. Do
not operate the equipment when barefoot or
wearing open sandals;
b) Do not wear loose clothing or jewellery that can
be drawn into the air inlet. Keep long hair away
from the air inlets.
c) Wear protective goggles while operating
d) To prevent dust irritation the wearing of a face
mask is recommended
e) Never operate the appliance with defective
guards or shields, or without safety devices
3) Operation
a) Take off the battery from the appliance,
- when not in use;
- before clearing a blockage;
- before checking, cleaning or working on the
appliance;
- if the appliance starts to vibrate abnormally.
b) Operate the appliance only in daylight or in
good articial light.
c) Do not overreach and keep your balance at all
times.
d) Always be sure of your footing on slopes.
e) Walk, never run;
f) Keep all cooling air inlets clear of debris.
g) Never blow debris in the direction of
bystanders.
h) Do not put hands or feet near or under rotating
parts.
4) Maintenance and storage
a) Keep all nuts, bolts and screws tight to be sure
the appliance is in safe working condition;
b) Replace worn or damaged parts.
c) Use only genuine replacement parts and
accessories.
d) Store the appliance only in a dry place.
SAFETY WARNINGS FOR
BATTERY PACK
a) Do not dismantle, open or shred cells or
battery pack.
b) Do not short-circuit a battery pack. Do not
store battery packs haphazardly in a box or
drawer where they may short-circuit each
other or be short-circuited by conductive
materials. When battery pack is not in use,
keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other
small metal objects, that can make a connection
from one terminal to another. Shorting the
battery terminals together may cause burns or a
re.
c) Do not expose battery pack to heat or fire.
Avoid storage in direct sunlight.
d) Do not subject battery pack to mechanical
shock.
e) In the event of battery leaking, do not allow
the liquid to come into contact with the skin
or eyes. If contact has been made, wash the
affected area with copious amounts of water
and seek medical advice.
f) Keep battery pack clean and dry.
g) Wipe the battery pack terminals with a clean
dry cloth if they become dirty.
h) Battery pack needs to be charged before
use. Always refer to this instruction and use
the correct charging procedure.
i) Do not maintain battery pack on charge
when not in use.
j) After extended periods of storage, it may
be necessary to charge and discharge
the battery pack several times to obtain
maximum performance.
k) Recharge only with the charger specified by
Kress. Do not use any charger other than
that specifically provided for use with the
equipment.
l) Do not use any battery pack which is not
designed for use with the equipment.
m) Keep battery pack out of the reach of
children.
n) Retain the original product literature for
future reference.
o) Remove the battery from the equipment
when not in use.
p) Dispose of properly.
q) Do not mix cells of different manufacture,
capacity, size or type within a device.
r) Keep the battery away from microwaves and
high pressure.
s) Warning! Do not use non-rechargeable
batteries.
SAVE THESE INSTRUCTIONS

Cordless Blower KG560E KG560E.X
54
SYMBOLS
Read the operator’s manual
Warning
Wear eye protection
Do not use in the rain or leave
outdoors while it is raining.
Wear ear protection
Keep bystanders away
Warning of hazard
Remove battery from the
socket before carrying out
any adjustment, servicing or
maintenance.
Plus; positive polarity
Minus; negative polarity
KA3713
KA3714
Use with model KA3713/KA3714
battery charger, See instruction
manual for additional battery
chargers.
Li-I on
Li-I on
Li-Ion battery. This product has
been marked with a symbol
relating to ‘separate collection’
for all battery packs and battery
pack. It will then be recycled or
dismantled in order to reduce
the impact on the environment.
Battery packs can be hazardous
for the environment and for
human health since they contain
hazardous substances.
Do not burn
Batteries may enter water cycle if
disposed improperly, which can
be hazardous for ecosystem. Do
not dispose of waste batteries as
unsorted municipal waste.
RCM marking
ABN: Australian Business Number. By this
number, business information such as entity type,
status, business location etc. can be found at
website http://abr.business.gov.au.
ABN of Positec Australia Pty Limited is 14 101
682 357

