FS-3920DN - monochrome laser printer
FS-3920DN - monochrome laser printer
SAVINGS RELIABILITY ENVIRONMENT
®
With an exhilarating 40 pages per minute, an integrated network
interface and duplex functionality, the FS-3920DN is the perfect device
for busy workgroups. It accommodates different user needs, by offering
flexible paper handling, memory options, and controller functionality.
The FS-3920DN also boasts enhanced security features and a very low
cost per page.
• Up to 40 pages per minute A4
• Fine 1,200 dpi printing quality
• Standard duplex unit for double-sided printing
• Standard Network, USB and Parallel Connectivity
• 100-sheet multi-purpose tray
• 500-sheet universal cassette
• Direct PDF Print from USB Flash memory device
• Exceptionally low printing costs in its class
THE FLEXIBLE WORKGROUP
DEVICE FOR MONOCHROME IN A4.

The FS-3920DN includes:
PRESCRIBE IIe
With the Kyocera page design and control language PRESCRIBE IIe, even complex graphics, logos and forms (multipart forms) can
be created independently on the system and saved and updated in the printer. Consequently, integration into print files no longer
applies. They are only accessed as required and therefore relieve the load on the network.
The KMnet Viewer
The KMnet Viewer enables complete monitoring and control of all ECOSYS printers and digital KYOCERA multifunction units from any
Windows©PC and thus provides ideal network administration. It also supports the standardised SNMP protocol.
Status Monitor and Command Center
The Status Monitor shows the current printers condition and gives direct access to the Command Center for the modification of
settings that are not contained in the drivers (e.g. network settings, adjustment of sleep mode or blocking of the control panel).
USB Host Interface for USB Flash Memory
PDF files can be printed directly from a USB Flash Memory (e.g. USB stick) via the USB host interface. Documents are selected directly
via the printer’s control panel. No computer is required.
FS-3920DN
MONOCHROME PRINTER FOR A4 FORMATS
General
Technology
Kyocera ECOSYS Laser
Engine speed
Up to 40 A4 pages per minute
Resolution
1,200 dpi
Duty cycle
Max. 200,000 pages per month,
Max. average 25,000 pages per month
Warm-up time
Approx. 17 seconds or less from power on
Time to first print
Approx. 10.5 seconds or less
Dimensions (W x D x H)
382 mm x 394 mm x 320 mm
Weight
Approx. 16.7 kg (main unit)
Power source
AC 220/240 V, 50/60 Hz
Power consumption
Printing: 641 W
Stand-by: 9.5 W
Power-Saving (ECO power): 5.9 W
Noise (ISO 7779 / ISO 9296)
Printing: 54 dB(A)
Stand-by: 30 dB(A)
Safety standards
GSGS, TÜV, CE
This unit is manufactured according to ISO 9001 quality
standard and ISO 14001 environmental standard.
Paper Handling
All paper capacities quoted are based on 80gsm paper,
thickness of max 0.11mm. Please use paper recommended by
Kyocera under normal environmental conditions.
Input capacity
100-sheet multi-purpose tray; 60–220 g/m2;
A4, A5, A6, B5, Letter, Legal, Custom
(70 x 148 – 216 x 356 mm)
500-sheet universal paper cassette, 60–120 g/m2;
A4, A5, A6, B5, Letter, Legal, Custom
(140 x 210 mm – 216 x 356 mm)
Max. input capacity incl. options: 2,500 sheets
Duplex unit
Duplex as standard supports A4, A5, B5, Letter, Legal,
Custom (140 x 210 mm – 216 x 356 mm), 60–120 g/m2
Output capacity
500-sheet-face-down with paper full sensor and optional
250-sheet-face-up with PT-310
Controller
CPU
PowerPC 440/600 MHz
Memory
128MB RAM , can be increased to 1,152MB RAM (single DIMM
slot) as an option
Standard interface
Fast Ethernet: 10/100 Base-TX for IPv4/IPv6
High-speed bi-directional parallel (IEEE 1284),
USB 2.0 (Hi-Speed), USB Host Interface dedicated for USB Flash
Memory device.
