LEGEND SERIES SHEAR
SAFETY, OPERATION & MAINTENANCE
516649 User Manual 1/2020 Ver. 5
MSD
LaBounty | 1538 Hwy 2 | Two Harbors, MN 55616 | 1-800-522-5059 | www.stanleyinfrastructure.com/brands/labounty
www.stanleyinfrastructure.com/brands/labounty
2 | MSD Legend Series Operation & Maintenance Manual
PREFACE
This manual contains information for the safe operation and maintenance of the LaBounty MSD Legend Series shear.
Read the entire manual before the initial start-up of the attachment. It is important to know the correct operating
procedures of the attachment and all safety precautions to prevent the possibility of property damage and personal
injury.
The LaBounty attachment has been designed and manufactured with high quality materials and care in workmanship.
The instructions in this manual have been prepared to ensure that, when followed properly, the attachment will provide
ecient and reliable service. Continuing product development and improvement may have caused changes in the
attachment that are not reected in this manual. If a question arises regarding the operation or maintenance of the
attachment, contact a LaBounty dealer for the most current information available.
IMPORTANT
This operator’s manual must accompany the attachment at all times and be readily available to the operator.
MANUAL REPLACEMENT
Should this manual become damaged, lost or additional copies are required, immediately contact any authorized
LaBounty dealer. You may also download a PDF copy at www.stanleyinfrastructure.com.
REGISTRATION FORM
The Warranty Registration Form must be lled out by the dealer or customer and returned to LaBounty indicating the
date the machine went into service.
POSSIBLE VARIATIONS
LaBounty cannot anticipate every possible circumstance that might involve a potential hazard, as the owner’s
requirements and equipment may vary. Therefore, the warnings in this publication and on the product may not be all-
inclusive and you must ensure that the procedure, application, work method and operating technique is safe for you,
and others, before operation.
PUBLIC NOTICE
LaBounty reserves the right to make changes and improvements to its products and technical literature at any time,
without public notice or obligation. LaBounty also reserves the right to discontinue manufacturing any product at its
discretion, at any time.
WARRANTY
All work or repairs to be considered for warranty reimbursement must be authorized by the LaBounty Service
Department before work is started. Any alterations, modications or repairs performed before authorization by the
LaBounty Service Department will render all warranty reimbursement consideration null and void without exception.
Improper operation or improperly performed maintenance may render any warranty null and void.
MSD Legend Series Operation & Maintenance Manual | 3
CONTENTS
SAFETY .....................................................................................................4
DECALS......................................................................................................6
TERMS .......................................................................................................7
INSTALLATION.........................................................................................8
Second Member Installation.............................................................................................................................................8
Third Member Installation..................................................................................................................................................8
Non-Rotating Installation...................................................................................................................................................8
Hydraulic Installation ...........................................................................................................................................................9
InSite™ Electrical Installation...........................................................................................................................................10
Connect to Excavator DC Power.....................................................................................................................................11
Connect to the Excavator Ignition Switch ...................................................................................................................11
InSite Power Cable Wiring Diagram ...............................................................................................................................12
Download & Install the InSite Mobile Application .....................................................................................................13
Removing the Shear from the Excavator .....................................................................................................................13
Storing the Shear..................................................................................................................................................................14
OPERATION ...............................................................................................15
Before You Start ....................................................................................................................................................................15
Safety Devices ......................................................................................................................................................................15
Technical Specications ....................................................................................................................................................16
Controls....................................................................................................................................................................................16
Operating Tips .......................................................................................................................................................................17
Bleed the Shear Hydraulic Circuit...................................................................................................................................18
Bleed InSite .............................................................................................................................................................................19
Check for Leaks.....................................................................................................................................................................20
MAINTENANCE ........................................................................................21
8-Hour Inspection Checklist.............................................................................................................................................21
80-Hour Inspection Checklist..........................................................................................................................................22
1500-Hour Inspection Checklist.....................................................................................................................................22
2,000- Hour Inspection Checklist...................................................................................................................................22
Hydraulic Inspection ............................................................................................................................................................23
Shear Lubrication..................................................................................................................................................................23
Planetary Gearbox Lubrication........................................................................................................................................24
Inspect / Torque Bolts .........................................................................................................................................................25
Blade Maintenance...............................................................................................................................................................26
Blade Removal........................................................................................................................................................................26
Measuring & Shimming Blade Gaps...............................................................................................................................28
Blade Rotation........................................................................................................................................................................31
Jaw Build Up & Hardsurfacing..........................................................................................................................................38
Replace Wear Plates & Bars..............................................................................................................................................41
Slide Screw Adjustment .....................................................................................................................................................41
Check the Cylinder Gap......................................................................................................................................................42
Speed Valve ............................................................................................................................................................................43
Speed Valve Assembly Illustrations...............................................................................................................................45
Hydraulic Schematics .........................................................................................................................................................49
4 | MSD Legend Series Operation & Maintenance Manual
SAFETY
The Safety Alert Symbol alerts you to potential personal
injury hazards. Obey all safety messages that follow to
avoid possible injury or death.
