Landoll Icon 824 Guide

Model 824/1024/1224
Box Scraper
Service/Parts Manual
LANDOLL COMPANY, LLC
1900 North Street
Marysville, Kansas 66508
[phone]
800-428-5655 ~ WWW.LANDOLL.COM
F-1070-0520 05/2020 - Present
®

F-1070-0520
Manuals for the 824-1024-1224 Box Scraper
MANUAL NUMBER MANUAL NAME
F-1070 824-1024-1224 Service/Parts Manual

i
INDEX
Table of Contents
1 Introduction and Safety Information
Introduction .................................................................. 1-1
Understanding Safety Statements ............................................. 1-2
Decal Safety ............................................................. 1-2
Transporting Safety ........................................................ 1-2
Attaching, Detaching, and Storage ............................................ 1-3
Maintenance Safety ........................................................ 1-3
High Pressure Fluid Safety .................................................. 1-3
Protective Equipment ...................................................... 1-3
Chemical Safety .......................................................... 1-3
Prepare for Emergencies ................................................... 1-3
Tire Safety ............................................................... 1-3
Safety Chain ............................................................. 1-4
2 Standard Specifications
Model Specification ........................................................... 2-1
General Torque Specifications (rev. 4/97) ....................................... 2-2
Hydraulic Fitting Torque Specifications ......................................... 2-3
Introduction .............................................................. 2-4
Owner Assistance ......................................................... 2-4
Warranty Registration ...................................................... 2-4
3 Assembly and Lubrication
Hitch Assembly ............................................................... 3-2
Remove Hitch from Main Frame .............................................. 3-2
Attach Hitch to Main Frame .................................................. 3-2
Rear Frame Assembly .......................................................... 3-6
Remove Shipping Brackets .................................................. 3-6
Cylinder Installation ........................................................ 3-6
Fittings and Hose Installation ................................................ 3-6
Electrical ..................................................................... 3-9
LED Light Installation ..................................................... 3-10
Lubrication Maintenance ................................................... 3-12
4 Hookup and Operation
Description of Machine ..................................................... 4-1
Tie Strap Designations ..................................................... 4-1
Hookup to the Remote ..................................................... 4-2
Learning to Operate the Box Scraper .......................................... 4-2
5 Illustrated Parts List
General Assembly ............................................................. 5-1
General Assembly ......................................................... 5-1
Box Scraper Assembly ......................................................... 5-2
Main Frame Box Assembly .................................................. 5-3

ii F-1070-0520
INDEX
Non-Tilt Feature ...........................................................5-5
Tilt Feature ...............................................................5-7
Skid Steer Mount Feature ...................................................5-9
Hitch Assembly ..........................................................5-11
Hub And Spindle Assembly - 6 Bolt ...........................................5-13
Hydraulics ...................................................................5-14
Hydraulic Assembly .......................................................5-15
Cylinder Assembly 3 X 8 ...................................................5-16
Electrical ....................................................................5-17
Electrical Assembly W/ LED Lights ...........................................5-19
Decals ......................................................................5-21
Decals .................................................................5-23
6 Index

1-1
INDEX TABLE OF CONTENTS Chapter 1
Introduction and Safety Information
Introduction
The Landoll /Icon Model 824/1024/1224 Box Scraper is a quality product designed to give years of trouble free
performance. By following each section of this manual, your system will perform as designed for you and your
operation.
CHAPTER 1 Gives basic instructions on the use of this manual and understanding the safety
statements.
CHAPTER 2 Gives product specifications for the equipment. These specifications supply lengths and
measurements for your equipment. A Standard Bolt Torque Table is provided to give
guidelines for bolt torques to be used when servicing this product.
CHAPTER 3 Contains assembly instructions for your Box Scraper. When these procedures are
correctly followed, your equipment should provide you years of trouble-free operation and
service.
CHAPTER 4 Instructs how to operate your equipment before using it, and describes adjustments
needed. Gives practical advice for the care and maintenance of your Landoll equipment.
Drawings in this section locate adjustment points on the equipment.
IF YOU HAVE ANY QUESTIONS CONTACT:
LANDOLL COMPANY, LLC
1900 NORTH STREET
MARYSVILLE, KANSAS 66508
PHONE # [phone] or [phone]
OR
FAX # [phone]
CHAPTER 5 Contains various assemblies, subassemblies, and systems. Refer to this section of
manual when ordering Landoll/Icon replacement parts. Order parts from your
Landoll/Icon dealer.
WARRANTY The Warranty Registration form is included with the product documents. Fill it out and
mail it within 15 days of purchase.
NOTE: IMPROPER ASSEMBLY, MODIFICATION, OR MAINTENANCE OF YOUR
LANDOLL MACHINE CAN VOID YOUR WARRANTY.
COMMENTS Address comments or questions regarding this publication to:
LANDOLL COMPANY, LLC
1900 NORTH STREET
MARYSVILLE, KANSAS 66508
ATTENTION: PUBLICATIONS - DEPT. 55

