lancer ESCORT III Manual

REV: 03/31/06
P.N. 28–0003/04
INSTALLATION AND SERVICE MANUAL
FOR THE
ESCORT III, JUICE DISPENSER
This manual supersedes Installation and Service Manual 28-0003/03, dated 01/30/03
SPECIFICATIONS
DIMENSIONS:
• Width 14 1/16 inches (357 mm)
• Depth 23 1/8 inches (587 mm)
• Height (with legs) 26 1/2 inches (673 mm)
WEIGHT:
• Shipping 152 pounds (68.95 kg)
• Empty 135 pounds (61.24 kg)
• Operating 180 pounds (81.65 kg)
ELECTRICAL REQUIREMENTS (Running):
• 115V/60Hz 7 Amps
WATER REQUIREMENTS:
• Minimum flowing pressure of 25 PSI (1.76 kg/cm2) at a
flow rate of three (3) ounces (88.7 mI) per second.
•Connection 5/8 inch - 18 male flare (3/8 inch flare).
COMPRESSOR: 1/3 HP
CONCENTRATE CONTAINER CAPACITY:
• Left container 128 ounces (3.79 Liters)
• Middle container 106 ounces (3.14 Liters)
• Right container 128 ounces (3.79 Liters)
• Concentrate container 35oF (1.7oC)
constant temperature
• Ice bath water capacity 320 ounces; 2.5 U.S. gallons
(9.07 kg; 9.46 L)
• Ice bank 8.0 pounds (3.63 kg)
DRINK CAPACITY:
Four (4) five (5) ounce (148 cc) drinks per minute under 45oF (7.2oC) at 75oF (23.9oC) ambient inlet water.
Please refer to the Lancer web site (www.lancercorp.com) for
information relating to Lancer Installation and Service Manuals,
Instruction Sheets, Technical Bulletins, Service Bulletins, etc.
FAX Engineering: • 210-310-7096
"Lancer" is the registered trademark of Lancer • Copyright — 2006 by Lancer, all rights reserved
6655 LANCER BLVD. • SAN ANTONIO, TEXAS 78219 USA • [phone]
FAX SALES
• NORTH AMERICA – 210-310-7245 • INTERNATIONAL SALES – 210-310-7242 • CUSTOMER SERVICE – 210-310-7242 •
• LATIN AMERICA – 210-310-7245 • EUROPE – 32-2-755-2399 • PACIFIC – 61-8-8268-1978 •
"Minute Maid" and “Minute Pak” are registered trademarks of The Coca-Cola Company.
dinecompany.com

TABLE OF CONTENTS
SPECIFICATIONS......................................................................................................................................Cover
TABLE OF CONTENTS...................................................................................................................................i-ii
1. INSTALLATION ...........................................................................................................................................1
1.1 RECEIVING........................................................................................................................................1
1.2 UNPACKING ......................................................................................................................................1
1.3 SELECTING COUNTER LOCATION .................................................................................................1
1.4 CONNECTING TO WATER SUPPLY.................................................................................................1
1.5 FILLING UNIT WITH WATER ............................................................................................................1
1.6 CONNECTING TO ELECTRICAL POWER .......................................................................................2
1.7 PURGING UNIT OF AIR ....................................................................................................................2
1.8 LOAD MINUTE PAKS®.......................................................................................................................2
1.9 PRIMING CONCENTRATE PUMPS ..................................................................................................2
1.10 ADJUST CONCENTRATE TO WATER RATIO (oBRIX) ....................................................................2
2. OPERATING UNIT.......................................................................................................................................4
2.1 CHANGING PRODUCT .....................................................................................................................4
2.2 OPERATING ESCORT III JUICE DISPENSERS WITH SOLD OUT FEATURE ...............................4
2.3 CLEANING AND SANITIZING INSTRUCTIONS ...............................................................................5
2.4 LIGHTED FRONT SECTION .............................................................................................................6
3. PRINCIPLES OF OPERATION ...................................................................................................................6
3.1 WATER SYSTEM ...............................................................................................................................6
3.2 CONCENTRATE SYSTEM ................................................................................................................7
3.3 CONCENTRATE LOW LEVEL INDICATOR SYSTEM ......................................................................7
3.4 ELECTRONIC CONTROL SYSTEM..................................................................................................8
3.5 DISPENSING PADDLE SYSTEM ......................................................................................................8
3.6 FLUSH SYSTEM................................................................................................................................8
3.7 REFRIGERATION SYSTEM ..............................................................................................................8
4. RELOCATING OR SHIPPING UNIT ...........................................................................................................9
4.1 REMOVING AN OPERATING UNIT ..................................................................................................9
4.2 TRANSPORTING UNIT .....................................................................................................................9
4.3 SHIPPING UNIT.................................................................................................................................9
5. PERIODIC MAINTENANCE ........................................................................................................................9
5.1 LUBRICATION....................................................................................................................................9
5.2 CLEANING WATER STRAINER ........................................................................................................9
5.3 CLEANING INLET AIR FILTER..........................................................................................................9
5.4 CLEANING CONDENSER ...............................................................................................................10
5.5 CLEANING CONCENTRATE CONTAINER COMPARTMENT........................................................10
6. REPAIR AND REPLACEMENT.................................................................................................................10
6.1 COMPLETE FRONT PANEL REPLACEMENT................................................................................10
6.2 DRIVER PCB REPLACEMENT .......................................................................................................10
6.3 PADDLE SENSOR ...........................................................................................................................11
6.4 CONCENTRATE PUMP AND MOTOR ............................................................................................11
6.5 PUMP SUPPORT.............................................................................................................................12
6.6 CONTROL PANEL AND HOUSING .................................................................................................12
6.7 FLUSH SOLENOID VALVE..............................................................................................................12
6.8 WATER SOLENOID VALVE .............................................................................................................13
6.9 REGULATOR ASSEMBLY ...............................................................................................................13
6.10 VACUUM BREAKER........................................................................................................................14
6.11 TRANSFORMER CABINET ASSEMBLY .........................................................................................14
6.12 ELECTRONIC ICE BANK CONTROL..............................................................................................14
6.13 AGITATOR MOTOR .........................................................................................................................15
6.14 AGITATOR DECK.............................................................................................................................15
6.15 WATER COIL CAGE ASSEMBLY ....................................................................................................15
6.16 FRONT COVER ...............................................................................................................................15
6.17 TOP COVER ....................................................................................................................................15
6.18 WRAPPER .......................................................................................................................................16
6.19 CONDENSER FAN MOTOR ............................................................................................................16
7. TROUBLESHOOTING...............................................................................................................................16
7.1 NO WATER OR CONCENTRATE ON EITHER SIDE, OR NO POWER.........................................16
7.2 NO WATER OR CONCENTRATE ON ONE SIDE ONLY ................................................................17
i
dinecompany.com

