INFLATABLE LIFERAFT
OWNER’S MANUAL
&
LOG BOOK

2

3
Contents
1. Safety Precautions
2. Introduction
3. Description of the Liferaft
4. Instructions for use of the Liferaft
5. Equipment of the liferaft
6. Advice on the transportation and the storage of the liferaft
7. Advice on maintenance and servicing of the liferaft
8. Immediate Action Card
9. Log Book

4
1. Safety Precautions
• TheLALIZASLeisure-Raftisdesignedforuseinemergencyonly.
• Donotexposeliferafttoheatorame.ContainscompressedCO2gas cylinder.
• Toavoidinjury,stayawayfromtheliferaftwhileitinates.
• Readowner’smanualbeforeuse.
• Donotuseitintemperaturesnotrecommended.
• Donotinateliferaftfortestorpracticeunlessit’sanemergency.Ination without
reasonmaycausedamagetothefabricsandothercomponentsoftheliferaft.
Furthermore,itmaydamagethevalisefabric.
• Donotrepacktheliferaftonyourown.Itisdesignedtofoldandtthevalisein
a certainway.Onlyauthorizedservicestationsshouldrepackandinspectthe
LALIZASLeisure-Raft.
• LALIZAS Leisure-Raft does not comply with any ISO, SOLAS or USCG
regulations.
• AlwayswearanapprovedbylocalauthoritiesPersonalFlotationDevice.
2. Introduction
This manual applies to the LALIZAS Inatable Liferaft series Leisure-Raft. The
LALIZASLeisure-Raftsareavailableinthefollowingtypes:
LALIZAS Product Code Specications
72200 4 persons with canopy
72201 4 persons without canopy
72202 6 persons with canopy
72203 6 persons without canopy

5
3. Description of the Liferaft
TheliferafthasanOperatingTemperatureof00Cto+500C and a stowage/drop height
ofmaximum4mabovethesea-level.
Theliferaftispackedinavalisewhichcanbestoredinaninternallockeraswell.The
liferaft container is manufactured by materials that are resistant to exposure of bad
weather.
Theliferaftcanbeup-rightedincaseofitbeingcapsizedanditisabletowithstand
thenumberofthepersonsitisdesignedtoaccommodatewhenitoats.Itautomatically
inatesbypullingthepainterlineandretainsitsnormalconditionwhenitisloadedwithall
thepersonsandtheequipment.Itsoorismanufacturedbywaterproofmaterials.
Themainbodyoftheliferaftconsistsofonebuoyantcompartment(containingsafety
valve)manufacturedbyNylonTPUcoated.Itisinatedthroughanon-returnvalve,ensuring
theotationoftheliferaft.Incasethebuoyancychamberisdamaged,thepump,thatis
includedinthestandardequipmentoftheLiferaft,canbeusedforrestoringthepressure.
Thecanopyoftheliferaft(forthemodelswithcanopy)whichisofvividcolorisdesigned
toprotectthepersonsintheliferaftagainstbadweatherconditions.Itbearsoneentrance
thatiseasilyindicatedandallowstheowofsufcientairforthepersonsonboard(even
when it is closed).
TheinationsystemoftheliferaftprovidesenoughCO2gastoinatethebuoyancy
chamberandbearsanonreturnvalveactivatedbyanoperatingheadthatisdrivenbythe
painter line.
For all models of the Leisure-Raft, gas cylinder used for ination is rellable. To
maintainthegoodoperationofgascylinder,itmustbeinspectedperiodicallybyaLALIZAS
authorized service station.
Picture 1. Valise of the liferaft

6
Picture 2. Basic Construct of the Liferaft
InthebelowDiagramoftheLALIZASLeisure-RaftthelocationoftheLiferaftttings
areincluded:
CANOPY
Sea Anchor
Painterline
Handpump
Canopy
Water Activated Light
Boarding Strap
Boarding Strap
Water Pockets
Water Pockets
ToppingOffValve
Lifeline
Raft Knife
Bailer
Canopy Kit Bag
CO2 InationSystem
Pressure Relief Valve
Boarding Handle
For codes equiped with
canopy 72201 and 72203

