Landa SGP-302214S User manual

8.913-917.0
OPERATOR’S MANUAL
For Home Depot Tool Rental Support consult,
our web page at www.hdtr.landa.com
■ SGP-302214S
SGP
L
I
S
T
E
D
®
8.900-266.0
YELLOW 15° GREEN 25° WHITE 40°
RED 0°

CONTENTS
2
Model Number ________________________________________
Serial Number ________________________________________
Date of Purchase ______________________________________
The model and serial numbers will be found on a decal attached to
the pressure washer. You should record both serial number and date
of purchase and keep in a safe place for future reference.
HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
Introduction & Important Safety Instructions ................................. 4-5
Component Identification ................................................................. 6
Assembly Instructions ...................................................................... 7
Operating Instructions................................................................... 8-9
Detergents and Cleaning Tips........................................................ 10
Shut-Down and Clean Up .............................................................. 11
Storage........................................................................................... 11
Maintenance.............................................................................. 12-14
Troubleshooting......................................................................... 15-17
Maintenance & Oil Change Charts ................................................ 18
Exploded View & Parts Lists ..................................................... 19-21
Control Panel & Parts List ............................................................. 22
Hose & Spray Gun Assembly ........................................................ 23
Downstream Injector Assembly...................................................... 24
Hose Reel Option .......................................................................... 25
UU1 Unloader Exploded View and Parts List................................. 26
LG Series Pump Exploded View and Parts List ........................ 27-28
Burner Specifications ................................................................ 29-31
Warranty

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
3
PRESSURE WASHER
OPERATOR’S MANUAL
INTRODUCTION & IMPORTANT SAFETY INFORMATION
Thank you for purchasing this Pressure Washer.
We reserve the right to make changes at any time
without incurring any obligation.
Owner/User Responsibility:
The owner and/or user must have an understanding of
the manufacturer’s operating instructions and warnings
before using this pressure washer.Warning information
should be emphasized and understood. If the operator
is not fluent in English, the manufacturer’s instructions
and warnings shall be read to and discussed with
the operator in the operator’s native language by the
purchaser/owner, making sure that the operator com-
prehends its contents.
Owner and/or user must study and maintain for future
reference the manufacturers’ instructions.
The operator must know how to stop the machine
quickly and understand the operation of all controls.
Never permit anyone to operate the engine without
proper instructions.
SAVE THESE INSTRUCTIONS
This manual should be considered a permanent
part of the machine and should remain with it if
machine is resold.
When ordering parts, please specify model and
serial number. Use only identical replacement parts.
This machine is to be used only by trained operators.
IMPORTANT SAFETY
INFORMATION
READ OPERATOR’S
MANUAL THOROUGHLY
PRIOR TO USE.
WARNING:To reduce the risk of
injury, read operating instruc-
tions carefully before using.
1. Read the owner's manual
thoroughly. Failure to follow
instructions could cause mal-
function of the machine and
result in death, serious bodily
injury and/or property dam-
age.
2. Know how to stop the machine and bleed pressure
quickly. Be thoroughly familiar with the controls.
3. Stay alert — watch what you are doing.
WARNING
KEEP WATER
SPRAY AWAY FROM
ELECTRICAL WIRING.
WARNING: Keep wand, hose, and
water spray away from electric
wiring or fatal electric shock may
result.
4. All installations must comply
with local codes. Contact
your electrician, plumber,
utility company or the selling
distributor for specific details.
WARNING
EAR PROTECTION
MUST BE WORN
WARNING:This machine exceeds
85 db appropriate ear protection
must be worn.
WARNING
USE PROTECTIVE
EYE WEAR
AND CLOTHING
WHEN OPERATING
THIS EQUIPMENT.
WARNING: High pressure spray
can cause paint chips or other
particles to become airborne
and fly at high speeds. To avoid
personal injury, eye, hand and
foot safety devices must be
worn.
5. Eye, hand, and foot protection
must be worn when using this
equipment.
6. Keep operating area clear of all persons.
RISK OF EXPLOSION:
OPERATE ONLY WHERE
OPEN FLAME OR TORCH
IS PERMITTED
WARNING
WARNING: Flammable liquids
can create fumes which can ig-
nite, causing property damage
or severe injury.
WARNING: Risk of explosion —
Operate only where open flame
or torch is permitted.
RISK OF FIRE.
DO NOT ADD FUEL
WHEN OPERATING
MACHINE.
WARNING
WARNING: Risk of fire — Do not
add fuel when the product is
operating or still hot.
WARNING: Do not use gasoline
crankcase draining or oil con-
taining gasoline, solvents or
alcohol. Doing so will result in
fire and/or explosion.
WARNING: Risk of fire — Do not
Spray flammable liquids.
WARNING:This product contains chemicals known
to the state of California to cause cancer and birth
defects or other reproductive harm. Operation of
this equipment may create sparks that can start
fires around dry vegetation. A spark arrestor may
be required. The operator should contact: Local
fire agencies for laws or regulations relating to fire
prevention requirements.

