Lainly CS1 User manual
STEP ONE
ank you for purchasing your new Lainly Portable Partition Wall.
Please use these assembly instructions to get everything set up.
Before you begin building, confirm you’ve got everything you need to continue
– and make sure there’s a Phillips or flathead screwdriver handy.
• Remove the two base feet and position them to either side.
• Remove the two bottom poles but don’t connect them yet.
Screws with Washers (Qty: 8)
Wheels (Qty: 4)
Side Poles (Qty: 4)
Corner Connectors (Qty: 2)
Base Feet (Qty: 2)
Bottom Poles (Qty: 2)
Top Poles (Qty: 2)
Fabric Wrap (Qty: 1)
PARTS & MATERIALS
• To correctly position the base feet just make sure that the screw holes for
the wheels are facing down (toward the floor).
• e screw holes for the bottom pole connections should be facing each
other when laid out on the floor.
• Each bottom pole should be aligned with both the pin clip and the hole for
the pin clip facing up.
• No need to clip the poles together right now though, we will get to that a
few steps later.
STEP TWO
STEP TWO
(CONTINUED)
• Grab your screwdriver and attach each bottom pole to its respective base
foot using two screws and washers for each side.
• Now you’re ready to install the wheels. We suggest having one locking
wheel on each base foot.
• Simply screw each wheel into the bottoms of each base, and voila!
You’re ready to roll!
STEP THREE
STEP FOUR
• Clip the two bottom poles and base feet together until the pin clip
clicks into place.
• Unwrap and set aside the two side poles with T-bar base plates. ese will
connect directly to the base feet.
• Using two screws and washers for each side, simply attach each side pole
to its respective base foot.
STEP FIVE
STEP SIX
STEP FIVE
(CONTINUED)
• Be sure when positioning the poles to the base feet that the pin clips on
each pole are facing inward on the frame and facing each other.
• Take the remaining side poles you unwrapped (it doesn’t matter which side
pole you use for each connection) and just clip those together their bottom
halves already connected.
• When you hear the click you know its secure.
• is might be the easiest part of the entire assembly – grab the two corner
connectors and slide them into place on the end of each side pole.
• You know it’s in the correct position if you can read (le to right) the Lainly
logo imprinted on each connector.
• ere should be two poles labeled “Top” le. Now is the time to unwrap
them and connect together.
• When the pin clip clicks into place you are good to go.
STEP SEVEN
STEP EIGHT
• Pick either side to start and slide the corner connector into the open end of
the top pole.
• Congrats on building the frame! Take a minute to admire your work.
• Now let’s give it some style.
STEP NINE
• Unpack and unwrap the fabric cover. Open the hook and loop strips and
zippers on the bottom.
• Don’t be intimidated, we designed our fabric to be installed like you are
putting on a t-shirt – a giant t-shirt that fits onto a steel frame with
wheels.
• Whether installing solo or with a buddy, place the open side lengthwise
along the top of the frame from corner to corner. is is just to get the
fabric secured to the frame. You can drape the extra fabric over the frame
to make it easier to maneuver for this step.
Hook and Loop Strips and Zippers on the Bottom
STEP TEN
STEP ELEVEN
STEP TWELVE
• Ensure the semi-circle on each side aligns with the top of each side pole.
• Make sure you don’t stand on or put your full weight on the base feet and
wheels during this process.
• Gently ease the fabric down each side pole until the bottom edge of the
fabric aligns with the base pole.
• Adjust as needed and don’t worry if the frame flexes or moves during
installation – we designed it to flex when needed.
STEP THIRTEEN
• Once the fabric is secured to the frame, fasten the hook and loop strip in
the middle and then close the zippers on each side.
Fabric Installation Note:
Because we design our fabric wraps to fit our frames very precisely, some
customers prefer not to use the zipper and hook and loop connectors on the
bottom. is is a personal choice but will not affect the look or performance of
the unit.
Our fabric wraps are sewn to fit each frames exact measurements so whether
you use the hook and loop straps / zippers or not your fabric will stay securely
on the frame and will not wrinkle or bunch up.
