KSB Amarex N Manual

Cust. Doc. No.:GDSTP-24090-MAN-0005-P2
KSB Doc. No.:KSB-88980-060
KSB REF No: 88980/ 02
Client : Thiess Pty Ltd
Project : Goodna Sewerage Treatment Plant Upgrage [Stage 4A]
P.O. No. : GDSTP-24090-CON-0000
Equipment / Tag No.: WAS PUMP 1 & 2 PU-0530-010
OPERATING AND
MAINTENANCE
INSTRUCTIONS
KSB Australia Pty Ltd
ABN 29 006 414 642
A Quality Endorsed Company AS/NZ ISO9001:2008
Sales and Service
Phone : [phone]
Fax : [phone]
Email : [email protected]
Spares : 1300 KSB SPARES ( 1300 572 772 )
Issue Date: 19/12/2011
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 1 of 76

INDEX
1. Pump
•Amarex N Pumps Installation & Operating Instructions
2. Additional Data
•Data Sheet
3. Drawing
•Certified G.A. Drawing No.UX02010
4. I.T.P.s
•I.T.P.s
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 2 of 76

Submersible Motor Pump
Amarex® N
Pump sizes DN 50 to DN 100
Motor sizes:
2-pole: 002 to 042
4-pole: 004 to 044
Installation/Operating
Manual
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 3 of 76

Copyright/Legal information
Installation/Operating Manual Amarex® N
Original operating manual
KSB Aktiengesellschaft Pegnitz
All rights reserved. Contents provided herein must neither be distributed, copied, reproduced,
processed for any other purpose, nor otherwise transmitted to a third party without KSB´s express
written consent.
Subject to technical modification without prior notice.
© KSB Aktiengesellschaft Frankenthal 24.03.2010
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 4 of 76

Contents
Glossary ................................................................................................ 5
1 General ................................................................................................ 6
1.1 Principles .......................................................................................................... 6
1.2 Installation of partly completed machinery .................................................. 6
1.3 Target group ................................................................................................... 6
1.4 Other applicable documents .......................................................................... 6
1.5 Symbols ............................................................................................................ 7
2 Safety ................................................................................................... 8
2.1 Key to safety symbols/markings ..................................................................... 8
2.2 General ............................................................................................................ 8
2.3 Intended use .................................................................................................... 8
2.4 Personnel qualification and training ........................................................... 10
2.5 Consequences and risks caused by non-compliance with these operating
instructions .................................................................................................... 10
2.6 Safety awareness ........................................................................................... 10
2.7 Safety information for the operator/user .................................................... 10
2.8 Safety information for maintenance, inspection and installation work ... 11
2.9 Unauthorised modes of operation ............................................................... 11
2.10 Explosion protection ..................................................................................... 11
3 Transport/Temporary Storage/Disposal ........................................... 12
3.1 Transport ....................................................................................................... 12
3.2 Storage and preservation ............................................................................. 12
3.3 Return to supplier ......................................................................................... 13
3.4 Disposal .......................................................................................................... 13
4 Description of the Pump (Set) .......................................................... 14
4.1 General description ....................................................................................... 14
4.2 Designation ................................................................................................... 14
4.3 Name plate .................................................................................................... 14
4.4 Design details ................................................................................................ 15
4.5 Types of installation ...................................................................................... 15
4.6 Configuration and function ......................................................................... 16
4.7 Scope of supply ............................................................................................. 16
4.8 Dimensions and weights ............................................................................... 17
5 Installation at Site ............................................................................. 18
5.1 Safety regulations ......................................................................................... 18
5.2 Checking the site before installation ........................................................... 18
5.3 Installing the pump set ................................................................................. 20
5.4 Electrical connection ..................................................................................... 27
Contents
Amarex® N 3 of 66
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 5 of 76

