Automation and Robotics
SERVO ROBOT SYSTEM
SERIES 5250
GENERAL DESCRIPTION
The Lab-Volt Servo Robot System, Model 5250, provides
complete and affordable training in the programming and
operation of industrial robots. Through the curriculum and
hands-on experience with the Servo Robot System,
students learn to create automated work cells ideal for
Flexible Manufacturing Systems (FMS) and Computer
Integrated Manufacturing (CIM).
The precision-built, articulated arm of the Servo
Robot represents an important step in automation and
handling. It is driven by servo motors equipped with
optical encoders to provide feedback to the controller.
The Servo Robot has five axes of rotation plus a
gripper. All joints can be used simultaneously to perform
a sequence of moves. The Servo Robot can be operated
in the Articular mode, which allows each articulation to
be controlled and moved independently, or it can be
operated in the Cartesian mode where the gripper moves
linearly, parallel to a specified axis. The Servo Robot can
be controlled and programmed using a hand-held terminal
or from a PC host computer running the RoboCIM 5250
Software or the Robotics software.

SERVO ROBOT SYSTEM
SERIES 5250
2
RoboCIM 5250 Software and Robotics Software
Robot Controller Module
The Robot Controller module is provided with TTL
(Transistor-Transistor Logic) inputs for the monitoring of
input devices; TTL outputs to communicate with other
robot units or control external accessories such as a belt
conveyor; relay outputs for the control of external acces-
sories such as Signal Tower, Model 5924; output ports
for the control of external devices such as the Linear Slide
or Rotary Carousel; and serial communication port for
host control operation and for uploading and downloading
programs.
The Robot Controller module is also equipped with
CNC (Computerized Numerical Control) ports, which
enable communication with Lab-Volt Automation CNC
machines. This allows for a truly integrated flexible manu-
facturing system where the robot and CNC machines can
operate in “wait” mode until contacted by other equip-
ment. The Robot Controller also houses a floppy disk
drive for program storage.
The Hand-Held Terminal connects to the Robot
Controller via a serial communication port. It is used for
programming points, saving programs, and general
operation of the Servo Robot System.
The RoboCIM 5250 Software or Robotics software
can be used in place of the Hand-Held Terminal. The
Robotics software allows the user to point and click to
move the Servo Robot and select points. The editing and
labeling processes are very user-friendly. Furthermore,
the capability of Robotics to create task programs allows
the design of complex processes. With the RoboCIM
5250 Software, the motion of the Servo Robot can be
controlled or simulated. The software provides a
three-dimensional virtual environment and an easy-to-use
interface allowing students to easily learn the fundamen-
tals of robotics. Two programming modes are available:
an intuitive icon programming mode and a text program-
ming mode to create more complex tasks.
The Servo Robot and external devices offered as
options with the Servo Robot System are equipped with
location pins (or push-lock fasteners). These pins are
designed to be used with the metallic, perforated work
surfaces. This easy-to-use mechanism ensures the
position of the equipment when repeating programs.
TABLE OF CONTENTS
General Description ......................... 1
Table of Contents of the Student Manual ........ 4
ListofEquipment ........................... 4
Optional Kits ............................... 5
Optional Equipment ......................... 5
Module Description .......................... 6
Specifications ............................. 14
OrderingNumbers ......................... 19

3
Location pin on a Gravity Feeder
Robot Calibration Tools
The equipment supplied with the Servo Robot Sys-
tem, Model 5250-1, includes a Servo Robot, Robot Con-
troller, Hand-Held Terminal, Emergency Stop Button
module, RoboCIM 5250 Software, Robotics software,
Grids, Robot calibration tools, student and instructor
manuals, user guides, and all leads and cables required
to operate the system. The Servo Robot System,
Model 5250-2, is supplied with all the equipment of the
Model 5250-1 and two solid-metal perforated work sur-
faces that can be linked together using the provided
Spacers. They can be put atop a regular work table or
installed on one of the optional benches.
Many optional devices can be added to the system
to perform more complex processes. The optional devices
include a Rotary Carousel, Belt Conveyor, Gravity
Feeders, Pneumatic Feeders, a Signal Tower, and a
Linear Slide.
Features
Servo Robot
CHigh torque servo motors
CSteel and aluminum construction
CHTD (High Torque Drive) drive belts for power transfer
(enclosed for safety)
CEasily adjustable belt tension pulleys to maintain posi-
tional accuracy
COilite and UHMW (Ultra-High Molecular Weight) bush-
ings for durability, minimum maintenance, and lubrica-
tion
CBoundary and current limit protection on all axes
Robot Controller
COn-board microprocessor
CEight TTL input ports, color coded, and with LED status
indicators
CEight TTL output ports, color coded, and with LED
status indicators
CFour relays, each equipped with a set of normally open
and normally closed contacts and LED status indicators
CServo Robot and external motor release switch, and
LED status indicator
CFloppy-disk drive for program storage
CHand-Held Terminal communication port
Safety Features
CKey-Activated Emergency Stop Button module
Robotics Software
CEasy-to-use, menu-driven software
CDirect keyboard control over all robot axes and func-
tions
CControl output ports and read instruction channels
CTask commands include jump, loop, if-then-else, and
while-repeat conditions
CPoint-to-point and task programming
RoboCIM 5250 Software
CEasy-to-use, menu-driven software
CSimulation and control modes
CThree-dimensional (3D) virtual environment
CSeven predefined layout/camera view settings
CControl the movements of the Servo Robot using "artic-
ular" and "Cartesian" coordinates
CProgramming without actual equipment

SERVO ROBOT SYSTEM
SERIES 5250
1The ordering numbers shown apply to the English 120-V version. Other versions are available. Refer to the Ordering Numbers section.
2Includes RoboCIM 5250 Software, Robotics software, Hand-Held Terminal, Emergency Stop Button module, Robot calibration tools, and all leads and cables required to operate the system.
4
CPoint recorder panel to easily record, rename, view
coordinates, hide, and delete points
CCreate and run simple task programs using icons and
graphical tools (no keyboarding required)
CCreate and run simple and complex task programs by
entering all necessary commands using the keyboard
CPowerful set of task commands such as: Delay,
Do-Until, If-Else, Gosub, Home, Input, Output,
While-Repeat, and many others
TABLE OF CONTENTS OF THE STUDENT MANUAL
Introduction to Robotics (34175-00)
CIntroduction
CFamiliarization with the Servo Robot System
CPoint-to-Point Programs
CTask Programs
CProgram Editing
CControl Overview
CIndustrial Application Simulation Using a Gravity
Feeder
CIndustrial Application Simulation Using a Belt Conveyor
CIndustrial Application Simulation Using a Pneumatic
Feeder
CIndustrial Application Simulation Using a Rotary Carou-
sel