Indicates an imminently hazardous situation which will
result in death or serious injury.
Indicates a potentially hazardous situation which could
result in death or serious injury.
Indicates hazards that could result in damage to the
equipment or personal injury.
Indicates important procedures.
Your safety and the safety of others is a
direct result of how you operate and
maintain your equipment. Read and
understand this manual and other safety
information provided with the base
machine and be sure that you
understand all controls and operating
instructions before attempting to operate this equipment.
Failure to follow the safety precautions can result in
personal injury, death or property damage.
Carefully read all safety messages in this manual and on
your equipment safety signs. Keep safety signs in good
condition. Replace missing or damaged safety signs.
Because LaBounty cannot foresee all hazardous
circumstances, the precautions listed in this manual and
on the equipment are not all-inclusive. If a procedure,
method, tool or part is not specically recommended by
LaBounty, determine whether it is safe for you and others,
and that the equipment will not be damaged or made
unsafe as a result of your decision to implement it.
The basic rules are summarized in this section of the
manual. They also appear throughout the manual along
with additional specic rules for safety and operation.
GENERAL
• If the attachment is not functioning properly, shut
down the machine, follow proper Lock-out / Tag-out
procedures and follow proper repair procedures.
• Remove and replace any damaged or worn parts
with parts recommended by LaBounty. Use of parts
that are not factory approved may cause damage or
unnecessary downtime and may void the warranty.
• NEVER operate equipment without the original safety
guards in place.
• DO NOT process material with the attachment over
the operator’s cab. Doing so will result in severe
personal injury or death from falling debris.
• DO NOT attempt to process brittle materials, such as
axles and railroad rail. DO NOT process any material in
a position that may propel it toward the operator, other
workers, buildings or equipment.
• Clear all persons and equipment from the area of
operation and machine movement. NEVER move
loads over people or equipment. When viewing the
operation of the attachment, maintain a safe distance
of at least 30 feet (10 meters).
• NEVER approach power lines with any part of the
machine. Keep clear at a minimum of 15 feet (5
meters).
• DO NOT close the attachment on a structure and
reverse the excavator in an attempt to pull down
material.
• Use of this tool on certain materials could generate
dust potentially containing a variety of hazardous
substances, such as, asbestos, silica or lead.
Inhalation of dust containing these, or other
hazardous substances could result in serious injury,
cancer or death. Protect yourself and those around
MSD Legend Series Operation & Maintenance Manual | 5
you. Research and understand the materials you are
processing. Follow safety procedures and comply
with all applicable national, state or provisional health
and safety regulations relating to them. If appropriate,
arrange for the safe disposal of the materials by a
qualied person.
• Disassembly of any pin-connected attachment can
be hazardous. NEVER remove any pin unless the
attachment is on the ground and blocked up. Serious
injury or death could result. Metal chips or debris may
y when a connecting pin is struck. Use a brass drift
when striking pins and always wear protective clothing
and proper eye protection. Pins may y when struck
with force to drive them in or out. Always keep people
clear when removing or installing pins.
• Do not operate this, or any other equipment, under the
inuence of drugs or alcohol.
• DO NOT modify LaBounty equipment without factory
authorization. This equipment is designed to do a
specic job and alterations could result in injury.
• ALWAYS lower the boom to the ground before leaving
the cab. If it is necessary to work on an attachment
o the ground, securely support the machine and
attachment. DO NOT support the machine on cinder
blocks, hollow tiles or props that may crumble under
continuous load. DO NOT rely on a cylinder to hold the
attachment in the air. If a control is moved or hydraulic
pressure is otherwise released, the attachment may
drop. DO NOT work under a machine that is supported
only by a jack.
