KSB AMTROBOX EEx ia Configuration guide

Type series booklet
8526.12/18--10
AMTROBOX EEx ia
AMTRONIC EEx ia
Ex ia IIC T6
Position monitoring
and on/off pneumatic distribution functions
Intrinsically safe
remote indication and control box
for ACTAIR and DYNACTAIR
pneumatic actuators
and MR manual actuators
II 1 G
0081
Applications
Explosive atmospheres.
All sectors of Water, Energy and Industry markets.
General information
AMTROBOX EEx ia and AMTRONIC EEx ia (R 1172) remote
indication and control boxes are of intrinsically safe
protection design for use in explosive atmospheres.
AMTROBOX EEx ia R 1172
Specially designed for use with double acting ACTAIR and
spring return DYNACTAIR pneumatic actuators and MR
manual actuators, this box integrates, in a modular form, the
following electric functions:
-- Position detection (opening and closing) by microswitches
or inductive proximity detectors
-- Feed--back position by angle sensor and 4--20 mA
transmitter (option).
AMTRONIC EEx ia R 1172
Specially designed for use with double acting ACTAIR and
spring return DYNACTAIR pneumatic actuators, this box
ensures the following functions:
-- Position detection (opening and closing) by microswitches
or inductive proximity detectors,
-- Feed--back position by angle sensor and 4--20 mA
transmitter (option)
-- On/off pneumatic distribution.
They are approved Ex ia IIC T6 in accordance with EN
60079--0 and EN 60079--11 standards.
EC type examination certificate: LCIE 03 ATEX 6435X
The representative gas of explosion risk is hydrogen, the
maximum temperature of the box is 80 °C.
They are in accordance with ATEX 94/9/CE directive and
marking:
II 1 G
0081
Explosive area: Ex ia IIC T6
It can to be fitted directly onto actuators by the intermediate of
it VDI/VDE 3845 interface.
It is equipped with a bicolor visual pointer large size allowing
the visualisation of the quater--turn valve position.
Protection
Protection level: IP 67
Its cataphoresis coating ensures a good resistance in
corrosive environments.
Temperature range
From –10 °Cto+50°C
Material
Housing: Aluminium.
Base plate: Aluminium.
Standard variante
Feed--back position.
This leaflet is also to be used as a start--up guide ref. 42 057 237

AMTROBOX EEx ia
AMTRONIC EEx ia
2
AMTROBOX EEx ia
Angle sensor (option)
Transparent sight glass
Pointer
Adjustable cams
Microswitches or
inductive proximity detectors
on supporting plate
4--20 mA transmitter (option)
External earth terminal

AMTROBOX EEx ia
AMTRONIC EEx ia
3
Transparent sight glass
Pointer
Push--buttons
for emergency control
of the electric pilots
Electric pilots
Angle sensor (option)
Pneumatic
valves
Microswitches or
inductive proximity detectors
on supporting plate
4--20 mA transmitter (option)
External earth terminal
Operating time
adjustment
Adjustable cams
AMTRONIC EEx ia

AMTROBOX EEx ia
AMTRONIC EEx ia
4
Contents
Page
General technical data 5
Overall dimensions and weight 5
Parts common to all versions 6
Position detection: AMTROBOX EEx ia and AMTRONIC EEx ia
-- General 8
-- Construction 8
By microswitches -- Boxes ref. R 1172--A2....
-- Technical characteristics of microswitches 9
-- Wiring diagram 9
-- Barriers and interfaces 9
By inductive proximity detectors -- Boxes ref. R 1172--K3.... and R 1172--J7....
-- Technical characteristics of detectors 10
-- Wiring diagram 10
-- Barriers and interfaces 10
On/off pneumatic distribution: AMTRONIC EEx ia
-- Construction 11
-- Various available configurations 12
-- Technical data of electro--pneumatic valve -- Wiring diagram -- Barriers and interfaces 13
Optional feed--back position 0°to 90°by a 4--20 mA signal 14
Pneumatic supply 15
Commissioning
-- W a r n i n g 16
-- Electric connection 16
-- Pneumatic connection 16
-- Operating time adjustment (AMTRONIC EEx ia) 17
-- Open/close position detection adjustment 17
-- Angle sensor adjustment 18
-- 4--20 mA feed--back adjustment 18
Declaration of conformity 19
Product features 20

