LYNCOM MODEL N25T
PV SYSTEM LIGHTING
CONTROLLER
Lyncom’s microprocessor based charge controllers incorporate state-of-the-art design and
advanced pulse-width-modulation (PWM) battery charging operation, offering the highest
quality and more features than comparably priced
PV controllers.
Model N25T is an advanced PV lighting system
controller for 12 or 24 volt solar systems rated up to
25 amps, designed specifically for applications such
as billboards, street or park lights, campground and
recreation facilities and marinas.
Field proven PWM design for battery charging,
reduces water loss, extends battery life, and allows
more daily amp-hours into the battery as compared
to traditional “on-off” controllers. Model N25T
features an automatic load timer, which senses
dusk by the solar array and initiates the lighting
time period, which is field adjustable.
The Model N25T lighting timer can be pre-set for
operation of 2, 4, 6, 8, 10 hours, or from dusk to dawn. A low battery voltage load disconnect
circuit (LVD) prevents battery over-discharge during extended overcast periods. Model N25T
features four system status LED’s and a red reverse polarity LED for PV or battery.
Standard Features
•Advanced solid state design
•On-board microprocessor to control voltage settings and parameters accurately
•Pulse-width-modulation charge algorithm to extend battery life compared to conventional
“on-off” type controllers
•Temperature compensation circuit to automatically adjust the optimum battery regulation
voltage and LVD voltage for a range of -30°C to +80°C
•Lightning transient protection
•PV and battery reverse polarity protection
•Over-voltage protection
•Over-temperature protection
•Load short circuit and over-current protection
•Selection of battery type between flooded and sealed
•Automatic battery equalization for flooded battery
•Parallel capability
•5 year limited warranty
Ratings
•Battery Voltage: 12/24 Volts Auto Select
•Maximum PV current: 25.0 Amps
•Maximum Load current: 25.0 Amps
•Self-Consumption: 13.0 mA

7812 EAST ACOMA DRIVE
SCOTTSDALE, AZ 85260 USA
480/951-6330 • 800/544-6466
FAX: [phone]
www.kyocerasolar.com
e-mail: [email protected] Specifications subject to change without notice.
LYNCOM MODEL N25T
PV SYSTEM LIGHTING CONTROLLER
Temperature Setpoints
•High Temperature Shutdown:
Disconnect PV: 70°C
Disconnect Load: 80°C
Reconnect PV: 60°C
Reconnect Load: 50°C
•Operating Temperature Range: -40°C to +80°C
•Temperature Compensation Coefficient: -4mV/Cell/C°
•Cold Temperature Load Cutoff: -30°C
•Reconnect of ColdTemperature Load Cutoff: -20°C
Control Setpoints Sealed Flooded
BatteryBattery
•High BatteryVoltage System
Shutdown (8 seconds): 15.5 V 15.5 V
•Reset For High Voltage Shutdown (
Instantly ): 14.5 V 14.5 V
•Battery Equalization: – 15.3 V
•Regulation Voltage: 14.1 V 14.4 V
•Battery LVD Voltage (32 seconds): 11.3 V 11.4 V
•Load Reconnect After Low Voltage
Disconnect (LVD) (Instantly): 12.8 V 13.0 V
•Automatic equalization: – 14 days
•Equalization can be triggered (32 seconds): –
V<11.4V
(24V set points are twice the12V values)
Microprocessor Sampling Period
•PV Voltage Sampling: 8 seconds
•Battery Voltage Sampling: Constantly
•Temperature Sampling: 3 seconds
•Load Current Sampling
After Over-Current Sampling: 3 - 6 seconds
Other Specifications (All ratings at 25°C)
•Weight: 14 oz. (.4 kg)
•Dimensions: 6.3 x 5.3x 1.8 in. (16.0 x 13.46 x 4.57 cm)
•Voltage Drop PV/Battery: 0.25 Volts
•Load Short Circuit Rating: 30 Amps
