Lakes QUADRANT Installation and operating instructions

QUADRANT/ OFFSET QUADRANT
Installation / Maintenance Instructions
Rev 01/19

IMPORTANT NOTES :
Please Read Carefully & retain these instructions for Future Reference.
1. For ease & safety we advise that two persons assemble this product.
2. Protect shower tray surfaces at all times.
3. Exposed glass corners / edges MUST NOT contact hard surfaces at any time.
4. Check for cables, pipes etc before drilling walls.
5. Ensure all surfaces are dry, clean & free of loose debris / dust.
6. Unpack goods with care (small parts can become lodged in packaging & inadvertently discarded).
Check parts supplied against parts & fittings listed herein. Damaged parts / omissions may be
resolved by calling Lakes Bathrooms Helpline.
7. Whilst precautions are taken in manufacture, care must be taken when handling as rail ends may
have sharp edges.
8. Before commencing, check :
a) shower tray (or base) is level & completely sealed to finished / tiled walls.
b) finished walls are sound & free of cracks, loose tiles / grout.
8. AFTER INSTALLATION, DO NOT ‘WET’ ENCLOSURE FOR 48 HOURS TO ENSURE FULL CURE OF
SILICONE SEALANT.
USE :
General Care & Maintenance.
Provided this product is installed & operated in accordance with these instructions, problems should
not arise. However should maintenance be required it should be carried out by a competent person
with reference to these instructions. Before any work is carried out the root cause of the problem
must be identified. Lakes Bathrooms service engineers are available if necessary to consult / carry out
remedial work. Call Lakes Bathrooms HELPLINE.
Cleaning.
(Every one to two weeks depending on local water {hardness} conditions).
All glass panels in this product have a hydrophobic coating aiding ‘runoff’ of water droplets, reducing
the need for frequent cleaning. For best appearance / product life however, regular cleaning is
recommended.
Use ONLY mild soap / detergent solutions to clean. Rinse with water, squeegee glass panels & wipe
frames dry with a soft cloth. Under no circumstances should abrasive, caustic or scouring products be
used. Non compliance with these cleaning instructions may cause decorative finishes to deteriorate &
could adversely affect safe operation of the enclosure.
Daily Care.
To prevent the build up of limescale, do not allow water droplets to dry on glass or frames. After
showering, rinse with water, remove droplets from glass with a squeegee & wipe frame with a soft
cloth.
Customer Service.
Quality Guarantee : Lakes Bathrooms Ltd guarantee Shower Doors & Enclosures against any
manufacturing or material defects for the lifetime of the product. We will resolve defects free of charge
by repairing / replacing parts as we feel necessary. To be ‘free of charge’ service work must be carried
out by Lakes Bathrooms or approved agents.
Seals are considered 'wear & tear' parts, as such they are guaranteed for 12 months from purchase.
Not Covered by this Guarantee : Damage or defects that result from improper installation, improper
use, or lack of maintenance (including limescale buildup). Damage or defects that result from repairs /
modifications undertaken by unauthorized persons. This guarantee is in addition to statutory & other
legal rights.
What to do if something goes wrong : Should the product not function correctly on initial use, firstly,
contact the installer to check that unit installation & commissioning are in accordance with these
instructions. Should this not resolve difficulties or should performance decline, consult
‘Troubleshooting’ section to see if simple home maintenance is needed. Alternatively our HELPLINE staff
can assist, or if necessary arrange for a service engineer to visit.
Spares : We maintain extensive spare part stocks. Spares can be ordered / purchased from your retailer
in the first instance. Parts will normally be dispatched within two working days from order placement.

Top Wheel
Assy (4x)
(fitted to door glass)
SUPPLIED PARTS :
Panel Sub
Assy (2x)
Wall Rail
1850mm
(2x)
Bottom Wheel
Assy (4x)
(fitted to door glass)
Top Cap
(Panel Rail)
(1x LH & 1x RH)
Top Cap
(Wall Rail ~ 2x)
Centre Bracket
(2x)
Doorstop
Block (4x)
Doorstop
(Rubber) Buffer
(4x)
Door Glass
(2x)
Magnetic Seal
(2x)
Edge Seal
(2x 1831mm)
(2x 1760mm)
Handle Kit (2x)
comprising :
Handle
Top Knob
Bottom Knob
Screw (2 per kit)
Sleeve (2 per kit)
Washer (4 per kit)
4 x 45 long self tapping
screw (6x) ~ fig A.
8mm Wall Plug
(6x) ~ fig A.
3.5 x 10 long self tapping
pan head screw (6x) ~ fig G.
Cup Washer (6x) ~ fig G.
Decorative Screw Cover Cap (6x)
fig G.
3.5 x 12 long self tapping
countersunk screw (12x) ~ fig F.
Decorative Screw Cover Cap (12x)
fig F.