• DO NOT weld on any structural member unless
specically authorized by LaBounty. Unauthorized
welding will void the warranty, may cause structural
failure and could result in personal injury.
• Keep clear of potential pinch points, including the
moving upper jaw, cylinder connections, bucket
linkages and other moving parts.
• Before operating the attachment, read and observe
all safety instructions in the Operation & Maintenance
manual. If you are unfamiliar with any operation or
maintenance procedure, seek instruction before
proceeding.
• Inspect the attachment daily. Do not operate a poorly
maintained or damaged attachment.
• Never operate a machine if an unsafe condition exists.
Attach a “Do Not Operate” tag to the machine.
BASE MACHINE
• Ensure that the cab is equipped with the proper safety
guards for LaBounty applications. The cab MUST be
equipped with an approved Falling Object Protection
Structure (FOPS) and cab guarding. The FOPS must
meet the requirements of SAE standard J1356. A
transparent, shatter-resistant shield covering the
front of the cab, is also required. Contact your base
machine equipment dealer or manufacturer for
more information on the availability of FOPS and cab
guarding. Lack of proper FOPS and guards may result
in injury or death.
• Avoid tipping. The attachment will alter the lift
capacities of the base machine. DO NOT overload
the excavator or serious injury could result. Lift
capacities will vary if the base machine is not on level
ground. Lifting incorrectly can cause severe injury or
machine damage. Use the recommended excavator
counterweight. Use short slings and lift the load only
as high as necessary.
• DO NOT allow riders on the machine. Riders are
subject to serious injuries, such as being struck by
foreign objects or being thrown o the machine.
Riders also distract and obstruct the operator,
resulting in the machine being operated in an unsafe
manner. NEVER use the attachment as a work
platform or personnel carrier.
• Check ground conditions before operating. Avoid
unstable or slippery areas and position the base
machine on rm, level ground. If level ground is
not possible, position the base machine to use the
attachment to the front or back of the carrier. Avoid
working over the side of the base machine.
HYDRAULIC
• Hydraulic oil becomes hot during operation. DO NOT
come in contact with hot hydraulic oil as it could cause
severe burns. Wear adequate protective clothing and
safety equipment.
• DO NOT tamper with hydraulic lines or components
while they are pressurized. Escaping uid under
pressure can penetrate the skin, causing serious
injury. Keep hands and body away from pinholes and
nozzles which eject uids under high pressure. Use
a piece of cardboard to search for leaks. If ANY uid
is injected into the skin, seek immediate medical
assistance.
PPE
• ALWAYS wear close-tting clothing and safety
equipment appropriate to the job. Safety equipment
should be worn at all times when viewing, operating
or maintaining the attachment. Safety equipment
includes eye protection, hard hat, steel toe shoes,
gloves, hearing protection and respirator.
6 | MSD Legend Series Operation & Maintenance Manual
DECALS
Grease Decal
116338
(At each tting)
FIGURE 5
1538 Highway 2
Two Harbors, MN 55616
tel: 1-800-522-5059
fax: 218-834-3879
www.stanleyhydraulics.com
Made in the U.S.A. with Global Materials
Attachment Model:
Serial Number:
Year of Manufacture:
Weight:
Model/Serial Number Plate
511045
FIGURE 2
Patent Plate
116404
FIGURE 3
Top and front cab
guarding required during
any material processing
application
Cab Safety Decal
503647
FIGURE 6
Safe Viewing Distance Decal
116389 (13” x 30”)
503706 (6” x 13”)
FIGURE 4
InSite Decal
516648
FIGURE 8
Cylinder Bleed Decal
512554
FIGURE 7
Pressure Relief Decal
512572
FIGURE 1
MSD Legend Series Operation & Maintenance Manual | 7
TERMS
ROTATING HEAD
SERIAL NUMBER
UPPER SHEAR
PIERCING
TIPS
LOWER
SHEAR
MAIN
PIVOT
GROUP
STICK
CONNECTION
CONNECTION
UPPER
CUTTING
BLADES
TRANSPORT PIN
MANIFOLD
BLOCK
REAR
PIN
FRONT
PIN
LOWER
CUTTING
BLADES
CROSS
BLADE
GUIDE
BLADE
8 | MSD Legend Series Operation & Maintenance Manual
INSTALLATION
1. Locate at, hard ground (e.g. concrete oor).
2. Place the shear on the ground so the boom pivot is up.
Use blocking to keep the shear stable and level.