TABLE OF CONTENTS (CONTINUED)
7.3 WATER ONLY - NO CONCENTRATE .............................................................................................17
7.4 CONCENTRATE ONLY - NO WATER EITHER SIDE......................................................................17
7.5 CONCENTRATE ONLY - NO WATER ON ONE SIDE ONLY..........................................................17
7.6 NO FLUSH WATER EITHER SIDE, SYSTEM DISPENSES NORMALLY ......................................17
7.7 WEAK DRINK OR INCONSISTENT DRINK....................................................................................18
7.8 NO WATER ALL VALVES.................................................................................................................18
7.9 WATER LEAKS AT SPOUT CONNECTION ....................................................................................18
7.10 DRINK WILL NOT SHUT OFF .........................................................................................................18
7.11 CUP DOES NOT FILL COMPLETELY OR OVERFLOWS (PORTION CONTROL ONLY) .............18
7.12 NO FLUSH WATER - ONE SIDE ONLY, SYSTEM DISPENSES NORMALLY ...............................18
7.13 WATER DRIPS FROM SPOUT WHEN DRINK IS NOT BEING DISPENSED ................................18
7.14 WATER LEAKING INTO CONCENTRATE CONTAINER AND/OR CONCENTRATE TUBE...........18
7.15 WATER LEAKING INTO CONCENTRATE CONTAINER DURING FLUSH CYCLE .......................18
7.16 CONCENTRATE LEAK UNDER DISPENSER ................................................................................18
7.17 AIR LEAKING INTO CONCENTRATE TUBE AND/OR CONCENTRATE PUMP............................18
7.18 RATIO CANNOT BE ADJUSTED LOW ENOUGH (OR oBRIX HIGH ENOUGH)............................19
7.19 RATIO CANNOT BE ADJUSTED HIGH ENOUGH (OR oBRIX LOW ENOUGH)............................19
7.20 oBRIX VARIES FROM DRINK-TO-DRINK.......................................................................................19
7.21 CONCENTRATE LOW LEVEL INDICATOR ON BUT CONCENTRATE CONTAINER
STILL HAS CONCENTRATE REMAINING......................................................................................19
7.22 VACUUM BREAKER LEAKS WATER OUT OF END ......................................................................19
7.23 WATER CONTINUALLY OVERFLOWS FROM ICE BANK COMPARTMENT
INTO CONCENTRATE COMPARTMENT AND INTO DRIP TRAY..................................................19
7.24 COMPRESSOR STARTS AND CONTINUES TO RUN UNTIL FREEZE UP
AND WILL NOT CUT OFF ...............................................................................................................19
7.25 WARM DRINKS................................................................................................................................20
7.26 COMPRESSOR DOES NOT START (NO HUM), CONDENSER FAN MOTOR
DOES NOT RUN AND NO ICE BANK.............................................................................................20
7.27 COMPRESSOR DOES NOT START (NO HUM), NO ICE BANK, BUT
CONDENSER FAN MOTOR RUNS.................................................................................................20
7.28 COMPRESSOR DOES NOT START, BUT HUMS ..........................................................................20
7.29 COMPRESSOR STARTS AND SWITCHES OFF OF START WINDING (WILL ONLY
RUN FOR A FEW SECONDS BEFORE INTERNAL OVERLOAD SWITCHES
COMPRESSOR OFF) ......................................................................................................................20
7.30 COMPRESSOR STARTS AND RUNS A SHORT TIME, BUT SHUTS OFF
ON OVERLOAD ...............................................................................................................................21
7.31 SELECT OR LOW CONCENTRATE LIGHTS INOPERATIVE BUT AUDIBLE
ALARM IS O.K. ................................................................................................................................21
7.32 FRONT COVER LAMPS DO NOT LIGHT .......................................................................................21
8. TROUBLESHOOTING USING PCB 12 VOLT (GREEN), MOTOR OVER CURRENT (YELLOW)
AND MOTOR (RED) DIAGNOSTIC LIGHTS............................................................................................22
9. ILLUSTRATIONS, PARTS LISTINGS, AND WIRING DIAGRAMS ..........................................................23
9.1 FINAL ASSEMBLY ......................................................................................................................23-24
9.2 PUMP/REGULATOR ASSEMBLY...............................................................................................25-26
9.3 WATER/CONCENTRATE COMPONENT ASSEMBLY ...............................................................27-28
9.4 REFRIGERATION ASSEMBLY ...................................................................................................29-30
9.5 AGITATOR DECK ASSEMBLY.........................................................................................................31
9.6 LIGHTED FRONT COVER ASSEMBLY, PN 82-1782......................................................................32
9.7 TRANSFORMER BOX ASSEMBLY .................................................................................................33
9.8 WIRING CONNECTIONS ................................................................................................................34
9.9 WIRING DIAGRAM ..........................................................................................................................35
ii
dinecompany.com

1. INSTALLATION
1.1 RECEIVING
Each unit is completely tested under operating conditions and thoroughly inspected before
shipment. At the time of shipment, the carrier accepts the unit and any claim for damage must be
made with the carrier. Upon receiving units from the delivering carrier, carefully inspect carton for
visible indication(s) of damage. If damage exists, have carrier note same on bill of lading and file a
claim with the carrier.
1.2 UNPACKING
A. Cut band and remove.
B. Carefully remove top portion of carton by lifting up.
C. Remove top inner carton pad from inside of packing box.
D. Remove package containing four (4) legs (PN 81-0112) from drip tray.
E. Lift unit by plywood shipping base and remove lower portion of carton.
F. Remove plywood shipping base from unit by removing screws from bottom. This is best done
by moving unit so that one side extends past edge of counter top or table, allowing access to
screws on bottom of plywood shipping base.
NOTE
If unit is to be transported, it is advisable to leave unit secured to plywood shipping base.
G. Assemble legs (PN 81-0112) to unit by tilting unit. DO NOT LAY UNIT ON ITS SIDE OR BACK.
H. Inspect unit for concealed damage and if evident, notify delivering carrier and file a claim against
same.
I. Remove accessory kit of loose parts (listed below, with quantity in parenthesis) from drip tray.
•PN 05-0017 Flare Seal Washer (2)
•PN 22-0017 Brush (1)
•PN 54-0038 Dispensing Nozzle (2 or 3)
•PN 81-0301 Keys (for Key Switch) (2)
•PN 49-0226 Inlet Water Shut Off (1)
1.3 SELECTING COUNTER LOCATION
A. Select a location close to a properly grounded electrical outlet and water supply that meet the
requirements as listed in the SPECIFICATIONS (see Cover).
B. Condenser air is drawn in on the bottom of the unit and discharged out the rear of the unit. A
minimum of two (2) inches (5.08 cm) must be maintained between the back of the unit and the
wall. Failure to maintain the proper clearance space will cause the compressor to overheat and
result in premature compressor failure.
1.4 CONNECTING TO WATER SUPPLY
A. Flush water supply line thoroughly.
B. Remove drip tray by pulling up slightly and away from unit. Remove dispensing paddles by
squeezing together at top and pull down.
C. Remove splash plate by pulling bottom up slightly and then out from unit.
CAUTION
USE A BACKUP WRENCH TO PREVENT DAMAGE TO STRAINER.
D. Connect the inlet water shut off to water inlet fitting on bottom of unit using a flare seal washer
(PN 05-0017).
E. Connect other end of the water tube assembly to water supply line using a flare seal washer.
Open valve on water supply and check for leaks.
F. Replace splash plate, drip tray and dispensing paddles.
1.5 FILLING UNIT WITH WATER
A. Remove both lids from top of unit.
1
dinecompany.com

