KUBE SYSTEMS Kube Essentials User manual

Charging Station with
Alarm Clock
User Guide
Please read these instructions completely
before operating this product.
Version 1.1
Kube Essentials

— 1 —
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS .............................................................................2
INTRODUCTION..................................................................................................................4
Getting to Know Your Kube Essentials...............................................................................4
AC Connection ..................................................................................................................5
Dimmer..............................................................................................................................5
OPERATION ........................................................................................................................6
Setting the Time ............................................................................................................... 6
Setting the Alarm Time.......................................................................................................8
Turning Off the Alarm.........................................................................................................9
Snooze ..............................................................................................................................9
AC Outlet Reset.................................................................................................................9
Threaded Security Bolt Installation - Example 1 ...............................................................10
Threaded Security Bolt Installation - Example 2 ...............................................................11
CHARGING....................................................................................................................... 12
Charging Via Qi Wireless Charging (Optional) ...................................................................12
Charging Via Built-in Connectors .....................................................................................13
Charging Via USB Ports...................................................................................................13
SPECIFICATIONS............................................................................................................. 14
TROUBLESHOOTING...................................................................................................... 14
KUBE SYSTEMS PRODUCTS LIMITED WARRANTY.................................................... 15

— 2 —
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: To reduce the risk of electric shock do not remove cover (or
back). No user serviceable parts inside. Refer servicing to qualied service
personnel.
DANGEROUS VOLTAGE: The lightning ash with arrowhead, within an
equilateral triangle, is intended to alert the user to the presence of
uninsulated dangerous voltage within the product’s enclosure that may be
of sufcient magnitude to constitute a risk of electric shock topersons.
ATTENTION: The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
This Class B digital apparatus complies with European Union CE – EMC Directive (2004/108/
EC) and European Union CE – Low Voltage Directive (2006/95/EC). This Bluetooth module
is in compliance with the essential requirements and other relevant provisions of R&TTE
Directive (1999/5/EC). This product is marked with the CE logo and uses radio frequency
bands that are harmonized throughout the European Community.
PRODUCT SAFETY: When used in the directed manner, this unit has been designed and manufactured to ensure your
personal safety. Improper use of this product can result in potential electrical shock or fire hazards. Please read all safety and
operating instructions carefully before installation and use, and keep these instructions handy for future reference.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
FCC Compliance Statement: This device complies with Part 15 of the FCC rules. Operation is
subjected to the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may
cause undesired operation.
FCC WARNING
This equipment has been tested and found to comply with limits for a Class B digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in residential installations. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause interference to radio or television equipment reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving Antenna.
• Move the equipment away from the receiver.
• Plug the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/television technician for additional suggestions.
CAUTION: Any changes or modifications to this equipment not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
WARNING:
STRANGULATION HAZARD: Infants have STRANGLED in power cords. Keep power cords more than 3 feet away from
cribs, bassinets, play yards, and other safe sleep environments for infants.

