Landoll 317D User manual

F-486-1011 10/2011
LANDOLL CORPORATION
1900 North Street
Marysville, Kansas 66508
[phone]
800-428-5655 ~ WWW.LANDOLL.COM
Model 317D/318D
Trailer
Operator’s Manual

F-486-1011 Edition i
Table of Contents
1 Introduction
Understanding Safety Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
2 Standard Specifications
3 Operating Instructions
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Landing Gear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Parking Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Air Brake System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Anti-Lock Brake System (ABS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Hydraulic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Pre-Coupling of Semitrailer and Tractor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Coupling of the Tractor to the Semitrailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Connecting Tractor Services to the Semitrailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Tractor and Semitrailer Check-Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Towing the Semitrailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Parking the Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Uncoupling Towing Vehicle from Semitrailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Trailer Tilt Lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Axle Control Lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Loading Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Securing the Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Unloading Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Winch Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Free Spool Clutch Operation (DP Winch) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Free Spool Clutch Operation (Braden) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Remote Control (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Dock Leveler Control Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
Hydraulic Power Supply Engine Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-20
Air Ride Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-23
Front Extension/Bulkheads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-23

ii F-486-1011 Edition
Rear Impact Guard System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25
Anti-Lock Brake System (ABS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25
Cold Weather Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-26
Hot Weather Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-26
4 Maintenance and Lubrication
Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Maintenance Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Repair Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Tools and Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Torque Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Gooseneck, Frame, And Deck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Repairing Structural Defects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Hydraulic System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Hydraulic Engine Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Electrical System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Suspension Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Air Ride Suspension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Air Ride Height Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
Wheel Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-13
Axle Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
Manual Alignment Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
Air Ride Suspension Axles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
Brake System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
Spring Air Brake Chambers (30/30) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
Caging the Power Spring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Air Brake Chambers (Type 30) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
Tandem Relay Valve Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
Brake Assembly Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
Brake Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
Disassembly for 12-1/4” X 7-1/2” Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
Reassembly for 12-1/4” X 7-1/2” Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-21
Disassembly for 16-1/2” x 7" Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-21
Reassembly for 16-1/2 x 7" Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-21
Automatic Slack Adjusters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
Operational Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
Replacing Slack Adjuster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-23
Adjusting Slack Adjuster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-23
Hub and Drum Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-24

F-486-1011 Edition iii
Wheel Bearing Lubrication and Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
Tire Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
Tire Inflation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
Tire Matching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
Tape Measuring Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
Straight Edge or String Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
Mounting Tire and Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28
Winches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
Dock Levelers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
Disassembly/Assembly Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
Leg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
Stabilizer Leg Check Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
Crank Landing Gear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34
5 Troubleshooting Guide
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Tires - Wheels - Suspension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Brake Drums . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Hydraulic System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Hydraulic Power Supply Engine Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
Dock Leveler Hydraulics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9

iv F-486-1011 Edition

1-1
Chapter 1
Introduction
This manual provides operating, servicing, and maintenance instructions for Model 317D/318D semitrailer
manufactured by Landoll Corporation, Marysville, Kansas 66508.
CHAPTER 1 gives basic instructions on the use of this manual.
CHAPTER 2 gives product specifications for the trailer, including measurements and component
specifications. A Standard Bolt Torque Table is provided to give guidelines for bolt
torques to be used when servicing this product.
CHAPTER 3 gives instructions for the proper operation of the equipment.
CHAPTER 4 gives general maintenance procedures, a maintenance schedule, and a lubrication
schedule. Improper maintenance will void your warranty.
IF YOU HAVE ANY QUESTIONS CONTACT:
LANDOLL CORPORATION
1900 NORTH STREET
MARYSVILLE, KANSAS 66508
or phone:
[phone] or
[phone]
or FAX:
[phone]
CHAPTER 5 is a troubleshooting guide to aid in diagnosing and solving problems with the trailer.
PARTS MANUAL is a separate manual showing the various assemblies, subassemblies, and systems.
Refer to that manual when ordering Landoll replacement parts. Order parts from your
Landoll dealer.
WARRANTY The Warranty Registration form is included with the product documents. Fill it out and
mail it within 15 days of purchase.
NOTE: IMPROPER ASSEMBLY, MODIFICATION, OR MAINTENANCE OF YOUR
LANDOLL MACHINE CAN VOID YOUR WARRANTY.
COMMENTS Address comments or questions regarding this publication to:
LANDOLL CORPORATION
1900 NORTH STREET
MARYSVILLE, KANSAS 66508
ATTENTION: PUBLICATIONS -DEPT. 55