B. Disconnect check valves (feed line) from top of concentrate containers, and remove concentrate
containers from unit.
C. Remove yellow plug from agitator deck.
D. Using a funnel or tube, fill with water until water flows out of overflow hole into concentrate
container compartment. The overflow water will drain into the drip tray.
NOTE
Facing the front of the unit, the overflow hole is in the rear wall of the concentrate container
compartment.
E. Replace yellow plug.
1.6 CONNECTING TO ELECTRICAL POWER
WARNING
THIS UNIT MUST BE PROPERLY ELECTRICALLY GROUNDED TO AVOID POSSIBLE FATAL
ELECTRICAL SHOCK OR SERIOUS INJURY TO THE OPERATOR. THE POWER CORD IS
PROVIDED WITH A THREE PRONG GROUNDED PLUG. IF A THREE-HOLE GROUNDED
ELECTRICAL OUTLET IS NOT AVAILABLE, USE AN APPROVED METHOD TO GROUND THE
UNIT.
DO NOT USE EXTENSION CORDS WITH THIS UNIT. DO NOT “GANG” TOGETHER WITH
OTHER ELECTRICAL DEVICES ON THE SAME OUTLET.
Plug unit power cord into electrical outlet. Compressor and condenser fan motor will not begin
running until five (5) minutes after the unit is energized. Agitator motor will run continuously.
1.7 PURGING UNIT OF AIR
A. Raise front cover and turn key switch ON.
B. Using a cup, actuate each dispensing paddle until a steady flow of water is obtained.
C. Turn key switch OFF.
1.8 LOAD MINUTE PAKS®
A. Remove lid over concentrate compartment.
B. Minute Paks®must be completely thawed and thoroughly shaken before loading.
C. Load each Minute Pak®per the flavor label on the front of the unit.
D. Replace check valves (white elbow) in Minute Paks®, using a rotating movement while pushing
down.
E. Replace lid on top of unit.
1.9 PRIMING CONCENTRATE PUMPS
A. Turn key switch ON.
B. Depress the Sold Out Reset button.
NOTE
An initial eight (8) to ten (10) ounces (236.6 ml to 295.7 ml) of water will be dispensed before
the concentrate/water mixture reaches the spout.
C. Hold cup under spout and depress the dispensing paddle.
1.10 ADJUST CONCENTRATE TO WATER RATIO (oBRIX)
A. Install dispensing nozzles.
B. Inlet water is distributed to two (2) water regulators which supply water to the mixing spouts,
independently of each other. They are marked LEFT and RIGHT, indicating the mixing spout
they supply. On the ESCORT III, the LEFT also supplies the middle spout. Both regulators are
preset at 25 PSIG (1.76 kg/cm2). With a proper water source, each spout will dispense
approximately 1.25 ounces of water per second (36 ml/sec). When mixed with concentrate
(5 to 1 ratio), the finished drink will be dispensed at 1.5 ounces per second (43 ml/sec).
C. There are NO select options on ESCORT III units. These units are factory preset
(electronically) for the spouts and ratios provided in Table 1 (see following page).
2
dinecompany.com

3
Figure 1
screws finger tight. Be sure control panel is properly seated in control housing.
2. OPERATING UNIT
2.1 CHANGING PRODUCT
A. Remove nozzle from spout and clean.
B. Flush unit until only water is dispensed from spout (see Section 1.9).
C. Remove lid from top of unit.
D. Remove the Minute Pak®from the unit. Replace with new flavor.
E. Replace lid and nozzle.
ESCORT III
Left Middle Right
Ratio 6:1 5:1 5:1
NOTES: Because the ratios are factory preset electronically, they are not
exact and may require a slight adjustment at time of installation.
This can be accomplished by using a refractometer as follows:
1. Dispense a 5 or 6 ounce (147.9 to 177.4 ml) cup of product
and discard.
2. Dispense a 5 or 6 ounce cup (147.9 to 177.4 ml) of product
and stir thoroughly.
3. Using a refractometer read the oBrix. Adjust as necessary as
explained in 1.10.D below and re-Brix.
Factory PreSet Select, Ratio, Product
Table 1
D. To adjust the °Brix, loosen two (2) screws on face of control panel until control panel can be
pulled partially out of control housing. Screws are captive and can be used to pull control panel
from control housing.
(1) Each spout of the unit is controlled by an independent Drive Printed Circuit Board (PCB)
plugged into the Master PCB. The driver PCB has adjusting knobs which control the °Brix
of the product selections.
(2) To adjust the °Brix turn the adjusting control as follows:
INCREASE
SELECTOR TAB
DRIVER PC BOARD
MOTOR OVER-CURRENT (YELLOW)
12 VOLTS (GREEN)
MOTOR VOLTS (RED)
SEL 2
SEL 1
Decrease °Brix..............Turn Counter
(less concentrate) Clockwise
Increase °Brix................Turn Clockwise
(more concentrate)
E. To set a unit that has not been factory preset for a
product, adjust °Brix and change product plate on
control panel.
F. In some locations, the water supply pressure may be so
low or may fluctuate so much that a 25 PSIG
(1.76 kg/cm2) flowing water pressure cannot be
maintained. As a result, the unit will not dispense a
product at the proper °Brix. In this event, the
regulated water pressure should be reduced below the
local inlet water supply pressure so that a
proper °Brix can be maintained. Reducing the regulated
water pressure will reduce the finished product flow rate.
Normally, the minimum recommended setting is 15 PSIG
(1.06 kg/cm2) flowing. To reset the regulator, refer to
Section 6.9, items K-Q.
G. Readjust °Brix as necessary.
H. Slide control panel into control housing and tighten
dinecompany.com

F. Depress the Sold Out Reset button.
G. Depress dispensing paddle with cup until a steady flow of pre-mixed product is obtained. Unit
is now ready to dispense. Install nozzles and check °Brix (see Section 1.10).
H. Change product plate on front cover to indicate new product.
NOTE
If the new product requires a different mixing ratio, see Section 1.10 (°Brix).
2.2 OPERATING ESCORT III JUICE DISPENSERS WITH SOLD OUT FEATURE
A. New Package
1. Turn key to "ON".
2. Remove front lid.
3. Load "Minute Pak®”. Thoroughly shake "Minute Pak®” before loading.
4. Install check valve into package.
5. Press red "Reset" Button.
6. Replace front lid.
7. Prime pump by dispensing until product is dispensed.
B. Intermittent Lockout
Every precaution has been taken to produce a Sold Out Feature which will operate properly with all of the
Minute Maid®products. However, it is possible that an individual machine may lockout inadvertently.
Should the machine lockout while product remains, simply press the "Reset" button.
If the machine continues to lockout, check the condition of the concentrate tubes. If the tubes are heavily
stained from the product, the tube(s) must be changed out.
C. Test Procedure
Should you desire to determine if the Sold Out Feature is working, you may perform the following
procedure:
1. Load Product into machine.
2. Press "Reset" button.
3. Dispense for 20 continuous seconds.
NOTE:
The 20 second continuous dispense is ONLY required for testing.
4. The Sold Out Feature should now be armed. To test, remove the check valve from the
concentrate package. Then dispense until lockout alarm sounds (this simulates an empty
package).
5. When alarm sounds, press "Reset" button to return to monitoring condition.
6. If alarm does not sound, repeat test procedure. If alarm does not sound after repeating the
test procedure several times, contact the Service Center.
D. Disabling of Sold Out Feature
The Sold Out Feature can be disabled by pressing the "Flush" button three (3) times (in rapid succession).
The dispenser will follow with three (3) short beeps.
E. Enabling of Sold Out Feature
Press the "Reset" button to enable the Sold Out Feature. Dispenser will follow with three (3) short beeps.
2.3 CLEANING AND SANITIZING INSTRUCTIONS
For optimum dispenser performance and highest drink quality, please follow the instructions listed
below for cleaning your dispenser. The instructions are also shown on the inside front cover for the
Escort Dispenser.
CAUTION
DO NOT USE ANY POWDERS OR ABRASIVE CLEANING COMPOUNDS THAT WILL DAMAGE
FINISH.
A. Daily
1. Flush each valve of dispenser until clear water flows from the nozzle.
4
dinecompany.com