1-2 F-1070-0520
INTRODUCTION AND SAFETY INFORMATION
TABLE OF CONTENTS INDEX
Understanding Safety
Statements
You will find various types of safety information on the
following pages and on the machine signs (decals)
attached to the vehicle. This section explains their
meaning.
TThe Safety Alert Symbol means ATTENTION! YOUR
SAFETY IS INVOLVED!
NOTE
Means that failure to follow these instructions could
cause damage to the equipment or cause it to operate
improperly.
NOTICE
CAUTION
WARNING
DANGER
NOTE
Make sure you read and understand the information
contained in this manual and on the machine signs
(decals) before you attempt to operate or maintain this
vehicle.
The safety statements contained in this manual relate to
the operation of the Landoll/Icon Box Scraper.
Decal Safety
1. Examine safety decals and be sure you have the
correct safety decals for the implement.
2. Keep these signs clean so they can be observed
readily. It is important to keep these decals cleaned
more frequently than the implement. Wash with soap
and water or a cleaning solution as required.
3. Replace decals that become damaged or lost. Also,
be sure that any new implement components
installed during repair include decals which are
assigned to them by the manufacturer.
4. When applying decals to the implement, be sure to
clean the surface to remove any dirt or residue.
Where possible, sign placement should protect the
sign from abrasion, damage, or obstruction from
mud, dirt, oil etc.
DANGER
Transporting Safety
IMPORTANT
It is the responsibility of the owner/operator to
comply with all state and local laws.
1. When transporting the implement on a road or
highway, use adequate warning symbols, reflectors,
lights and slow moving vehicle sign as required. Slow
moving tractors and towed implements can create a
hazard when driven on public roads. They are difficult
to see, especially at night.
2. Do not tow an implement that, when fully loaded,
weighs more than 1.5 times the weight of the towing
vehicle.
3. Carry reflectors or flags to mark the tractor and
implement in case of breakdown on the road.
Special notice - read and thoroughly understand
Caution means serious equipment or other
property damage can occur if instructions on this
label are not properly followed.
Warning means serious injury or death can occur
if safety measures or instructions on this label
are not properly followed.
Danger means a life-threatening situation exists.
Death can occur if safety measures or
instructions on this label are not properly
followed.

• Do not allow anyone to ride on the tractor or
implement. Riders could be struck by foreign
objects or thrown from the implement.
• Never allow children to operate equipment.
• Keep bystanders away from implement during
operation.