A
X
X
Wall Profile Position (To Inside) & Tray Protrusion
Size Dim’n X Dim’n Y (Minimum)
800 752mm 785mm
900 852mm 885mm
1000 952mm 985mm
1200 1152mm 1185mm
Lakes Offset Quadrant is fully reversible, so is suitable for fitting
to either right or left hand Trays.
Ensure tray is correctly levelled & that tray / wall (tile) joints are sealed &
cured over entire length of tray sides (See Fig A) prior to fitting enclosure.
DO NOT SEAL TRAY EDGES UPTO A FITTED ENCLOSURE !
Measure & mark wall rail Positions. (ensure rails do not overhang
tray edge).Mark fixing hole positions, drill, plug & affix wall rails.
Dia 8mm
Tile / Masonry
Drill Bit
Dia 2,8mm
HSS Drill Bit
Pencil
Screwdriver (Pozi Drive)
Spirit Level (with vertical ‘bubble’)
Wall / Tray Joint
Wall / Tray Joint
Wall / Wall Joint
Tools Required
Good quality Silicone
Sealant & applicator
Y
Tape
Measure
Standard Sizes Adjustment
Dim’n A & B
800mm 765 to 790mm
900mm 865 to 890mm
1000mm 965 to 990mm
Offset Sizes Adjustment
900800mm A= 865 to 890mm
B= 765 to 790mm
1000800mm A= 965 to 990mm
B= 765 to 790mm
1200800mm A= 1165 to 1190mm
B= 765 to 790mm
1200900mm A= 1165 to 1190mm
B= 865 to 890mm
A
B
RH tray
Shown
Ensure continuous
silicone sealant
bead before fitting
wall rails
dia4x40lg
Dia 3mm
HSS Drill Bit

B
Top Wheel ~ Screw Adjustable
(Assemble with Screw Head to Underside)
D
C
Bottom Wheel ~ Spring Loaded
(Assemble with Button to Top)
Door Assembly
(LH) (RH)
Fit Panels onto
Wall Rails
Handle Assembly
Washer
Sleeve
Screw

F
M3 5x12
CSK
.
E
Assemble centre brackets
& door stops ~ fit doorstop
rubber buffers to wheel side of block
Carefully engage door top
wheels onto respective
panel rails
|
(Bottom wheels may be
inserted into rail ends at
same time)
Slide Door to Open
Position
Press button & engage
wheels
in bottom rails
Apply silicone to both rail
faces of lower centre bracket as
indicated before fitting to rails.
After joining wipe off all visible
excess sealant.
15 ~ 20mm

H
G
M3 5x10 Pan Head.
Adjust Enclosure panels to give even
gap to tray edge all around.
From inside enclosure, using vertical rail
holes as a guide, drill (dia 2,8mm)
& using ‘cup’ washers & decorative caps
screw enclosure to wall rails (6 places).
Fit Magnetic seals to door (centre) edges.
(Note Seal Orientations)
Panel
Glass
Door
Glass
Fit Edge Seals to Door
& Panel glass Note : Seals may be wetted to ease assembly.
Dia 3mm
HSS Drill Bit

J
K
Use of good quality silicone sealant & cleaning / degreasing
of all joint areas is recommended.
Apply continuous silicone sealant bead as indicated EXTERNALLY ONLY
Fit Caps to wall &
panel vertical rails
Adjust door heights until
even & doors run smoothly
between stops. Adjust door
angles so that magnetic
seals hold doors closed
with no gaps. Turn adjusting
screw clockwise to raise
door.

BASIC TROUBLESHOOTING :
Door magnetic seals not meeting precisely / not holding :
Ensure magnetic seals are pushed fully onto door edge over entire door length.
Check door alignments & adjust if necessary (see fig J).
Check Magnetic Seal orientations (see fig H).
Door motion noisy / Door not running smoothly / Door loose on bottom rail :
Check for edge seals dragging on glass (can cause ‘clicking’ noise).
Check top wheels engaged properly in rails & roll smoothly along rails.
Check door height adjustment ~ raise doors so that spring loaded bottom wheels are in
contact with & roll smoothly along bottom rails.
Wheels & Grooves are factory greased, however over time this may disperse or become
contaminated by dust etc, cleaning of grooves & re application of sanitary silicone based
grease will restore & ensure smooth door motion.
Leakage :
The sealing method described in these instructions relies on a continuous seal being applied
between shower walls & tray before installing the enclosure (see fig A), it ensures a watertight
seal around the perimeter of the enclosure to the shower walls & tray.
In the unlikely event of an enclosure leak, water will be visible on the outside of the enclosure
itself, or around the perimeter silicone seal ONLY. Water / moisture appearing outside this area
(ie at floor level) is normally due to incorrect tray installation.