6 Commissioning/Start-up/Shutdown ................................................. 32
6.1 Commissioning/start-up ................................................................................ 32
6.2 Operating limits ............................................................................................ 33
6.3 Shutdown/storage/preservation ................................................................... 35
6.4 Returning to service ...................................................................................... 35
7 Servicing/Maintenance ...................................................................... 37
7.1 Safety regulations ......................................................................................... 37
7.2 Maintenance/Inspection ............................................................................... 38
7.3 Drainage/disposal .......................................................................................... 42
7.4 Dismantling the pump set ............................................................................ 42
7.5 Reassembling the pump set .......................................................................... 44
7.6 Tightening torques ....................................................................................... 48
7.7 Spare parts stock ........................................................................................... 48
8 Trouble-shooting ............................................................................... 50
9 Related Documents ........................................................................... 51
9.1 General assembly drawing with list of components ................................... 51
9.2 Wiring diagrams ............................................................................................ 57
9.3 Wiring diagrams overload protection ......................................................... 59
9.4 Flamepaths on explosion-proof motors ....................................................... 60
9.5 Installation drawings of the mechanical seal .............................................. 62
10 EC Declaration of Conformity .......................................................... 63
11 Certificate of Decontamination ....................................................... 64
Index .................................................................................................. 65
Contents
4 of 66 Amarex® N
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 6 of 76

Glossary
Certificate of decontamination
A certificate of decontamination certifies that
the pump (set) has been properly drained to
eliminate any environmental and health
hazards arising from components in contact
with the fluid handled.
Hydraulic system
The part of the pump in which the kinetic
energy is converted into pressure energy
Monobloc pump set
Motor housing and pump casing form a single
component.
Glossary
Amarex® N 5 of 66
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 7 of 76

1 General
1.1 Principles
This manual is supplied as an integral part of the type series and variants indicated
on the front cover (for details, please refer to the table below).
Table 1: Variants covered by this manual
Sizes Impeller
types
Material variant
G G1 G2 GH1)
50-170 F, S F, S F F F
50-172 S S - - -
50-220 F, S F, S F F F
50-222 S S - - -
65-170 F F F F F
65-220 F F F F F
80-220 F, D F, D F F F
100-220 F, D F, D F F F
This manual describes the proper and safe use of this equipment in all phases of
operation.
The name plate indicates the type series and size, the main operating data, the order
number and the order item number. The order number and order item number
clearly identify the pump (set) and serve as identification for all further business
processes.
In case of damage, immediately contact your nearest KSB service centre to maintain
the right to claim under warranty.
1.2 Installation of partly completed machinery
To install partly completed machinery supplied by KSB, refer to the sub-sections
under Servicing/Maintenance.
1.3 Target group
This manual is aimed at the target group of trained and qualified specialist technical
personnel. (⇨ Section 2.4 Page 10)
1.4 Other applicable documents
Table 2: Overview of other applicable documents
Document Contents
Data sheet Description of the technical data of the pump
(set)
General arrangement drawing/
outline drawing
Description of mating and installation dimensions
for the pumps/pump sets
Hydraulic characteristic curve Characteristic curves showing head, flow rate,
efficiency and power input
General assembly drawing2) Sectional drawing of the pump
Spare parts lists2) Description of spare parts
Supplementary operating
instructions2)
e.g. for installation parts for stationary wet
installation
1) Variant GH only for pump sets WL and YL
2) If agreed to be included in the scope of supply
1 General
6 of 66 Amarex® N
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 8 of 76

1.5 Symbols
Table 3: Symbols used in this manual
Symbol Description
✓Conditions which need to be fulfilled before proceeding with the
step-by-step instructions
⊳Safety instructions
⇨Result of an action
⇨Cross-references
1.
2.
Step-by-step instructions
Note
Recommendations and important information on how to handle
the product
1 General
Amarex® N 7 of 66
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 9 of 76