3. Remove the excavator bucket. Follow the
manufacturer’s recommended procedure
Note: Plug hydraulic hoses and lines to prevent
contamination.
SECOND MEMBER INSTALLATION
Note: A second member mount is where the shear
replaces the excavator stick.
1. Remove the excavator stick. Follow the manufacturer’s
recommended procedure.
2. Bring the excavator in position, carefully lining up the
boom with the shear boom connection on the mounting
bracket.
Note: It may be necessary to lift the rear of the shear
with a hoist or forklift, to allow the boom to connect to
the bracket.
3. Pin the excavator boom to the boom connection (See
Figure 9).
4. Clear all personnel and instruct the excavator operator
to slowly lift the shear so there will be enough clearance
to pin the excavator cylinder to the cylinder connection.
5. Extend the arm cylinder rod and connect the cylinder to
the cylinder connection using the cylinder connection
pin.
6. If you have a rotating shear, remove the transport pin
and place it in its stowed position (see Figure 12).
THIRD MEMBER INSTALLATION
Note: A third member installation is where the shear
replaces the excavator bucket.
1. Bring the excavator in position, carefully lining up the
stick tip wit the stick connection on the mounting
bracket.
Note: It may be necessary to lift the rear of the shear
with a hoist or forklift, to allow the stick to connect to the
bracket.
2. Pin the excavator stick to the stick connection.
3. Carefully extend the excavator bucket cylinder to move
the bucket linkage. Position the link into the mounting
bracket linkage connection.
4. Pin the linkage connection to the shear bracket.
5. Remove the transport pin and place it in its stowed
position (see Figure 12).
NON-ROTATING INSTALLATION
Care must be taken when unloading the shear. Place the
shear on secure, stable blocking. Ensure the blocking
will not allow the upper jaw move in any way or touch the
ground.
Second Member Installation
FIGURE 9
Non Rotating Installation
FIGURE 11
Third Member Installation
FIGURE 10
MSD Legend Series Operation & Maintenance Manual | 9
REMOVE TRANSPORT PIN
STOW TRANSPORT PIN
Stowed Transport Pin
FIGURE 12
HYDRAULIC INSTALLATION
Note: Refer to “Hydraulic Schematics” on page 49.
Do not connect hydraulic lines while they are pressurized.
serious injury.
Hydraulic Circuit Requirements
Note: Values given are standard values. For custom attachments reference the parts manual.
Model Jaw Cycle Circuit (Max) Rotation Circuit (Max) Connection
MSD1000 80 GPM (300 LPM)
4000-5500 PSI (275-380 Bar) 3-4GPM (11-19 LPM)*
2000-2500 PSI (138-172 Bar)
Cylinder: 1 inch Code 62
Rotation: -8 FFORX
MSD1500 110 GPM (410 LPM)
4000-5500 PSI (275-380 Bar)
Cylinder:1 inch Code 62
Rotation: -8 FFORX
MSD 2000 130 GPM (490 LPM)
4000-5500 PSI (275-380 Bar)
5-7 GPM (19-30 LPM*
2000-2500 PSI (138-172 Bar)
Cylinder: 1.25 inch Code 62
Rotation: -8 FFORX
MSD 2250 135 GPM (511 LPM)
4000-5500 PSI (275-380 Bar)
8-10 GPM (30-42 LPM)*
2000-2500 PSI (138-172 Bar)
Cylinder: 1.25 inch Code 62
Rotation: -8 FFORX
MSD 2500 140 GPM (530 LPM)
4000-5500 PSI (275-380 Bar)
8-11 GPM (30-45 LPM)*
2000-2500 PSI (138-172 Bar)
Cylinder: 1.25 inch Code 62
Rotation: -8 FFORX
MSD 3000 150 GPM (560 LPM)
4000-5500 PSI (275-380 Bar)
8-11 GPM (30-45 LPM)*
2000-2500 PSI (138-172 Bar)
Cylinder: 1.25 inch Code 62
Rotation: -8 FFORX
MSD 4000 180 GPM (680 LPM)
4000-5500 PSI (275-380 Bar)
Cylinder: 1.25 inch Code 62
Rotation: -8 FFORX
MSD 4500 200 GPM (750 LPM)
4000-5500 PSI (275-380 Bar)
Cylinder: 1.5 inch Code 62
Rotation: -8 FFORX
*Rotation ow specications are an estimate. Adjust your specic ow so that the shear rotates at 3-6 RPM. Rotating
faster than 3-6 RPM can cause rotation component damage.