— 3 —
— 2 —
IMPORTANT SERVICE SAFETY INSTRUCTIONS
Damages caused by non-compliance with this operating manual will void the warranty!
1. Read and Follow Instructions - All the safety and operating instructions should be read before
the product is operated. Follow all operating instructions.
2. Retain Instructions - The safety and operating instructions should be retained for future
reference.
3. Heed Warnings - Comply with all warnings on the product and in the operating instructions.
4. Power Sources - This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supplied to your
location, consult your video dealer or local power company. For products intended to operate
from battery power, or other sources, refer to the operating instructions.
5. Overloading - Do not overload wall outlets or extension cords as this can result in the risk of
re or electric shock. Overloaded AC outlets, extension cords, frayed power cords, damaged
or cracked wire insulation, and broken plugs are dangerous. They may result in a shock or re
hazard. Periodically examine the cord, and if its appearance indicates damage or deteriorated
insulation, have it replaced by your service technician.
6. Power-Cord Protection - Power supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them. Pay particular attention to cords
at plugs, convenience receptacles, and the point where they exit from the product.
7. Surge Protectors - It is highly recommended that the video equipment be connected to a
surge protector. Doing so will protect the equipment from damage caused by power surges.
Surge protectors should bear the UL listing mark or CSA certication mark.
8. Uninterruptible Power Supplies (UPS) - It is recommended that you connect the product to an
uninterruptible power supply. An uninterruptible power supply has an internal battery that will
keep the product running in the event of a power outage. Uninterruptible power supplies should
bear the UL listing mark or CSA certication mark.
CAUTION: Maintain electrical safety. Power line operated equipment or accessories connected to
this product should bear the UL listing mark or CSA certication mark on the accessory itself and
should not be modied so as to defeat the safety features. This will help avoid any potential hazard
from electrical shock or re. If in doubt, contact qualied service personnel.
9. Ventilation - Slots and openings in the case are provided for ventilation to ensure reliable
operation of the product and to protect it from overheating. These openings must not be
blocked or covered. The openings should never be blocked by placing the video equipment
on a bed, sofa, rug, or other similar surface. This product should never be placed near or over
a radiator or heat register. This product should not be placed in a built-in installation such
as a bookcase or rack unless proper ventilation is provided and the product manufacturer’s
instructions have been followed.
10. Attachments - Do not use attachments unless recommended by the product manufacturer as
they may cause a hazard.
11. Water and Moisture - Do not use receivers or video monitors near water — for example, near
a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, near a swimming pool
and the like.
12. Heat - The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products (including ampliers) that produce heat.
13. Accessories - Do not place this video equipment on an unstable cart, stand, tripod, or table.
The video equipment may fall, causing serious damage to the product. Use this product only
with a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the
product. Any mounting of the product should follow the manufacturer’s instructions and use a
mounting accessory recommended by the manufacturer.
IMPORTANT SAFETY INSTRUCTIONS

— 4 —
INTRODUCTION
Getting to Know Your Kube Essentials
iPod/iPhone USB Charge Port
Clock Display
Lightning Charge Cable
Micro USB Charge Cable
AC Outlet Reset
Power Cord Socket
Threaded Security Bolt
Socket (Bottom of Unit)
Qi Charging Pad Socket
(Bottom of Unit)
ALARM SET/OFF Button
SNOOZE/DIMMER Button
Set – Button
AC Outlet (100-240VAC/5A)
iPad USB Charge Port
Set + Button
FRONT/LEFT SIDE
REAR/BOTTOM

— 5 —
— 4 —
INTRODUCTION
AC Connection
u
Connect the AC Power plug to the AC
jack on the rear of the unit, then plug
into properly installed and grounded
three prong outlet. See safety
precautions in the next column.
BATTERY BACKUP: This unit comes
with a battery backup that will save
the time and alarm time if unplugged
or power goes out.
Dimmer
u
Press the SNOOZE/DIMMER button to
set the brightness of the display to one
of the four levels.
Grounding Instructions
THIS APPLIANCE MUST BE
GROUNDED.
In the event of an electrical short circuit,
grounding reduces the risk of electric
shock by providing an escape wire for
the electric current. This unit is equipped
with a cord having a grounding wire with
a grounding plug. The plug must be
plugged into an outlet that is properly
installed and grounded.
• Plug into properly installed and
grounded three-prong outlet.
• DO NOT remove ground prong.
• DO NOT use an adapter.
Power Supply
• Extension cords can be used only if:
(1) the marked electrical rating of the
extension cord is at least as great as
the electrical rating of the unit,
(2) the extension cord must be a
grounding-type three-wire cord, and
(3) the longer cord should be
arranged so that it will not drape over
the countertop or tabletop.
3-Pronged Plug
Ground Plug
3-Prong Receptacle

— 6 —
OPERATION
Setting the Time
u
To set the time, simultaneously
press and hold the ALARM SET/OFF
and SNOOZE/DIMMER buttons for
approximately 6 seconds; “SEt” will
blink in the display.
w
Within 2 seconds, press the Set + and
– buttons to set the month. Press the
ALARM SET/OFF button and the day
will blink.
x
Within 2 seconds, press the Set +
and – buttons to set the day. Press the
ALARM SET/OFF button and the hour
will blink.
v
Within 2 seconds, press the Set +
and – buttons to set the year. Press
the ALARM SET/OFF button and the
month will blink.