2 Safety
All the information contained in this section refers to hazardous situations.
2.1 Key to safety symbols/markings
Table 4: Definition of safety symbols/markings
Symbol Description
!DANGER
DANGER
This signal word indicates a high-risk hazard which, if not avoided,
will result in death or serious injury.
!WARNING
WARNING
This signal word indicates a medium-risk hazard which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION
This signal word indicates a hazard which, if not avoided, could
result in damage to the machine and its functions.
Explosion protection
This symbol identifies information about avoiding explosions in
potentially explosive atmospheres in accordance with EC Directive
94/9/EC (ATEX).
General hazard
In conjunction with one of the signal words this symbol indicates a
hazard which will or could result in death or serious injury.
Electrical hazard
In conjunction with one of the signal words this symbol indicates a
hazard involving electrical voltage and identifies information
about protection against electrical voltage.
Machine damage
In conjunction with the signal word CAUTION this symbol indicates
a hazard for the machine and its functions.
2.2 General
This manual contains general installation, operating and maintenance instructions
that must be observed to ensure safe pump operation and prevent personal injury
and damage to property.
The safety information in all sections of this manual must be complied with.
This manual must be read and completely understood by the responsible specialist
personnel/operators prior to installation and commissioning.
The contents of this manual must be available to the specialist personnel at the site
at all times.
Information attached directly to the pump must always be complied with and be
kept in a perfectly legible condition at all times. This applies to, for example:
▪Arrow indicating the direction of rotation
▪Markings for connections
▪Name plate
The operator is responsible for meeting all local regulations which are not taken into
account in this manual.
2.3 Intended use
Only operate the pump (set) within the application limits specified in the other
applicable documents.
▪Only operate pump sets which are in perfect technical condition.
▪Do not operate partially assembled pump sets.
!DANGER
2 Safety
8 of 66 Amarex® N
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 10 of 76

▪Only use the pump to handle the fluids described in the data sheet or product
literature of the pump model.
▪Never operate the system without the fluid to be handled.
▪Observe the limits for continuous operation specified in the data sheet or
product literature (Qmin3) and Qmax4) ) (prevention of damage such as shaft
fracture, bearing failure, damaged mechanical seal, etc).
▪When handling untreated waste water the duty points in continuous operation
lie within 0.7 to 1.2 x Qopt5) to minimise the risk of clogging/hardening.
▪Avoid duty points for continuous operation at very low speeds and small flow
rates (<0.7 x Qopt5) ).
▪Observe the information on the maximum flow rates provided in the data sheet
or technical product literature (prevention of overheating damage, cavitation
damage, bearing damage, etc).
▪Do not throttle the flow rate on the suction side of the system (prevention of
cavitation damage).
▪For any operating modes which are not specified in the data sheet or product
literature, contact the manufacturer.
▪Only use impeller types designed for the fluid handled, as described below.
Impeller with cutter
(impeller type S)
Suitable for the following fluids:
Faeces, domestic sewage and waste water
containing long fibres
Free-flow impeller
(impeller type F)
Suitable for the following fluids:
Fluids containing solids and stringy
material as well as fluids with entrapped
air or gas
Open, diagonal single
vane impeller
(impeller type D)
Suitable for the following fluids:
Waste water with solid substances and
long fibres
Prevention of foreseeable misuse
▪Observe the minimum flow velocities for fully open swing check valves to prevent
the reduction of pressure and risk of clogging.
(Contact the manufacturer for the required minimum flow velocities/loss
coefficients.)
▪Never exceed the permissible application limits specified in the data sheet and in
the product literature regarding pressure, temperature, etc.
▪Observe all safety notes and instructions in this manual.
3) Minimum permissible flow rate
4) Maximum permissible flow rate
5) Optimum efficiency
2 Safety
Amarex® N 9 of 66
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 11 of 76

