KVM-TEC 4K Ultraline DP 1.2 UVX Operator's manual

kvm-tec
First Aid
UVX
Video error
(stripes in the
picture)
USB is not
working
No Power
(No LED)
Check the
powerplug
Is the power
supply ok? Try
another Unit.
Try reprogramming
the Unit by using a
JTAG programmer
Contact kvm-tec
support
Are the USB
Devices plugged
in correctly?
Is the USB cable
on the Local side
plugged into the
PC?
Are the USB
Devices working
directly on the
PC?
Check if local
and remote Unit
have the same
fi rmware
Replace the USB
cable from PC to
the Local
Extender
Check if the local
or the remote
Unit is causing
the problem by
swaping fi rst the
local and than the
remote Unit to
another Unit
Contact kvm-tec
support
Check if all
cables are plug-
ged in correctly
Check if the PC is
sending a Image by
plugging in a
monitor on the
local out of the
local Unit
Check if the DDC is
set correctly (in menu
under point „O“)
Check if both
Units have the
correct fi rmware
No Video
Contact kvm-tec
support
Check if all
cables are plug-
ged in correctly
Check if the PC is
sending a Image
by plugging in a
monitor on the
local out of the
local Unit
Check if local and re-
mote Unit have the
correct fi rmware
Check if the DDC
is set correctly (in
the menu under
point „o“)
Check if the
network switch
is setup correctly
and has enough
bandwidth
Contact kvm-tec
support
Check if other units
have the same
behaviour
We are here for you to answer
your questions about installation?
Manual download www.kvm-tec.com
or
kvm-tec Installationchannel on our homepage
personally [phone]
kvm-tec Support [email protected] Phone: [phone] - 30
Check out
our Installation Channel:
www.kvm-tec.com
our Installation Channel:
line
ultra
kvm-tec
Quick
Instruction
4K Ultraline DP 1.2
UVX
6901 SET COPPER
6901L CPU/LOCAL
6901R CON/REMOTE
www.kvm-tec.com
connect collaborate communicate control
kvm-tec = C 4

USB frrom keyboard and mouse
Networkcable CAT 6a/7 up to 100m/328ft
RS232
UVX1 CPU
dp in
aux dp out 1 dp out 2
audio
4k displayport 1.2 kvm-extender power/status
100-240V AC
50-60Hz 24VA
red. Power
12V 2A
usb 2.0
power plug
12V > 2A
Earth
connection
power plug
100-240 VAC
DP in from PC
USB to PC
Audio to PC
Audio to PC
DP out
to Monitor
DP out to Monitor
RS232
UVX1 CON
auxusb 2.0 dp out 2
audio
4k displayport 1.2 kvm-extender power/status
100-240V AC
50-60Hz 24VA
red. Power
12V 2A
Audio from microphone
Audio to speaker
power plug
100-240 VAC
DP to Monitor
DP to Monitor
power plug
12V >2A
Quick Installation ULTRALINE 4K
local / CPU – remote / CON
1. Connect the CON / Remote and the CPU / Local Unit with the supplied IEC power cable. Optionally, you can also use a 12V >2A
power supply.
2. Now connect the USB cable to a USB port on your PC and connect the other end to the CPU / Local Unit. Connect keyboard and
mouse to the CON / Remote Unit.
3. Connect the CPU / Local and the CON / Remote Unit with a network cable.
4. Connect the DP cable in the DP socket of the PC -in and to the DP socket DP / in of the local device and connect the screen on the
remote side with the DP cable. Optionally, connect the DP cable from the Local DP / out to another monitor.
5. Then connect PC audio/out with the audio cable to Local audio/in. Connect audio/out via the audio cable
6. Almost done! Now connect the audio cable Local audio/out to the PC audio/in and Remote audio/in with the audio cable to the micro-
phone.
HAVE FUN - your kvm-tec Extender is now in use for many years (MTBF approx 10 years)
Please note that the recommended length of the display port cable should be max. 1.8m,5.9 ft otherwise interference-free
4K transmission may not be guaranteed.
VIDEOADAPTER
Please use a video adapter with 60 Hz (for video adapters with 30 Hz
the screen will turn black and it would be a pity if you couldn‘t see the great 4K image.)
OUR RECOMMENDATION
Club 3D - Type CAC - 1070
FIBERCABLE
Please also use an OM3 cable to have enough bandwidth