INTRODUCTION AND SAFETY INFORMATION
1-3
TABLE OF CONTENTSINDEX
4. Do not transport at speeds over 20 MPH under good
conditions. Never travel at a speed which does not
allow adequate control of steering and stopping.
Reduce speed if towed load is not equipped with
brakes.
5. Avoid sudden stops or turns because the weight of
the implement may cause the operator to lose control
of the tractor. Use a tractor heavier than the
implement.
6. Use caution when towing behind articulated steering
tractors; fast or sharp turns may cause the implement
to shift sideways.
7. Keep clear of overhead power lines and other
obstructions when transporting. Know the transport
height and width of your implement.
Attaching, Detaching, and
Storage
1. Do not stand between the tractor and implement
when attaching or detaching implement unless both
are not moving.
2. Block implement so it will not roll when unhitched
from the tractor.
3. Store in an area where children normally do not play.
Maintenance Safety
1. Understand the procedure before doing the work.
Use proper tools and equipment.
2. Make sure all moving parts have stopped.
3. Do not make adjustments or lubricate implement
while it is in motion.
4. Block the implement so it will not roll when working
on or under it to prevent injury.
High Pressure Fluid Safety
1. Escaping fluid under pressure can be nearly invisible
and have enough force to penetrate the skin causing
serious injury. Use a piece of cardboard, rather than
hands, to search for suspected leaks.
2. Any fluid injected into the skin must be surgically
removed within a few hours or gangrene may result.
3. Avoid the hazard by relieving pressure before
disconnecting hydraulic lines.
Protective Equipment
1. Wear protective clothing and equipment.
2. Wear clothing and equipment appropriate for the job.
Avoid loose fitting clothing.
3. Because prolonged exposure to loud noise can
cause hearing impairment or hearing loss, wear
suitable hearing protection, such as earmuffs or
earplugs.
Chemical Safety
1. Agricultural chemicals can be dangerous. Improper
use can seriously injure persons, animals, plants, soil
and property.
2. Read chemical manufacture’s instructions and store
or dispose of unused chemicals as specified.
3. Handle chemicals with care and avoid inhaling
smoke from any type of chemical fire.
4. Store or dispose of unused chemicals as specified by
the chemical manufacturer.
Prepare for Emergencies
1. Keep a First Aid Kit and Fire Extinguisher handy.
2. Keep emergency numbers for doctor, ambulance,
hospital and fire department near the phone.
Tire Safety
1. Tire changing can be dangerous and should be
performed by trained personnel using correct tools
and equipment.
2. When inflating tires, use a clip-on chuck and
extension hose long enough to allow you to stand to
one side, not in front of or over the tire assembly. Use
a safety cage if available.
3. When removing and installing wheels use
wheel-handling equipment adequate for the weight
involved.

1-4 F-1070-0520
INTRODUCTION AND SAFETY INFORMATION
TABLE OF CONTENTS INDEX
Safety Chain
1. Use a chain with a strength rating equal to or greater
than the gross weight of towed machinery, which is
11,000 pounds minimum in accordance with ASAE
S338.2 specifications. If two or more implements are
pulled in tandem, a larger chain may be required.
Chain capacity must be greater then the TOTAL
weight of all towed implements.
2. A second chain should be used between each
implement.
3. Attach the chain to the tractor drawbar support or
specified anchor location. Allow only enough slack in
the chain to permit turning. The distance from hitch
pin to attachment point or intermediate support point
should not exceed 9 inches.
4. Replace the chain if any links or end fittings are
broken, stretched or damaged.
5. Do not use a safety chain for towing.

2-1
INDEX TABLE OF CONTENTS Chapter 2
Standard Specifications
Model Specification
Specification
Model 824 Model 1024 Model 1224
Blade Size 8’ W X 24” H 10’ W X 24” H 12’ W X 24” H
Replaceable Cutting Edge 1/2” X 6” X 8’ 1/2” X 6” X 5’ 1/2” X 6” X 6’
Blade Tilt Side to Side 5° 5° 5°
Blade Clearance at Full Raised 19” 19” 19”
Length Overall 13’-4” 13’-4” 13’-4”
Width Overall 8’-1” 10’-1” 12’-1”
Shipping Weight 1,474 lbs. 1,670 lbs 1,850 lbs
Cylinders Welded Industrial - Tilt 3” X 8” 3” X 8” 3” X 8”
Cylinders Welded Industrial - Raise/Lower 3” X 8” 3” X 8” 3” X 8”
Hydraulic Hoses 3,000 psi rated 3,000 psi rated 3,000 psi rated
Hitches Pintle/Clevis Pintle/Clevis Pintle/Clevis
Grease Locations 222
Safety Warning Lights Optional LED Optional LED Optional LED
Hub & Spindle 6 Bolt 3,600 lbs. 6 Bolt 3,600 lbs. 6 Bolt 3,600 lbs.
Tire Inflation
Tire Size Tire Manufacturer Ply/Load Rating Inflation Pressure (Psi) (Max.)
9.5L X 15 BKT 2,470 lbs. @ 40 mph 44 psi
Recommended Torque Specification For Lug Bolts and Nuts
Bolt Size Torque (FT. LBS.)
1/2-20 X 1-3/8” 85- 100 ft - lbs.