2.4 Personnel qualification and training
All personnel involved must be fully qualified to install, operate, maintain and
inspect the machinery this manual refers to.
The responsibilities, competence and supervision of all personnel involved in
installation, operation, maintenance and inspection must be clearly defined by the
operator.
Deficits in knowledge must be rectified by sufficiently trained specialist personnel
training and instructing the personnel who will carry out the respective tasks. If
required, the operator can commission the manufacturer/supplier to train the
personnel.
Training on the pump (set) must always be supervised by technical specialist
personnel.
2.5 Consequences and risks caused by non-compliance with these operating
instructions
▪Non-compliance with these operating instructions will lead to forfeiture of
warranty cover and of any and all rights to claims for damages.
▪Non-compliance can, for example, have the following consequences:
– Hazards to persons due to electrical, thermal, mechanical and chemical
effects and explosions
– Failure of important product functions
– Failure of prescribed maintenance and servicing practices
– Hazard to the environment due to leakage of hazardous substances
2.6 Safety awareness
In addition to the safety information contained in this manual and the intended use,
the following safety regulations shall be complied with:
▪Accident prevention, health and safety regulations
▪Explosion protection regulations
▪Safety regulations for handling hazardous substances
▪Applicable standards and laws
2.7 Safety information for the operator/user
▪The operator shall fit contact guards for hot, cold or moving parts and check that
the guards function properly.
▪Do not remove the contact guard while the pump is running.
▪Connect an earth conductor to the metal jacket if the fluid handled is
electrostatically charged.
▪Provide the personnel with protective equipment and make sure it is used.
▪Contain leakages (e.g at the shaft seal) of hazardous fluids handled (e.g.
explosive, toxic, hot) so as to avoid any danger to persons and the environment.
Adhere to all relevant laws.
▪Eliminate all electrical hazards. (In this respect refer to the applicable national
safety regulations and/or regulations issued by the local energy supply
companies.)
2 Safety
10 of 66 Amarex® N
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 12 of 76

2.8 Safety information for maintenance, inspection and installation work
▪Modifications or alterations of the pump are only permitted with the
manufacturer's prior consent.
▪Use only original spare parts or parts authorised by the manufacturer. The use of
other parts can invalidate any liability of the manufacturer for consequential
damage.
▪The operator ensures that all maintenance, inspection and installation work is
performed by authorised, qualified specialist personnel who are thoroughly
familiar with the manual.
▪Carry out work on the pump (set) during standstill only.
▪The pump casing must have cooled down to ambient temperature.
▪Pump pressure must have been released and the pump must have been drained.
▪When taking the pump set out of service always adhere to the procedure
described in the manual.
▪Decontaminate pumps which handle fluids posing a health hazard.
▪As soon as the work is completed, re-install and/or re-activate any safety-relevant
and protective devices. Before returning the product to service, observe all
instructions on commissioning. (⇨ Section 6.1 Page 32)
2.9 Unauthorised modes of operation
Never operate the pump (set) outside the limits stated in the data sheet and in this
manual.
The warranty relating to the operating reliability and safety of the supplied pump
(set) is only valid if the equipment is used in accordance with its intended use.
2.10 Explosion protection
Always observe the information on explosion protection given in this section when
operating an explosion-proof pump set.
Sections of the manual marked by the Ex symbol apply to explosion-proof pump sets
also when temporarily operated outside potentially explosive atmospheres.
Only pumps/pump sets marked as explosion-proof and identified as such in the data
sheet must be used in potentially explosive atmospheres.
Special conditions apply to the operation of explosion-proof pump sets in accordance
with EC Directive 94/9/EC (ATEX).
When operating explosion-proof pump sets, especially adhere to the additional
requirements marked by the Ex symbol.
The explosion-proof status of the pump set is only assured if the pump set is used in
accordance with its intended use.
Never operate the pump (set) outside the limits stated in the data sheet and on the
name plate.
Prevent impermissible modes of operation at all times.
2.10.1 Repair
Special regulations apply to repair work on explosion-proof pumps. Modifications or
alteration of the pump set may affect explosion protection and are only permitted
after consultation with the manufacturer.
Repair work at the flameproof joints must only be performed in accordance with the
manufacturer's instructions. Repair to the values in tables 1 and 2 of EN 60079-1 is
not permitted.
!DANGER
2 Safety
Amarex® N 11 of 66
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 13 of 76

