KUAREZ RD1000 User manual

Installation
How to install your LED grow light?
Note: Power off the light before installation
RD1000 Installation Steps
STEP 3
STEP 1
STEP 4
STEP 2
RD2000 and RD4000 Installation Steps
STEP 3
STEP 1
STEP 4
STEP 2
Step 1: Fix the lifting device(rope hanger) on suitable place.
Step 2: Fix the hanging kits/chains on back of the light.
Step 3: Connect the hanging kits/chains to the lifting device(rope hanger).
Step 4: Connect the power cord, and then power on the light.
Warranty Terms
Your KUAREZ LED grow light is offered 36 months warranty time and the light is warranted
against original defects in materials and workmanship for a period of 12 months from the date
of purchase.This warranty provides all labor and any replacement product or part necessary
to ensure your light is in proper operating condition during the warranty period. A dated proof
of purchase is required at the time of warranty service.The replacement of any part of your
product under warranty will not extend the period of the warranty. If there is any problem with
the item, please kindly send email to us: [email protected]
765
Important Safety InstructionsWireless Remote Controller Usage Instructions
1 2 3
4 5 ID
50% 60% 70%
80% 90% 100%
BRIGHTNESS
GROUPING
10%
30%
20%40%
ON OFF
Turn on Turn off
50% 60% 70%
80% 90% 100%
10%
30%
20%40%
Click OFF button to turn off the light for saving the current status
of brightness,and then turn on the light, the previous brightness
saved will be displayed by default.
Click corresponding button to set the certain brightness, 10
levels of brightness for your choice as photo.
All lights which were matched code to this remote
controller will be selected.
E.g: press button ALL then press button OFF, all the lights
matching code to this remote controller will be turned off.
1 2
4 5
3
ID
Group selecting buttons
1. Before grouping lights, the procedure of matching the code
needs to be completed firstly.
2. Unplug the lights, keep pressing the group selection button,
then plug the lights and 3-5s later the light will flash, release the
group selection button to finish grouping. This procedure of
grouping lights is suitable for lights under both status of ON and
status of OFF.
3. This function aims to control the lights in different area
separately, when you need to control the lights in same group,
press the group selecting button firstly. E.g: press button 2 and
set 30% intensity, then the intensity of all the lights grouping to
Group 2 will be 30%.
Matching the code for light
1. If the light is under the status of ON, unplug the light and long
pressing the ‘ID’ button to keep the controller’s indicator on, then
plug the light and release the ‘ID’ button after the light flashes, the
code-matching succeed.
2. If the light is under the status of OFF, we need to wait for 15s
firstly after unplug the light, then follow the next procedures of
matching the code as above.
1. The light has a power-off memory function, it saves the last status before power off, includes the OFF
status or any status of the brightness you chose. (When turn off the light, and unplug it, the light will
keep the OFF status, then plug it, you need to click ON button to turn on the light.)
2. The setting defaulted by factory of the light is 100% of brightness, when plug the light, it will display
100% of brightness at the first time.
3. The barrier-free and interference-free distance between the light and the remote controller should be
less than 25m, matching code for several lights simultaneously is available, then you can use one
remote controller to control several lights.
4. The light and the remote controller which are in one package has completed code-matching, if you
would like to use this remote controller to control other lights(KUAREZ brand and RD series lights),
firstly, you need to complete the code-matching between the controller and other lights.
Kindly Note:
1. CAUTION: Do not look directly at the LED grow light when the lighting equipment is working.
2. CAUTION: The minimum required distance between adjacent led grow light is 4 inches(10cm) and
between the led grow light and combustible materials is 40 inches(100cm) such as walls, ceiling,
movable, partitions. Providing this installation limitations are needed to prevent overheating of led grow
light or combustible materials within the installation environment.
3. The maximum temperature of the installed environment(ambient temperature) should ensure safe
operation of the led grow light. So you will need to control the temperature within the installed environ-
ment. (Example: a mechanical ventilation or cooling system is required to maintain the temperature
within the growing space below 104°F(or 40℃) when the led grow light is in operation).
4. Instructions to the installation of cords:
a. Do not conceal or extend cords through a wall, floor, ceiling, or other parts of the building structure,
b. Do not place cords above the suspended ceiling or dropped ceiling,
c. Do not permanently affixed cords to the building structure,
d. Are routed so that cords are not subject to strain and are protected from physical damage,
e. Make the cords are visible over their entire length during installation.
f. Cords should be used within their rated ampacity as determined for the maximum temperature of the
installed environment specified in the instructions.