2. Remove drip tray and cup rest. Wash drip tray and cup rest thoroughly with warm, soapy
water using a mild detergent. Rinse thoroughly with clean, warm water and reinstall drip tray
and cup rest to dispenser.
3. Wipe down dispenser to remove any product residue.
WARNING
REMOVE SANITIZING SOLUTION FROM DISPENSER AS INSTRUCTED. RESIDUAL
SANITIZING SOLUTION LEFT IN SYSTEM COULD CREATE HEALTH HAZARD.
CAUTION
DO NOT SOAK NOZZLES IN CHLORINE SOLUTION OVERNIGHT. THIS WILL CAUSE NOZZLES
TO SWELL AND PLASTIC WILL BEGIN TO DETERIORATE.
B. Weekly
1. Flush each valve of dispenser until clear water flows from the nozzle.
2. Turn off water supply to dispenser.
3. Remove lid and wash thoroughly with warm, soapy water using a mild detergent. Rinse
thoroughly with clean, warm water.
4. Lift up on the check valve (white or yellow elbow) to remove it from the Minute Pak®.
5. Remove Minute Pak®from dispenser.
6. Remove nozzles and disassemble (see NOZZLE ASSEMBLY instructions). Wash
thoroughly with warm, soapy water using a mild detergent. Rinse thoroughly with clean,
warm water and replace. DO NOT SOAK NOZZLES IN CHLORINE SOLUTION
OVERNIGHT. THIS WILL CAUSE NOZZLES TO SWELL AND PLASTIC WILL BEGIN TO
DETERIORATE.
7. Fill the specially marked sanitizing container with 80 ounces of COOL chlorinated sanitizing
solution (Diversol CX, or equivalent) minimum 100 PPM available chlorine, but not to
exceed 200 PPM; replace sanitizing container in dispenser.
8. Replace check valve in sanitizing container.
9. Activate valve for two (2) minutes ensuring concentrate lines are full of solution. Let
solution stand for five (5) minutes without dispensing.
10. Perform a second two (2) minute dispense and let stand for an additional five (5) minutes.
11. Activate valve until the sanitizing solution empties from the sanitizing container.
12. Remove check valve from sanitizing container, remove container, and pour out excess
sanitizing solution.
13. Repeat for each valve.
14. Reinstall Minute Pak®, and replace check valves.
15. Run concentrate through valves to remove traces of sanitizing solution from the dispenser.
NOTE
Please note that a fresh water rinse cannot follow sanitization of equipment. Purge only with
the end use product. This is an NSF requirement.
16. Remove drip tray and cup rest. Wash thoroughly with warm, soapy water using a mild deter-
gent. Rinse thoroughly with clean, warm water.
17. Wipe the dispenser with a clean damp cloth, taking care to remove all product residue.
18. Replace drip tray, and cup rest.
19. Turn on the water supply to the unit.
20. Reinstall lid.
21. Prime dispenser by holding cup under spout and activating the valve until a
concentrate/water mix is dispensed.
2.4 LIGHTED FRONT SECTION
A. Replacing Graphics in Lighted Front Section
1. Turn the key to the “OFF” position, turn switch on inside of front cover to the “OFF” position,
and unplug unit.
2. Open front cover and push the clear clips (protruding from the reflector) into the slots in the
reflector. Return cover to the closed position.
5
dinecompany.com

3. Lean the outer lens (PN 05-1164) back far enough so that it can be removed from the front
cover. Remove clear backing and remove old graphics. Insert new graphics into recess of
lens, and replace backing sheet.
4. With lens horizontal, insert tabs into bottom of front cover and rotate lens to an upright
position. Push lens in, until lens is flush with front cover and until the lens snaps into place.
Be sure that the lens is properly seated.
5. Plug in the unit, open front cover and turn switch on the inside of the cover to the “ON”
position.
6. Turn the key to the “ON” position, and return front cover to the closed position.
B. Operating Instructions
1. Plug unit in. If graphics do not light up, open front cover, and turn switch to the “ON”
position.
NOTE
The key does not turn off the lighted front graphics. Graphics are controlled by the switch
located on the inside of the front cover.
3. PRINCIPLES OF OPERATION
3.1 WATER SYSTEM
Inlet water is distributed through the strainer to the left and right regulators, which reduces the inlet
water pressure to 25 PSIG (1.76 kg/cm2).
Water is fed from the regulator through stainless steel tubes (embedded in the insulation of the tank
assembly) and into the copper water coil, where the water is chilled to below 40°F (4.4°C). Water
is then fed past a vacuum breaker through a stainless steel tube (embedded in the insulation of the
tank assembly) to the front of the tank assembly and into the water solenoid. When a valve is
activated, the corresponding water solenoid opens allowing water to pass into the spout and mix with
concentrate.
Each water system is completely independent of the other. On the Escort Ill units, products can
be dispensed singularly or simultaneously through the right and either left or middle spouts
without a change in °Brix. When the inlet water is disconnected from the unit, the vacuum breaker
will open automatically allowing water to drain out of the unit, thus preventing a freeze up when
transported or stored at ambient temperatures below 32°F (0°C).
3.2 CONCENTRATE SYSTEM
When the dispensing valve is activated, concentrate is drawn from the bottom of the concentrate
container, up the integral dip tube and through the check valve and concentrate tube, to the inlet of
the concentrate pump.
It is metered by volume and pumped into the spout where it mixes with the water. The temperature
of the concentrate does not effect the °Brix as long as it is above 32°F (0°C). The volume output of
the concentrate pump is controlled electronically and can be adjusted to change the °Brix.
3.3 CONCENTRATE LOW LEVEL INDICATOR SYSTEM
The dispenser is equipped with an infrared sensor on each concentrate tube that senses the
difference in light density that is passed through the tube. The unit reads juice characteristics and
obtains a measurement (Learn Mode). If the unit senses a change in density, indicating a bubble or
lack of concentrate while dispensing, the unit will go into Lock-Out Mode. When the unit is in
Lock-Out Mode, it will disable the valve and turn on the Sold-Out LED. It will also beep if you
depress the dispense button while in Lock-Out Mode. To enable dispensing, reload the concentrate
container and press the reset button. This will clear the lock-out and put the unit into Learn Mode.
NOTE:
The Lock-Out Mode can be cleared by cycling power (key switch). When power is restored the unit
will not go into Learn Mode.
A. If the flush switch is depressed, the unit will go into flush wait mode. In this mode the unit will
not lock out. Nine seconds of dispensing [in three (3) second continuous intervals] will take the
6
dinecompany.com

