Printer Driver
for Windows 7
User’s Manual

1
Regarding this manual
This manual explains how to install Windows Printer Driver and how to use it.
This Printer Driver can be used with Microsoft Windows 7.

2
Index
1. INSTALLATION METHOD................................................................................ 3
1.1. Install TCP/IP Port......................................................................................................................................................... 3
1.2. Add “KM-4800w TCP/IP Port”.................................................................................................................................... 7
1.3. Add Printer....................................................................................................................................................................11
1.4. About Printer Port........................................................................................................................................................18
1.5. About reinstall of Printer..............................................................................................................................................20
2. SETTING ITEM OF PRINTER DRIVER ....................................................25

3
1. Installation Method
1.1. Install TCP/IP Port
1. Insert Installation Disk in CD-ROM drive.
2. Open “(the optical drive)\Software\PrinterPort\”.
Right-click on “KM4800wTcpMon_xxx.exe” and select “Run as administrator”.
(xxx is the version)
[Use Account Control] message will appear. Click “Yes”.
3. Click “OK”.

4
4. Click “Next”.
5. Click “Install”.

5
6. Please wait while the wizard is installing the components.
7. Click “Finish”.

6
If the following message appears, click “This Program installed correctly”.
TCP/IP port installation is completed.

7
1.2. Add “KM-4800w TCP/IP Port”
1. Point “Start Menu” and click “Devices and Printers”.
2. Click “Fax” and then “Print server properties”.

8
3. “Print Server Properties” is displayed.
Open “Ports” and click “Change Port Settings”.
4. Click “Add Port”.

9
5. Select “KM-4800w TCP/IP Port” and click “New Port”.
6. Enter the KM-4800w’s IP address or host name.
Click “OK”.
7. Click “Close”.

10
8. Confirm that “KM-4800w TCP/IP Port” is displayed in the list. Click “Close”.
Adding “KM-4800w TCP/IP Port” is completed.

11
1.3. Add Printer
1. In “Devices and Printers”, click “Add a printer”.
2. Choose “Add a local printer”.

12
3. Choose “Use an existing port:” and then select “KM-4800w:192.168.100.10 (KM-
4800w TCP/IP Port)” in the pull down menu. Click “Next”.
4. Click “Have Disk”.

13
5. Click “Browse”.
6. Specify “K48PREN.INF” at “(the optical drive)\Software\PrinterDriver\EN\”
Click “Open”.
English: specify \Software\PrinterDriver\EN\ K48PREN.INF
French: specify \Software\PrinterDriver\FR\ K48PRFR.INF
German: specify \Software\PrinterDriver\DE\ K48PRDE.INF
Italian: specify \Software\PrinterDriver\IT\ K48PRIT.INF
Spanish: specify \Software\PrinterDriver\ES\ K48PRES.INF

14
7. Click “OK”.
8. Click “Next”.

15
9. If KM-4800w Printer Driver is already installed on your system, the following screen
appears.
Select “Replace the current driver” and click “Next”.
10. Printer name can be changed at your option.
Click “Next”.

16
11. Check “Always trust software from “KYOCERA MITA Corporation”.” and click “Install”.
12. Click “Finish”.

17
13. Confirm that “KM-4800wEN” is added in “Printers and Faxes”.
Installation of printer has been finished.

18
1.4. About Printer Port
In “Devices and Printers”, select “KM-4800wEN” and click “Print server properties”.
Open “Ports” and then click “Change Port Settings”.

19
Select “KM-4800w TCP/IP Port” and then click “Configure Port”.
The following information is indicated.
You do not have to change any of the above settings in usual case.
Change these settings when KM-4800w does not wake up correctly from the Power
Save Mode caused by the network settings.
MAC Address: MAC Address of output printer
Broad Cast Address: An address used to send the data to all PC on the network
Magic Boot Port: Port number to send the data
Timeout: Timeout when no response comes from the output printer
Retry: Number of retry when no response comes from the output printer
