Lambrecht AEM ECONOMY User manual

USER MANUAL
Wind Speed Sensor
ECONOMY

aem.eco
LAMBRECHT meteo |AEM | ECONOMY
page –2
Warranty
Please note the loss of warranty and non-liability by unauthorized manipulation of the system. You need a written
permission of the LAMBRECHT meteo GmbH for changes of system components. These activities must be
operated by a qualied technician.
The warranty does not cover:
1. Mechanical damages caused by external impacts (e. g. icefall, rockfall, vandalism).
2. 

3. Damages caused by improper handling, e. g. by wrong tools, incorrect installation, incorrect electrical
installation (false polarity) etc.
4. 
Maintenance
Maintenance of the sensor is not necessary.
Troubleshooting
If the sensor does not provide a signal, the following issues should be checked:
1. Does the cup rotor spin? If the sensor has no heating, is the cup rotor frozen? If the sensor has a heating system,
check the power supply at pins M and G.
2. Is the sensor supply voltage present at pin J and H? If not, check the voltage source or the cable.
If there is no output signal at the sensor, even though points 1 to 2 of the troubleshooting were OK, the sensor must be
returned to the manufacturer for repair.
Electrical connection
The electrical connection is made using a 12-pin plug connector. A shielded cable 10 x AWG 24 C UL sw with a
wire cross-section of 0.22 mm² is recommended for connection. The maximum cable length is approx. 100 m.


aem.eco
LAMBRECHT meteo |AEM | ECONOMY
page –3
Dimensioned drawing
WeitergabesowieVervielfältigungdieserUnterlage,VerwertungundMitteilungihresInhaltsnicht
gestattet,sowienichtausdücklichzugestanden.ZuwiderhandlungverpflichtenzuSchadensersatz.
AlleRechtefürdenFallderPatenterteilungoderGebrauchsmuster-Eintragungvorbehalten.
Passingonandduplicationofthisdocument,utilizationandcommunicationof
it's contentsprohibitedunlessdefinitelypermitted.Infringementisboundto
compensation.Allrightsreservedforpatentorregisteredpattern.
Maße ohne Toleranzangabe nach
Zust. Änderungen Datum Name Dateiname Ersatz für:
Blatt
Bl
MaßstabMaterial
Bearb.
Gepr.
Datum Name
Artikelnummer
DIN ISO 2768-m
Benennung
80.14575.000B01.idw
1 / 1
16.11.2022 curdt
80.14575.000B01
Oberfläche
Maßzeichnung 00.14575.435000
1
A4
Norm.
Revision
154,2
20
8
M
10
74n
Für 50 mm Masten geeignet
suitable for 50 mm poles
1:1

aem.eco
LAMBRECHT meteo |AEM | ECONOMY
page –4
Wiring diagram
WeitergabesowieVervielfältigungdieserUnterlage,VerwertungundMitteilungihresInhaltsnicht
gestattet,sowienichtausdücklichzugestanden.ZuwiderhandlungverpflichtenzuSchadensersatz.
AlleRechtefürdenFallderPatenterteilungoderGebrauchsmuster-Eintragungvorbehalten.
Passingonandduplicationofthisdocument,utilizationandcommunicationof
it'scontentsprohibitedunlessdefinitelypermitted.Infringementisboundto
compensation.Allrightsreservedforpatentorregisteredpattern.
Zust. Änderungen Datum Name Dateiname Ersatz für:
Blatt
Bl
Bearb.
Gepr.
Datum Name
Artikelnummer
Benennung
80.14565.000E08.idw
1 / 1
16.11.2022 curdt
80.14565.000E08
Anschlussplan 00.14565.400000 /
00.14575.435000
1
A4
Norm.
Revision
EFG
DMH
J
L
C
BAK
Anschlussbild / connection diagram
Buchstabe
letter PIN Kabelfarbe color code
Funktion
function
F1 RD / BU + 0...20 mA
E2 GY / VT GND (I OUT)
D 3 WH + 4...20 mA
C 4 GY
factory use only
L 5 VT Fout 700 Hz
(WG)
B 6 BU GND (A GND)
A 7 GN
factory use only
K 8 YE
factory use only
J 9 OG + 10...30 VDC
(Elektronik)
H10 RD GND
M11 BN - 24 VDC
Heating
G12 BK + 24 VDC
Heating
0...20 mA = 0...50 m/s
4...20 mA = 0...50 m/s 0...20 mA = 0...360°
4...20 mA = 0...360°

aem.eco
LAMBRECHT meteo |AEM | ECONOMY
LAMBRECHT meteo GmbH Tel [phone]
Friedländer Weg 65-67 Fax [phone]
37085 Göttingen E-Mail [e-mail]
Germany Internet www.lambrecht.net
14575-24V_b-de.indd 46.22
Photo copyright: © Galyna Andrushko - Adobe stock
Copyright © 2022 LAMBRECHT meteo GmbH. All rights reserved.
Information in this document subject to change without notice.
page –5
Technical data
ECONOMY Wind Speed Sensor
Id No. 00.14565.200304
Measuring range 0.7...50m/s
Accuracy 2 % FS
Resolution 0.1 m/s
Starting value 0.7 m/s
Output 0...20 mA = 0...50 m/s (maximum load 500 Ohm at 15 V)
4...20 mA = 0...50 m/s (maximum load 500 Ohm at 15 V)
Range of application temperatures -30...+70 °C heated; 0...+70 °C unheated
survival wind speed 0...75 m/s
Operating voltage 10...30 VDC
Heating voltage 24 VDC, 600 mA (for controlled heating)
Housing seawater resistant aluminum; anodized; IP 53
Measuring elements three-armed cup rotor, break-proof
Dimensions see dimensional drawing; for mounting on pipe Ø 49...51 mm
Weight 0.4 kg
ACCESSORIES (please order separately)
Id No. 32.14565.060000 
Id No. 32.14565.060020 
Disposal
LAMBRECHT meteo GmbH is listed and registered at the Stiftung Elektro-Altgeräte Register ear under:
WEEE-Reg.-Nr. DE 45445814
In the category of monitoring and control instruments, device type: “Monitoring and control instruments for
exclusively commercial use”.
Within the EU
The device has to be disposed according to the European Directives 2002/96/EC and 2003/108/EC
(Waste Electrical and Electronic Equipment). Do not dispose the old device in the household waste!

company for electronic waste.
Outside the EU
Please follow the regulations in your country regarding the appropriate disposal of waste electronic equipment.