— 7 —
— 6 —
OPERATION
Setting the Time (Continued)
y
Within 2 seconds, press the Set + and
– buttons to set the hour. Make sure
the correct AM/PM setting is also set.
Press the ALARM SET/OFF button and
the minute will blink.
V
Within 2 seconds, press the Set + and
– buttons to set your region’s Daylight
Savings Time (DST) zone. Press the
ALARM SET/OFF button and the
snooze repeat setting will blink.
W
Within 2 seconds, press the Set + and
– buttons to set the desired Snooze
setting. This setting will control how
many times the Snooze function can
be repeated. When done do not press
any button for 2 seconds and the clock
will be set.
U
Within 2 seconds, press the Set + and
– buttons to set the minutes. Press
the ALARM SET/OFF button and the
country will blink.

— 8 —
OPERATION
Setting the Alarm Time
u
Press the ALARM SET/OFF button; the
alarm time will blink.
w
Press the ALARM SET/OFF button and
the alarm will be set and activated to
turn on when the time reaches the set
alarm time.
v
Within 2 seconds, press the Set + and
– buttons to set the alarm time making
sure to set the correct AM/PM.

— 9 —
— 8 —
OPERATION
u
When the alarm is sounding, press the
ALARM SET/OFF button to turn it off.
It will NOT be set for the next day and
OFF will appear in the display.
v
To set it to turn on the following day,
press the ALARM SET/OFF button
again and the ALARM TIME will blink
for a couple seconds and then be
activated for the next day.
u
While the alarm is sounding, press
the SNOOZE/DIMMER button; the
alarm will turn back on automatically
10 minutes later. You can repeat the
Snooze function up to three times
depending on the Snooze Function
setting (see page 7).
u
This unit comes equipped with an
external outlet so you can plug in
another device (up to 5A). If the
display shows “ERR”, the AC outlet
on the top of the unit has been over-
loaded. Press the AC Outlet Reset
button to reset the outlet.
Turning Off the Alarm
Snooze AC Outlet Reset
IMPORTANT ALARM NOTE:
• The Alarm will only go off once (single day alarm) and will not repeat daily.

— 10 —
OPERATION
If desired, tether to a wall or piece of furniture by attaching a security cable to the Threaded
Security Bolt Socket on the bottom of the unit. Note that there are many types of installations,
the next two pages just show a couple of examples. Refer to the owner’s manual that came
with the Security Cable Kit.
u
TO ATTACH USING STANDARD
TETHER:
Bolt the eyelet of the cable into the
bottom of the unit using a TORX
Screwdriver.
v
Secure using the hardware included with
the Kit (not included).
Threaded Security Bolt Installation - Example 1
NOTE: Security cable/bolt/hardware not included.

— 11 —
— 10 —
OPERATION
u
TO ATTACH USING RETRACTOR
WITH EYELET:
Bolt the eyelet side of the cable into
the bottom of the unit using a TORX
Screwdriver.
v
Secure using the hardware included with
the Kit (not included).
Threaded Security Bolt Installation - Example 2
NOTE: Security cable/bolt/hardware not included.

— 12 —
CHARGING
Charging Via Qi Wireless Charging (Optional)
v
Remove Qi Wireless Charging Pad
along with two hex screws and one hex
key. Align the Qi pad’s plug and the
Qi Charging pad socket and insert the
Kube Essentials unit on top of the pad.
Secure using the supplied hex screws and hex key.
w
To charge, simply place the Qi
compatible device on the Qi Wireless
Charging Pad.
u
Designed with inductive charging capabilities, the Qi Wireless Charging Pad (Optional),
for Kube Essentials, is a wireless charger for Qi-certified devices. Simply place your
compatible device on top of the Qi Charging Pad and it will automatically charge your
device without the hassle of plugs and cables. Follow the instructions below to learn
how to use your Qi Wireless Charging Pad for Kube Essentials. Make sure your device is
Qi compatible or utilizes a Qi case or other Qi charging option (both available separately),
then place the unit on top of the Qi Wireless Charging Pad.