76
Cordless Blower KG560E KG560E.X
1
2
3
456
7
8
9
10

Cordless Blower KG560E KG560E.X
76
DC
BA
F1
E
Click!
1
2
2
1

98
Cordless Blower KG560E KG560E.X
1
F2
3
O
1
2
G1
3
O
1
2
G2
2
3
3
2
1

Cordless Blower KG560E KG560E.X
98
H
G3
2
1
O
O

1110
Cordless Blower KG560E KG560E.X
COMPONENT LIST
1. AIRSPEED SELECTOR NOZZLE
2. BLOWER TUBE
3. TUBE RELEASE BUTTON
4. VARIABLE SPEED DIAL
5. TURBO BUTTON FOR POWER
BOOSTING
6. HANDLE
7. BATTERY PACK RELEASE BUTTON
8. TRIGGER
9. MOTOR HOUSING
10. NOZZLE RELEASE BUTTON
Not all the accessories illustrated or described
are included in standard delivery.
TECHNICAL DATA
Type Designation KG560E KG560E.X
(5 - designation of machinery, representative of
blower)
KG560E KG560E.X **
Voltage 60 V Max.*
Maximum air volume 1275 m3/h
(Air volume mode)
Maximum air speed 215 km/h
(Air speed mode)
Machine weight
(bare tool) 2.3 kg
* Voltage measured without workload. Initial
battery voltage reaches maximum of 60 volts.
Nominal voltage is 54 volts.
** X=1-999, A-Z, M1-M9 there are only used for
different customers, there are no safe relevant
changes between these models.
SUGGESTED BATTERIES
AND CHARGERS
Category Type Capacity
60V Battery
KA3000 2.0 Ah
KA3001 2.5 Ah
KA3002 4.0 Ah
KA3008 5.0 Ah
60V Charger
KA3713 3.0 A
KA3714 5.0 A
We recommend that you purchase your accessories
from the same store that sold you the tool. Refer to
the accessory packaging for further details. Store
personnel can assist you and offer advice.
INTENDED USE
The blower is intended for residential use only.
Use the blower outdoors to move yard debris as
needed.
BEFORE OPERATION
ASSEMBLING & DISASSEMBLING THE
BLOWER TUBE
To Assemble (Fig. A)
- Align the groove and push the tube onto the
blower housing until you hear a “click”.
To Disassemble (Fig. B)
- Press the tube-release button and pull the tube
out.
INSTALLING & REMOVING THE BATTERY
PACK
To Install (Fig. C)
- After recharging, insert the battery pack into
tool’s battery port. A simple push and slight
pressure will be sufcient.
To Remove (Fig. D)
- Press the battery release button to release
battery pack from your tool.
OPERATION
AIR SPEED MODE (FIG.E)
NOTE: The blower is in the air speed mode as
packed in the box.
- Air speed mode is recommended for cleaning
on grass, as shown in Fig. G1.
AIR VOLUME MODE (FIG.F1,F2)
- Depress the nozzle release button and slide

Cordless Blower KG560E KG560E.X
1110
forward for air volume mode.
- Air volume mode is recommended for cleaning
on hard ground such as cement, as shown in
Fig.G2
NOTE: To change modes, slide backward for air
speed mode.
To st ar t
Variable Speed Dial control (Fig. G1, G2)
Turn the Variable Speed Dial clockwise or
anticlockwise to increase or decrease the blowing
speed / air volume with 3-speed switch.
NOTE: When Variable Speed Dial is in “O”
position, the blower cannot be started. Turn
the Variable Speed Dial to the desired speed
selection which will start the blower.
To stop (Fig. G3)
Turn the Variable Speed Dial clockwise to “O” or
depress the Trigger and release it to have a quick
stop. Turn the Variable Speed Dial clockwise to “O”
position after each use.
NOTE: After completing the quick stop, Variable
Speed Dial will not work until you have the throttle
trigger fully depressed.
USER TIPS
- Hold the blower tube approximately 8’’ above
the ground when operating the tool.
Use a sweeping motion from side to side.
Advance slowly keeping the accumulated
debris/leaves in front of you.
- After blowing the debris/leaves into a pile, it is
easy to dispose of the pile.
CAUTION!
- Do not blow hard objects such as nails, bolts,
or rocks.
- Do not operate the blower near bystanders or
pets.
- Use extra care when cleaning debris from
stairs or other tight areas.
- Wear safety goggles or other suitable eye
protection, long pants, and shoes.
TURBO BUTTON FOR POWER BOOSTING (FIG.
H)
- Press the turbo button for power boosting
while working to temporarily increase the air
ow to the maximum level
- Release the Turbo button, the blower will return
to the previously selected speed.
NOTE: Turbo button for power boosting can
increase air ow signicantly, and it can be used
for clearing heavy or wet debris.
CLEANING THE TOOL
Clean the tool regularly.
WARNING! Keep your product dry. Under
no circumstances spray with water.
- To clean the tool, use only mild soap and a
damp cloth.
- Do not use any type of detergent, cleaner or
solvent which may contain chemicals that
could seriously damage the plastic.
- Self lubricating bearings are used in
your product, therefore lubrication is not
required.
FOR BATTERY TOOLS
The ambient temperature range for the use and
storage of tool and battery is 0 0C-45 0C.
The recommended ambient temperature range for
the charging system during charging is 5 0C-40 0C.
Details regarding safe disposal of used batteries
At the end of the life of the appliance, remove
the battery pack safely before disposing of the
appliance. Do not throw batteries away or throw
them in the normal trash can. Also do not dispose
of the battery with the machine. Remove the used
battery pack from the appliance and dispose
of it at the nearest or convenient dedicated
recycling facility. If in doubt, consult your local
environmental protection department. Batteries
may enter water cycle if disposed improperly,
which can be hazardous for ecosystem. Do not
dispose of waste batteries as unsorted municipal
waste.
Positec Australia Pty Limited
10 Corporate Blvd Bayswater , VIC 3153, Australia

Copyright © 2023, Positec. All Rights Reserved.
AR01728100