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
OPERATOR’S MANUAL PRESSURE WASHER
4
13. To reduce the risk of injury, close supervision is
necessary when a machine is used near children.
Do not allow children to operate the pressure
washer. This machine must be attended during
operation.
TRIGGER GUN KICKS
BACK - HOLD WITH
BOTH HANDS
WARNING
WARNING: Grip cleaning wand
securely with both hands before
starting. Failure to do this could
result in injury from a whipping
wand.
14. Never make adjustments on
machine while in operation.
15. Be certain all quick coupler fittings are secured
before using pressure washer.
RISK OF INJECTION
OR SEVERE INJURY
TO PERSONS. KEEP
CLEAR OF NOZZLE.
WARNING
WARNING: High pressure devel-
oped by these machines will
cause personal injury or equip-
ment damage. Keep clear of
nozzle. Use caution when oper-
ating. Do not direct discharge
stream at people, or severe in-
jury or death will result.
WARNING
PROTECT FROM
FREEZING
WARNING: Protect machine from
freezing.
16. To keep machine in best
operating conditions, it is
important you protect machine
from freezing.Failure to protect
machine from freezing
could cause malfunction of the
machine and result in death,
serious bodily injury, and/or property damage. Fol-
low storage instructions specified in this manual.
17. Inlet water must be clean fresh water and no hotter
then 90°F.
WARNING
RISK OF
ASPHYXIATION: USE
THIS PRODUCT ONLY
IN A WELL
VENTILATED AREA.
WARNING: Risk of asphyxiation.
Use this product only in a well
ventilated area.
18. Avoid installing machines in
small areas or near exhaust
fans. Adequate oxygen is
needed for combustion or
dangerous carbon monoxide
will result.
19. Manufacturer will not be liable for any changes
made to our standard machines or any components
not purchased from us.
20. The best insurance against an accident is precau-
tion and knowledge of the machine.
IMPORTANT SAFETY INFORMATION
7.Allow engine to cool for 1-2 minutes before refueling.If
any fuel is spilled, make sure the area is dry before
testing the spark plug or starting the engine. (Fire
and/or explosion may occur if this is not done.)
Gasoline engines on mobile or portable equipment
shall be refueled:
a. outdoors;
b. with the engine on the equipment stopped;
c. with no source of ignition within 10 feet of
the dispensing point; and
d. with an allowance made for expansion of the
fuel should the equipment be exposed to a
higher ambient temperature.
In an overfilling situation, additional precautions are
necessary to ensure that the situation is handled
in a safe manner.
WARNING: Risk of injury. Disconnect battery
ground terminal before servicing.
8. When in use , do not place machine near flammable
objects as the engine is hot.
9. Oil burning appliances shall be installed only in
locations where combustible dusts and flammable
gases or vapors are not present. Do not store or
use gasoline near this machine.
10. Use No. 1 or No. 2 heating oil (ASTM D306) only.
NEVER use gasoline in your fuel oil tank. Gasoline
is more combustible than fuel oil and could result
in a serious explosion. NEVER use crankcase or
waste oil in your burner. Fuel unit malfunction could
result from contamination.
11. Do not confuse gasoline and fuel oil tanks. Keep
proper fuel in proper tank.
WARNING
RISK OF INJURY.
HOT SURFACES
CAN CAUSE BURNS
WARNING: Risk of injury. Hot
surfaces can cause burns. Use
only designated gripping areas
of spray gun and wand. Do not
place hands or feet on non-insu-
lated areas of the pressure
washer.
12. Transport/Repair with fuel tank EMPTY or with fuel
shut-off valve OFF.
HOT DISCHARGE FLUID:
DO NOT TOUCH OR
DIRECT DISCHARGE
STREAM AT PERSONS.
CAUTION: Hot discharge fluid.
Do not touch or direct discharge
stream at persons.
WARNING: This machine pro-
duces hot water and must have
insulated components attached
to protect the operator.

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
5
PRESSURE WASHER
OPERATOR’S MANUAL
IMPORTANT SAFETY INFORMATION
WARNING
RISK OF INJURY
FROM FALLS WHEN
USING LADDER.
WARNING: Be extremely careful
when using a ladder, scaffolding
or any other relatively unstable
location. The cleaning area
should have adequate slopes
and drainage to reduce the pos-
sibility of a fall due to slippery
surfaces.
21. Do not allow acids, caustic or abrasive fluids to pass
through the pump.
22. Never run pump dry or leave spray gun closed
longer than 1-2 minutes.
23. Machines with shut-off spray gun should not be
operated with the spray gun in the off position for
extensive periods of time as this may cause dam-
age to the pump.
24. Protect discharge hose from vehicle traffic and
sharp objects. Inspect condition of high pressure
hose before using or bodily injury may result.
25. Before disconnecting discharge hose from water
outlet, turn burner off and open spray gun to al-
low water to cool below 100° before stopping the
machine. Then open the spray gun to relieve pres-
sure. Failure to properly cool down or maintain the
heating coil may result in a steam explosion.
WARNING: Moving this machine
on a incline may cause instability
and could result in the machine
tipping over. Equipment dam-
age or body harm could occur.
26. Do not overreach or stand on
unstable support. Keep good foot-
ing and balance at all times.
27. Do not operate this machine when fatigued or under
the influence of alcohol, prescription medications,
or drugs.
28. In oil burning models, use only kerosene, No. 1
home heating fuel, or diesel. If diesel is used, add
a soot remover to every tankful.
Follow the maintenance instructions
specified in the manual.
WARNING
TIP OVER HAZARD

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
OPERATOR’S MANUAL PRESSURE WASHER
6
COMPONENT IDENTIFICATION
Pump — Develops high pressure.
Starter Grip — (Not Shown) Used for starting the
engine manually.
Spray Gun — Controls the application of water and
detergent onto cleaning surface with trigger device.
Includes safety latch.
Detergent Injector — Allows you to siphon and mix
detergents.
Variable Pressure Control Wand — Must be con-
nected to the spray gun. This wand handle controls
dishcharge flow from one tube to both wand tubes.
When water is discharged from both tubes you will have
a pressure loss and allows chemical siphoning when
used in combination with a detergent injector.
High Pressure Hose — Connect one end to water
pump discharge nipple and the other end to spray gun.
Note:If trigger on spray gun is released for more
than 2 minutes, water will leak from valve. Warm
water will discharge from pump protector onto floor.
This system prevents internal pump damage.
Brass
Soap
Nozzle
Nozzle
Quick
Coupler
High Pressure
Hose
Quick
Coupler
Collar
Discharge
Nipple
Trigger
Spray
Gun
Pump
Water Supply
Hose
(not included)
Unloader
Detergent
Injector
Control Wand
Handle
Variable Pressure
Control wand
Wand Coupler
Starter Grip
Gasoline
Tank

