Kyocera FS-6025MFP User manual




SAVINGS RELIABILITY ENVIRONMENT
®
These new multifunctional devices offer all the benefits of a professional
document management solution for workgroups and small offices.
Featuring advanced functionality, easy to operate touchscreen, and
a range of paper-handling options, all in a well-designed compact
package. Cost-efficient and eco-friendly offices will appreciate KYOCERA’s
unique ECOSYS™ technology which increases operating life, reduces
environmental impact, cuts printing costs and ensures reliability.
Up to 30 A4 pages per minute
Time to first copy: 9.2 seconds or less
Professional print, copy, scan and fax functionality
Paper capacity up to 1,600 sheets and a range of paper-handling
options
Easy to install and operate
Easy to use wizard-style navigation
Low noise emissions match desktop printers
Compact, 360° all-round stylish design to match any office
ECOSYS™ Long-life components provide unprecedented efficiency
and reliability
Exceptionally low printing costs in its class



General
Technology: KYOCERA ECOSYS, Mono Laser
Engine speed:
FS-6025MFP - Up to 25 pages A4 per minute
FS-6030MFP - Up to 30 pages A4 per minute
Resolution: 600 x 600 dpi (print, copy and scan)
PM cycle: 300,000 pages
Warm-up time: Approx. 20 seconds or less
Time to first print: Approx. 8 seconds or less
Time to first copy: Approx. 9.2 seconds or less
CPU: PowerPC 464 / 800 MHz
Memory: Standard 512 MB, max. 1,536 MB
Integrated accounting: 20 department codes
Dimensions (W x D x H): 590 x 590 x 694 mm
Weight: Approx. 52.2 kg including toner container
Power source: AC 220 ~ 240 V, 50/60 Hz
Safety standards: AS / NZ53260 / C-TICK
This unit is manufactured according to ISO 9001 quality
standard and ISO 14001 environmental standard.
Paper Handling
All paper capacities quoted are based on a paper thickness
of max. 0.11 mm (80gsm). Please use paper recommended
by KYOCERA under normal environmental conditions.
Input capacity: 100-sheet multi-purpose tray, 45–256
gsm, 200 mm (Postcard); 52–163 gsm (larger than A4
/ Letter size), A3, A4, A5, A6, B5, Letter, Legal, Folio,
envelopes, Custom (98 x 148 to 297 x 432 mm) 500-sheet
universal paper cassette, 60–163 gsm, A3, A4, A5, A6,
B5, Letter, Legal, Folio, max. input capacity with options:
1,600 sheets
Duplex unit: Duplex as standard supports 60–163 gsm
A3-A5R
Reversing document processor: 50-sheet, Simplex scan
45–160 gsm, Duplex scan 50–120 gsm, A3, A4, A5, B5,
Letter, Legal, Custom (140 x 182 to 297 x 432 mm)
Output capacity: Max. 250 sheets face-down (Main Tray),
50 sheets (Job Separator Tray)
Print functions
Controller language: PRESCRIBE
Emulations:
PCL 6 (5e/XL), KPDL 3 (PostScript 3 compatible),
PDF Direct Print, XPS Direct Print
Interface: USB 2.0 (High-Speed), USB Host 2.0, Fast Ethernet
10/100/1,000Base-TX, Slot for optional print server, Slot for
optional Memory Card
Operating systems: All current Windows operating
systems, MAC OS X Version 10.2 or higher, Unix, Linux as
well as other operating systems on request
Fonts/bar codes: 93 outline fonts (PCL 6, KPDL3) + 8
(Windows Vista), OCR: OCR-A, OCR-A kana, OCR-B, OCR-B
kana, OCRkana bitmap fonts, 45 types of one-dimensional
bar codes, 1 type of two-dimensional bar code (PDF 417) -
via PRESCRIBE
Features: encrypted PDF Direct Print, IPP printing, e-mail
printing, WSD print, secure printing via SSL, IPsec, SNMPv3
Copy functions
Max. original size: A3/Ledger
Continuous copying: 1–999 Zoom range: 25–400% in
1% steps
Preset magnification ratios:
5 Reductions / 5 Enlargements
Features: Scan-once-copy-many, sort, 2in1, 4in1, job reserve,
priority print, program, auto duplex copy, split copy,
continuous scan, auto cassette change (PF-470 or PF-471 is
required), copy density control, Prevent Bleed-Through
Exposure mode: Auto, manual: 7 steps
Image adjustments: Text, Photo, Text + Photo, Graphic/
Map, Copy/Printout
Scan functions
Functionality: Scan-to-Email, Scan-to-FTP, Scan-to-PC, Scan
to USB Host, TWAIN , WSD scan
Interface: Fast Ethernet 10/100Base-TX, USB Host 2.0
Scan speed: 40 ipm (300 dpi, A4, b/w), 20 ipm (300 dpi,
A4 colour)
Scan resolution: 600, 400, 300, 200 dpi (256 greyscales
per colour)
Max. scan size: A3, Ledger
File types: TIFF, PDF, JPEG , XPS
Features: Integrated address book, encrypted data transfer,
multi send (e-mail, fax, SMB/FTP folder, print) at once
Fax functions †