1. Connect the hydraulic hose to the connections located on each side of the head.
Note: Each port on the head is labeled so users can easily identify the cylinder, rotation and case drain ports.
2. For rotating models, after installing the hydraulic circuits on the base machine, install additional hydraulic lines up
the boom.
• Two 1/2” (13 mm) diameter feed lines
10 | MSD Legend Series Operation & Maintenance Manual
• One 1/2” (13 mm) diameter case drain
3. Install jump lines from each of these lines to the shear bulkhead or manifold ttings. Refer to the parts manual.
4. Torque all hydraulic ttings to values shown in “Inspect / Torque Bolts” on page 25.
Do not check for hydraulic leaks with your hands. Hydraulic oil
could inject into the skin. Seek immediate medical attention if
an injection injury occurs.
5. Visually check for hydraulic oil leaks or hydraulic hose interference.
Note: The hydraulic circuit must be bled before putting the shear into service (see “Bleed the Shear Hydraulic
Circuit” on page 18).
INSITE™ ELECTRICAL INSTALLATION
MSD Legend shears are equipped with InSite. InSite pulls information from the shear to provide performance metrics
that help increase productivity and reduce downtime. InSite requires DC power from the excavator.
Run Power Cable Up the Excavator Boom
disconnect switch is in the open position. Risk of electric
shock. Perform Lock-Out / Tag-Out procedures on all electrical
energy sources.
InSite requires +12 VDC or +24 VDC from the excavator. The power supply cable will be fed to the excavator and
connected to the main battery disconnect switch (or excavator fuse panel, if preferred) and to the keyed ignition switch.
1. Connect the short armored jump cable to the power cable receptacle on the InSite control box.
Power Cable Receptacle
2. Connect the long InSite power supply cable to the jump cable.
3. Using the supplied zip ties, run the InSite power supply cable up the excavator boom and to the excavator. Secure
the cable at least every 2 feet (610 mm) .
4. Ensure the power cable is not allowed to touch or rub objects that may damage the cable.
5. The end of the power supply cable will terminate in 3 bare wires.
MSD Legend Series Operation & Maintenance Manual | 11
CONNECT TO EXCAVATOR DC POWER
6. Connect one 5A fuse holder to the white wire of the power supply cable.
7. Connect a length of 18 AWG wire from the terminal on the opposite end of the 5A fuse holder to the positive
terminal of the excavators main battery disconnect switch.
8. Connect the green wire to chassis ground.
CONNECT TO THE EXCAVATOR IGNITION SWITCH
Note: InSite power is electrically connected to the excavator ignition switch. This doesn’t mean you need to wire
ignition switch, as long as InSite power will be OFF when the excavator key is removed.
9. Connect one 5A fuse holder to the black wire.
10. Connect a length of 18 AWG wire from the terminal on the opposite end of the 5A fuse holder to the excavator
ignition switch.
Confirm InSite is Communicating
InSite has two LED’s that we can use to conrm that the unit is working properly.
LED Meaning
Solid Green InSite is powered and connected via cellular.
Flashing
Green
InSite is powered, but is searching for a cellular
connection.
No Light InSite is not powered. Check electrical
connections.
12 | MSD Legend Series Operation & Maintenance Manual
InSite Control Box Excavator Battery Main
Disconnect Switch
Power / Extension Cable
Run Down Excavator Boom
INSITE POWER CABLE WIRING DIAGRAM
MSD Legend Series Operation & Maintenance Manual | 13
DOWNLOAD & INSTALL THE INSITE MOBILE APPLICATION
InSite sends data about each of your InSite equipped LaBounty shears to a smart phone or mobile device.
1. Access the app store for your iPhone, iPad or Android device. Search for “InSiteProCall”.
2. Install the InSite application.
3. Open the application and register a new InSite account, if you don’t already have one.
4. Log in and accept the End User License Agreement.
5. Contact InSite service at (218) 834-6840 to obtain your equipment group code. The group code allows access to
your data.
REMOVING THE SHEAR FROM THE EXCAVATOR
1. Position the shear on the ground under the excavator boom, as far as the stick cylinder will extend.
Note: Use blocking to support the stick cylinder from the excavator boom.
Disassembly of any pin-connected attachment can be
hazardous. Never remove pins unless the attachment is on the
ground and blocked up. Serious injury could result.