2-2 F-1070-0520
STANDARD SPECIFICATIONS
TABLE OF CONTENTS INDEX
General Torque Specifications
(rev. 4/97)
Table 2-1: General Torque Specifications
TORQUE SPECIFIED IN FOOT POUNDS - This chart provides tightening torques for general purpose applications
when special torques are not specified on process or drawing. Assembly torques apply to plated nuts and capscrews
assembled without supplemental lubrication (as received condition). They do not apply if special graphite moly-disulfide or
other extreme pressure lubricants are used. When fasteners are dry (solvent cleaned) add
331432/1432RS/1632/1432/1432RS/1632/1632RS to as received condition torque. Bolt head identification marks indicate
grade and may vary from manufacturer to manufacturer. Thick nuts must be used on grade 8 capscrews. Use value in [ ] if
using prevailing torque nuts.
UNC
SIZE
SAE
Grade 2
SAE
Grade 5
SAE
Grade 8
UNF
SIZE
SAE
Grade 2
SAE
Grade 5
SAE
Grade 8
1/4-20 4 [5] 6 [7] 9 [11] 1/4-28 5 [6] 7 [9] 10 [12]
5/16-18 8 [10] 13 [13] 18 [22] 5/16-24 9 [11] 14 [17] 20 [25]
3/8-16 15 [19] 23 [29] 35 [42] 3/8-24 17 [21] 25 [31] 35 [44]
7/16-14 24 [30] 35 [43] 55 [62] 7/16-20 27 [34] 40 [50] 60 [75]
1/2-13 35 [43] 55 [62] 80 [100] 1/2-20 40 [50] 65 [81] 90 [112]
9/16-12 55 [62] 80 [100] 110 [137] 9/16-18 60 [75] 90 [112] 130 [162]
5/8-11 75 [94] 110 [137] 170 [212] 5/8-18 85 [106] 130 [162] 180 [225]
3/4-10 130 [162] 200 [250] 280 [350] 3/4-16 150 [188] 220 [275] 320 [400]
7/8-9 125 [156] 320 [400] 460 [575] 7/8-14 140 [175] 360 [450] 500 [625]
1-8 190 [237] 408 [506] 680 [850] 1-14 210 [263] 540 [675] 760 [950]
1-1/8-7 270 [337] 600 [750] 960 [1200] 1-1/8-12 300 [375] 660 [825] 1080 [1350]
1-1/4-7 380 [475] 840 [1050 1426 [1782] 1-1/4-12 420 [525] 920 [1150] 1500 [1875]
1-3/8-6 490 [612] 1010 [1375] 1780 [2225] 1-3/8-12 560 [700] 1260 [1575] 2010 [2512]
1-1/2-6 650 [812] 1460 [1825] 2360 [2950] 1-1/2-12 730 [912] 1640 [2050] 2660 [3325]
1-3/4-5 736 [920] 1651 [2063] 2678 [3347] 1-3/4-12 920 [1150] 2063 [2579] 3347 [4183]
METRIC:
Coarse thread metric class 10.9 fasteners and class 10.0 nuts and through hardened flat washers, phosphate coated,
Rockwell “C” 38-45. Use value in [ ] if using prevailing torque nuts.
Nominal
thread
diameter
(mm)
Newton
Meters
(Standard
Torque)
Foot Pounds
(Standard
Torque)
Nominal
Thread
Diameter
(mm)
Newton
Meters
(Standard
Torque)
Foot Pounds
(Standard
Torque
6 10 [14] 7 [10] 20 385 [450] 290 [335]
7 16 [22] 12 [16] 24 670 [775] 500 [625]
8 23 [32] 17 [24] 27 980 [1105] 730 [825]
10 46 [60] 34 [47] 30 1330 [1470] 990 [1090]
12 80 [125] 60 [75] 33 1790 [1950] 1340 [1450]
14 125 [155] 90 [115] 36 2325 [2515] 1730 [1870]
16 200 [240] 150 [180] 39 3010 [3210] 2240 [2380]
18 275 [330] 205 [245] --------------- --------------- ---------------