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
7
PRESSURE WASHER
OPERATOR’S MANUAL
ASSEMBLY INSTRUCTIONS
STEP 1: Attach the high pres-
sure hose to the spray gun
using teflon tape on hose
threads.
STEP 3: Release the coupler collar
and push the nozzle until the collar
clicks. Pull the nozzle to make sure it
is seated properly.
STEP 5: Connect the high pressure
hose to the pump discharge fitting. Push
coupler collar forward until secure.
STEP 2: Pull the spring-loaded collar
of the wand coupler back to insert your
choice of pressure nozzle.
STEP 6: Connect garden hose to the
cold water source.
STEP 7: Connect the garden hose
to pump water inlet. Inspect inlets.
CAUTION: Do not run the pump
without water or pump damage
will result.
Safety
Latch
Spray
Gun
High Pressure
Hose
Wand
Coupler
Pressure
Nozzle
Pressure
Nozzle
Wand
Coupler
Wand
Collar
Discharge Fitting
High Pressure Hose
Cold
Water
Source
Garden
Hose
Coupler Collar
STEP 4: Remove shipping
cap and install oil dipstick.
Check pump oil level by using
dipstick or observe oil level in
oil window (if equipped). Use
30 wt. non detergent oil.
DipStick
Pump
Water Inlet
Garden
Hose

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
OPERATOR’S MANUAL PRESSURE WASHER
8
OPERATING INSTRUCTIONS
STEP 1: Check engine oil level. Oil level should be level with the bottom
of the oil filler neck. Be sure the machine is level when checking the oil
level. (Refer to the engine's operating manual included with machine.) We
recommend that the oil be changed after the first 5 hours of use, then once
every 50 hours. Note: Improper oil levels will cause low oil sensor to shut
off engine. IMPORTANT! Do not run engine with high or low oil levels
as this will cause engine damage.
STEP 3: Connect garden hose to
the cold water source and turn water
on completely. Never use hot water.
STEP 5: Rotate the fuel shut-off valve to the "On"
position. Slide the fuel valve lever to the "ON" position.
When the engine is not in use, leave the fuel valve in
the "OFF" position.
STEP 4: Trigger the spray gun to
eliminate trapped air then wait for a
steady flow of water to emerge from
the spray nozzle.
STEP 2: Fill gas tank with unleaded
gasoline. Do not use leaded gaso-
line. Caution: Read warnings on
pg. 4 and engine manual.
STEP 6: Pull the choke lever out to the "Choke" position
(on a warm engine, leave the choke lever in, in the run
position). Push the choke lever to the "Closed" position.
To restart a warm engine, leave the choke lever in the
"Open" position.
Oil Dipstick Gas
Tank
Cold
Water
Source
Garden
Hose
Choke
Lever
Fuel
Valve

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
9
PRESSURE WASHER
OPERATOR’S MANUAL
OPERATING INSTRUCTIONS
Safety
Latch
STEP 7: Turn the engine to "Run" position. STEP 8: Pull the starter grip. If the engine fails to start
after 2 pulls, squeeze the trigger gun to release pressure
and repeat step. Return starter gently. After the engine
warms up enough to run smoothly, move choke to run
position and throttle to fast position.
CAUTION: Small engines may kick back. Do not hold
pull starter grip tightly in hand.
WARNING! Never replace noz-
zles without engaging the safety
latch on the spray gun trigger.
The two color-coded quick connect
nozzles provide a wide array of
spray widths from 25° to 40° and
are easily accessible when placed in
the convenient rubber nozzle holder,
which is provided on the front of the
machine.
NOTE: For a more gentle rinse,
select the white 40° or green 25°
nozzle.
NOZZLES
Throttle
Burner
Swutch
STEP 9: If hot water is required, turn
on burner switch to begin heating
water.
Selection of high or low pressure is accompanied by
turning the handle. NOTE: High pressure nozzle must
be inserted at end of wand to obtain high pressure. To
apply soap read operator's manual.
Variable Pressure
Control Handle
Trigger
Variable Pressure
Wand (VP)
High
Pressure
Nozzle
Brass Soap
Nozzle

