KUBE SYSTEMS Audio Clock II User manual

Charging Station with
Bluetooth Audio and Alarm Clock
Kube Audio Clock II
User Guide
Please read these instructions completely
before operating this product.


_3 _
INTRODUCTION
Getting to Know Your Alarm Clock
HR (Hour) Button
Bluetooth PAIR Button
MIN (Minute Button)
SNOOZE/DIMMER
Alarm SET Button
Alarm ON/OFF Button
Apple® Lightning Connector
Clock Display
Micro USB Connector
FRONT/LEFT SIDE

_4 _
INTRODUCTION
Getting to Know Your Alarm Clock
iPad USB Jack
Qi Wireless
Charging Pad (Optional)
Ambient Sensor
iPod/iPhone USB Jack
USB-C Connector
DC IN Jack
Kensington Lock
Attachment Point
®
REAR/RIGHT SIDE

_5 _
INTRODUCTION
Getting to Know Your Alarm Clock
BOTTOM
TIME
SET
HOUR
MIN
DST
(SEL)
+1
DST
-1
DST –1 Button
DST +1 Button
MIN Button
HOUR Button
TIME SET Button
Speaker
Threaded Security Bolt Socket
Used to connect a security lanyard
or retractable cable.

_6 _
AC Connection
Auto-Dimming Display
Insert the 12VDC/4A plug
into the DC In jack on the rear
of the unit.
Plug AC adapter into 100-240v
(50-60hz) wall outlet. The clock
will display the time.
The ambient light sensor on the right side
of the unit will dim the clock display when
it detects the ambient light is low if the unit
is clear of obstructions.
Display brightness can also be adjusted
via the SNOOZE/DIMMER button.
There are 4 settings (100,75, 50, and
25%) for a lit room, and 4 settings for
a dark room (75, 50, 25%, and OFF).
OPERATION

_7 _
OPERATION
Setting the Time
To set the time, turn the unit
upside down. Press and release
the TIME SET button on the
bottom of the unit; the time will
flash in the display.
Within 3 seconds, press the
HOUR button to set the hour,
making sure to set the correct
AM/PM.
TIME
SET
HOUR
MIN
TIME
SET
HOUR
MIN
Within 3 seconds, press the MIN
button to set the minutes. When
done, wait a few seconds and
the clock will stop flashing.
Note: if the IR app has been used
to program the unit, the bottom buttons
will be disabled. To enable the bottom
buttons press and hold SET and MIN
together for 5 seconds. The display
will indicate Lb.on (Lower buttons ON).
DST
(SEL)
+1
DST
-1
DST
(SEL)
+1
DST
-1
TIME
SET
HOUR
MIN
DST
(SEL)
+1
DST
-1

_8 _
DST (Daylight Saving Time)
To change the time for Daylight Savings
Time, press the DST+ or DST- buttons
to adjust the time by 1 hour.
OPERATION
Manual Setting Mode
Hold SET + HR for 5 seconds
to enter setting mode. Press SET
to set year, month, date, 12/24 hr
mode, hour, min, DST zone and
1-day/7-day alarm mode.
Use HR & MIN as + and -.
A short press of the SNOOZE button
will return to normal time display.
TIME
SET
HOUR
MIN
DST
(SEL)
+1
DST
-1
TIME
SET
HOUR
MIN
DST
(SEL)
+1
DST
-1

_9 _
OPERATION
Setting the Alarm Time
Press the Alarm ON/OFF button. The current alarm time
will be displayed. To change the alarm time, press
the SET and HR buttons together to set the hours.
The Alarm icon will flash in the display.
Press the SET and MIN
button together to set the
minutes. When done, wait
a few seconds and the
Alarm icon will stop flashing.
To activate the alarm, press the
Alarm ON/OFF button once;
the unit will beep and the Alarm
icon will appear in the display.

Snooze
While the alarm is sounding,
press the SNOOZE button;
the alarm will turn back on
automatically 10 minutes later.
You can repeat the Snooze
function up to three times.
IMPORTANT ALARM NOTE:
By default (1-day alarm option), the alarm will only be activated for one day,
then the alarm icon will go off. To reset the alarm each day in this mode, press the
Alarm ON/OFF button again. The alarm will be reset and the icon will be displayed.
If the 7-day alarm option has been set (see ‘Manual Setting Mode’ on page 8),
the alarm will repeat daily until de-activated with Alarm ON/OFF button.
_10 _
Turning Off the Alarm
When the alarm is sounding,
press the Alarm ON/OFF button
to turn it off. It will NOT be set
for the next day. If desired, reset
alarm following the instructions
above.
OPERATION

_11
OPERATION
Pairing Via Bluetooth
Kube Audio Clock
ON
Bluetooth
Bluetooth
ON
Press and release the Bluetooth
button on the top of the unit;
the button will flash blue and
white.
Some Bluetooth devices will ask
you to accept the connection.
If the units are paired properly,
you will hear the word “connected”
and “BT” will appear on the display.
Start playback on the external
device. Adjust the volume using
the external device’s Volume
buttons.
On the Bluetooth device,
enable Bluetooth and select
Kube Audio Clock from the
Device List. It may take a
few seconds to appear.
BT

_12 _
Charging Via Qi Wireless Charging (Optional model)
Designed with inductive charging
capabilities, this unit allows you to
place your Qi compatible device on
top of the unit for wireless charging.
It’s that simple! Make sure your device
is Qi compatible or utilizes a Qi case
or other Qi charging option (both
available separately), then place the
unit on the Qi Wireless Charging logo
(orientation as per diagram).
CHARGING

_13 _
CHARGING
Charging Via Built-in Cables
Charge up to three devices using
the built-in Charging Cables.
Simply pull out the desired
connector and insert it into
your device.
Apple® Lightning Connector
Used for charging Apple devices
that feature a Lightning jack.
USB-C Connector:
Used for charging many of the latest
smartphones and accessories.
Micro USB Connector:
Used for charging devices that
utilize the Micro USB jack.
Many Android devices.
Apple®
Lightning Connector
USB-C Connector
Micro USB Connector
Apple®
Lightning Connector
Micro USB Connector

_14 _
Charging Via USB Ports
CHARGING CABLES:
The charging cables are replaceable if they become damaged.
Caution
: Charging cables do not stretch.
CHARGING
Charge up to two additional
devices using the two USB ports
on the rear of the unit.
Each outlet has its own intelligent
auto-configuring USB circuit
that allows any device to charge
properly.
These ports are labeled, “iPod/iPhone”
(1A) and “iPad” (2.4A) but can be used
to connect most USB cables in order to
accommodate different connections.