— 13 —
— 12 —
CHARGING
Charging Via USB Ports
u
Charge up to two additional devices
using the two USB ports on the top
of the unit. The iPad port outputs 2.1
Amps and the iPod/iPhone port outputs
1 Amp. Each port has its own intelligent
auto-configuring USB circuit that allows
any device to charge properly.
These ports are labeled, “iPod/ iPhone” and “iPad” but can be used to
connect most USB cables in order to
accommodate different connections.
Charging Via Built-in Connectors
u
Charge up to two devices using the
built-in Charging Cables. Simply pull out
the desired connector and insert it into
your device.
Apple® Lightning Connector (2.1 Amp): Used for charging newer Apple
devices with the Lightning jack.
Micro USB Connector (1.5 Amp): Used for charging devices that utilize the
Micro USB jack.

— 14 —
SPECIFICATIONS
TROUBLESHOOTING
If you have any trouble with your system, try these simple steps which should handle most
common issues.
SYMPTOM: Cannot set time.
SOLUTION(s): Make sure press and hold BOTH the ALARM SET/OFF and SNOOZE DIMMER
buttons for 6 seconds. See Setting the Time section.
SYMPTOM: The Alarm worked fine this morning but did not activate the next day.
SOLUTION(s): The alarm of Clock is a one-day alarm. This means a user will always have to
turn on the alarm again after it has been activated
SYMPTOM: The Clock display does not show the time but instead displays “ERR”.
SOLUTION(s): The AC Outlet on the top of the unit has been over-loaded. Press the AC
Outlet Reset button on the rear of the unit to reset the outlet.
AC Input........................................................................................................... 100 - 240 VAC
AC Output ............................................................................................100 - 240VAC; max 5A
USB-A Output 1 ....................................................................................................... 5V ~ 2.1A
USB-A Output 2 .......................................................................................................... 5V ~ 1A
microUSB Cable Output ........................................................................................... 5V ~ 1.5A
Lightning Cable Output............................................................................................. 5V ~ 2.1A
Wireless Charge Pad Output .............................................................................................. 5W
Specications

— 15 —
— 14 —
KUBE SYSTEMS PRODUCTS LIMITED WARRANTY
KUBE SYSTEMS, INC.
KUBE SYSTEMS PRODUCTS LIMITED WARRANTY
WHAT IS COVERED AND FOR HOW LONG
If your product does not work properly because of a defect in materials or workmanship, Kube
Systems, Inc. (“Kube Systems”) products will, for the length of the period indicated on the
chart below, which starts with the date of original purchase (the “Limited Warranty Period”),
at its option either (a) repair your product with new or refurbished parts, or (b) replace it with
a new or refurbished product. When a product or part is exchanged, any replacement item
becomes your property and the replaced item becomes the property of Kube Systems. The
decision to repair or replace will be made by Kube Systems.
During the “Parts” Limited Warranty Period, there will be no charge for parts. During the
“Labor” Limited Warranty Period there will be no charge for labor. If necessary repairs are not
covered by this Limited Warranty, or if a product is examined which is not in need of repair, you
will be charged for the repairs or examination. You must carry-in or mail-in your product during
the Limited Warranty Period. This Limited Warranty only applies to new products which were
not sold “as-is,” purchased and serviced either directly from Kube Systems or an authorized
distributor or dealer who was authorized by Kube Systems to sell such products at the time of
the original purchase.
WHO IS COVERED
This Limited Warranty is extended only to the original purchaser of a Kube Systems product,
and shall not be extended to any other person or transferee.
CARRY-IN OR MAIL-IN SERVICE
If your Kube Systems product ever needs service, please return the product to your distributor or
dealer. Otherwise, for carry-in or mail-in service please email us at [email protected].
You must pay any shipping charges if it is necessary to ship the product for service. Please
note that shipping charges vary and may be higher for destinations outside of the United
States. However, if the necessary repairs are covered under this Limited Warranty, we will pay
the reasonable return shipping charges to any destination. Please be sure to save the original
shipping carton(s), because a charge will be made for additional cartons. A purchase receipt
is required for Limited Warranty service. Please attach a copy of your purchase receipt to this
statement of Limited Warranty and put it in a safe place.
PRODUCT OR PART
NAME
KUBE ESSENTIALS
KUBE ESSENTIALS
WIRELESS CHARGING PAD
KS Clock
ROOM PROGRAMMER
KS Portable
KS Portable CHARGING
TRAY
PARTS LIMITED
WARRANTY PERIOD
ONE (1) YEAR
ONE (1) YEAR
ONE (1) YEAR
ONE (1) YEAR
ONE (1) YEAR
ONE (1) YEAR
LABOR LIMITED
WARRANTY PERIOD
ONE (1) YEAR
ONE (1) YEAR
ONE (1) YEAR
ONE (1) YEAR
ONE (1) YEAR
ONE (1) YEAR