unit out of Flush Wait Mode.
B. If the valve does not dispense for over one hour, the unit will go into Inactivity Wait Mode. In
this mode the unit will not lock out. It will stay in this mode until a three (3) second continuous
dispense occurs.
C. The unit enters Learn Mode when the reset switch is depressed. The unit will beep once when
entering Learn Mode. (Note: If the reset switch is depressed and the unit does not beep, it is
already in Learn Mode). This clears the lock-out (shuts off the red LED, disables audible alarm,
and enables dispensing).
D. Pre-learn dispense - The unit will wait for 15 seconds of dispensing [in three (3) second
increments]. This delay ensures that concentrate is in the sensor region of the tube before
learning the concentrate.
E. Learn -The unit will "learn" the characteristics of whatever is in the sensor region of the tube
when a dispense (of at least one second) occurs after the pre-learn dispense is finished.
NOTE:
If the flush button is pressed after the reset/learn button, the unit will have to clear the Flush Wait
Mode before it will learn the concentrate. The Flush Wait Mode is cleared by three (3) dispenses
of at least three (3) seconds each. Since the pre-learn dispense requires five (5) dispenses of
at least three (3) seconds each, it should have no effect on the learn unless several seconds of
dispensing occur in the pre-learn dispense mode before the flush switch is pressed. In a worst
case scenario, it could take an additional nine seconds of dispensing before the learn occurs if
the flush switch was pressed just before the pre-learn dispense was finished.
F. The unit may be put into or out of Disable Lock-Out Mode by depressing the flush switch three
(3) times in less than two (2) seconds. When entering/leaving Disable Lock Out Mode, the unit
will beep three (3) times. In Disable Lock Out Mode, the dispenser will operate without the Low
Level/Sold Out features.
3.4 ELECTRONIC CONTROL SYSTEM
Electrical power is fed into the transformer cabinet assembly, which contains independent Class II
energy limiting step down transformers.
Each transformer is protected by a resettable circuit breaker on the primary side of the transformer.
Each transformer feeds 15.3VAC to a driver PCB which controls one spout of the unit. Each driver
PCB is independent of the other. The driver PCB plugs into an edge connector of the control panel
PCB. Failure of a transformer or driver PCB on one spout does not effect the operation of the other
spout of the unit.
Current supplied to the various devices (e.g., solenoids, sensors, lights, pump motor, etc.) by the
driver PCB does not exceed 15VDC. With the exception of the pump motor, any short circuit of one
or more of the devices controlled by the driver PCB will cause the driver PCB to shut OFF and cease
functioning. When the short circuit is corrected by repair or replacement of the faulty device, the
driver PCB will automatically reset and begin functioning. This is also true of the pump motor,
except that to reset the driver PCB, the key switch must be turned to the OFF position for
30 seconds and then turned back to ON.
When the dispensing valve is activated, the driver PCB activates the water solenoid and the pump
motor. The electronic system continuously monitors the pump motor and maintains exact speed
(°Brix) regardless of the load on the pump motor. °Brix is changed by turning the adjusting knob on
the driver PCB as described in Section 1.10C.
3.5 DISPENSING PADDLE SYSTEM
The dispensing paddle has an integrally sealed permanent magnet which activates the sensor
behind the splash plate when the paddle is depressed. This causes the electronic system to
activate the water solenoid and concentrate pump, allowing the unit to dispense product. The
dispensing paddles are removable, without tools, for cleaning. Paddles can be removed by
squeezing the top edges of each paddle together.
3.6 FLUSH SYSTEM
When the flush switch is held in position, the electronic system opens the flush solenoid and allows
7
dinecompany.com

water to flow to the check valve on the concentrate container and simultaneously operates the
concentrate pump. Water flows through the check valve, the concentrate pump, and the spout. The
check valve positioned at the concentrate container prevents flush water from entering the
concentrate container.
3.7 REFRIGERATION SYSTEM
An ice bank is formed and maintained on the copper tube evaporator located in the water bath
compartment of the tank assembly. Water is continually circulated by the agitator motor across the
ice bank and around the copper water coil. Water temperature is maintained at 32°F (0°C).
Because the water compartment and concentrate compartment form an integral aluminum die
casting, the concentrate compartment is maintained at a constant 35°F (0°C) temperature. When a
product is dispensed, water is drawn through the copper water coils and chilled. As the ice bank is
depleted, the ice bank control senses that the ice is melting and causes the compressor and
condenser fan motor to start. When the ice bank is rebuilt, the control shuts off the compressor and
condenser fan motor.
The compressor and condenser fan motor will operate periodically, even though no drinks are being
dispensed, in order to maintain the ice bank. If the unit is unplugged or power is disrupted while
operating, the compressor will not restart for a period of time during which the refrigerant pressures
equalize [approximately five (5) minutes]. This feature protects the compressor from premature
failure.
4. RELOCATING OR SHIPPING UNIT
4.1 REMOVING AN OPERATING UNIT
A. Perform FLUSH operation on each side of unit until a clean stream of water is being dispensed.
B. Remove Minute Paks®.
CAUTION
IF UNIT IS TO BE TRANSPORTED OR STORED WHEN AMBIENT TEMPERATURE IS 32°F (0°C)
OR LOWER, STEPS C AND D MUST BE PERFORMED TO PREVENT THE WATER SYSTEM
FROM FREEZING AND DAMAGING THE UNIT. DO NOT USE CO2GAS TO PURGE WATER
FROM UNIT AS IT WILL CAUSE A HEALTH HAZARD.
C. Shut off inlet water supply. Disconnect inlet water tube from bottom of unit. About six (6) ounces
(177.4 ml) of water will drain out of the unit as the vacuum breaker opens, allowing air into
system.
D. Depress each dispensing paddle. This allows additional air into the system and will cause a few
more ounces (ml) of water to drain from unit.
E. Turn key switch OFF.
F. Unplug unit power cord from electrical outlet.
G. Remove agitator deck (see Section 6.14), and using plastic tubing, siphon water out of ice bath
compartment. It will be necessary to pour about 12 ounces (354.8 ml) of warm water (do NOT
use extremely hot water) into the ice bath compartment to completely melt the ice bank. Drain
the remaining water and replace agitator deck and secure with nuts.
H. Remove drip tray and cup rest. Clean and reinstall. Wipe exterior surfaces of unit with a clean
damp cloth.
4.2 TRANSPORTING UNIT
The best method of handling and transporting a unit is to remove the legs and secure the unit to a
plywood shipping base. If it is to be handled and transported with the legs assembled to the unit,
special care should be taken not to damage unit. DO NOT LAY UNIT ON SIDE OR BACK.
4.3 SHIPPING UNIT
If a unit is to be shipped by a common carrier, it must be secured to the plywood shipping base and
repacked in the original carton with the inner packaging material. For this reason, it is wise to retain
the original packing material.
8
dinecompany.com

5. PERIODIC MAINTENANCE
5.1 LUBRICATION
All motors are lubricated for life and require no maintenance lubrication.
5.2 CLEANING WATER STRAINER
A. Remove splash plate.
B. Close inlet water shut off valve.
C. Remove plug from strainer on regulator assembly. Remove strainer screen.
D. Clean strainer screen with water. Inspect strainer screen for holes or other deterioration.
Replace, if appropriate.
CAUTION
DO NOT OVER TIGHTEN STRAINER PLUG.
E. Reinstall cleaned or new strainer screen. Reinstall strainer plug.
F. Open inlet water shut off valve.
G. Reinstall splash plate.
5.3 CLEANING INLET AIR FILTER
WARNING
FAILURE TO KEEP FILTER CLEAN WILL CAUSE A RESTRICTION OF AIR TO THE
CONDENSER AND THEREBY CAUSE PREMATURE COMPRESSOR FAILURE.
A. Remove splash plate.
B. Remove inlet air filter by removing spring retainers.
C. Clean air filter with water.
NOTE
Filter should be cleaned at least every three (3) months, or more frequently if required.
D. Squeeze excess water from filter, and reinstall air filter and spring retainer.
E. Reinstall splash plate.
5.4 CLEANING CONDENSER
A. Unplug unit power cord from electrical outlet.
B. Remove splash plate.
C. Remove fan guards (lower and upper).
D. Remove condenser fan motor.
E. Clean condenser with a small brush.
F. Reinstall condenser fan motor, fan guards and splash plate.
G. Plug unit power cord into electrical outlet.
5.5 CLEANING CONCENTRATE CONTAINER COMPARTMENT
CAUTION
DO NOT USE ANY POWDER OR ABRASIVE CLEANING COMPOUNDS THAT WILL DAMAGE
FINISH.
Use only warm water and damp cloth.
6. REPAIR AND REPLACEMENT
6.1 COMPLETE FRONT PANEL REPLACEMENT
A. Turn key switch OFF.
B. Loosen both (2) captive screws on control panel and partially pull control panel out of the
control housing.
C. Disconnect all wiring harnesses by depressing tabs on the harness connector.
D. Remove control panel from control housing.
9
dinecompany.com