Controller language
Prescribe IIe
Emulations
PCL6, PCL5c, PostScript*3 (KPDL3), with automatic emulation
sensing, XPS (Windows Vista), PDF Diret Print, Line Printer, IBM
Proprinter X24E, Epson LQ-850, Diablo 630
Operating systems
All current Windows operating systems,
Mac OS X Version 10.2 or higher,
UNIX, LINUX as well as other operating systems on request
Fonts/Barcodes
93 scalable fonts for PCL/PostScript*, 8 fonts for Windows
Vista*, 1 Bitmap font, 45 barcodes (e.g. EAN8, EAN13, EAN128)
with automatic generation of checksums as well as
support of two-dimensional barcodes PDF-417 under
PRESCRIBE (PCL and other barcodes available as an option)
Integrated Accounting
100 department codes
Consumables
TK-354 Toner-kit
Microfine toner for 15,000 pages A4, at 5% coverage, in
accordance with ISO/IEC 19752
Capacity of starter toner is 7,500 pages A4, at 5% coverage, in
accordance with ISO/IEC 19752
Maintenance Kit MK-350: Installed every 300,000 pages
Options
PF-310 Paper feeder
500 sheets; 60–120 g/m2 ; A4, A5, B5, Letter, Legal,
Custom (148 x 210 mm – 216 x 356 mm)
Max 3 x PF-310 can be attached for a total of 2,100 sheet input
PF-315 Bulk paper feeder and PB-315 Printer base
Max. 2,000 sheet, 60–200 g/m2,
not to be combined with PF-310 or EF-310
Max 1 x PF-315 can be attached for a total of 2,500 sheet input
EF-310 Envelope feeder
For max. 70 normal envelopes or max. 100 air mail
envelopes up to A6 size
PT-310 Paper tray
250-sheet-face-up output tray
Memory upgrade
DIMM-512P: 512MB or DIMM-1GBP: 1,024MB
1 slot available for memory upgrade
CompactFlash*-Card
1 slot (up to 4 GB) for printing forms, fonts, logos, macro
storage
USB Flash Memory
Supports PDF direct printing via USB Host Interface
HD-5A Hard Disk
40GB for forms, fonts, virtual mailbox and moreWarran
Optional interface
IB-31 Fast Ethernet: 10/100 Base-TX for IPv4/IPv6
Warranty
2-year warranty as standard. KYOCERA guarantees the drums
and developers for 2 years or maximum 300,000 pages
(whichever occurs sooner), provided the printer is used and
cleaned in accordance with the service instructions.
Windows Vista and the Windows Vista logo are trademarks or registered trademarks of Microsoft Corporation in
the United States and/or other countries.
* Kyocera does not warrant that any specifi cations mentioned will be error-free. Specifi cations are subject to
change without notice. Information is correct at time of going to press. All other brand and product names may
be registered trademarks or trademarks of their respective holders and are hereby acknowledged.
02/2009
KYOCERA MITA Australia
Ph: 13 KYOCERA
www.kyoceramita.com.au
KYOCERA MITA New Zealand
Ph: 0508 KYOCERA
www.kyoceramita.co.nz
KYOCERA MITA Australia Pty Ltd ABN 77 003 852 444
Our Unique Printing Technology
ECOSYS stands for ECOlogy,
ECOnomy and SYStem-printing.
With their long-life components, ECOSYS devices
are designed to maximise durability and minimise
the total cost of ownership with regard to
maintenance, administration and consumables.
The cartridge-free system means that only the toner
has to be replaced regularly, and the drum unit
every 300,000 prints. The modular design concept
allows you to add workflow enhancing functions as
required. Integrated system software provides long-
term cross-network compatibility. KYOCERA’s long-life
components cost you and the environment less.