2. Insert the transport pin between the rotating head and the shear.
3. Remove the stick cylinder pin from the shear mounting bracket.
4. Fully retract the stick cylinder.
5. Cycle the shear jaw closed.
6. Turn o the excavator and relieve any trapped pressure in the hydraulic system. Lock-out / Tag-out the hydraulic
power source.
14 | MSD Legend Series Operation & Maintenance Manual
Trapped hydraulic pressure may be present after the base
removing hydraulic hoses or lines. Injury or death could result.
7. Disconnect the hydraulic ttings. Plug the ttings,hoses and lines to prevent contamination of the hydraulic oil.
8. Ensure the shear is properly blocked-up and can receive the total weight of the shear.
9. Remove the boom pin from the shear.
STORING THE SHEAR
1. Grease the shear, as described in “Shear Lubrication” on page 23.
2. Fully retract the shear cylinder.
3. Block the shear o the ground using wood blocking. Ensure the shear is stable and will not move.
4. Plug all open hydraulic ports.
Note: While in storage, grease the turntable bearing every 6 months. See “Shear Lubrication” on page 23.
MSD Legend Series Operation & Maintenance Manual | 15
BEFORE YOU START
Know Your Safety Program
• Read and understand this manual and the base
machine manual.
• Know the employer’s safety rules. Consult your
foreman for instructions and safety equipment.
• Learn the trac rules at the work site. Know the hand
signals used on the job and who is responsible for
signaling. Take signals from only ONE person.
• Wear personal protection equipment (PPE) at all
times. This includes eye protection, hard had, steel
toe shoes, leather gloves and hearing protection that
conforms to standards ANSI Z87.1 (Eye and Face
Protection), ANSI Z89.1 (Head Protection), ANSI Z41.1
(Foot Protection) and ANSI S12.6 (S3.19) (Hearing
Protection).
Wear Ear
Protection
Wear Eye
Protection
Wear a Mask
Know Your Equipment
• Learn and test the function of all controls. If
malfunctions are found, shut the machine down and
report the malfunction for repair.
• Be familiar with safety devices, indicators, warning
devices and caution instructions. They will alert you to
conditions that are hazardous.
• Know the clearances in the work area.
Daily Safety Checks
• Ensure all decals are installed and legible. Contact
LaBounty for replacements as required.
• Have a safety dialog with all workers. Inform
them of any abnormal work that is planned. Remind
them of the safe working distance.
• Clear the area. look out for others. In any
work area, people constitute a serious safety hazard.
Before operating, walk around the machine to ensure
no workers are next to, under or on it. Warn nearby
workers that you are starting up. DO NOT start up until
they are out of danger. Review Job Safety Analysis
(JSA) with all personnel in the immediate proximity to
the work being done.
• Check the location of cables, gas lines and water
mains before operation. Ensure work site footing has
sucient strength to support the machine. When
working close to an excavation, position machine with
the propel motors at the rear.
• Keep bystanders clear, especially before moving the
boom, swinging the upper structure, or traveling.
be alert for bystanders in or near the
operating area.
SAFETY DEVICES
• Seat belts • Canopies
• Safety decals • Shields and guards
• Flags and ares • Barricades
• Signs and other
markings
• Warning lights
• Falling Objects
Protection Structures
(FOPS) and Cab Guards
• Visual or audible
warning devices
General Rules For Safe Operation
• Clear all persons and equipment from the area of
operation and machine movement. NEVER move
loads over people or equipment. When viewing the
operation of the attachment, maintain a safe distance
of at least 75 feet (23 meters).
• Maintain at least 15 feet (5 meters) between the
attachment and any nearby power lines.
• KNOW the capacity of the excavator and it’s
attachments. DO NOT overload or serious injury
could result. The attachment may have altered the
machine’s lift capabilities.
• NEVER leave the attachment suspended or pass it
over people, occupied vehicles or buildings.
• lower the attachment to the ground and
turn the base machine o when leaving the machine
unattended.
• DO NOT close the jaws on a structure and reverse
the excavator in an attempt to pull down material. This
is dangerous and will damage the excavator and the
attachment.
• This attachment is for processing materials. DO NOT
use for unapproved purposes.
• DO NOT continuously process oversized materials by
forcing them into the jaw. This will shorten the life of
the attachment.
• If attachment stalls, scale back the amount of material
being processed at one time. Overloading can cause
OPERATION
16 | MSD Legend Series Operation & Maintenance Manual
overheating or damage to the hydraulic system.