5. The led grow light is for indoor use only, avoid exposing the lamp to water for too long time.
6. CAUTION: For horticulture lighting structures, installation shall be performed by qualified personnel,
and that the structures and intended for installation subject to approval by the authority having
jurisdiction.
7. Set up your light in the operating environment that with adequate air circulation. Never push objects
into the ventilation openings.
8. When using this light, there is no need for any extra ballast.
9. When cleaning the outside of your light and its components, you need to shut off your light firstly, then
unplug the power cord. Using a clean, soft, lint-free cloth to wipe the light. Avoid getting moisture or
damage on any openings.
10. CAUTION: Possibly hazardous optical radiation emitted from this product. Do not stare at operating
lamp. Maybe harmful to the eyes.
LED GROW LIGHT
USER MANUAL
E-mail:[email protected]
2.4G Wireless Remote Controller

2 3 4
RD1000 Brightness
40%
60%
100%
100%
RD1000 Specification
RD1000 Display RD2000 Display RD4000 Display
Welcome
Using Suggestions Using Suggestions
RD1000
Model No. 250W HPS/MH 500W HPS/MH 1000W HPS/MH
AC100-277V AC100-277V AC100-277V
318pcs SMD LEDs
-20-50ȭ
Working Temperature
Package Includes 1X RD1000 LED Lighting, 1XRemote Controller, 1X 6ft Power Cable, 1X Hanging Kit
1X Rope Hanger,
1X User Manual, 2 X 1.5V AAA Battery
3.5 lbs
11.8 x 10.6 x 2.3 inches
Actual Power Draw 100W±5%
LED Qty
Please read this user manual carefully so that you can understand the function and operation of this
product quickly.
CONTENTS:
1. RD1000 Product Information ----------------------------------------------------------------------------------------- 2
2. RD2000 Product Information ----------------------------------------------------------------------------------------- 3
3. RD4000 Product Information ----------------------------------------------------------------------------------------- 4
4.
Wireless Remote Controller Usage Instructions ----------------------------------------------------------------- 5
5.
Important Safety Instructions ------------------------------------------------------------------------------------------ 6
6.
Installation and Warranty Terms ------------------------------------------------------------------------------ 7
RD2000
RD2000 Specification
Using Suggestions
RD4000 Specification
RD2000
1X RD2000 LED Lighting, 1XRemote Controller, 1X 6ft Power Cable, 2X Hanging
Chain, 2X Rope Hanger, 1X User Manual, 2
X 1.5V AAA Battery
LED Qty
23.9 x 10.6 x 2.6 inches
8.4 lbs
-20-50ȭ Working Temperature
Package Includes
700pcs SMD LEDs
Actual Power Draw 200W±5%
RD4000
1X RD4000 LED Lighting, 1XRemote Controller, 1X 6ft Power Cable, 2X Hanging
Chain, 2X Rope Hanger, 1X User Manual, 2
X 1.5V AAA Battery
LED Qty
17.5 lbs
23.9 x 21.3 x 2.6 inches
-20-50ȭ
Package Includes
Working Temperature
1400pcs SMD LEDs
425W±5%
Actual Power Draw
RD4000
Power Cord Connector
LED Driver
Hanging Holder
Signal Receiving Box
Power Cord Connector
LED Driver
Hanging Holder
Signal Receiving Box
Power Cord Connector
LED Driver
Hanging Holder
Signal Receiving Box
Brightness
40%
60%
100%
100%
Brightness
40%
60%
100%
100%
Model No. Model No.
Friendly Reminder: Since different plants have different needs, there will be no perfect
answer to the exact hanging height and brightness. Please always keep an eye on your plants
reaction, and adjust the light to the suitable hanging height and brightness.
Friendly Reminder: Since different plants have different needs, there will be no perfect
answer to the exact hanging height and brightness. Please always keep an eye on your plants
reaction, and adjust the light to the suitable hanging height and brightness.
Friendly Reminder: Since different plants have different needs, there will be no perfect
answer to the exact hanging height and brightness. Please always keep an eye on your plants
reaction, and adjust the light to the suitable hanging height and brightness.