AMTROBOX EEx ia
AMTRONIC EEx ia
5
General technical data
Environment
-- Protection level: IP 67
-- Resistance to impacts: 5gaccordingtoCEI68--2--27
-- Resistance to vibrations: 2 g, 6 mm from 5 to 500 Hz as per STANAG 4370 3 axis
-- Working temperature: from -- 10 °Cupto+50°C
-- Control air temperature: from -- 10 °Cupto+30°C (AMTRONIC EEx ia)
-- Electromagnetic compatibility:
Standards EN 61000--6--2; EN 61000--6--4
-- Protection against explosive
environment since intrinsically safe
EN 60079--0; EN 60079--11
Housing
-- M a t e r i a l : Aluminium
-- Coating: Black cataphoresis
-- Position indication: By visual pointer under transparent sight glass
-- Bolting: A2--70 stainless steel
Air distribution:
-- Pressure connection Port marked “P” equiped with an internal filter on the base (1/4 gas)
-- Central discharge connection Port marked “E” fitted with a silencer or connectable to exhausted network (1/4” gas)
-- Working pressure 3,5 to 7 bar (50 to 102 psi), dry or lubricated
-- Filtration level <50m
-- Dew point -- 5 °C
-- Maximum flow rate 300 Nl/mn at 6 bar (4/3) / 400 Nl/mn at 6 bar (4/2)
-- Pneumatic consumption when idle None
Overall dimensions (mm) and weight (kg)
58
78
Weight: 1,5 kg
View from F
209
F
144
Pneumatic connection 2 x 1/4” gas
PE

AMTROBOX EEx ia
AMTRONIC EEx ia
6
Parts common to all versions
554.2 900.3 817.1 412.1 191.1 81--2.2 900.4 81--2.1
160
191.1 890 188.1 900.5 410.2 747 412.2 900.9 81--18.1
A
A
B
B
819
554.2
900.2
553.1
191.1
81--29
626
210
970.2
81--84.1
629
412.1
970.1
62--2
81--33
900.1
554.1
410.1
932.1
314
903.1
Section B--B Section A--A

AMTROBOX EEx ia
AMTRONIC EEx ia
7
Common parts to all versions
Item Designation Materials
160 Cover Aluminium with black cataphoresis coating
188.1 Sheet Steel
191.1 Sheet support Polyamide 6
210 Operating shaft Acetal
314 Thrust washer 304 stainless steel
410.1 Cover gasket Nitrile
410.2 Base gasket Nitrile
412.1 Sigh glass O--Ring Nitrile
412.2 O--Ring Nitrile
553.1 Thrust Steel
554.1 Plain washer A2--70 stainless steel
554.2 Plain washer A2--70 stainless steel
62--2 3--cam sub--assembly Acetal + 30% fibreglass
626 Sight glass Transparent polycarbonate
629 Pointer Polyamide 6--6 with anti U.V. treatment
747 Check valve sub--assembly -- -- --
81--18.1 Snap -- -- --
81--2.1 500 SV type ground wire 1,5 mm2Copper
81--2.2 Ground wire + cable terminal Copper
81--29 Ex 05--0012--0002 earth terminal Bartec
81--33 Detection sheet for inductive proximity detector Steel
81--84.1 Wiring diagram Aluminium sticker
817.1 Cable way Skiffy
819 Terminal block Entrelec
890 Base Aluminium with black cataphoresis coating
900.1 Cheese--head screw A2--70 stainless steel
900.2 Cheese--head screw A2--70 stainless steel
900.3 Cheese--head screw A2--70 stainless steel
900.4 Self--cutting screw Zinc coated steel cl. 8--8
900.5 Cheese--head screw A2--70 stainless steel
900.9 Pozidriv screw Zinc coated steel cl. 8--8
903.1 Plug 1/4’’ Gas Polyamide 6--6
932.1 Spring retaining ring Steel
970.1 Identity plate Adhesive polyester
970.2 Instruction notice Paper

AMTROBOX EEx ia
AMTRONIC EEx ia
8
Position detection:AMTROBOX EEx ia and AMTRONIC EEx ia
General
The intrinsically safe microswitches and inductive proximity detectors fitted in AMTROBOX EEx ia and AMTRONIC EEx ia are in
accordance with EN 60079--0 and EN 60079--11 standards relating to components installed in explosive environment.
They must be connected individually to an approved safety barrier. Situated in a safe area, these barriers allow the power supply of
the microswitches installed in hazardous area.
Construction
554.4 900.7 920.1 839
View from F
F
900.7 554.4 818
196
FView from F
Microswitches
Proximity detectors
Item Designation Materials
196 Securing plate Steel
554.4 Plain washer Steel
818 Detector Ex ia ref. NS 5002 or
Detector V3 DIN 41635 NJ2--V3--N
IFM Effector (box ref. R 1172--J7....) or
Pepper & Fuchs (box ref. R 1172--K3....)
839 Microswitch V4 DIN 4635B ref. 83 136 069 Crouzet (box ref. R 1172--A2....)
900.7 Cheese--head screw Steel cl. 8.8
920.1 Hexagonal nut Steel cl. 8.8

