laguna iFlux 10 Elite User manual

10HPBAG FILTER
DUST COLLECTOR

10HP Bag Filter Dust Collector Manual
2
TABLE OF CONTENTS
Important Safety Instructions
Safety Guidelines - Definitions
General Safety Rules
Additional Safety For Dust Collectors
Power Connections
Motor Specifications
Grounding Instructions
Key Features and Components
Functional Description
Product Specifications
Assembly
General Tool Assembly
Maintenance Procedures
Cleaning the Filter
Routine Inspection
Trouble Shooting
Parts breakdown and parts list

10HP Bag Filter Dust Collector Manual
3
IMPORTANT SAFETY INSTRUCTIONS
READ AND UNDERSTAND ALL WARNINGS AND
OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT. Failure to
follow all instructions listed below, may result in electric shock, fire, and/or
serious personal injury or property damage.
Woodworking can be dangerous if safe and proper operating procedures are
not followed. As with all machinery, there are certain hazards involved with
the operation of the product. Using the machine with respect and caution will
considerably lessen the possibility of personal injury. However, if normal
safety precautions are overlooked or ignored, personal injury to the operator
may result. Safety equipment such as guards, push sticks, hold-downs,
featherboards, goggles, dust masks and hearing protection can reduce your
potential for injury. But even the best guard won’t make up for poor
judgment, carelessness or inattention. Always use common sense and
exercise caution in the workshop. If a procedure feels dangerous, don’t try it.
Figure out an alternative procedure that feels safer. REMEMBER: Your
personal safety is your responsibility.
This machine was designed for certain applications
only. We strongly recommend that this machine not be modified and/or used
for any application other than that for which it was designed. If you have any
questions relative to a particular application, DO NOT use the machine until
you have first contacted the manufacturer to determine if it can or should be
performed on the product.
If you have any questions relative to its application DO NOT use the product
until you have contacted the manufacturer and we have advised you.
When using an electrical appliance, basic precautions should always be
followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING (THIS APPLIANCE)
To reduce the risk of fire, electric shock, or injury:
1. Do not leave appliance when plugged in. Unplug from outlet when not in
use and before servicing.
2. Do not use outdoors or on wet surfaces
3. Do not allow to be used as a toy. Close attention is necessary when used
by or near children.
4. Use only as described in this manual. Use only manufacturer’s
recommended attachments.

10HP Bag Filter Dust Collector Manual
4
5. Do not use with damaged cord or plug. If appliance is not working as it
should, has been dropped, damaged, left outdoors, or dropped into water,
return it to a service center.
6. Do not pull or carry by cord, use cord as a handle, close a door on cord, or
pull cord around sharp edges or corners. Do not run appliance over cord.
Keep cord away from heated surfaces.
7. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
8. Do not handle plug or appliance with wet hands.
9. Do not put any object into openings. Do not use with any opening blocked;
keep free of dust, lint, hair, and anything that may reduce air flow.
10. Keep hair, loose clothing, fingers, and all parts of body away from
openings and moving parts.
11. Turn off all controls before unplugging.
12. Use extra care when cleaning on stairs.
13. Do not use to pick up flammable or combustible liquids, such as gasoline,
or use in areas where they may be present.
14. Connect to a properly grounded outlet only. See Grounding Instructions.
SAVE THESE INSTRUCTIONS
1. Read and understand the warnings posted on the machine and in this
manual. Failure to comply with all of these warnings may cause
serious injury.
2. Replace the warning labels if they become obscured or removed.
3. This Dust Collector is designed and intended for use by properly
trained and experienced personnel only. If you are not familiar with
the proper and safe operation of this type of dust collector, do not use
until proper training and knowledge have been obtained.
4. Do not use this machine for other than its intended use. If used for
other purposes, LAGUNA TOOLS INC., disclaims any real or implied
warranty and holds itself harmless from any injury that may result
from that use.
5. Always wear approved safety glasses/face shields while using this
machine.
6. Before operating this dust collector, remove tie, rings, watches and
other jewelry, and roll sleeves up past the elbows. Remove all loose
clothing and confine long hair. Non-slip footwear or anti-skid floor
strips are recommended. Do not wear gloves.
7. Wear ear protectors (plugs or muffs) during extended periods of
operation.