STANDARD SPECIFICATIONS
2-3
TABLE OF CONTENTSINDEX
Hydraulic Fitting Torque
Specifications
Table 2-2: Hydraulic Fitting Torque Specifications
TORQUE IS SPECIFIED IN FOOT POUNDS- 37oJIC, ORS, & ORB (REV. 10/97)
This chart provides tightening torques for general purpose applications when special torques are not specified on process or
drawing. Assembly torques apply to plated nuts and capscrews assembled without supplemental lubrication (as received
condition). They do not apply if special graphite moly-disulfide or other extreme pressure lubricants are used. When fasteners are
dry (solvent cleaned) add 331432/1432RS/1632/1432/1432RS/1632/1632RS to as received condition torque. Bolt head
identification marks indicate grade and may vary from manufacturer to manufacturer. Thick nuts must be used on grade 8
capscrews. Use value in [ ] if using prevailing torque nuts.
Parker Brand Fittings
Dash Size 37 Degree JIC O-Ring (ORS) O-Ring Boss (ORB)
-4 11-13 15-17 13-15
-5 14-16 --------------- 21-23
-6 20-22 34-36 25-29
-8 43-47 58-62 40-44
-10 55-65 100-110 58-62
-12 80-90 134-146 75-85
-16 115-125 202-218 109-121
-20 160-180 248-272 213-237
-24 185-215 303-327 238-262
-32 250-290 -------------- 310-340
Gates Brand Fittings
Dash Size 37 Degree JIC O-Ring (ORS) O-Ring Boss (ORB)
-4 10-11 10-12 14-16
-5 13-15 --------------- ---------------
-6 17-19 18-20 24-26
-8 34-38 32-40 37-44
-10 50-56 46-56 50-60
-12 70-78 65-80 75-83
-14 -------------- 65-80 --------------
-16 94-104 92-105 111-125
-20 124-138 125-140 133-152
-24 156-173 150-180 156-184
-32 219-243 -------------- --------------
Aeroquip Brand Fittings
Dash Size 37 Degree JIC O-Ring (ORS) O-Ring Boss (ORB)
-4 11-12 10-12 14-16
-5 15-16 --------------- 16-20
-6 18-20 18-20 24-26
-8 38-42 32-35 50-60
-10 57-62 46-50 75-80
-12 79-87 65-70 125-135
-14 -------------- -------------- 160-180
-16 108-113 92-100 200-220
-20 127-133 125-140 210-280
-24 158-167 150-165 270-360
-32 245-258 -------------- --------------

2-4 F-1070-0520
STANDARD SPECIFICATIONS
TABLE OF CONTENTS INDEX
Introduction
This manual is compiled as a guide for owners and
operators of the Box Scraper. Read it carefully so as to
be able to follow the suggestions made. Please take time
to understand the proper maintenance schedule and
SAFE operation of your equipment.
In the event that a new and inexperienced operator is
placed in charge of running the equipment, they should
read and understand, that part of the manual for proper
maintenance and SAFE operation, and to be trained in
regard by an experienced operator.
Owner Assistance
If customer service or repairs are needed, contact your
Icon dealer. They have trained personnel, parts and
service equipment specially designed for Icon products.
Your machine’s parts should only be replaced with Icon
parts. Have the Serial Number and complete Model
Number available when ordering parts from your Icon
dealer See Figure 2-1.
Figure 2-1: ID Plate
Warranty Registration
Be certain to register the Box Scraper, by online
registration at www.landoll.com within 10 days of
purchase or lease, in order to be on file at Landoll and
eligible for Warranty.
Take time to read and understand the Warranty for this
product. That Warranty is printed in the Owner’s Manual
See Figure 2-2,and a separate copy enclosed in the
packet.
ICON/Landoll reserves the right to make changes and/or
add improvements to it’s products at any time without
obligation to previously manufactured equipment.
ICON/Landoll recommends a maximum horsepower of
the pulling tractor for your Box Scraper to be 200 hp.
Additional power may shorten the life of the unit and will
alter the Warranty.
Please take time to complete the following information for
your personal reference, should you need to contact your
Dealer with questions or parts needs.
MODEL_____________________________________
SERIAL #____________________________________
DATE OF PURCHASE__________________________
DEALER NAME________________________________
We at ICON/Landoll wish to thank you for purchasing our
product. We have spent considerable time and effort to
research, design, test and develop this machine and are
confident it will serve you in the use for which it was
designed.
MODEL #
SERIAL #
MADE IN USA 1-573-010006
Landoll Company, LLC
Marysville, Kansas
www.landoll.com