AMTROBOX EEx ia
AMTRONIC EEx ia
9
Position detection by microswitches -- Box ref. R 1172--A2....
Technical characteristics of microswitches
Manufacture: Crouzet
Type: 83 186 069 lever 170A R=24 -- V4
Conformity certificate: Material according to EN 50020 §5 standard -- Common material
Electrical output: By 3--wire cable, section 0.5 mm2
Protection level: IP 67
Wiring: The two microswitches are workshop--connected to the main terminal block by means of
spring connectors, capacity 2.5 mm2. Refer to wiring diagram below.
Max. voltage: 60 VDC
Mechanical and electrical
life: 2.10
6cycles
Working temperature: From -- 25 °Cupto+70°C
Resistance to impacts: 5gaccordingtoCEI68--2--27
Resistance to vibrations: 2,5 g from 5 to 500 Hz as per STANAG 4370 3 axis
Function: Change--over
Special conditions for safe use
Working ambient
temperature : From -- 10 °Cto+50°C
Max. voltage U0:26,5 VDC
Max. current I0:127 mA
Wiring diagram
Hazardous area Safe area
Barriers and Interfaces
The barriers and interfaces recommanded by KSB--AMRI can be ordered to one of the manufacturers in the following table. When
ordering, specify that these components are intended for the electric supply of Crouzet type 83 186 069 microswitches.
Manufacturer Barrier reference Interface
reference
Laboratory
certificate Gas group Permitted areas
GEORGIN RDN 11
RDN 211
LCIE 02 ATEX 6104 X
LCIE 02 ATEX 6104 X
II C
II C
A
A
P
3
N A E V -- D I 2 N -- A 2 3 0 LCIE 00 ATEX 6034 X II C
A
ny area
A
P
3NAEV--DI 2 N--A115 LCIE 00 ATEX 6034 X II C
Any other barrier or interface of different construction may be used provided it complies with regulations requirements and that
calculation and installation rules are respected.
For each reference defined in the above table, KSB--AMRI can supply to the user the corresponding loop calculations.

AMTROBOX EEx ia
AMTRONIC EEx ia
10
Position detection by inductive proximity detectors -- Boxes ref. R 1172--K3.... or R 1172--J7....
Technical characteritics of detectors
Box ref. R 1172--J7.... Box ref. R 1172--K3...
Manufacturer: IFM Effector Pepperl & Fuchs
Type: NS 5002 NJ2--V3--N
Conformity certificate: PTB 01 ATEX 2191 PTB 00 ATEX 2032 X
Nominal voltage: 8.2 VDC 8VDC
Voltage: 5to25VDC -- -- -- -- --
Off state ondulation: <5% -- -- -- -- --
Cable max. resistance: 50 -- -- -- -- --
Output activation: <1mA <1mA
Output non activation: <2.2mA <3mA
Self capacity: <70F<35F
Self inductance: < 190 H<50H
Switching frequency: 800 hz 1000 hz
Resistance to impacts: < 30g on 10 ms -- -- -- -- --
Resistance to vibrations: < 10g to 55 hz. a = 1 mm -- -- -- -- --
Protection level: IP 67 IP 67
Rated operating distance: 2mm 1,62 mm
Output type: NF NF
Connection: Cable PVC : 2 x 0.14 mm2Cable PVC : 2 x 0.14 mm2
Working temperature From -- 25°Cupto+70°CFrom -- 25°Cupto+70°C
Special conditions for safe use
IFM Effector NS--5002 Pepperl & Fuchs NJ2--V3--N
Working ambient temperature : From -- 10°Cto+50°CFrom -- 10°Cto+50°C
Max. voltage U0:16 VDC 15,5 VDC
Max. current I0:50 mA 52 mA
Max. Consumption P0:150 mW 169 mW
Hazardous area Safe area
Wiring diagram
Nc
Nc
Barriers and Interfaces
The barriers and interfaces recommanded by KSB--AMRI can be ordered to any of the manufacturers in the following table. When
ordering, specify thatthese components are intended for the supply ofproximity detectors IFMEffector NS 5002 orPepperl& Fuchs
NJ2--V3--N.
Manufacturer Barrier reference Interface
reference
Laboratory
certificate
Gas group Permitted
areas
GEORGIN RDN 11
RDN 211
LCIE 02 ATEX 6104 X
LCIE 02 ATEX 6104 X
II C
II C
A
n
y
a
r
e
a
A
P
3
N A E V -- D I 2 N -- A 2 3 0 LCIE 00 ATEX 6034 X II C
A
ny area
A
P3 NAEV--DI 2 N--A115 LCIE 00 ATEX 6034 X II C
Any other barrier or interface of different construction may be used provided it complies with regulations requirements and that the
calculation and installation rules are respected.
For each reference defined in the above table, KSB--AMRI can supply to the user the corresponding loop calculations.