10HP Bag Filter Dust Collector Manual
5
8. Some dust created by power sanding, sawing, grinding, drilling and
other construction activities contain chemicals known to cause cancer,
birth defects or other reproductive harm. Some examples of these
chemicals are:
•Lead from lead based paint.
•Crystalline silica from bricks, cement and other masonry
products.
•Arsenic and chromium from chemically treated lumber.
Your risk of exposure varies, depending on how often you do this type
of work. To reduce your exposure to these chemicals, work in a well-
ventilated area and work with approved safety equipment, such as
face or dust masks that are specifically designed to filter out
microscopic particles.
9. Do not operate this machine while tired or under the influence of drugs,
alcohol or any medication.
10.Make certain the switch is in the OFF position before connecting the
machine to the power source.
11.Make certain the machine is properly grounded.
12.Make all machine adjustments or maintenance with the machine
unplugged from the power source.
13.Form a habit of checking to see that all extra equipment such as
adjusting keys, wrenches, scrap, stock, and cleaning rags are removed
away from the machine before turning on.
14.Keep safety guards in place at all times when the machine is in use. If
removed for maintenance purposes, use extreme caution and replace
the guards immediately when maintenance is complete.
15.Make sure the dust collector is on a flat even surface and the wheels
locked in place before use.
16.Check damaged parts. Before further use of the machine, a guard or
other part that is damaged should be carefully checked to determine
that it will operate properly and perform its intended function. Check
for alignment of moving parts, binding of moving parts, breakage of
parts, mounting and any other conditions that may affect its operation.
A guard or other part that is damaged should be properly repaired or
replaced.
17.Provide for adequate space surrounding work area and non-glare,
overhead lighting.

10HP Bag Filter Dust Collector Manual
6
18.Keep the floor around the machine clean and free of scrap material, oil
and grease.
19.Keep visitors a safe distance from the work area. Keep children
away.
20.Make your workshop child proof with padlocks, master switches or by
removing starter keys.
21.Give your work undivided attention. Looking around, carrying on a
conversation and “horse-play” are careless acts that can result in
serious injury.
.
22.Maintain a balanced stance at all times so that you do not fall or lean
against the dust collector. Do not overreach or use excessive force to
perform any machine operation.
23.Use the right tool at the correct speed and feed rate. Do not force a
tool or attachment to do a job for which it was not designed. The right
tool will do the job better and safer.
24.Use recommended accessories; improper accessories may be
hazardous.
25.Maintain machinery with care. Follow instructions for lubricating and
changing accessories.
26.Turn off the machine before cleaning. Use a brush or compressed air
to remove dust or debris — do not use your hands.
27.Do not stand on the machine. Serious injury could occur if the machine
tips over.
28.Never leave the machine running unattended. Turn the power off and
do not leave the machine until it comes to a complete stop.
Familiarize yourself with the following safety notices used in this manual:
SAFETY GUIDELINES - DEFINITIONS
This manual contains information that is important for you to know and
understand. This information relates to protecting YOUR SAFETY and
PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information,
we use the symbols below. Please read the manual and pay attention to
these sections.

10HP Bag Filter Dust Collector Manual
7
Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
Used without the safety alert symbol indicates
potentially hazardous situation which, if not avoided, may result in property
damage.
GENERAL SAFETY RULES
WARNING FAILURE TO FOLLOW THESE RULES
MAY RESULT IN SERIOUS PERSONAL INJURY.
FOR YOUR OWN SAFETY, READ AND UNDERSTAND THE INSTRUCTION
MANUAL BEFORE OPERATING THE MACHINE. Learn the unit’s application
and limitations as well as the specific hazards peculiar to it.
KEEP WORK AREA CLEAN. Cluttered areas and benches invite accidents.
DON’T USE IN DANGEROUS ENVIRONMENT. Don’t use this unit in damp
or wet locations, or expose it to rain. Keep work area well-lighted.
KEEP CHILDREN AND VISITORS AWAY. All children and visitors should be
kept a safe distance from work area.
DISCONNECT UNIT before servicing.
CHECK DAMAGED PARTS. Before further use of the unit, properly repair or
replace any part that is damaged.