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
OPERATOR’S MANUAL PRESSURE WASHER
10
WARNING: Some detergents
may be harmful if inhaled or in-
gested, causing severe nausea,
fainting or poisoning.The harm-
ful elements may cause property
damage or severe injury.
STEP 1: Connect detergent injec-
tor to discharge nipple on machine,
Connect high pressure hose to injector with quick
coupler(check to make sure locking coupler sleeves
are in proper position before applying water pressure
STEP 2: Use detergent designed
specifically for pressure washers.
Household detergents could dam-
age the pump. Prepare detergent
solution as required by the manu-
facturer. Fill a container with pres-
sure washer detergent. Place the
fi l ter end of detergent suction tube
into the detergent container.
STEP 3: Apply safety latch to spray gun trigger. Turn
variable pressure control handle until discharge water
exits both tubes. NOTE: Detergent cannot be applied
using Green or White nozzles.
STEP 4: With the engine running, pull trigger to operate
machine. Liquid detergent is drawn into the machine and
mixed with water. Apply detergent
to work area. Do not allow deter-
gent to dry on surface.
IMPORTANT: You must flush
the detergent injection system
after each use by placing the
suction tube into a bucket of
clean water, then run the pres-
sure washer in low pressure for 1-2 minutes.
THERMAL PUMP PROTECTION
If you run the engine on your pressure washer for 3-5
minutes without pressing the trigger on the spray gun,
circulating water in the pump can reach high tempera-
tures. When the water reaches this temperature, the
pump protector engages and cools the pump by dis-
charging the warm water onto the ground.This thermal
device prevents internal damage to the pump.
CLEANING TIPS
Pre-rinse cleaning surface with fresh water. Place de-
tergent suction tube directly into cleaning solution and
apply to surface at low pressure (for best results, limit
your work area to sections approximately 6’ square
and always apply detergent from bottom to top). Allow
detergent to remain on surface 1-3 minutes. Do not al-
low detergent to dry on surface. If surface appears to
be drying, simply wet down surface with fresh water. If
needed, use brush to remove stubborn dirt. Rinse at
high pressure from top to bottom in an even sweeping
motion keeping the spray nozzle approximately 1’ from
cleaning surface. Use overlapping strokes as you clean
and rinse any surface. For best surface cleaning action
spray at a slight angle.
Recommendations:
• Before cleaning any surface, an inconspicuous
area should be cleaned to test spray pattern and
distance for maximum cleaning results.
• If painted surfaces are peeling or chipping, use
extreme caution as pressure washer may remove
the loose paint from the surface.
• Keep the spray nozzle a safe distance from the
surface you plan to clean. High pressure wash a
small area, then check the surface for damage. If
no damage is found, continue to pressure washing.
CAUTION - Never use:
• Bleach, chlorine and other corrosive chemicals
• Liquids containing solvents (i.e., paint thinners,
gasoline, oils)
• Tri-sodium phosphate products
• Ammonia products
• Acid-based products
These chemicals will harm the machine and will dam-
age the surface being cleaned.
RINSING
It will take a few seconds for the detergent to clear.
Apply safety latch to spray gun. Select and install the
desired high pressure nozzle. NOTE: You can also stop
detergent from flowing by simply removing detergent
siphon tube from bottle.
WARNING
DETERGENTS AND CLEANING TIPS
Control
Handle
Detergent
Injector
Discharge
Nipple
High Pressure
Hose
Quick
Coupler

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
11
PRESSURE WASHER
OPERATOR’S MANUAL
SHUTTING DOWN AND CLEAN-UP
CAUTION: Always store your pressure washer in a
location where the temperature will not fall below
32°F (0°C).The pump in this machine is susceptible
to permanent damage if frozen. FREEZE DAMAGE
IS NOT COVERED BY WARRANTY.
1. Stop the pressure washer, squeeze spray gun trig-
ger to release pressure.
2. Detach water supply hose and high pressure hose.
3. Turn on the machine for a few seconds, until re-
maining water exits. Turn engine off immediately.
4. Drain the gas and oil from the engine.
5. Do not allow high pressure hose to become kinked.
6. Store the machine and accessories in a room which
does not reach freezing temperatures.
CAUTION: Failure to follow the above directions will
result in damage to your pressure washer.
When the pressure washer is not being operated or is
being stored for more than one month, follow these
instructions:
1. Replenish engine oil to upper level.
2. Drain gasoline from fuel tank, fuel line, fuel valve
and carburetor.
3. Pour about one teaspoon of engine oil through
the spark plug hole, pull the starter grip several
times and replace the plug. Then pull the starter
grip slowly until you feel increased pressure which
indicates the piston is on its compression stroke and
leave it in that position. This closes both the intake
and exhaust valves to prevent rusting of cylinder.
4. Cover the pressure washer and store in a clean, dry
place that is well ventilated away from open flame
or sparks. NOTE: The use of a fuel additive, such
as STA-BIL®, or an equivalent, will minimize the
formulation of fuel deposits during shortage. Such
additives may be added to the gasoline in the fuel
tank of the engine, or to the gasolinee in a storage
container.
After Extended Storage
CAUTION: Prior to restarting, thaw out any possible
ice from pressure washer hoses, spray gun or wand.
Engine Maintenance
During the winter months, rare atmosheric
conditions may develop which will cause an
icing condition in the carburetor. If this develops, the
engine may run rough, lose power and may stall. This
temporary condition can be overcome by deflecting some
of the hot air from the engine over the carburetor area.
NOTE: Refer to the engine manufacturer's manual for
service and maintenance of the engine.
STORAGE
STEP 1: Remove detergent suction
tube from container and insert into
1 gallon of fresh water.Turn variable
pressure wand handle for low pres-
sure. Pull trigger on spray gun and
siphon water for one minute.
STEP 2: Turn off the engine. STEP 3: Turn off water
supply.
STEP 5: Disconnect the gar-
den hose from the water inlet
on the machine.
STEP 6: Disconnect the high
pressure hose from high pres-
sure outlet.
STEP 7: Engage the
spray gun safety lock.
STEP 4: Press
trigger to release
water pressure.
High Pressure
Outlet Safety
Latch
On-Off
Switch
Water
Inlet