3 Transport/Temporary Storage/Disposal
3.1 Transport
DANGER
Improper transport
Danger to life from falling parts!
Damage to the pump set!
▷Use the attachment point (pump handle) provided for attaching lifting tackle.
▷Never suspend the pump set by its power cable.
▷Never use the chains or lifting ropes included in KSB's scope of supply for lifting
loads other than the KSB product supplied.
▷Safely attach transport ropes or chains to the pump and crane.
▷The number on the sign attached to the pump set must match the number on
the sign attached to the chain.
Transport the pump set as illustrated.
Fig. 1: Transporting the pump set
3.2 Storage and preservation
If commissioning is to take place some time after delivery, we recommend that the
following measures be taken for pump storage:
CAUTION
Improper storage
Damage to the power cables!
▷Support the power cables at the cable entry to prevent permanent deformation.
▷Only remove the protective caps from the power cables at the time of
installation.
CAUTION
Damage during storage by humidity, dirt, or vermin
Corrosion/contamination of the pump (set)!
▷For outdoor storage cover the pump (set) or the packaged pump (set) and
accessories with waterproof material.
CAUTION
Wet, contaminated or damaged openings and connections
Leakage or damage to the pump set!
▷Only remove caps/covers from the openings of the pump set at the time of
installation.
3 Transport/Temporary Storage/Disposal
12 of 66 Amarex® N
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 14 of 76

Table 5: Ambient conditions for storage
Ambient conditions Value
Relative humidity 5 % to 85 %
(non-condensing)
Ambient temperature - 10 °C to + 70 °C
▪Store the pump set under dry and vibration-free conditions, if possible in its
original packaging.
1. Spray-coat the inside wall of the pump casing, and in particular the impeller
clearance areas, with a preservative.
2. Spray the preservative through the suction and discharge nozzles.
It is advisable to then close the pump nozzles (e.g. with plastic caps or similar).
NOTE
Observe the manufacturer's instructions for application/removal of the preservative.
3.3 Return to supplier
1. Drain the pump as per operating instructions.
2. Always flush and clean the pump, particularly if it has been used for handling
noxious, explosive, hot or other hazardous fluids.
3. If the fluids handled by the pump leave residues which might lead to corrosion
damage when coming into contact with atmospheric humidity, or which might
ignite when coming into contact with oxygen, the pump set must also be
neutralised, and anhydrous inert gas must be blown through the pump for
drying purposes.
4. Always complete and enclose a certificate of decontamination when returning
the pump (set). (⇨ Section 11 Page 64)
It is imperative to indicate any safety and decontamination measures taken.
NOTE
If required, a blank certificate of decontamination can be downloaded from the KSB web
site at: www.ksb.com/certificate_of_decontamination
3.4 Disposal
WARNING
Fluids posing a health hazard
Hazardous to persons and the environment!
▷Collect and properly dispose of flushing liquid and any fluid residues.
▷Wear safety clothing and a protective mask, if required.
▷Observe all legal regulations on the disposal of fluids posing a health hazard.
1. Dismantle the pump (set).
Collect greases and other lubricants during dismantling.
2. Separate and sort the pump materials, e.g. by:
- Metals
- Plastics
- Electronic waste
- Greases and other lubricants
3. Dispose of materials in accordance with local regulations or in another controlled
manner.
3 Transport/Temporary Storage/Disposal
Amarex® N 13 of 66
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 15 of 76