CAUTION
PLACE THE BAD PCB IN THE ANTISTATIC SHIPPING BAG. THE CONTROL PCB IS NOT FIELD
REPAIRABLE AND MUST BE RETURNED TO LANCER CORPORATION FOR REPAIR. ANY
ATTEMPT TO FIELD REPAIR WILL VOID ANY WARRANTY.
A PCB MUST BE PACKAGED IN A PROTECTIVE ANTISTATIC SHIPPING BAG WHEN HANDLED,
STORED, TRANSPORTED OR SHIPPED. FAILURE TO DO SO MAY CAUSE DAMAGE TO THE
PCB.
E. Remove driver PCBs from control panel, by pulling straight out.
F. Assemble driver PCBs into new control panel.
G. Partially replace control panel in control housing.
H. Reconnect all harnesses to the control panel. Make sure connector tabs lock.
I. Turn key switch ON.
J. Adjust °Brix as required.
K. Slide control panel into control housing and tighten both captive screws finger tight.
6.2 DRIVER PCB REPLACEMENT
A. Turn key switch OFF.
B. Loosen both (2) captive screws on control panel and using screws, partially pull control panel
out of control housing.
C. Disconnect all wiring harnesses by depressing tabs on connector.
D. Remove control panel from control housing.
E. Remove driver PCB from control panel PCB by pulling straight out.
F. Remove new driver PCB from protective antistatic shipping bag and install in control panel PCB.
Package defective driver PCB in protective antistatic shipping bag.
G. Partially replace control panel in control housing.
H. Reconnect all harnesses to the control panel. Make sure connector tabs lock.
I. Turn key switch ON.
J. Adjust °Brix as required.
K. Slide control panel into control housing and tighten both captive screws finger tight.
6.3 PADDLE SENSOR
A. Turn key switch OFF.
B. Remove dispensing paddles and drip tray.
C. Remove splash plate.
D. Unplug sensor from harness.
E. Loosen nut on back of sensor.
F. Remove sensor from bracket.
NOTE
Sensors are sealed units and cannot be repaired. If the sensor is shorted (burned out), the PCB
will shut off automatically. When the sensor is replaced, The PCB will automatically reset.
G. Replace with new sensor and adjust so that sensor face is about 1/8 inch (3.175 mm) from
splash plate.
H. Replace splash plate.
I. Replace dispensing paddles and drip tray.
J. Turn key switch ON.
6.4 CONCENTRATE PUMP AND MOTOR
CAUTION
THE MOTOR IS A FACTORY SEALED UNIT AND IS NOT FIELD REPAIRABLE. ANY ATTEMPT
TO FIELD REPAIR WILL VOID WARRANTY.
A. Replacement
(1) If concentrate pump will operate, depress FLUSH mode until a clear stream of water is
dispensed.
(2) If concentrate pump will not operate, proceed to Step (3).
10
dinecompany.com

(3) Turn key switch OFF.
(4) Remove check valve from concentrate container by pulling up.
(5) Remove spout by loosening nut (turn counter clockwise) and pulling spout down. Do NOT
lose O-Ring between spout and threaded adaptor.
(6) Remove elbow retainer.
(7) Remove inlet elbow by pulling up.
(8) Remove concentrate pump by pulling out of pump support.
(9) Replace new concentrate pump by reversing above procedure.
(10) Turn key switch ON.
(11) Readjust °Brix (see Section 1.10).
B. Repair
(1) Remove the four (4) knurled screws on top of pump face plate.
(2) Remove face plate and clean with water. If any inner surface exposed to the impeller is
grooved or severely worn, replace the damaged parts.
(3) Remove the impeller and clean with plain water. DO NOT use pliers or other sharp
instruments to remove the impeller. Be careful not to scratch or deface inner concentrate
pump body. If the impeller is cut, nicked or severely worn, replace.
CAUTION
IF CONCENTRATE PUMP IS NOT PROPERLY ASSEMBLED, IT CAN CAUSE A PUMP
MOTOR OVERLOAD CONDITION AND WILL CAUSE THE CONTROL PCB TO GO INTO
OVER CURRENT LIMITING (YELLOW LED ON WHILE TRYING TO DISPENSE).
(4) Remove four (4) Phillips screws and separate concentrate pump body from motor to expose
the shaft seal (black). The shaft seal must be replaced if the inner cylindrical (seal/shaft)
surface and/or the outer cylindrical (seal/pump body) surface is grooved, scratched or
excessively worn. If the seal has failed prematurely, it is advisable to replace both the seal
and pump body. Clean only with plain water.
a. To replace seal, carefully press seal out of body.
CAUTION
USE ONLY LANCER LUBE. USE OF OTHER GREASE, LUBRICANT OR COMPOUNDS
MAY CAUSE OFF TASTE, ODOR AND/OR DAMAGE TO UNIT AND WILL VOID
WARRANTY.
b. Lubricate inside and outside of seal with Lancer lube (PN 15-0046). Press seal into
body until completely seated.
(5) Coat motor shaft and boss at base of shaft with Lancer lube. Carefully assemble pump body
to motor using a rotating motion so as not to damage shaft seal. Replace screws and
tighten evenly, 1/4 turn after finger tight. DO NOT TIGHTEN EXCESSIVELY.
(6) Install impeller, being careful to flex all impeller arms in a clockwise fashion (motor shaft will
rotate counter clockwise). Align the flats on the shaft and impeller and gently push impeller
onto the shaft until seated against back pump body surface. Operate the concentrate pump
(by using a test kit or depressing the paddle with the water supply OFF) for a few seconds
to properly seat the impeller.
(7) Replace o-ring, face plate and four (4) knurled screws. The sequence in which the screws
are tightened should be in a rotational manner, so that the face plate is tightened evenly (in
order of 3, 6, 9, and 12 o'clock positions). DO NOT TIGHTEN EXCESSIVELY.
6.5 PUMP SUPPORT
WARNING
DISCONNECT THE POWER CORD FROM THE ELECTRICAL OUTLET.
A. Depress FLUSH mode and the dispensing paddles until a clear stream of water is dispensed.
B. Remove check valve from concentrate container.
C. Remove control panel (see Section 6.1).
D. Remove drip tray, dispensing paddles, and splash plate.
11
dinecompany.com

E. Remove spout and concentrate pumps.
F. Remove four (4) screws attaching pump support to frame.
G. Remove pump support by pulling forward. Disconnect electrical connectors from pump support.
H. To assemble, reverse above procedure.
6.6 CONTROL PANEL AND HOUSING
WARNING
DISCONNECT THE POWER CORD FROM THE ELECTRICAL OUTLET.
A. Remove pump support (see Section 6.5).
B. Remove main wiring harness from inside control housing by unscrewing connector.
C. Remove four (4) screws attaching control housing to frame (second and third on each flange of
control housing.)
D. Pull control housing forward and feed 16 pin connector and harness through housing.
E. To assemble, reverse above procedure.
6.7 FLUSH SOLENOID VALVE
A. Turn key switch OFF.
B. Close inlet water shut off valve.
C. If coil is defective, remove wiring harness by pulling off quick connect terminals. Replace coil
and reassemble.
D. If solenoid valve is defective, remove plastic tubes (inlet and outlet) by loosening tube fitting
nuts.
E. Remove two (2) screws attaching solenoid valve bracket to tank assembly.
F. Remove two (2) screws attaching solenoid valve to bracket.
G. Replace solenoid valve by reversing above procedure.
NOTE
If the coil is shorted (burned out), or a short exists for any other reason in the +12VDC solenoid
wiring, the control PCB will shut off automatically (Green LED OFF). When the short is removed
(repaired), the control PCB will automatically reset.
6.8 WATER SOLENOID VALVE
WARNING
DISCONNECT THE POWER CORD FROM THE ELECTRICAL OUTLET.
A. Turn key switch OFF.
B. Close inlet water shut off valve.
C. Remove pump support (see Section 6.5).
D. If solenoid is leaking, remove nut on end of coil and remove coil. Unscrew armature housing
and remove spring and armature. Check for foreign matter or wear. If a foreign material is
present, open water supply and flush. Reassemble.
E. If coil is defective, remove wiring harness by pulling off quick connect terminals. Replace coil
and reassemble.
CAUTION
SOLENOID ASSEMBLY IS NOT NORMALLY FIELD REPAIRABLE. INLET AND OUTLET
ADAPTERS MUST BE FACTORY ASSEMBLED TO SOLENOID TO OBTAIN PROPER
POSITIONING AND OVERALL LENGTH.
F. If solenoid valve is defective, replace as follows.
(1) Remove adaptor from solenoid by pulling out.
(2) Loosen compression nut on inlet side of solenoid assembly. Use a backup wrench.
(3) Reassemble new solenoid assembly. Tighten compression nut 1/4 turn after finger tight.
USE A BACKUP WRENCH.
(4) Connect wiring harness to solenoid assembly.
G. Assemble adaptor assembly to pump support. Make sure hex portion of adaptor assembly is
properly seated in back of pump support. Lubricate o-rings on adaptor.
12
dinecompany.com