STANDARD SPECIFICATIONS
2-5
TABLE OF CONTENTSINDEX
Figure 2-2: Product Warranty
LANDOLL KDWEz>>
Product Warranty
LANDOLL KDWEz>> 1600 W. 8th St. Beloit KS 67420
(referred to as LANDOLL in this document)
LANDOLL shall Warrant workmanship and materials on the ICON Farm
Products for a period of 12 months from the date of original purchase, lease,
or rental, from the original Dealer, and in accordance with the following terms
and cŽŶĚŝƟŽŶƐ
Should any part or component fail within the Warranty period, and under
normal use cŽŶĚŝƟŽŶƐ>EK>> shall supply a new part or component for
replacement through the original DealerŽƐt of normal ground freight, for
that part or component to the Dealer, shall be paid bLJ>EK>>Zepair and
replacement labor cost, from the original Dealer, shall be paid bLJ>EK>>Ăƚ
a ratĞŶĞŐŽƟĂƚed bLJ>EK>>
EŽĨƵƌƚŚĞƌĞxpense shall be paid by LANDOLL, including but not limited to,
ůŽƐƐŽĨƟŵĞŽƌŝŶĐŽŵĞ
LANDOLL shall not provide Warranty on any part or component that has
failed due to abuse, misuse, altĞƌĂƟŽŶŝŵƉƌŽƉĞƌŵĂŝŶtenance, or normal
wear&ailure occurring while being pulled by a tractor in excess of engine
horsepower, as described in the owners manual and/or posted on the
machine, is considered abuse and misuse and shall not receive Warranty
Warranty applies only tŽŶŽƌŵĂůŝŶtermittent agricultural use, and not
commercial or indusƚƌŝĂůƵƐĞ
In regard to some components manufactured by other companies and sold
by LANDOLL, including but not limited tŽƟƌĞƐƐĂŝĚtarranty shall be
provided solely by that manufacturing company
This Warranty applies to products sold in the United StatĞƐĂŶĚĂŶĂĚĂ
and is made expressly in place of all other warranƟĞƐĞdžƉƌĞƐƐĞĚŽƌŝŵƉůŝĞĚ

2-6 F-1070-0520
STANDARD SPECIFICATIONS
TABLE OF CONTENTS INDEX
Table provided for general use.
NOTES:

3-1
INDEX TABLE OF CONTENTS Chapter 3
Assembly and Lubrication
It is very important that your new Box Scraper be properly
assembled, adjusted and lubricated before use.
Illustrations in this section show proper assembly
procedures. Remove paint from grease fittings. Replace
any grease fittings that are damaged or missing. Be sure
to return screws, clips, etc., to their original locations.
To insure alignment of assemblies, leave the nuts loose
until completion of final assembly. Use lock washers or
flat washers as specified. Spread all cotter pins.
After completion of final assembly, tighten all nuts
evenly to prevent misalignment, distortion or binding.
Tighten all screws and nuts to the recommended torques
(See “General Torque Specifications (rev. 4/97)” on
page 2-2.).
CAUTION
WARNING
DANGER
Be sure to bleed the hydraulic system of all air in
lines after installation. Failure to bleed the system
of all air can result in improper machine
operation.
Do not attempt to lift heavy parts (such as the
frame, disc gangs, rock shaft, and pull hitch)
manually. Use a hoist or a fork lift to move these
parts into position.
To prevent accidental lowering:
1. All hydraulically elevated equipment must be
locked out using the cylinder lockouts:
2. Lower equipment to the ground while
servicing or when it is idle.
Failure to take measures to prevent accidental
lowering may result in serious personal injury or
death.

3-2 F-1024-0520
ASSEMBLY AND LUBRICATION
TABLE OF CONTENTS INDEX
Hitch Assembly
Remove Hitch from Main Frame
1. Remove hitch assembly from main frame by
removing all u-bolts and shipping stand See
Figure 3-1.
Attach Hitch to Main Frame
1. Attach hitch assembly to main frame with 1/2-13 x 2
hex bolts, 1/2 flat washers (one on each side of
plates) and 1/2-13 lock nuts See Figure 3-2.
2. Attach hose holder bracket with 1/2-13 nylock nut.
3. Mount the harness store-a-way to bottom side of
hose holder bracket with 1/4-20 x 1 hex bolts and
1/4-20 lock nuts.
4. Mount the hose clamp holder to top of hose holder
bracket with 3/8-16 x 3-1/2 all thread, 3/8-16 hex nut
(bottom side clamp) and 3/8-16 lock nut (top side
clamp). Do not tighten hose clamp holder until hoses
and wire harness are routed through hose clamp
holder.