4 Description of the Pump (Set)
4.1 General description
Pump for handling untreated waste water containing long fibres and solid
substances, fluids containing gas and air as well as raw, activated and digested
sludge.
4.2 Designation
Example: Amarex N F 50 - 170 / 012 YLG 120
Table 6: Key to the designation
Code Description
Amarex N Type series
F Impeller type, e.g. F = free flow impeller
50 Nominal discharge nozzle diameter [mm]
170 Code number for hydraulic system size
01 Code number for motor size
2 Number of poles
YL Motor variant, e.g. YL = with explosion protection T4 (40
°C)
G Casing material, e.g. G = grey cast iron
120 Nominal impeller diameter [mm]
4.3 Name plate
Typ
No.
Q l/s l/s
P2 kW
V Hz
cos φ
°C
A
1/min
SEQUEDIN
F - 59320
2009
IP 68 S1 IA/IN kg Class F
3~
H m
M.-No.
Nicht unter Spannung öffnen.
Ne pas ouvrir sous tension.
Non aprire con motore sotto tensione.
Non abrir bajo tensión.
Do not open while energised.
Non abrir bajo tensión.
Do not open while energised.
Amarex N F 50-170/012 ULG - 120
39100049 39100049
0,3 - 10,8 0,3 - 10,8
1,9 1,9
2835 2835
400 400
4,5 4,5
4,4 4,4
42 42
0,83 0,83
50 50 55
15,6 - 4,99 15,6 - 4,99
70165000
DKN 82.2-2U DKN 82.2-2U
Amarex N F 50-170/012 YLG - 120
Nicht unter Spannung öffnen.
Ne pas ouvrir sous tension.
Non aprire con motore sotto tensione.
Typ
No. 2009 EN 12050
EN 12050
Q
3~
P2 kW
1/min
V
A
IP 68 S1 Ia/In kg
H m
M.-No.
Hz 40 °C
cos φ
SEQUEDIN
F - 59320
0081 II2G Ex d IIB
T 4 LCIE 03 ATEX 6428 X
Class F
a) b)
2
1
3
4
5
6
7
8
9
10
11
12
13
14
15
17
18
19
19
16
20
Fig. 2: Name plate a) for explosion-proof variant, B) for non-explosionproof variant
1 Designation 2 Material number
3 Flow rate 4 Motor type
5 Rated power 6 Rated speed
7 Rated voltage 8 Rated current
9 Enclosure 10 Mode of operation
11 Starting current ratio 12 Year of construction
13 Head 14 Maximum fluid and ambient temperature
15 Rated frequency 16 Power factor at design point
17 Thermal class of winding insulation 18 Total weight
19 Marking for explosion-proof pump sets 20 Motor number (only for variant YLG)
4 Description of the Pump (Set)
14 of 66 Amarex® N
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 16 of 76

4.4 Design details
Design
▪Fully floodable submersible motor pump
▪Not self-priming
▪Close-coupled unit
Impeller type
▪Various, application-based impeller types
Shaft seal
▪Two bi-directional mechanical seals in tandem arrangement, with liquid reservoir
Standard bearing assembly
▪Grease-packed bearings sealed for life
▪Maintenance-free
Reinforced bearing assembly (optional)
Pump-end bearing:
▪Grease-packed bearing sealed for life
The following hydraulic system/motor combinations can be equipped with a
reinforced bearing:
Table 7: Reinforced bearing
Hydraulic system
sizes
Motor size and number of poles
50-172 002, 012, 022
50-222 032, 042
Drive
▪Three-phase asynchronous squirrel-cage motor
Explosion-proof pump sets comply with type of protection Ex d IIB.
4.5 Types of installation
Two design variants are available, depending on the installation type:
▪Stationary wet installation (type of installation S)
▪Transportable wet installation (type of installation P)
The pump set is designed for continuous operation in submerged condition. The
motor is cooled by the fluid handled on the motor surface. Operation with the motor
outside the fluid handled is possible for short periods.
4 Description of the Pump (Set)
Amarex® N 15 of 66
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 17 of 76