H. Assemble in reverse order.
I. Reinstall and secure pump support on unit with four (4) screws.
J. Reinstall concentrate pump, spout and inlet elbow fitting.
K. Turn key switch ON.
L. Check °Brix as required (see Section 1.10).
M. Slide control panel into control housing and tighten both captive screws finger tight.
6.9 REGULATOR ASSEMBLY
A. Unplug unit power cord from electrical outlet.
B. Remove drip tray, dispensing paddles and splash plate.
C. Close inlet water shut off valve.
D. Remove tube assembly from inlet of regulator assembly. USE A BACKUP WRENCH TO
PREVENT DAMAGE TO STRAINER.
E. Loosen nuts on outlet fitting.
F. Remove nut on mounting bracket.
G. Remove regulator assembly.
H. Repair or replace defective parts. Use approved thread sealant.
I. Replace regulator assembly and connect inlet water shut off, being careful to include flare seal
washer.
J. Tighten nuts on copper outlet tube 1/4 turn, after finger tight. Open inlet water shut off valve and
check for leaks.
K. Remove cap on test connection on bottom of repaired or new regulator and connect test gauge.
L. Replace dispensing paddle.
M. Turn key switch ON.
N. Dispense one (1) six (6) ounce (177.4 ml) drink and discard. Set regulator at 25 PSIG
(1.76 kg/cm2) while activating the dispensing paddle.
O. Remove test gauge and replace test connection cap.
P. Reassemble unit.
Q. Check °Brix and adjust as necessary (see Section 1.10).
6.10 VACUUM BREAKER
A. Close inlet water shut off valve.
B. Remove lid over agitator deck.
C. Remove vacuum breaker by loosening adaptor nut on top side of tank assembly.
D. Remove cap from end of vacuum breaker.
CAUTION
USE ONLY LANCER LUBE. USE OF OTHER GREASE, LUBRICANT OR COMPOUNDS MAY
CAUSE OFF TASTE, ODOR AND/OR DAMAGE TO UNIT AND WILL VOID WARRANTY.
E. Inspect umbrella check valve and o-rings. Replace as necessary and reassemble. Lubricate
o-rings only with Lancer lube.
F. Open inlet water shut off valve and check for leaks.
G. Dispense several drinks while observing vacuum breaker. NO WATER SHOULD COME OUT
OF HOLE ON END OF VACUUM BREAKER CAP.
6.11 TRANSFORMER CABINET ASSEMBLY
WARNING
DISCONNECT THE POWER CORD FROM THE ELECTRICAL OUTLET.
A. Remove drip tray, dispensing paddles and splash plate.
B. Unplug both wiring harnesses from back side of transformer cabinet assembly.
C. Remove fan shroud.
D. Remove cover from transformer cabinet assembly by pulling plungers and lifting off.
E. Loosen nuts at base of transformer cabinet assembly.
F. Replace defective transformer(s).
G. To assemble, reverse above procedure.
13
dinecompany.com

6.12 ELECTRONIC ICE BANK CONTROL
WARNING
DISCONNECT FROM POWER SOURCE BEFORE BEGINNING THIS PROCEDURE.
A. Remove two screws retaining Rear Lid over Agitator Deck and remove Lid.
B. Remove cover from electronic ice bank control.
C. Disconnect ice bank probe lead from control board.
D. Remove three leads from ice bank control, noting which lead goes to the Junction Box (HOT IN)
and which lead goes to the Compressor (HOT OUT). The third lead goes to Agitator Motor. The
lead going to the Compressor is on Pin 1 of the Agitator/IBC connector and the lead going to
the Junction Box is on Pin 3 (see Wiring Diagram, Section 9.1, Page 22).
E. Remove the screws holding the ice bank control bracket to the Agitator deck and remove the
control. Save screws for reinstallation.
F. Remove one screw holding the bracket on the replacement electronic ice bank control housing
and loosen the other. Spin the bracket 90°, reinstall screw, and tighten both screws.
G. Mount new control to the Agitator Deck, using the screws removed in Step E.
H. Remove the cover of the replacement control. Connect lead from Compressor to screw
terminal marked "HOT OUT". Connect lead from Junction Box and Agitator Motor to terminal
marked "HOT IN" (see Wiring Diagram, Section 9.1, Page 22).
I. Plug the Probe Lead into the connector on the PCB.
J. Check all connections, and install Control Housing Assembly Cover. Tie all leads together,
ensuring that all leads are clear of any rotating equipment.
K. Reconnect to power source. When power is supplied to the EIBC, there is a five minute delay
before Compressor start-up. The Power Indicator Lamp should be illuminated and visible
through the Control Housing Assembly Cover. When the Compressor starts, the Power
Indicator Lamp will turn off.
L. Replace Rear Lid over Agitator Deck and the two screws.
M. Conduct operational check of unit.
6.13 AGITATOR MOTOR
WARNING
DISCONNECT THE POWER CORD FROM THE ELECTRICAL OUTLET.
A. Remove lid over agitator deck.
B. Unplug wiring harness from agitator deck.
C. Remove four (4) screws holding agitator motor bracket to agitator deck.
D. Disconnect agitator motor from wiring harness and remove.
E. Inspect propeller to be sure no blades are broken. Remove and replace propeller if damaged.
F. Replace agitator motor and propeller by reversing above procedure.
6.14 AGITATOR DECK
WARNING
DISCONNECT FROM POWER SOURCE BEFORE BEGINNING THIS PROCEDURE. WATER
BATH MUST BE DRAINED AND ICE BANK MUST BE COMPLETELY MELTED.
A. Remove two screws retaining Rear Lid over Agitator Deck and remove Lid.
B. Remove cover from electronic ice bank control.
C. Disconnect ice bank probe lead from control board.
D. Disconnect wire harness from Agitator Deck.
E. Remove foam plug from hole around ice bank probe lead.
F. Remove two (2) nuts holding Agitator Deck to tank assembly.
G. Lift Agitator Deck out of unit.
H. Installation is reverse of removal.
6.15 WATER COIL CAGE ASSEMBLY
WARNING
DISCONNECT THE POWER CORD FROM THE ELECTRICAL OUTLET.
A. Close inlet water shut off valve.
14
dinecompany.com