7
Table 1: Fittings of the Liferaft
FITTINGS
Painter line (6m) The portion of it coming out of the container is light resistant.
External lifelines Properforbeinggrasped,theydon’tslidefromhands.
Righting device Usedbyonepersoninordertorighttheliferaftwhencapsized.
Sea anchor (10m line) Connectedtotheliferaftbya10meterslongline.
Safety knife Inthesideoftheinletgascylindervalve,totheconnectionofthe
paintertotheraft.Connectedtotheliferaftbyalineofasuitable
length.Buoyant,withxedblade,roundedtips(sonodamageis
created to the liferaft in any case)
External light It turns on automatically when it comes in contact with water.
4. Instructions for use of the Liferaft
Ination of the liferaft
Whenthetimetousetheliferaftcomes,rstofallyoushouldsendalarmsandsignals
byallmeansandputonlifejacketsorotherprotectiveappliancesonboard.Youshouldalso
remembertocarryemergencypositionindicator(EPIRB),GPS,freshwaterandfoodas
muchaspossible.
Movetheliferaftfromthestowagepositiontoanopenplaceonthedeckoftheboat.
Takeoutthepainterlinemarkedfabriccovervaliseandpulloutapproximately2me-
tersofpainterline.Attachthepainterlinetoasolidpointonthedeckoftheboat(Picture
3) to secure the liferaft.
Takethevaliseandthrowitintothewater(Picture4).Thevaliseoftheliferaftwilloat.
Duringthetimeofthevalisefallingintothewater,thepainterlinewillbepulledout
continuously.Whenthevalisearrivesatthewatersurface,thestrongpullingoutofpainter
lineshallgoonimmediately(Picture5),untilthereleasecableconnectedtothepainterline
activates the operation head of the gas cylinder.
NEVER OPEN THE PACKAGE
Picture 3 Picture 4 Picture 5
09
07
05 A05 B
10
instruction
0605 C
08
D
D
09
07
05 A05 B
10
instruction
0605 C
08
D
D
09
07
05 A05 B
10
instruction
0605 C
08
D
D

8
Thegascylinderthenwillinatethebuoyancytubeoftheliferafttoitsfullshapeand
theliferaftwilloatonthewatersurface.Aftertheination,asmallnormalleakagemay
occurinordertostabilizethepressureofthechamber.Iftheliferaftisinupward-oating
positionafteritisfullyinated,pullthepainterlinetodrawtheliferaftclosetotheship.Ifthe
liferaftisinreversedpositionafteritisfullyinated,onepersonshallrightitovertoupward-
oatingpositioninthefollowingway:
Theoperatorshallgrabwithonehandthesidewhichisequippedwiththegascylinder,
pulltherightinghandleandturnitoveraboutthecylinder.Itwillbeeasierundercondition
of downwind.
Ifthepassenger’spositionisnotfarawayfromthewatersurface,heorshecanjump
intotheliferaftdirectly.Thepassengersfallenintothewatershallswimclosetotheliferaft,
andthenboardtheliferaftthroughboardingstrapaftertheyhavetakenoffshoesandsharp
objects.
Afterallthepassengershaveboardedtheliferaft,separatetheliferaftfromtheship
quicklybycuttingoffthepainterline.Checkthepositionofthesafetyknifeinthediagram
oftheliferaft(seePicture2).
Afterboarding,exceptseatingorderly,theoccupantsshallsearchanyothersinthe
waterandhelpthemtoboardtheliferaftbygivingprioritytotheinjuredones.Anyfainted
personsinthewatermustbeputonboardafterbeencarriedwiththeirbackclosetothe
tubeandliftedfromarmpits.Allthepersonsthatareonboardshallbeasdryandheated
aspossible.
When the liferaft is away from theabandonedshipandinasafeposition,afterchecking
thattheseaanchorisconnectedtotheLiferaftproperly,unrollitandlaunchitsoastoavoid
liferaftoatingtoofarawayfromthesinkingshipforthesakeofrescuingintime.
Maintain the liferaft in a good condition.
Installation of the Canopy
Forthemodelsequippedwithcanopyfollowtheinstructionsbelowtoinstallthecanopy.
• Findthecanopybagandopenit.
• Inatethecanopyarchusingtheredoraltube.
• Whendonewithination,assemblethecanopyarchwiththebuoyancychamber
usingthebucklesattheendsofthearch.
• Findthehook&looptapeontheinsideofthecanopyfabricandmatchthemwith
thehook&looptapeontheCanopyarch.
• PulltheorangefabricdownandhooktheclipsintheD-ringsonthebuoyancy
tube.
• Liftthecanopytillitisverticaltotheoor.
• Placethebottomofthecanopyoutsideoftheliferaft.
• Inordertoensureprotectionfromphysicalelementskeepthecanopydownand
closed.