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
OPERATOR’S MANUAL PRESSURE WASHER
12
PREVENTATIVE MAINTENANCE
1. Check to see that the water pump is properly lubri-
cated.
2. Follow Winterizing Procedures to prevent freeze
damage to the pump and coils.
3. Always neutralize and flush detergent from system
after use.
4. If water is known to be high in mineral content, use
a water softener in your water system or de-scale
as needed.
5. Do not allow acidic, caustic or abrasive fluids to be
pumped through system.
6. Always use our high grade quality cleaning prod-
ucts.
7. Never run pump dry for extended periods of time.
8. Use clean fuel: kerosene, No. 1 fuel oil or diesel.
Replace fuel filter every 100 hours of operation.
Avoid water contaminated fuel as it will seize up
the fuel pump.
9. If machine is operated with smoking or eye burning
exhaust, coils will soot up, not letting water reach
maximum operating temperature. (See section on
Air Adjustments.)
10. Never allow water to be sprayed on or near engine
or burner assembly or any electrical component.
11. Periodically delime coils as per instructions.
12. Check to see that engine is properly lubricated.
It is advisable, periodically, to visually inspect the
burner. Check air inlet to make sure it is not clogged or
blocked.Wipe off any oil spills and keep this equipment
clean and dry.
The areas around the pressure washer should be kept
clean and free of combustible materials, gasoline and
other flammable vapors and liquids.
The flow of combustion and ventilating air to the burner
must not be blocked or obstructed in any manner. Con-
sult factory if vent stacking is going to be used.
MAINTENANCE AND SERVICE
Unloader Valves:
Unloader valves are preset and tested at the factory
before shipping. Occasional adjustment of the unloader
may be necessary to maintain correct pressure. Call
your local dealer for assistance.
Winterizing Procedure:
Damage due to freezing is not covered by warranty. Ad-
here to the following cold weather procedures whenever
the washer must be stored or operated outdoors under
freezing conditions.
During winter months, when temperatures drop below
32°F, protecting your machine against freezing is neces-
sary. Store the machine in a heated room. If this is not
possible then mix a 50/50 solution of anti-freeze/water
into a 5 gallon bucket. Place a short section of garden
hose into the bucket and connect it to the machine.
Elevate the bucket and turn the pump on to siphon the
anti-freeze through the machine. If compressed air is
available, an air fitting can be screwed into the inlet
connector and, by injecting compressed air, all water
will be blown out of the system.
High Limit Hot Water Thermostat:
For safety, each machine is equipped with a high limit
control switch. In the event that the temperature of the
water should exceed its operating temperature, the high
limit control will turn the burner off until the water cools.
Pumps:
Use only SAE 30W non-detergent oil. Change oil after
the first 50 hours of use.Thereafter, change the oil every
three months or at 500 hour intervals. Oil level should be
checked by using the dipstick found on top of the pump
or the red dot visible through the oil gauge window. Oil
should be maintained at that level.
Cleaning of Coils:
In alkaline water areas, lime deposits can accumulate
rapidly inside the coil pipes.This growth is increased by
the extreme heat build up in the coil. The best preven-
tion for liming conditions is to use high quality cleaning
detergents. In areas where alkaline water is an extreme
problem, periodic use of our Deliming Powder (part
#9-028008) will remove lime and other deposits before
coil becomes plugged. (See Deliming Instructions for
use of Deliming Powder.)
Deliming Coils:
Periodic flushing of coils is recommended.
1. Fill a container or optional float tank with 4 gallons
of water, then add 1 lb. of deliming powder. Mix
thoroughly.
2. Remove wand assembly from spray gun and put
spray gun into container. Secure the trigger on the
spray gun into the open position.
3. Attach a short section (3-5 ft.) of garden hose to
machine to siphon solution from an elevated con-
tainer. Turn pump switch on, allowing solution to
be pumped through coils back into the container.
Solution should be allowed to circulate 2-4 hours.
4. After circulating solution flush entire system with
fresh water. Reinstall wand assembly to spray gun.
MAINTENANCE

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
13
PRESSURE WASHER
OPERATOR’S MANUAL
Fuel:
Use clean fuel oil that is not contaminated with water
and debris. Replace fuel filter and drain tank every 100
hours of operation.
Use No. 1 or No. 2 Heating Oil (ASTM D306) only.
NEVER use gasoline in your burner tank. Gasoline is
more combustible than fuel oil and a serious explo-
sion could result. NEVER use crankcase or waste oil
in your burner. Fuel unit malfunction could result from
contamination.
Fuel Control System:
These machines utilize a fuel solenoid valve located on
the fuel pump to control the flow of fuel to the combus-
tion chamber. This solenoid valve, which is normally
closed, is activated by a flow switch when water is flow-
ing through it.When an operator releases the trigger on
the spray gun, the flow of water through the flow switch
stops, turning off the current to the fuel solenoid. The
solenoid then closes, shutting off the supply of fuel to
the combustion chamber. Controlling the flow of fuel in
this way allows for an instantaneous burn or no burn
situation, thereby eliminating high and low water tem-
peratures, and combustion smoke normally associated
with machines incorporating a spray gun.
CAUTION: Periodic inspection is recommended to in-
sure that the fuel solenoid valve functions properly.This
can be done by operating the machine and checking to
see that when the trigger on the spray gun is in the off
position, the burner is not firing.
Electrode Setting:
(See illustration below.)
Burner Nozzle:
Keep the tip free of surface deposits by wiping it with a
clean, solvent-saturated cloth, being careful not to plug
or enlarge the nozzle. For maximum efficiency, replace
the nozzle each season.
Beckett Burner Air Adjustment:
Machines are preset and performance tested at the
factory - elevation 100 feet. A one-time initial correction
for your location will pay off in economy, performance
and extended service life. If a smoking or eye-burning
exhaust is being emitted from the stack, two things
should be checked. First, check the fuel to be certain
that kerosene or No. 1 home heating fuel is being used.
Next, check the air adjustment on the burner.
To adjust: Start machine and turn burner ON. Loosen
two locking screws found in the air shutter openings
(refer to illustration below) and close air shutter until
black smoke appears from burner exhaust vent. Note
air band position. Next, slowly open the air shutter until
white smoke just starts to appear. Turn air shutter half-
way back to the black smoke position previously noted.
Tighten locking screws.
If the desired position cannot be obtained using only
the air shutter, lock the air shutter in as close a position
Periodically check wiring connections. If necessary to
adjust electrodes, use diagram.
Top View Side View
5/32"
1/4"
5/32"
Nozzle
Electrode
BECKETT FUEL AIR ADJUSTMENT
Pressure
Gauge
Port
Pressure
Adjustment
Screw
7-00098 Fuel
Pump
To Fuel
Tank
Air Band
Air Band
Adjustment
Screw
Return Line
MAINTENANCE