B. Remove agitator deck (see Section 6.14).
C. Remove water from ice bank compartment.
D. Loosen tubing nuts on water coil.
E. Remove four (4) nuts holding cage assembly to bottom of tank.
F. Remove cage assembly from tank.
G. Remove defective water coil from cage assembly.
H. Reassemble cage assembly in tank by reversing procedure. Tighten water coil tubing nuts 1/4
turn after finger tight.
I. Open inlet water shut off valve and check for leaks.
J. Refill ice bank compartment to overflow port.
K. Replace agitator deck and lid.
6.16 FRONT COVER
CAUTION
CARE SHOULD BE USED WHEN HANDLING FRONT COVER SO AS TO NOT SCRATCH OR
MAR SURFACE. WHEN CLEANING, USE ONLY DAMP CLEAN CLOTH.
A. Lift front cover up so that it rests on top cover.
B. Loosen two (2) wing nuts (do not remove) holding retainer to front edge of top cover.
C. Slide retainer down.
D. Pull front cover forward and remove.
E. To reassemble, reverse procedure.
6.17 TOP COVER
A. Flush both sides of unit.
B. Turn key switch OFF.
C. Remove both lids.
D. Remove front cover.
E. Remove check valves from concentrate tubes.
F. Remove concentrate containers.
G. Loosen three screws (do not remove) holding top cover to frame at front of unit.
H. Loosen three screws (do not remove) holding top cover to frame at rear of unit.
I. Lift top cover up and off unit.
J. To reassemble, reverse the above procedures.
6.18 WRAPPER
WARNING
DISCONNECT THE POWER CORD FROM THE ELECTRICAL OUTLET.
A. Remove front cover (see Section 6.16) and top cover (see Section 6.17).
B. Remove drip tray, dispensing paddles and splash plate.
C. Remove eight (8) screws on front of unit [four (4) on each side]. Locations are as follows.
(1) Top and bottom in flange of control housing.
(2) Two (2) in wrapper below pump support.
D. Spread wrapper at front of unit slightly on each side in order to clear frame. Push wrapper
toward back of unit until wrapper is free of frame.
NOTE
It is not necessary to remove control housing and pump support when removing wrapper.
E. To reassemble, reverse above procedure being sure that cutout for power cord in rear of wrap-
per seats properly. Clean only with damp clean cloth or approved non-abrasive spray or liquid
stainless steel cleaner.
6.19 CONDENSER FAN MOTOR
WARNING
DISCONNECT THE POWER CORD FROM THE ELECTRICAL OUTLET.
A. Disconnect fan motor electrical cord from junction box.
15
dinecompany.com

B. Remove four (4) screws holding fan guards.
C. Remove four (4) nuts holding fan motor bracket to base of unit and remove from unit.
D. Remove fan motor from bracket.
E. Remove fan blade from fan motor. Do NOT bend fan blade.
F. Clean condenser with a brush.
G. To reassemble, reverse above procedure.
7. TROUBLESHOOTING (Causes are listed in order of probability.)
TROUBLE CAUSE REMEDY
7.1 No water or concentrate A. Key switch OFF. A. Turn key switch ON.
on either side, or no B. Unit not connected to B. Connect unit power cord to
power. electrical outlet. electrical outlet.
C. Both electrical circuit C. Reset circuit breaker by depressing
breakers on control box button on control box.
assembly tripped.
D. Power supply electrical D. Reset breaker or replace fuse.
breaker tripped or fuse blown. If problem persists:
1. Check unit for electrical short
(wiring, compressor, fan motor,
etc.).
2. Electrical circuit overload.
Switch to another circuit.
E. Wiring harnesses not E. Connect wiring harness to
connected to transformer transformer cabinet assembly.
cabinet assembly.
F. Sold Out has locked out F. Check product levels and reset
valves. Sold Out.
7.2 No water or concentrate A. Driver PCB not properly A. Connect driver PCB to control
on one side only. connected to control panel panel PCB.
PCB.
B. Driver PCB defective. B. Replace driver PCB.
C. Sensor not adjusted properly C. Adjust sensor to move it closer
in relation to paddle. to paddle.
D. Sensor not connected to D. Connect sensor to wiring harness.
wiring harness.
E. Defective sensor. E. Replace sensor.
F. Water solenoid valve defective F. Repair or replace water solenoid
and concentrate pump not valve and properly install
properly installed in pump concentrate pump in pump support
support or defective. or repair or replace same.
G. Sold Out has locked out G. Check product levels and reset
valves. Sold Out.
7.3 Water only - A. Check valve not properly A. Push check valve all the way into
no concentrate. installed in concentrate concentrate tank.
containers.
B. Concentrate pump not B. Properly install (push in)
properly installed in pump concentrate pump in pump
support. support.
C. Concentrate pump defective. C. Repair or replace concentrate
pump.
D. Check valve clogged. D. Remove and clean check valve.
E. Air leak caused by defective E. Replace o-rings on check valve or
o-ring(s) on check valve or pump inlet fitting.
pump inlet fitting.
F. Frozen concentrate. F. Thaw concentrate.
G. Driver PCB defective. G. Replace driver PCB.
H. Concentrate tube kinked. H. Remove kink in tube.
7.4 Concentrate only - no A. Inlet water shut off valve A. Turn inlet water shut off valve ON.
water either side. turned OFF.
(Section 7.4 continued on next page)
16
dinecompany.com

(Section 7.4 continued from previous page)
B. Inlet water strainer dirty/ B. Remove strainer and clean.
clogged.
C. Water coils frozen. C. Replace ice bank control. Check
umbrella check valve in vacuum
breaker and replace if necessary.
D. Water regulator not properly D. Connect test gauge to each
set and not passing water. water regulator and reset to
proper pressure.
E. Water solenoid valve not E. Connect wiring harness to water
connected to wiring. solenoid valves.
F. Driver PCBs defective. F. Replace driver PCBs.
7.5 Concentrate only - no A. Defective driver PCB. A. Replace driver PCB.
water on one side only. B. Water solenoid valve not B. Connect wiring harness to water
connected to wiring harness. solenoid valve.
C. Defective coil on water C. Replace coil.
solenoid.
D. Defective water solenoid D. Repair or replace water solenoid
valve. valve.
E. Water coil frozen. E. Replace ice bank control. Inspect
umbrella check valve in vacuum
breaker and replace if necessary.
F. Water regulator not properly F. Connect test gauge to water
set and not passing water. regulator and reset to proper
pressure.
G. Water regulator defective. G. Repair or replace water regulator.
7.6 No flush water either A. Flush solenoid valves not A. Connect wiring harness to water
side, system dispenses connected to wiring harness. flush solenoid valves.
normally. B. Both driver PCBs defective. B. Replace driver PCBs.
C. Both FLUSH switches bad. C. Replace front panel.
7.7 Weak drink or A. Swollen or pinched o-ring on A. Replace o-ring(s).
inconsistent drink. check valve or pump inlet
fitting.
B. Vent holes surrounding B. Remove any pieces of seal that
opening on Minute Pak®are covering vent holes.
are covered with paper
left from package seal.
C. Water leaking into C. Replace ball and o-ring in check
concentrate container valve; dispose of diluted
during “FLUSH” cycle due concentrate and refill concentrate
to missing ball in check valve. container with fresh product.
7.8 No water all valves. A. Inlet water shut off valve A. Check to make sure valve is “ON”.
turned “OFF”.
B. Water bath frozen due to B. Contact Phone Fix®. Turn water
bad ice bank control or supply “OFF”, unplug dispenser,
refrigeration unit. and refrigerate concentrate.
7.9 Water leaks at A. O-ring missing where spout A. Replace o-ring.
spout connection. connects to dispenser.
B. Nut loose on spout. B. Tighten nut.
7.10 Drink will not shut off. A. Spring missing or loose A. Reinstall spring or replace paddle.
on paddle.
B. Paddle broken. B. Replace paddle.
7.11 Cup does not fill A. Portion control settings out A. Reset portion control program.
completely or overflows of program. (See Portion Control Programming
(Portion Control Only). Instructions.)
TROUBLE CAUSE REMEDY
17
dinecompany.com
