Kurgo AUTO ZIP LINE User manual

1. Hook the two s-hooks (B) onto the rear passenger seatbelt tabs (A1/A2) (See gure 1).
The end of the zip line with the cam buckle (E) should be on the driver’s side.
2. With your left hand, lock the rear driver’s side seatbelt in place by swiftly pulling
down on the seatbelt strap.
3. With right hand, grab extra zip line webbing (D) and apply constant pressure to the
extra webbing to ensure that the seatbelt stays in the locked position. (see gure 2)
4. With left hand, reach over and lock the passenger seatbelt in position using the
same swift pulling motion.
5. With the 2 seatbelts in the locked position pull on the extra zip line webbing in
your right hand to remove all slack from the zip line. (See gure 3)
6. Roll up extra webbing (D) towards cam buckle (E) and secure using bungees &
toggle system. (See gures 4 & 5).
7. Tug on each seatbelt before attaching the dog to ensure they are in the correct
locked position. (This should be done before each trip)
8. Place Carbineer (F) onto zip-line (C).
9. Attach leash clip to harness D-ring (H).
10. Locate appropriate leash nook (J) that permits Fido to sit up and lay down and
loop onto the carbineer (F).
AUTO ZIP LINE - SEATBELT INSTALLATION INSTRUCTIONS
Kurgo products •2D Fanaras Drive, Salisbury, MA 01952 •tel: [phone] •kurgo.com •[email protected]
KEY
Seatbelt tab (rear drivers)
Seatbelt tab (rear passengers)
S-hook
Nylon zip-line
Extra zip-line webbing
Cam buckle
Carabineer
Wander leash/tether
Harness D-ring
Bungee & toggle
Leash nook
More setup
options on
reverse side
Maintain tension on
seatbelt in locked position
while adjusting the other
seatbelt connection
Located on back
of harness
Passenger side
seatbelt tab
WARNING
• Only secure the Auto Zip Line to OEM car manufactured and
installed parts on your vehicel
• Never travel with a passenger in the rear of the car when the
Auto Zip Line is installed
• Pets should not be left unattended in vehicle at any time
• Ensure proper installation of the Zip Line before each trip

See the complete Dog Travel line at kurgo.com
AUTO ZIP LINE - ALTERNATE INSTALLATION OPTIONS
Kurgo products •2D Fanaras Drive, Salisbury, MA 01952 •tel: [phone] •kurgo.com •[email protected]
D-ring Leash
Upper Straps
Padded
Chest
Plate
Lower Straps
Side Release
Buckles
safety/walking harness parts
Passenger handle installation (fig.1)
1. Place the two s-hooks onto the rear passenger handles.
2. Tighten the zip line by pulling the extra webbing through the cam buckle.
3. Roll up extra webbing toward cam buckle and secure
using bungee & toggle setup.
4. Place carabineer onto zip line.
5. Attach leash clip to harness D-ring.
6. Locate appropriate leash nook that permits Fido to sit up and lay down and
loop onto the carbineer.
Seatbelt installation (fig.2)
1. Buckle seatbelt and attach the carabineer.
2. Locate appropriate leash nook that permits Fido to sit up and lay down and
loop onto the carbineer.
3. Attach leash to D-ring on harness.
Cargo hook installation (fig.3)
1. Attach carabineer to cargo hook.
2. Locate appropriate leash nook that permits Fido to sit up and lay down and
loop onto the carbineer.
3. Attach leash to D-ring on harness.
Safety/walking harness instructions (fig.4)
1. Place upper strap (with steel D-ring) around pets neck.
2. Place 2 lower straps around pet’s chest and behind front legs.
3. Fasten side release buckles on both sides.
4. Adjust upper and lower straps to t comfortably and securely.
fig.1
fig.2
fig.3
fig.4
8/08
WASHING INSTRUCTIONS:
• Brush off loose dirt with a dry brush
• As needed, wipe off with a damp
sponge and mild soap
• Rinse only, if possible. Use cold water and
a sponge or rinse in a tub without soap
• Machine wash in front-loading unit
(DO NOT use machine with agitator),
with cold water and mild soap etc.
Not detergents
• Rinse thoroughly to eliminate soap residue
• Lay flat to dry