10HP Bag Filter Dust Collector Manual
8
FAILURE TO FOLLOW THESE RULES MAY RESULT
IN SERIOUS INJURY.
ADDITIONAL SAFETY FOR DUST COLLECTORS
Intended use. This dust collector is only intended for collecting wood dust
and chips from woodworking machines. Do not use this dust collector to
collect metal, dirt, pebbles, drywall, asbestos, lead paint, silica, liquids,
aerosols, or any flammable, combustible, or hazardous materials.
Hazardous dust. Dust created while using machinery may cause cancer,
birth defects, or
long-term respiratory damage. Be aware of dust hazards associated with
each work piece material, and always wear a NIOSH-approved respirator to
reduce your risk.
Dust allergies. Dust from certain woods may cause an allergic reaction in
people and animals.
Make sure you know what type of wood dust you will be exposed to in case
there is a possibility of an allergic reaction.
Wear respirator. Fine dust that is too small to be caught in the filter will be
blown into the ambient air during operation. Always wear a NIOSH-approved
respirator during operation and for a short time after to reduce your risk of
permanent respiratory damage.
Emptying dust. When emptying dust from the collection container, wear a
respirator and safety glasses. Empty dust away from ignition sources and
into an approved container.
Disconnecting power supply. Turn the switch off, disconnect the dust
collector from the power supply, and allow the impeller to come to a
complete stop before leaving the machine unattended or doing any service,
cleaning, maintenance, or adjustments.
Suspended dust particles and ignition sources. Do not operate the dust
collector in areas were explosion risks are high. Areas of high risk include,
but are not limited to, areas near pilot lights, open flames, or other ignition
sources.
Fire suppression. Only operate the dust collector in locations that contain a
fire suppression system or have a fire extinguisher nearby.
Impeller hazards. Do not place your hands or tools near the open inlet
during operation for any reason. The powerful suction could easily cause
accidental contact with the impeller, which will

10HP Bag Filter Dust Collector Manual
9
cause serious personal injury or damage to the machine. Always keep small
animals and children away from open dust collection inlets.
Avoiding sparks. Do not allow steel or rocks to strike the impeller—this
may produce sparks.
Sparks can smolder in wood dust for a long time before a fire is detected. If
you accidentally cut
Into wood containing tramp metal (nails, staples, spikes, etc.), immediately
turn off the dust collector, disconnect it from power, and wait for the
impeller to stop—then empty the collection container into an approved
airtight metal container.
Operating location. To reduce respiratory exposure to fine dust, locate
permanently installed dust collectors away from the working area, or in
another room that is equipped with a smoke detector. Do not operate the
dust collector in rainy or wet locations—exposure to water may create a
shock hazard or decrease the life of the machine.
Static electricity. Plastic dust lines generate high amounts of static
electricity as dust chips pass through them. Although rare, sparks caused by
static electricity can cause explosions or fire. To reduce this risk, make sure
all dust lines are thoroughly grounded by using a grounding wire.
Regular cleaning. Regularly check/empty the collection bags or drum to
avoid the buildup of fine dust that can increase the risk of fire. Make sure to
regularly clean the surrounding area where the machine is operated—
excessive dust buildup on overhead lights, heaters, electrical panels, or other
heat sources will increase the risk of fire.
This means that if precautions are not heeded, it may result in minor injury
and/or possible machine damage.
This means that if precautions are not heeded, it may result in serious injury
or possibly even death.
SAVE THESE INSTRUCTIONS.
Refer to them often and use them to instruct others.

10HP Bag Filter Dust Collector Manual
10
POWER CONNECTIONS
Electric drawing:

10HP Bag Filter Dust Collector Manual
11
MOTOR SPECIFICATIONS
Your machine is wired for 220V, 60 HZ alternating current.
Before connecting the machine to the power source, make
sure the switch is in the “OFF” position.
GROUNDING INSTRUCTIONS
THIS MACHINE MUST BE GROUNDED WHILE IN USE
TO PROTECT THE OPERATOR FROM ELECTRIC SHOCK.
1. This appliance must be connected to a grounded metal, permanent wiring
system; or an equipment-grounding conductor must be run with the circuit
conductors and connected to the equipment-grounding terminal or lead on
the appliance.
The installer, such as a qualified electrician, cut (or bend over) and insulate
the grounding conductor from a field wiring supply cable.
In the event of certain types of malfunctions or breakdowns, grounding
provides a path of least resistance for electric current—in order to reduce the
risk of electric shock.
Improper connection of the equipment-grounding wire can result in a risk of
electric shock. The wire with green insulation (with or without yellow stripes)
is the equipment-grounding wire. If repair or replacement of the power cord
or plug is necessary, do not connect the equipment-grounding wire to a live
(current carrying) terminal.
Check with a qualified electrician or service personnel if you do not
understand these grounding requirements, or if you are in doubt about
whether the tool is properly grounded. If you ever notice that a cord or plug
is damaged or worn, disconnect it from power, and immediately replace it
with a new one.
Full Load a mperage Draw
Amp draw at 220V ( p r e wi r e d ) .................. 28Am ps
Amp draw at 440V ……………….. .................. 14 Am ps
Power Supply Circuit Requirements
The power source c i r cu i t for your m a ch i ne must be grounded and
rated for
the amperage g iv en below. Never replace a circuit breaker
on an exist ing circuit with one of higher amperage without consulting a
qualified
electrician to ensure compl i ance with wiring codes. If you are
unsure about the wiring codes in your area or you plan to connect
your machine to a shared circuit, consult a qualified electrician.
C i r c u i t Size ( 220 V ) .................................. 50 A m p s
C i r c u i t Size ( 440 V ) .................................. 30 A m p s

10HP Bag Filter Dust Collector Manual
12
IN ALL CASES, MAKE CERTAIN THE RECEPTACLE IN
QUESTION IS PROPERLY GROUNDED. IF YOU ARE NOT SURE, HAVE A
QUALIFIED ELECTRICIAN CHECK THE RECEPTACLE.
220V Three-Phase Operation
The motor supplied with your machine is a 220 volt motor. It is shipped
ready-to-run for 220 volt operation.
This unit is equipped with a phase shortage protector. When you have
connected this unit to the power source and push the on button with no
response. Open the control box and change the power cord connections.
Swap any two of the connections in the figure below.
440V Conversion
This unit can be rewired for 440V operation. This rewiring job consists of
disconnecting this cyclone from the power source, changing the control box
and rewiring the motor.
The conversion components have been supplied with this cyclone. Please
make sure to use the components supplied.
When complete, the rewiring job must be inspected by a qualified electrician
before the cyclone is connected to the power source. Follow the steps below
and refer to the wiring diagrams.
1. Disconnect the cyclone from the power source.
2. Open the control box and identify the overload relay and the
transformer.
3. Replace the overload relay with the one included in the conversion
kit and turn the AMP dial to 14A.

10HP Bag Filter Dust Collector Manual
13
4. Move the R1 wire on the transformer from the 220V terminal to
the 440V terminal. Remove the T1 wire from the 0 terminal to the
top O terminal. (See figure below)
5. Open the motor junction box, rewire the motor terminals for 440V
power. (See figure below). Close the motor junction box.

10HP Bag Filter Dust Collector Manual
14
CONTROL PANEL DESCRIPTION
ON/OFF
SWITCH
REBOOT
SWITCH
AMP
METER

10HP Bag Filter Dust Collector Manual
15
PRODUCT SPECIFICATIONS
Motor Specs:
10 HP
Electrical Specs:
220V/440V / 60Hz / 3PH / 1720 RPM
Running AMP
28A at 220V; 14A at 440V
Air Volume:
5500CFM (cubic feet per minute)
Max. static pressure
6.5 Inches of water
Fan size
22”
Inlet:
Ø15”
Switch
Control box
Machine weight
1069 lbs ( 485kgs)
Shipping weight
1113 lbs ( 505kgs)
Filter Media
filtering area: 38m2 (409ft2)
Cartridge Filter
1 Micron D.168xH1800mm Filter bags x40pcs

10HP Bag Filter Dust Collector Manual
16
GENERAL TOOL ASSEMBLY
Tools Required
Open end wrench 12 (not supplied)
Open end wrench 14 (not supplied)
Open end wrench 17 (not supplied)
SEVERE LACERATION HAZARD. TURN THE UNIT “OFF”,
DISCONNECT THE UNIT from the power source and wait 2-
1/2 minutes to allow time for internal rotating components to stop before
installing or removing accessories, before adjusting or changing set-ups,
clearing clogs or when making repairs. For your own safety, do not connect
the machine to the power source until the machine is completely assembled.
Please also make sure that you read and understand the entire instruction
manual.
ASSEMBLY TIME ESTIMATE 4 hour to 5 hours
DISCONNECT THE MACHINE FROM THE POWER SOURCE!
1. MANUAL BAG CLEANING
SHAKER
Take the housing assembly with
the top filter bags; the shaker has
already been set in place inside
the filter bags. (Fig. 1) You need
to lift the upper frame (Fig. 3) and
take the triangular tips and bolt
onto the upper frame using the
hex bolts 3/8”, flat washers 3/8”
and lock nuts 3/8”. (Fig. 2) Do not
completely fasten, as you will
need it to be movable to clean the
filter bags. You will need to do the
same for the opposite side.
Fig.1
Fig.2
Fig.3