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
OPERATOR’S MANUAL PRESSURE WASHER
14
as can be obtained, then repeat the above procedure
on the air band setting.
Fuel Pressure Adjustment:
To adjust fuel pressure, turn the adjusting screw clock-
wise to increase, counterclockwise to decrease. Do not
exceed 200 psi. NOTE: When changing the fuel pump,
a bypass plug must be installed in the return port or the
fuel pump will not prime.
Removal of Soot and Heating Coil:
In the heating process, fuel residue in the form of soot
deposits may develop on the heating coil and block air
flow which will affect burner combustion. When soot
has been detected on visual observation, the soot
on the coil must be washed off after following the coil
removal steps.
1. Remove the tank head assembly by lifting the tank
head off.
2. Remove the two pipe nipples and associated fit-
tings.
3. Lift the coil out of the outer wrap.
CAUTION:The coil weighs about 80 lbs. Use proper
lifting techniques.
4. Clean, repair and replace the coil by reversing the
above steps.
Coil Reinstallation:
Reinstall by reversing the above steps 4 through 1.
Final Note:
The 12 VDC burner systems can draw as much as 18
amps! For such burners to run properly, the battery and
engine charging system must be kept in good condition.
The engine must run at the correct RPM to adequately
charge the battery. It is equally important not to throttle
down the engine on models without batteries, since all
power to run the burner comes solely from the engine.
Do not throttle down the engine at anytime while the
machine is operating.
Karcher Clear Fire Oil Burner
Burner Air Adjustment:The oil burner on this machine
is preset for operation at altitudes below 1000 feet. If
operated at higher altitudes, it may be necessary to
adjust the air band for a #1 or #2 smoke spot on the
Bacharach scale.
To adjust, start machine and turn burner ON. Loosen
two locking screws found on the air band and close air
band until black smoke appears from burner exhaust
vent. Note air band position. Next, slowly open the air
band until white smoke just starts to appear. Turn air
band halfway back to the previously noted position.
Tighten locking screws.
KNA Burner Air Adjustment
Reference Numbers
Air Band Locking Screws
Air Band
CAUTION: If white smoke appears from burner ex-
haust vent during start-up or operation, discontinue
use and readjust air bands.
NOTE: If a flue is installed, have a professional service-
man adjust your burner for a #1 or #2 smoke spot on
the Bacharach scale.
MAINTENANCE

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
15
PRESSURE WASHER Troubleshooting Guide
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
LOW OPERATING
PRESSURE Water supply is insufficient Use larger supply hose; clean filter at water
inlet.
Spray nozzle is old, worn or
incorrect Match the nozzle number to the machine and/or replace with new nozzle.
Belt slips Tighten or replace belt; use correct belt.
Plumbing or hose is leaking Check plumbing system for leaks. Retape
leaks with teflon tape.
Unloader is faulty or misadjusted Adjust unloader for proper pressure. Install
repair kit when necessary or replace.
Packing in pump is worn Install new packing kit.
Discharge valve in pump or inlet is
fouled or dirty Check inlet and discharge valve.
Discharge valve or inlet is worn Replace with valve kit.
Spray nozzle has obstruction Remove obstruction.
Steam pressure control valve is
leaking (where applicable) Rebuild or replace as necessary.
Engine RPM is slow Set engine speed at proper specifications /
see serial plate.
BURNER WILL
NOT LIGHT There is little or no fuel Fill tank with fuel.
Improper fuel or water in fuel Drain fuel tank and fill with proper fuel.
Fuel line is clogged Clean or replace fuel line.
Fuel filter is plugged Replace fuel filter as needed.
Burner air bands are misadjusted Readjust air bands for clean burn.
Little or no fuel pressure from fuel
pump Increase fuel pressure to specification and/or replace fuel pump.
Burner transformer is faulty Test transformer for proper arc between
contacts. Replace as needed.
Electrical wiring is disconnected or
has short in it All wire contacts should be clean and tight with no breaks in wire.
Flex coupling is slipping on fuel
pump shaft or burner motor shaft Replace if needed.
ON-OFF switch is defective Check for electrical current reaching burner
assembly with burner switch on.Replace
switch if needed.
Heavy sooting on coil and burner
can cause interruption of air flow and
shorting of electrodes
Clean as required.
Electrode setting is improper Check and reset according to diagram in
manual.
25 amp circuit breaker tripped Push in reset button.
Bridge rectifier defective Test and replace.
12V DC relay defective Test and replace.

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
PRESSURE WASHER Troubleshooting Guide
16
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
BURNER WILL
NOT LIGHT
(continued from
previous page)
Burner nozzle is clogged Clean as required.
Thermostat has malfunctioned Test and replace if needed.
Fuel solenoid has malfunctioned Test and replace if needed.
MACHINE
SMOKES Fuel is improper or water is in fuel Drain tank and replace contaminated fuel.
Air adjustment is improper Readjust air bands on burner assembly.
Fuel pressure is low Adjust fuel pump pressure to specifications.
Burner nozzle is plugged or dirty Replace nozzle. Check parts breakdown for
nozzle size.
Burner nozzle spray pattern is
faulty Replace nozzle. Check parts breakdown for nozzle size.
Coil and burner assembly have
heavy accumulation of soot Remove coils and burner assembly, clean thoroughly. Call local dealer.
Electrode setting is misaligned Realign electrodes to specifications.
Smoke stack has obstruction Check for blockage or other foreign objects.
Engine RPM is low Increase RPM to correct specs. See serial
plate.
LOW WATER
TEMPERATURE Fuel is improper or has water in it Replace with clean and proper fuel.
Fuel pressure is low Increase fuel pressure.
Fuel pump is weak Check fuel pump pressure. Replace pump if
needed.
Fuel filter is partially clogged Replace as needed.
Soot buildup on coils is not
allowing heat transfer Clean coils.
Burner nozzle is improper Call your local dealer for proper nozzle.
WATER
TEMPERATURE
TOO HOT
Incoming water to machine is
warm or hot Lower incoming water temperature.
Fuel pump pressure is too high Call your local dealer for proper fuel pressure.
Fuel pump is defective Replace fuel pump.
Fuel nozzle is incorrect size See parts breakdown or serial plate for proper
size.
Water supplied is insufficient Check water GPM to machine.
Water flow is restricted Check nozzle for obstruction and proper size.
Check serial plate for correct size.
PRESENCE OF
WATER IN OIL Oil seal is worn Check and replace if necessary.
Air humidity is high Check and change oil twice as often.
Packing is worn or bad Check and replace if necessary.