9
Procedure is described in pictures below:
Sea Anchor
Whenboardedontheliferaft,throwtheseaanchortotheseainordertoprevent
liferaft from drifting.
5. Equipment and ttings of the liferaft
Theinstalledequipmentofeveryliferaftislistedinthefollowingtable:
09
07
05 A05 B
10
instruction
0605 C
08
D
D
09
07
05 A05 B
10
instruction
0605 C
08
D
D
09
07
05 A05 B
10
instruction
0605 C
08
D
D
Inate the canopy arch
using the red oral tube Match the Velcros of canopy and canopy arch
Lift the canopy arch
Assemble the canopy arch
using the buckles
Clip the canopy on the
D-rings Place the canopy outside of the buoyancy tube
Table 2:ListoftheEquipmentoftheLiferaft
No. Name Unit Quantity Comments
1 FabricBailer Pc 1For taking out water from the liferaft interior
2Sea-anchor Pc 1To prevent liferaft from drifting out of the search area
3 Pump Pc 1 Torestorethepressureofthechamberifitislow
4 Safety Knife Pc 1To cut painter line
5Owner’sManual Book 1 Contains:Instructions,Logbook,Immediateactions
6Water activated
Locator Light Pc 1Lights automatically when it comes in touch with water
7 Topping off valve Pc 1Usedtotthepumpandrestorepressureortodeate
the liferaft
09
07
05 A05 B
10
instruction
0605 C
08
D
D

10
6. Advice on the transportation and the storage of the liferaft
6.1Transportationoftheliferaft:
• When transporting or moving the liferaft use only the handle on the top of the
valise.
• When placing it down on surfaces put it with special care.
6.2Storageoftheliferaft:
• Beforeputtingtheliferaftinitslocationreadtheowner’smanual.Keeptheman-
ual in a safe position.
• Theliferaftmustalwaysbelocatedinadryplace,withoutobstacles
• Donotputweightsoranymetallicitemsinthemainbodyoftheliferaft.
• Itisalwaysnecessarytofollowtheregulationsthatareobligedabouttheinstal-
lationoftherescuemeansonboard.
• Theliferaftshouldneverbeusedasasteporasaseat.
• Theliferaftshouldneverbeattachedusingchainsoranydevicewhichisdifcult
tobeseparated.
• Youshouldinstallmore liferaftsonthe sameboat.If so,theliferafts mustbe
located with a certain distance one to the other.
• Itmustbestowedinsuchawaythatwouldnotsufferanycollisionsandwouldbe
protectedagainstanyfactorsbytheenvironmentelements.
• Iftheliferafthasmajordamagesonthevalise,youshouldcontactaLALIZAS
authorized Service Station.
• Thereisapossibilitythatsomeofthestandardttingsoftheliferaftmayaffect
theperformanceofacompass,soyoushouldkeeptheliferaftatleastonemeter
away from the compass.
• Grease,oil, fuel andvarious impurities maydamage the fabricand affectthe
lifetime and operation of the liferaft.
7. Maintenance and servicing of the liferaft
Advice on the servicing of the liferaft
Theliferaftshouldbeinspectedandservicedatintervalsnotlongerthanthreeyears.
Incaseofactivation,orexistenceofdamages,serviceitimmediately.Theinspectionand
servicemustbeperformedbyaLALIZASauthorizedServiceStation.LALIZASS.A.isnot
liableforanyinspectionorservicecarriedoutbyanunauthorizedServiceStation.
FormoreinformationonLALIZASworldnetworkofAuthorizedServiceStationsplease
refertothefollowinglink:http://www.LALIZAS.com/service.php

11
8. Immediate Action Card
1. CUTTHEPAINTERLINEANDGETCLEAROFTHEVESSEL
2. CHECKRAFTFORPROPERINFLATION.RAFTTUBESHOULDBEFIRM
3. LOOKFORANDPICKUPOTHERSURVIVORS
4. PICKUPANYFLOATINGEQUIPMENT
5. ENSURESEA-ANCHORSTREAMEDWHENCLEAROFVESSEL
6. SITLOWONTHEFLOORWITHYOURBACKTOWARDSTHETUBE
7. BAILOUTANYWATERTHATHASENTEREDTHERAFT
8. ACTIVATEANYEMERGENCYRADIOBEACONS,IFAVAILABLE
9. SET-UPCANOPY(IFEQUIPPED)
10. CLOSEUPENTRANCE
11. MAKEACALMESTIMATIONOFYOURSITUATION
12. KEEPCALM.DONOTMOVEUNLESSNECESSARY
Important Note: Makesurethatallthepartsoftheliferaftareinated.Ifthetubeof
theliferaftisdeated,youshouldrestorethepressurebyusingthepumpofthestandard
equipment of the liferaft. The pressure relief valve is usually located inside the liferaft. If
thereisaleakoftheinationgas,theraftmustbeventilatedusingthecanopyopening.
Water: Eliminatethewaterthathadenteredtheliferaftusingthebailerofthestandard
equipment of the liferaft