• Cycle the cylinder completely when processing.
Fully cycling will allow hydraulic uid to circulate and
prevents overheating.
• When working in conned spaces, keep watch on
exposed parts to avoid damage.
• Avoid collision of the boom or jaws, especially when
working with limited visibility or inside buildings.
Know the height and reach of the attachment during
operation, transport and when swinging the excavator.
Watch out for overhead obstacles.
• DO NOT alter factory preset hydraulics. This may void
the warranty.
• DO NOT use attachment as a jack hammer or
wrecking ball.
• DO NOT operate a poorly maintained or damaged
attachment.
• The attachment is not a dozer. DO NOT position it on
the ground and travel forward.
• Lifting lugs are to be used for shipping and installation.
Do not use them in cable-hung applications.
TECHNICAL SPECIFICATIONS
Model Min. Excavator Weight
2nd Member
Min. Excavator Weight
3rd Member Attachment Weight Jaw Opening Jaw Depth Reach
MSD 2250 44,000 Lbs
20 mTons
88,000 Lbs
40 mTons
10,600 Lbs
4,800 Kg
30 In
760 mm
30 In
760 mm
8.6 Ft
2.6 M
MSD2250R 53,000 Lbs
24 mTons
99,000 Lbs
45 mTons
12,700 Lbs
5,750 Kg
30 In
760 mm
30 In
760 mm
11.7 Ft
3.6 M
MSD 2500 51,000 Lbs
23 mTons
88,000 Lbs
40 mTons
11,900 Lbs
5,400 Kg
31 In
790 mm
33 In
840 mm
8.7 Ft
2.7 M
MSD 2500R 66,000 Lbs
30 mTons
110,000 Lbs
50 mTons
14,800 Lbs
6,700 Kg
31 In
790 mm
33 In
840 mm
12.7 Ft
3.9 M
MSD 3000 66,000 Lbs
30 mTons
143,000 Lbs
65 mTons
14,200 Lbs
6,400 Kg
34 In
860 mm
37 In
940 mm
10 Ft
3 M
MSD 3000R 88,000 Lbs
40 mTons
154,000 Lbs
70 mTons
17,100 Lbs
7,700 Kg
34 In
860 mm
37 In
940 mm
13.1 Ft
4 M
MSD 4000 77,000 Lbs
35 mTons
143,000 Lbs
65 mTons
17,100 Lbs
7,800 Kg
38 In
970 mm
43 In
1,090 mm
11.5 Ft
3.5 M
MSD 4000R 99,000 Lbs
45 mTons
165,000 Lbs
75 mTons
19,800 Lbs
9,000 Kg
38 In
970 mm
43 In
1,090 mm
14.8 Ft
4.5 M
CONTROLS
Learn the control for each movement of the attachment before
attempting to operate.
Second Member Control
MSD Legend Series Operation & Maintenance Manual | 17
Arm In → Shear In
Bucket Curl → Jaws Closed
FIGURE 14
Arm Out → Shear Out
Bucket Dump → Jaws Open
FIGURE 13
Third Member Control
Note: When installed as a third member, use the excavator auxiliary control to open and close the jaws.
Bucket Curl → Shear In
FIGURE 15
Bucket Dump → Shear Out
FIGURE 16
OPERATING TIPS
• The control levers should be moved in a gradual, deliberate way rather than with jerky, abrupt movements. Jerky
movements will provide a rough ride in the cab and could give the appearance of instability.
• Avoid handling long, heavy materials o center. Excessive weight held out to one side can force the attachment to
rotate or “Back-drive”. Back-driving puts increased strain on the rotation system and, if done continually, can lead to
rotation component problems. The rotator is for positioning only.
• Do not apply excavator force or weight at either end of the upper shear in an attempt to un-jam the shear or to cut
materials that are too large.
• Avoid handling long, heavy materials o center.
18 | MSD Legend Series Operation & Maintenance Manual
• When processing oversized material, make partial bites to start the breakage and then back o before making the
next partial bite. This will allow the broken material to fall away between bites.
• When processing any rigid member, use the rotator to square the jaws to the cut. If the jaws are not square, the
rotator will back-drive to adjust to the cut.
• When shearing large steel members, such as I-beams or tubing, try doing it in two cuts rather than one. Pierce the
material about halfway through with the rst cut, and then nish it o with the second cut.