— 16 —
KUBE SYSTEMS PRODUCTS LIMITED WARRANTY
WHAT IS NOT COVERED
This Limited Warranty covers defects in material and workmanship with the following specified
exceptions: (a) damage resulting from (i) improper or unreasonable use, maintenance or
neglect, (ii) failure to follow operating instructions, (iii) accident, (iv) excess moisture, (v) insects,
(vi) lightning, (vii) power surges, (viii) connections to improper voltage supply, (ix) unauthorized
alteration or modification of original condition, (x) inadequate packing or shipping procedures,
(xi) use with non-Kube Systems products, (xii) modification or adaptation to enable a Kube
Systems product to operate in any particular country, (xiii) service performed by anyone who
is not an authorized representative of Kube Systems, (xiv) fire, flood, earthquake or other
external causes, or (xv) acts of God or force majeure; (b) loss of, damage to or corruption of
stored data; (c) repair of products damaged by any modification or adaptation to enable a
Kube Systems product to operate in any particular country; (d) damage to, or deterioration
of, any accessory or decorative surface; (e) any Kube Systems product on which the serial
number has been effaced, modified or removed; or (f) Kube Systems products purchased from
unauthorized distributors or dealers. This Limited Warranty covers only actual defects within
the product itself, and does not cover the cost of installation or removal from a fixed installation,
normal setup or adjustments, claims based on misrepresentation by the seller or performance
variations resulting from installation-related circumstances.
LIMITATION ON IMPLIED WARRANTIES
KUBE SYSTEMS SHALL NOT BE ANY KUBE SYSTEMS PRODUCT, OR ARISING OUT
OF ANY BREACH OF THIS LIMITED LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF WARRANTY. TO THE EXTENT PERMITTED BY
APPLICABLE LAW, KUBE SYSTEMS DISCLAIMS ANY AND ALL STATUTORY OR IMPLIED
WARRANTIES, WRITTEN OR ORAL, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, NON-INFRINGEMENT
AND WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS. IF KUBE SYSTEMS CANNOT
LAWFULLY DISCLAIM STATUTORY OR IMPLIED WARRANTIES, THEN TO THE EXTENT
PERMITTED BY LAW, ALL SUCH WARRANTIES SHALL BE LIMITED IN DURATION TO THE
DURATION OF THIS LIMITED WARRANTY. THE MAXIMUM LIABILITY OF KUBE SYSTEMS
SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID BY YOU FOR THE PRODUCT.
OTHER LEGAL RIGHTS
This Limited Warranty gives you specific legal rights, and you also may have other rights that
vary from place to place. Some places do not allow limitations on implied warranties or the
exclusion or limitation of incidental or consequential damages, so the above limitations or
exclusions may not apply to you.
PARTS AND SERVICE WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY ARE
YOUR RESPONSIBILITY.
INFORMATION
If you have questions regarding the installation or operation of this product, please e-mail us at
[email protected].
http://www.kubesystems.com

— 16 —
http://www.kubesystems.com