Compatibility: ITU -T Super G3
Modem speed: Max. 33.6 kbps
Transmission speed: Less than 3 sec
Scanning speed: 2.0 seconds (Quick Scanning, Bitmap)
Address book: 200 entries
Interface: Fast Ethernet 10/100/1000Base-TX, Telephone
interface
Scanning density:
Normal: 8 dot/mm x 3.85 line/mm
Fine: 8 dot/mm x 7.7 line/mm
Superfine: 8 dot/mm x 15.4 line/mm
Ultrafine: 16 dot/mm x 15.4 line/mm
Halftone: 8 dot/mm x 7.7 line/mm
Maximum original size: A3, Ledger
Compression method: JBIG , MMR, MR, MH
Memory reception: 700 sheets or more
Features: Network fax, duplex transmission and reception,
encrypted transmission and reception, polling
transmission and reception, broadcast
Options
Paper handling
PF-470 Paper feeder: Max. 500 sheets; 60–163 gsm; A3, A4,
A5, B5, Letter, Legal, Custom (98 x 148 to 297 x 432 mm)
PF-471 Paper feeder: Max. 1,000 sheets; 60–163 gsm; A3, A4,
A5, B5, Letter, Legal, Custom (98 x 148 to 297 x 432 mm)
DF-470 Document finisher: Max. 500 sheets 52–256 gsm; A3,
A4, A5, B5, Letter, Legal, Custom (98 x 148 to 297 x 432 mm)
AK-470 Bridge Unit: To be used with DF-470
Memory upgrade
DIMM-512 MBP: 512 MB; DIMM-1GBP: 1024 MB
Others
USB Flash Memory: Supports direct printing and scanning
of PDF, XPS,TI FF, JPEG files via USB Host interface
Optional Interfaces
Fax System: Type U
Additional network card: IB-50
Consumables
TK-479 Toner Kit: Microfine toner black for 15,000 pages A4
in accordance with ISO/IEC 19752
Capacity of starter toner is 3,000 pages in accordance with
ISO/IEC 19752
Warranty
“3-year warranty as standard. KYOCERA guarantees the
drums and developers for 3 years, or maximum 180,000
pages for FS-6025MFP and 150,000 pages for FS-6030MFP
(whichever occurs sooner), provided the printer is used and
cleaned in accordance with the service instructions.
FS-6025MFP / FS-6030MFP
MONOCHROME MULTIFUNCTIONAL FOR A4/A3 FORMAT
The FS-6025MFP / FS-6030MFP includes:
Windows Vista and the Windows Vista logo are trademarks or registered trademarks of Microsoft Corporation in
the United States and/or other countries.
* Kyocera does not warrant that any specifications mentioned will be error-free. Specifications are subject to
change without notice. Information is correct at time of going to press. All other brand and product names may
be registered trademarks or trademarks of their respective holders and are hereby acknowledged.
† The fax functionality is an optional feature.
KYOCERA MITA Australia
Ph: 13 KYOCERA
www.kyoceramita.com.au
KYOCERA MITA New Zealand
Ph: 0508 KYOCERA
www.kyoceramita.co.nz
KYOCERA MITA Australia Pty Ltd ABN 77 003 852 444
1/2011
Product depicted includes optional extras.
Our Unique Printing Technology
ECOSYS stands for ECOlogy, ECOnomy and
SYStem-printing. With long-life components, ECOSYS
devices are designed to maximise durability and min-imise
the total cost of ownership with regard to maintenance,
administration and consumables. The cartridge-free system
means that only the toner has to be replaced regularly,
and the drum units every 300,000 pages. The modular
design concept allows you to add workflow-enhancing
functions as required. Integrated system software provides
long-term cross-network compatibility. KYOCERA’s long-life
components cost you and the environment less.
PRESCRIBE
With the KYOCERA page design and control language PRESCRIBE, even complex graphics, logos and forms (multipart forms) can
be created independently on the system and saved and updated in the printer. Consequently, integration into print files no lon-
ger applies. They are only accessed as required and therefore relieve the load on the network.
The KM NetViewer
The KM NetViewer enables complete monitoring and control of all ECOSYS printers and digital KYOCERA multifunction units
from any Windows© PC and thus provides ideal network administration. It also supports the standardised SNMP protocol.
Status Monitor and Command Centre
The Status Monitor shows the current printers condition and gives direct access to the Command Center for the modification of
settings that are not contained in the drivers (e.g. network settings, adjustment of sleep mode or blocking of the control panel).
USB Host Interface for USB Flash Memory
PDF files can be printed directly from a USB Flash Memory (e.g. USB stick) via the USB host interface. Documents are selected
directly via the printer’s control panel. No computer is required.