ASSEMBLY AND LUBRICATION
3-3
TABLE OF CONTENTSINDEX
Figure 3-1: Hitch Removal from Main Frame
HITCH
ASSEMBLY
SHIPPING
STAND
1/2-13
LOCK NUT
1/2-13 X 4-9/16 X 5-1/2
U-BOLT
1/2-13 X 4-9/16 X 5-1/2
U-BOLT
JACK

3-4 F-1024-0520
ASSEMBLY AND LUBRICATION
TABLE OF CONTENTS INDEX
Figure 3-2: Hitch Assembly to Main Frame
HITCH
ASSEMBLY
3/8-16 X 3-1/2 ALL THREAD,
3/8-16 HEX NUT, 3/8-16 LOCK NUT.
HOSE CLAMP HOLDER
1/2-13 X 2
HEX BOLTS,
1/2 FLAT WASHERS,
1/2-13 LOCK NUT
HARNESS STOR-A-WAY,
1/4-20 X 1 HEX BOLTS,
1/4-20 LOCK NUTS
HOSE HOLDER BRACKET,
1/2-13 NYLOCK NUT
JACK

ASSEMBLY AND LUBRICATION
3-5
TABLE OF CONTENTSINDEX
Table provided for general use.
NOTES:

3-6 F-1024-0520
ASSEMBLY AND LUBRICATION
TABLE OF CONTENTS INDEX
Rear Frame Assembly
Remove Shipping Brackets
1. Remove the 1-8 x 4 hex bolt and1-8 locknut from
mainframe bracket and lower rear frame See
Figure 3-3.
2. Remove 1/2-13 x 1, 1-8 x 3-1/2 hex bolts and
shipping link from Tilt Feature See Figure 3-3.
Figure 3-3: Tilt Shipping Link
3. Install tire/wheel assembly to all 6 bolt hub/spindle
assemblies with 1/2 wheel bolts.
4. Torque wheel bolts 85 to 100 ft-lbs.
NOTE
All tire/wheel assemblies are mounted with the valve
stem facing outward.
Cylinder Installation
1. Install the tilt cylinder anchor with 1/2-13 x 1-1/4 hex
bolts, 1/2 lock washers and 1/2 flat washers See
Figure 3-3.
2. Install the 3 x 8 lift and tilt feature cylinder with 1 x 4
pins and 1/4 x 1-1/2 roll pins See Figure 3-4.
Figure 3-4: Cylinder Installation
Fittings and Hose Installation
3. Install the lift fittings and hoses as shown See
Figure 3-5.
4. Install the tilt feature fittings and hoses as shown See
Figure 3-6.
5. Insure that the hoses are clear of any moving parts
and secure with tie wraps provided. Route hoses
through all hose loops and clamp.
6. Fill hydraulic systems with Mobil 424 hydraulic oil
using hydraulic pump, activate all moving parts and
bleed air from the system. Hold 3000 psi. hydraulic
pressure against all cylinders, fittings, and hoses.
7. Check hydraulic components for leaks.
8. Recheck that all retainers are installed.
9. Clean and touch up paint on the machine.
1/2-13 X 1
HEX BOLT
SHIPPING LINK
1-8 X 3-1/2
HEX BOLT
1-8 LOCK NUT
1-8 X 4
HEX BOLT
1-8 LOCK NUT
TIRE/WHEEL ASSEMBLY,
1/2 WHEEL BOLTS
HUB/SPINDLE
ASSEMBLY
3 X 8 CYLINDER,
1 X 4 PIN,
1/4 X 1-1/2
ROLL PIN
TILT CYLINDER
ANCHOR,
1/2-13 X 1-1/4
HEX BOLT,
1/2 LOCK WASHER,
1/2 FLAT WASHER
LIFT
CYLINDER
TILT FEATURE
CYLINDER