12
9. LOG BOOK
Instructions on how to keep the log book
A. Thelogbookofaliferaftshouldalwaysfollowtheliferaftinallitssuccessiveassignments.
B. The liferaft should be equipped with the same accessories and materials when it is
delivered and during its successive assignments afterward.
C. Theliferaftshouldbeinspected&servicedperiodically,whichmustbedoneonlyby
Service Stations authorized by LALIZAS. LALIZAS is not liable for any inspection and
servicecarriedoutbyanunauthorizedServiceStation.
D.In caseof loss,theft, orchange of names of the assigned ship, a new copy of this
manualmustberequestedfromLALIZASS.Awhowillsenditagainstpayment.
I. Specications
Type: LEISURE-RAFT
RatedCapacity: __________
SerialNo: ________________
ManufacturingDate: ______
PainterLineLength: ______
StowageHeight: __________
II. Ination System
CerticateNo.ofGasCylinder:
CylinderSerialNo.:
CylinderWorkingPressure:
EmptyCylinderWeight: ___
CO2 Weight: ______________
ToleranceofCO2: _________
TotalWeightofGasCylinder(excludingoperatinghead):
OperatingHeadType: _____________________________________ _______
PressureReliefValveType:
Non-returnInletValveType:
ToppingoffValveType: ___

13
Shipping Information
Ship’sName:
PortofRegistry:
Gas Cylinder Check
EmptyGasCylinderWeight: GascylinderSerialNo.
GasWeight(CO2):
WeightofGasandGasCylinder:
TotalWeight:
Notes:Beforegascylinderisinstalled,checktheweightofthecylinderandconrmthatitconformsthaton
themarking.Ifthereductionexceeds2%ofthestipulatedweightorexceeds100g(takethesmallervalueof
thetwo),thegascylinderisunqualied.
Liferaft Body Check
Liferaftbodychecking Parts replacement
ServiceConclusion:
ServiceRecordNo.:
SignatureandSealofServiceStation:
Shipping Information
Ship’sName:
PortofRegistry:
Gas Cylinder Check
EmptyGasCylinderWeight: GascylinderSerialNo.
GasWeight(CO2):
WeightofGasandGasCylinder:
TotalWeight:
Notes:Beforegascylinderisinstalled,checktheweightofthecylinderandconrmthatitconformsthaton
themarking.Ifthereductionexceeds2%ofthestipulatedweightorexceeds100g(takethesmallervalueof
thetwo),thegascylinderisunqualied.
Liferaft Body Check
Liferaftbodychecking Parts replacement
ServiceConclusion:
ServiceRecordNo.:
SignatureandSealofServiceStation:
III. Regular Check Records

14
Shipping Information
Ship’sName:
PortofRegistry:
Gas Cylinder Check
EmptyGasCylinderWeight: GascylinderSerialNo.
GasWeight(CO2):
WeightofGasandGasCylinder:
TotalWeight:
Notes:Beforegascylinderisinstalled,checktheweightofthecylinderandconrmthatitconformsthaton
themarking.Ifthereductionexceeds2%ofthestipulatedweightorexceeds100g(takethesmallervalueof
thetwo),thegascylinderisunqualied.
Liferaft Body Check
Liferaftbodychecking Parts replacement
ServiceConclusion:
ServiceRecordNo.:
SignatureandSealofServiceStation:
Shipping Information
Ship’sName:
PortofRegistry:
Gas Cylinder Check
EmptyGasCylinderWeight: GascylinderSerialNo.
GasWeight(CO2):
WeightofGasandGasCylinder:
TotalWeight:
Notes:Beforegascylinderisinstalled,checktheweightofthecylinderandconrmthatitconformsthaton
themarking.Ifthereductionexceeds2%ofthestipulatedweightorexceeds100g(takethesmallervalueof
thetwo),thegascylinderisunqualied.
Liferaft Body Check
Liferaftbodychecking Parts replacement
ServiceConclusion:
ServiceRecordNo.:
SignatureandSealofServiceStation:

15

LALIZAS Hellas
3Gounari,PiraeusP.C.18531,Greece
Tel.:+302104226274,Fax:+302104226273
e-mail:[email protected],www.lalizas.com