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
17
PRESSURE WASHER Troubleshooting Guide
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
DETERGENT NOT
DRAWING Air is leaking Tighten all clamps. Check detergent lines for holes.
Injector head may be blocked,
dirty or damaged Clean and make sure ball and spring behind detergent hose barb or injector body are working
properly.
Filter screen on detergent
suction hose is plugged Clean or replace.
Detergent has high viscosity Dilute detergent to specifications.
Not using soap nozzle Insert soap nozzle into wand coupler.
Detergent level is low Add detergent if needed.
PUMP RUNNING
NORMALLY BUT
PRESSURE LOW
ON
INSTALLATION
Pump is sucking air Check water supply and possibility of air seepage.
Valves are sticking Check and clean or replace if necessary.
Unloader valve seat is faulty Check and replace if necessary.
Nozzle sized incorrectly Check and replace if necessary (see serial plate for
proper size).
Packing piston is worn Check and replace if necessary.
FLUCTUATING
PRESSURE Valves are worn Check and replace if necessary.
Valve has a blockage Check and replace if necessary.
Pump is sucking air Check water supply and air seepage at joint in suction
line.
Packing piston is worn Check and replace if necessary.
PUMP NOISY Air is in suction line Check water supply and connections on suction line.
Inlet or discharge valve
springs are weak or broken Check and replace if necessary.
Excessive matter is in valves Check and replace if necessary.
Bearings are worn Check and replace if necessary.
WATER DRIPPING
FROM UNDER
PUMP
Piston packing is worn Check and replace if necessary.
O-Ring plunger retainer is
worn Check and replace if necessary.
Piston is cracked Check and replace if necessary.
Pump protector is worn Lower water supply pressure. Do not run the spray
gun closed longer than 5 minutes.
OIL DRIPPING Oil seal is worn Check and replace if necessary.
EXCESSIVE
VIBRATION IN
DELIVERY LINE
Valves are functioning
irregularly Check and replace if necessary.
BURNER MOTOR
WILL NOT RUN Fuel pump has seized Replace fuel pump.
Burner fan loose or
misaligned Position correctly and tighten set screw.
Control switch is defective Replace switch.
There is a loose wire Check and replace or tighten wiring.
Burner motor is defective Replace motor.

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
PRESSURE WASHER Troubleshooting Guide
18
MAINTENANCE CHARTS
PREVENTATIVE MAINTENANCE
This pressure washer was produced with the best available materials and quality craftsmanship. However, you
as the owner have certain responsibilities for the correct care of the equipment. Attention to regular preventative
maintenance procedures will assist in preserving the performance of your equipment. Contact your dealer for
maintenance. Regular preventative maintenance will add many hours to the life of your pressure washer. Perform
maintenance more often under severe conditions.
MAINTENANCE SCHEDULE
Engine Oil
Inspect Daily
Change Every 25 hours
Filter Every 50 hours
Air Cleaner Inspect Every 50 hours or monthly
Clean Every 3 months
Battery Level Check monthly
Engine Fuel Filter 500 hours or 6 months
Spark Plug Maintenance 500 hours or 6 months
Clean Fuel Tank(s) Annually
Replace Fuel Lines Annually
Pump Oil Inspect Oil level daily
Change After first 50 hours, then every 500 hours or annually
Clean Burner Filter Monthly (More often if fuel quality is poor)
Remove Burner Soot Annually
Burner Adjustment/Cleaning Annually
Replace Burner Nozzle Annually
Descale Coil Annually (more often if required)
Replace High Pressure Hose Every 6 months
Replace Quick Couplers Annually
Clean Water Screen/Filter Weekly
OIL CHANGE RECORD
Date Oil Changed
Month/Day/Year
Estimated Operating
Hours Since Last
Oil Change
Date Oil Changed
Month/Day/Year
Estimated Operating
Hours Since Last
Oil Change

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
19
PRESSURE WASHER
OPERATOR’S MANUAL
EXPLODED VIEW
“Thisproduct contains chemicals knownto the State of
Californiato cause cancer and birth defects or other
reproductiveharm.Operation ofThisEquipment May
CreateSparksThat Can Start Fires Around Dry Vegetation.
ASpark Arrestor May be Required. The Operator Should
ContactLocal Fire Agencies for Laws or Regulations
Relatingto Fire Prevention Requirements.”
WARNING
8.917-015.0
1
8
9
10
65
3
59
21
96
33
69
11
14
29 28
2
25
64
65
67
91
92
63
18
19
20
For
Detail See
Control
Box Illus.
18
19
34
12
56
77
35
98
23
27
26
47
97
17
76
15
16
20
90
86
88
84
31
87
79
31
79
30
100
78
31
42
31
20
46
54
50 39
24
Reversed
View of
Regulator
48
93
2
62
45
89
71
43
For Brake
Detail See
Reversed View
A-A Above
61
58
41
2
99
103
37
54
53
View A-A
(Enlarged)
74
85
75
81
94
40
81
81
74
20
80
32
36
44
22
66
101
13
72
60
60
54
53
60
Reversed View
of Label
102
4
54
52
68
38
52
55
49