4.6 Configuration and function
1
2
3
4
8
9
10
7
6
5
1 Shaft 2 Bearing bracket
3 Discharge cover 4 Suction cover
5 Suction nozzle 6 Discharge nozzle
7 Impeller 8 Shaft seal
9 Bearing, pump end 10 Bearing, motor end
The pump is designed with an axial fluid inlet and a radial outlet. The hydraulic
system sits on the extended motor shaft. The shaft runs in common bearings.
The fluid enters the pump axially via a suction nozzle (5) and is accelerated outward
in a cylindrical flow by the rotating impeller (7). The flow profile of the pump casing
converts the kinetic energy of the fluid into pressure energy. The fluid is pumped to
the discharge nozzle (6), where it leaves the pump. At the rear side of the impeller,
the shaft (1) enters the casing via the discharge cover (4). The shaft passage through
the cover is sealed towards the atmosphere with a shaft seal (8). The shaft runs in
rolling element bearings (9 and 10), which are supported by a bearing bracket (2)
linked with the pump casing and/or discharge cover.
The pump is sealed by two bi-rotational mechanical seals in tandem arrangement.
A lubricant reservoir in-between the seal elements ensures cooling and lubrication of
the mechanical seals.
4.7 Scope of supply
Depending on the model, the following items are included in the scope of supply:
Stationary wet installation (type of installation S)
▪Pump set complete with electric cables
▪Claw with sealing material and mounting elements
▪Lifting rope or chain
▪Mounting bracket with mounting elements
▪Duckfoot bend with mounting elements
▪Guiding equipment
(guide rails are not included in KSB's scope of supply)
Transportable wet installation (type of installation P)
▪Pump set complete with electric cables
Design
Function
Sealing
4 Description of the Pump (Set)
16 of 66 Amarex® N
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 18 of 76

▪Foot pad or pump stool with mounting elements
▪Lifting rope or chain
NOTE
A separate name plate is included in KSB's scope of supply.
This name plate must be attached in a clearly visible position outside the place of
installation, e.g. at the control panel, pipeline or mounting bracket.
4.8 Dimensions and weights
For dimensions and weights please refer to the general arrangement drawing/outline
drawing or data sheet of the pump set.
4 Description of the Pump (Set)
Amarex® N 17 of 66
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 19 of 76

5 Installation at Site
5.1 Safety regulations
DANGER
Improper installation in potentially explosive atmospheres
Explosion hazard!
Damage to the pump set!
▷Comply with the applicable local explosion protection regulations.
▷Observe the information given in the data sheet and on the name plate of the
pump set.
DANGER
Persons in the tank during pump operation
Electric shock!
▷Never start up the pump set when there are persons in the tank.
5.2 Checking the site before installation
5.2.1 Preparing the place of installation
Place of installation for stationary models
WARNING
Installation on foundations which are unsecured and cannot support the load
Personal injury and damage to property!
▷Make sure the foundation concrete is of sufficient strength (min. class 32.5 N to
EN 197-1 or equivalent).
▷Make sure the foundation has set firmly before placing the duckfoot bend on it.
▷Only place the duckfoot bend on horizontal and level surfaces.
▷Refer to the weights given in the data sheet/on the name plate.
Any resonances at the usual excitation frequencies (1 x and 2 x rotational frequency,
rotational noise) must be prevented both in the foundation and in the connected
piping, as such frequencies may cause extreme vibrations.
1. Check the structural requirements.
All structural work required must have been prepared in accordance with the
dimensions stated in the outline drawing/general arrangement drawing.
Place of installation for transportable models
WARNING
Placing the pump set on an unsecured and uneven mounting surface
Personal injury and damage to property!
▷Always place the pump set on a solid and level surface with the pump set in
vertical position and the motor on top.
▷Only place the pump set on a surface of sufficient load-carrying capacity.
▷Use appropriate means to secure the pump set against overturning or tipping
over.
▷Refer to the weights given in the data sheet/name plate.
Any resonances at the usual excitation frequencies (1 x and 2 x rotational frequency,
rotational noise) must be prevented both in the foundation and in the connected
piping, as such frequencies may cause extreme vibrations.
Resonances
Resonances
5 Installation at Site
18 of 66 Amarex® N
Goodnal STP ST041 Biological Treatment (KSB WAS PUMP 1 & 2 PU-0530-010 OM Instructions) Vendor Manual
Q-Pulse Id VM381
Active 29/10/2013
Page 20 of 76
