kube Kubebooth Kwe User manual

Kubebooth Kwe
ASSEMBLY GUIDE

PACKAGE 01
Configuration
Kme
Kwe_GU_P01
-
IN THE BOX Stage Page
FS201 x16 - Self tapping screw
for units corners assembly
FS202 x48 - Self tapping screw
for flat frame assembly
FS203 x28 - Stand-off cap M10
for glass assembly
FS205 x4 - Black M6 screw
for flat frame (door side) assembly
FS206 x2 - Door magnets set
Door hinges x2
Door handle set x1
Stand-off cap key

PACKAGE 02
Configuration
Kwe
Kwe_GU_P02
-
WALL UNIT (prefabricated) Stage Page
Outside View Inside View
1. Holes for unit corners
assembly
2. Holes for metal frame
and glass/door assembly
3. Cutouts for wiring
4. Airflow grill
3
6
"
8
8
"
4
"
1
2
3
4
1
3

PACKAGE 03
Configuration
Kwe
Kwe_GU_P03
-
CONSOLE UNIT w/Power & Data (prefabricated) Stage Page
Unit View Removed panel View
1. Holes for assembly
2. Cutouts for wiring
3. Power/Data outlet
Top w/Brackets to be
installed upon assembling
completion
2
4
"
3
"
8
0
"
1
2
3

PACKAGE 04
Configuration
Kwe
Kwe_GU_P04
-
BASE UNIT (prefabricated) Stage Page
As delivered
Floor access
panel removed
1. Holes for unit corners
assembly
2. Holes for metal frame
and glass/door assembly
3. Cutouts for wiring
4. Casters w/Leveler
5. Leveler bolt
6. Cutouts for seismic bracket
7. Floor access panel
1
2
7
4
5
6
8
0
"
3
6
"
3

PACKAGE 05
Configuration
Kwe
Kwe_GU_P05
-
CEILING UNIT (prefabricated) Stage Page
As delivered
Roof access
panel removed
1. Holes for unit corners
assembly
2. Holes for metal frame
and glass/door assembly
3. Cutouts for wiring
4. Cutouts for fans
5. Knock out hole for
sprinkler (optional)
6. Roof access panel
7. Power control system inc.
(power box w/outlets,
LED driver, 2 LED lights,
motion sensor, splitter box,
2 air fans)
3
5
1
4
2
5
7
8
0
"
6
3
6
"

PACKAGE 06
Configuration
Kwe
Kwe_GU_P06
-
FLAT METAL FRAMES Stage Page
ST221
ST225
ST221 - Frame metal part (2 on front, 2 on back)
with self taping screws (FS201 x 8) per piece.
This part has 5 holes for glass assembly.
ST225 - Frame metal part on the rear of the
unit with Self tapping screws (FS201 x 6).
This part has 2 holes for glass assembly.
ST226 - Frame metal part on the front of the
unit with self-tapping screws (F201 x 4) for
glass assembly and 2 for M6 Screws (F205)
All parts have plastic gaskets on the edges
ST221
ST221
ST221
ST226
ST225
ST226
ST222
ST222
ST222
ST222

PACKAGE 07
Configuration
Kwe
Kwe_GU_P07
-
GLASS PANELS Stage Page
GL211 - Sidelight glass panel
has 7 holes for assembly by
M10 countersunk screw FS203
with plastic socket cap FS204
two pairs of holes for door hinges
assembly
GL212 - Sidelight glass panel
has 7 holes for assembly by
M10 countersunk screw FS203
with plastic socket cap FS204
GL213 - Door glass panel has
two pairs of holes for door hinges
assembly
pair of holes for handle
pair of holes for magnets
GL214 - Back glass panel x2
has 7 holes for assembly by
M10 countersunk screw FS203
with plastic socket cap FS204
GL211
GL212
GL213
GL214
x2

ASSEMBLY 08
Configuration
Kwe
Kwe_GU_P08
1
UNITS ASSEMBLY (on floor) Stage Page
FS201 screws x4
for each corner
Ensure a minimum of 48" area
is left clear behind the unit
to allow the unit to be stood up
Floor access panel removed

ASSEMBLY 09
Configuration
Kwe
Kwe_GU_P09
2
UNITS ASSEMBLY (on floor) Stage Page
Roof access
panel removed
Floor access
panel removed
FS201 screws x4
for each corner

ASSEMBLY 10
Configuration
Kwe
Kwe_GU_P10
3
BACK METAL FRAME ASSEMBLY Stage Page
Self tapping screws
FS202 x20
Self tapping screws
FS202 x20
ST225
ST225
Self tapping screws
FS202 x20
Self tapping screws
FS202 x20
Self tapping screws
FS202 x20

ASSEMBLY 11
Configuration
Kwe
Kwe_GU_P11
4
BACK GLASS PANEL ASSEMBLY Stage Page
GL214
Screws FS203 x14 with
Plastic sleeves
GL214
Insert Acrylic seal between glass. Be sure to remove
plastic to expose glazing tape, this ensures a good bond.
Screws FS203 x14 with
Plastic sleeves

ASSEMBLY 12
Configuration
Kwe
Kwe_GU_P12
5
POD ASSEMBLY (raised vertically) Stage Page
Ensure levelers have been retracted
so that wheels are exposed.
This will allow the unit to be rolled
into its final installation location.
Then level the unit.
3
6
"
8
8
"
8
8
"

ASSEMBLY 13
Configuration
Kwe
Kwe_GU_P13
6
FRONT METAL FRAME ASSEMBLY Stage Page
M6 screws FS205 x4
Self tapping screws
FS202 x24
Self tapping screws
FS202 x24
Self tapping screws
FS202 x24
M6 screws FS205 x4
Self tapping screws
FS202 x24
ST226
ST226
M6 screws FS205 x4

ASSEMBLY 14
Configuration
Kwe
Kwe_GU_P14
7
CONSOLE UNIT ASSEMBLY Stage Page
Draw main cable
thrue the hole
Draw both cables
thrue the hole
Remove front panel (with electrical)
of console unit. Bring inside to the
glass and aligne with floor panel edges.
Screw to the floor/ceiling panels.
Console unit skin panel removed

ASSEMBLY 15
Configuration
Kwe
Kwe_GU_P15
8
FRONT GLASS PANEL & DOOR ASSEMBLY Stage Page
Magnets x2
Hinges x2
Screws FS203 x14 with
Plastic sleeves
GL213
Screws FS203 x14 with
Plastic sleeves
Screws FS203 x14 with
Plastic sleeves
Door handle
GL211
GL212
Screws FS203 x14 with
Plastic sleeves

ASSEMBLY 16
Configuration
Kwe
Kwe_GU_P16
9
CABIN ASSEMBLY (completion) Stage Page
Cross connect fan wire
and install roof
Install floor
Install top

ASSEMBLY 17
Configuration
Kwe
Kwe_GU_P17
10
ELECTRICAL JUNCTIONS Stage Page
Connect fan YELLOW labeled
wires to the splitter
Connect wall electrical outlet
cable to the RED labeled outlet
Connect the main cable
to the BLUE labeled outlet
Draw both cables from
Console Unit