HOME DEPOT SGP • 8.913-917.0 • Rev. 08/13
OPERATOR’S MANUAL PRESSURE WASHER
20
ITEM PART NO. DESCRIPTION QTY
1 8.920-754.0 Black Tank Head Assembly 1
2 9.800-006.0 Label, Hot/Caliente w/Arrows 3
Warning
3 9.802-825.0 Clip, Retaining, U-Type 4
4 9.803-108.0 Retainer Ring, Insulation 1
5 8.919-133.0 Coil Assy 1
6 8.921-567.0 Black River Outter Coil Wrap 1
7 8.705-975.0 Nipple, 1/2" x M x M, Hex 1
8 8.706-236.0 Tee, 1/2", Street-
P/N-TF3759X8 1
9 9.802-041.0 Elbow, 3/8" Street, 45 Dgr 1
10 9.802-171.0 Coupler, 3/8", Male 1
11 8.711-785.0 Hose, 3/8" Push On, 2.5 ft.
12 9.803-092.0 Fuel Strap, Long 2
13 9.802-811.0 Washer, Fender 2
14 9.802-753.0 Screw, 1/4" x 3/4" HH NC 8
15 9.802-900.0 Insulation, Tank Bottom, 1
1" Blanket
16 9.803-120.0 Assy. Frame 1
17 8.900-300.0 Label, Die-Cut 2
18 8.711-905.0 Wheel & Tire, 13", Foam Fille 4
19 9.802-782.0 Collar, 5/8" Bore Shaft 4
20 9.802-810.0 Washer, 5/8", Flat, SAE 4
21 9.802-314.0 Engine, Robin, 211cc, 200W 1
22 8.904-895.0 Pump, Landa LG 3030G 1
23 8.918-427.0 Hose, 3/8" X 36",2 Wire,
Pressure 1
24 8.707-256.0 Pump Protector, 1/2" PTP 1
25 9.802-458.0 Switch, Pressure N/O, 1/4" 1
NPT
26 9.802-039.0 Elbow, 1/2" JIC x 3/8", 90° 1
27 9.175-018.0 UU1 3500PSI,
Universal Unloader 1
28 8.706-984.0 Adapter, 1/2" x 1/2" Pipe 1
29 9.802-146.0 Swivel, 1/2" MP x 3/4" GHF 1
w/Strainer
30 9.802-753.0 Screw, 1/4-20 x 3/4" Loc 2
31 6.390-126.0 Clamp, Hose, UNI .46 - .54 4
32 9.800-018.0 Label, Tip Over 1
33 8.706-214.0 Tee, 3/8", Female Pipe 1
34 9.802-081.0 Tank, Fuel, 6 Gallon 1
35 9.802-089.0 Cap, Fuel Tank, Plastic 1
H60-AV
36 9.800-049.0 Label, Manufacturer's 1
Cleaning Solutions
37 9.803-308.0 Mount, Rubber Vibration, 4
70 Duro
EXPLODED VIEWS PARTS LIST
ITEM PART NO. DESCRIPTION QTY
38 9.198-004.0 3/8 USS F/W Zinc 4
39 9.802-064.0 Grommet, Rubber, 2
Nozzle Holder
40 9.802-705.0 Bolt, Carriage, 1/4" x 1" 4
41 Burner Assy, See Burner Specifications Page
42 8.706-941.0 Hose Barb, 1/4" Barb x 1/4" 1
43 9.802-781.0 Nut, 3/8" Flange, Whiz Loc 4
44 8.712-185.0 Switch, Snap, 225 1
45 8.706-880.0 Nipple, 1/2" MPT X 3/8" MP 1
46 8.908-396.0 Axle, Front 2
47 9.800-008.0 Label, Danger Cool Engine 1
48 9.802-042.0 Elbow, 1/2" JIC x 3/8", Fem 1
49 8.921-570.0 Throttle Engine Cover 1
50 9.802-710.0 Bolt, 5/16" x 1" 8
52 8.751-096.0 Label, Regulation 4442.6 1
53 9.802-776.0 Nut, 5/16" ESNA 14
54 8.718-980.0 Washer, 5/16" Flat 24
55 9.196-051.0 Cheese Head Machine
Screw M5x16mm 1
56 9.802-177.0 Valve, 1/4" Shut Off 1
57 8.712-185.0 Switch, Snap 225°F 1
58 9.802-103.0 Bushing, 5/8" Snap 1
59 9.802-904.0 Insulation, Tank Head 1
60 8.900-809.0 Label, Home Depot 3
61 9.802-793.0 Nut, Cage, 1/4" x 16 Gauge 4
62 9.800-021.0 Label, Hot Water Outlet 1
63 8.706-941.0 Hose Barb, 1/4" x Barb x 1/4" 1
64 9.802-153.0 Swivel, 1/4" JIC Fem, 1
Push-On
65 9.802-125.0 Plug, 1/4" JIC 1
66 9.802-104.0 Bushing, 3/4" Snap 1
67 9.802-254.0 Hose, 1/4" Push-On 7"
68 9.802-743.0 Bolt, M6X1.0X12, Metric 8.8
69 8.902-433.0 Valve, Safety Relief 1
71 9.802-958.0 Key, 0.185 SQR x 1.75" 1
72 9.802-832.0 Bolt, 5/16" x 2-3/4" Whiz Loc 2
73 9.802-754.0 ▲ Screw, 1/4" x 1/2" HH NC, 2
Whiz Loc
74 9.802-773.0 Nut, 1/4"-20, ESNA 4
75 9.802-996.0 Bracket, Brake Pad 1
76 9.800-094.0 Label, Warning, Text 1