10HP Bag Filter Dust Collector Manual
17
2. TOP FILTER BAG
SUPPORT RODS
With the help of three other
people; you need to lift the upper
frame and insert the top filter bag
support rods (Fig. 4). After
inserting it into the upper frame,
make sure to use the hex bolts
5/16” to tighten each rod in
place. Each rod needs to be
secured in two places, one on the
top (Fig. 5) and one at the
bottom (Fig. 6) Check each filter
bag for any loose connections
(Fig. 7) to prevent any dust
leakages.
Fig.4
Fig.6
Fig.5
Fig.7
3.
ASSEMBLE INTAKE
FLANGE TO MOTOR
HOUSING
Take the intake flange and
assemble to the motor housing
using hex bolts 3/8” and flat
washers 3/8”.
Fig.8
Fig.9
4. ASSEMBLE INTAKE
ADAPTER TO THE
FLANGE
Take the intake adapter with five
5” ports and assemble to the
intake flange.
Fig.10

10HP Bag Filter Dust Collector Manual
18
5.
ASSEMBLE MOTOR
HOUSING TO FILTER BAG
HOUSING
Use a crane to lift the motor
housing up to about 5 feet high. Be
careful that the motor housing does
not swing around and cause injury.
Use a fork lift and place a wooden
pallet on the forks that will be used
to lift the filter bag housing. Lift to
the same height as the motor
housing at 5 feet (Fig. 11). Use the
hex bolts 3/8”, flat washers 3/8”
and lock nuts 3/8” to assemble the
two together.
6.
ASSEMBLE LEG STANDS
Take the four leg stands and
assemble to each corner using
the hex bolts 3/8” and flat
washers 3/8” (Fig. 12 and Fig.
13). It does not matter which
After you have completed
assembling them, make sure to
take the vibration pads (Fig. 14)
and set underneath each leg
before lowering forklift and crane
to set the unit on the ground.
Fig.11
Fig.12
Fig.13
Fig.14

10HP Bag Filter Dust Collector Manual
19
7. ASSEMBLE CONTROL
PANEL
Take control panel and assemble
to the motor housing using hex
bolts 3/8”, flat washers 3/8” and
lock nut 3/8”. (Fig.15)
There are three points on the top
of the control panel to secure
with the hex bolts. And two
points on the leg stand to secure
with the hex bolts. (Fig. 16)
Make you tighten and fasten to
secure the control panel in place.
8.
ASSEMBLE WHEELS
ONTO DRUM
Take the eight wheels and
assemble to the bottom of each
drum (four each) using hex bolts
5/16” and flat washers 5/16”.
(Fig. 17 and Fig. 18)
Fig.15
Fig.16
Fig.17
Fig.18

10HP Bag Filter Dust Collector Manual
20
9.
ASSEMBLE EZ LIFT
HANDLE
First remove the three hex bolts
3/8”, flat washers 3/8” and lock
3/8” from underneath the lower
filter housing. Set aside for use
when you assemble the ez lift
handle. The inner row of bolts will
need to bolt on with one hand/arm
reaching in from inside the filter
housing. Do the same for the other
handle. (Fig. 19 and Fig. 20)
Take the ez lift handle kit, both
handles are the same it does not
matter which one you take; make
sure you have the right side facing
upwards to match the bolt holes
on the filter housing. (Fig. 21)
Aerial view
Side view
Fig.19
Fig.20
Fig.21
10. ASSEMBLE EZ LIFT
HANDLE TO DRUM LID
One person must stand in the front
where the handle kit is, and hold up
the two side bars. Take note that the
handle must be in the lower position,
push the drum kit underneath the
filter housing to make the attachment
(Fig. 22). Use the hex bolts 3/8” flat
washers and lock nuts 3/8” to
assemble the side bar to the drum lid
spring support base on each side (Fig.
23). Do the same for the other drum.
Fig.22
Fig.23