• The shear jaws are best capable of processing light, thinner gauge materials immediately after performing
blade maintenance. When processing larger materials, the condition of the blades are not as critical. See “Blade
Maintenance” on page 26.
• Sort your scrap to get the highest capacity from the attachment.
• Start processing smaller materials and work up to larger materials. This will help you learn the limitations of the
machine and will allow the machine to warm up properly.
• Understand that the attachment does have limits. Sometimes it may be necessary to downsize very large material
by another method before the attachment can process it eectively.
• Cut material deliberately. Do not plunge the jaws into a pile of material and cut indiscriminately.
• Keep the attachment properly maintained. Jaws with excessive blade gaps or dull teeth are much less eective.
Lack of maintenance can lead to greater problems and potential downtime.
• Only use the force of the cylinder to cut material. Do not attempt to apply other forces on the shear to aid in material
processing.
• The rotation function is for positioning only. Do not use it for bending, breaking or prying.
BLEED THE SHEAR HYDRAULIC CIRCUIT
Air must be bled out of the hydraulic circuit prior to operation. Air in the system leads to cavitation, oxidation of the
oil and excessive heat. These conditions promote hydraulic oil break-down, contamination, noise, sluggish operation,
reduced component life and potential cylinder damage.
1. Start with the shear in the vertical position.
2. Set the excavator at idle speed.
3. Slowly open the jaws until a noticeable change in tone of the excavator is heard, indicating a full cylinder. Release
the controls and do not continue to apply full operating pressure to the cylinder.
4. Slowly close the jaws until the cylinder rod is extended approximately 1/4 stroke.
5. Open the jaws to retract the cylinder all the way.
6. Repeat steps 3 and 4. Extend the cylinder a quarter stroke more each time, until you reach full stroke.
7. Slowly cycle back and forth, at least ve times, to full stroke. Be careful not to apply full operating pressure to the
cylinder at this time.
8. Check the base machine hydraulic uid level and ll if necessary.
9. Slowly extend and retract the excavator cylinder to it’s limits. Check for interference between the attachment and
the excavator boom or stick. Check the hydraulic lines that connect to the attachment. Ensure they are not rubbing
or becoming damaged in any way. Contact your dealer immediately if interference occurs.
MSD Legend Series Operation & Maintenance Manual | 19
BLEED INSITE
1. Remove the cover from the InSite box.
2. Connect a bleed hose (part number 227831) to the CW and CCW bleed couplers on the InSite control box. Be aware
that the shear may move slightly when connected.
Note: If you have a non-rotating shear, you will not have CW and CCW bleed couplers.
Do not connect the CW or CCW connections to the ROD or
BORE connections. Seal damage and unexpected movement
may result.
Bleed Hose
CCW Bleed Coupler CW Bleed Coupler
Clear all persons and equipment from the area of operation
and machine movement. NEVER move loads over people or
equipment. When viewing the operation of the attachment,
maintain a safe distance of at least 30 feet (10 meters).
3. Power up the excavator and make one full rotation in both the clockwise and counter clockwise directions.
4. Power down the excavator and relieve hydraulic pressure.
5. Disconnect the bleed hose from the CW and CCW bleed couplers.
Do not connect the CW or CCW connections to the ROD or
BORE connections. Seal damage and unexpected movement
may result.
20 | MSD Legend Series Operation & Maintenance Manual
6. Connect a bleed hose (part number 227831) to the ROD and BORE bleed couplers on the InSite control box.
Bleed Hose
ROD Bleed Coupler
BORE Bleed Coupler
Clear all persons and equipment from the area of operation
and machine movement. NEVER move loads over people or
equipment. When viewing the operation of the attachment,
maintain a safe distance of at least 30 feet (10 meters).
7. Power up the excavator and fully open and close the shear jaws.
8. Power down the excavator, relieve hydraulic pressure and remove the bleed hose from the bleed couplers.
CHECK FOR LEAKS
Keep hands and body away from pinholes and nozzles which
can penetrate the skin, causing serious injury. Use a piece of
cardboard to search for leaks.
1. Starting at idle, or low hydraulic ow, operate the shear.
2. Visually inspect the attachment for leaks.
3. Set the hydraulic power supply to full operation ow and pressure.
4. Visually inspect the attachment for leaks.
5. Check the hydraulic oil reservoir and ll as stated in the excavator manual.
Other manuals for MSD Series
1
This manual suits for next models
9
Table of contents
Other Labounty Power Tools manuals