1-2 F-486-1011 Edition
INTRODUCTION
Understanding Safety
Statements
You will find various types of safety information on the
following pages and on the machine signs (decals)
attached to the vehicle. This section explains their
meaning.
The Safety Alert Symbol means ATTENTION! YOUR
SAFETY IS INVOLVED!

DANGER

WARNING

CAUTION
NOTE
Means that failure to follow these instructions could
cause damage to the equipment or cause it to operate
improperly.
NOTE
Make sure you read and understand the information
contained in this manual and on the machine signs
(decals) before you attempt to operate or maintain this
vehicle.
The safety statements contained in this manual relate to
the operation of the Model 317D/318D semitrailer.
Danger means a life-threatening situation exists.
Death can occur if safety measures or
instructions on this label are not properly
followed.
Warning means serious injury or death can occur
if safety measures or instructions on this label
are not properly followed.
Caution means serious equipment or other
property damage can occur if instructions on this
label are not properly followed.

2-1
Chapter 2
Standard Specifications
MODEL 317D/318D
CAPACITY*:
TANDEM AXLE (MODEL 317D) 70,000 LB. DISTRIBUTED
STANDARD FRAME DESIGN 50,000 LB. CONCENTRATED IN 10’
TRIPLE AXLE (MODEL 318D) 100,000 LB. DISTRIBUTED
STANDARD FRAME DESIGN 70,000 LB. CONCENTRATED IN 10’
SWING OUT OVERWIDTHS AND PULL OUT EXTENSION MAXIMUM CAPACITY IS ONE HALF FRAME
CAPACITY LISTED ABOVE.
GOOSENECK: HYDRAULIC TILT
KING PIN SETTING:
MODEL 317D 18” or 24” (Standard is 24”)
MODEL 318D 26”
UNDERCARRIAGE TRAVEL:
LOW LOAD ANGLE 14’-0”
GROUND LOAD ANGLE:
LOW LOAD ANGLE 8.5º
MAXIMUM TILT ANGLE 13.3º
DOCK LEVELER CAPACITY:
MODEL 317D
1 PAIR 60,000 LB.
MODEL 318D 2 PAIR 62,000 LB. (124,000 LB.)
NOTE: DOCK LEVELER NOT AVAILABLE W/ 17.5 LOW PROFILE TIRES
HYDRAULIC HOOKUP:
QUICK COUPLERS FLAT FACE 3/4” BODY SIZE
MAXIMUM OPERATING PRESSURE 2500 PSI
OPERATING FLOW 17 GPM

2-2 F-486-1011 Edition
STANDARD SPECIFICATIONS
ELECTRICAL HOOKUP: 7-WAY CONNECTOR
AIR HOOKUP: COLOR CODED GLAD HANDS
MODEL 317D/318D

STANDARD SPECIFICATIONS
2-3
SPECIFIC BOLT TORQUES
AIR RIDE SUSPENSION:
EQUALIZER BEAM PIVOT AND ADAPTER BOLTS
DESIGNATED W/ NEWAY ON BOLT HEAD 800 FT.-LBS.
DESIGNATED W/ HOLLAND NEWAY ON
BOLT HEAD
550 FT.-LBS.
4” AND 5” CAM FOLLOWERS ATTACHED TO
UNDERCARRIAGE:
GREASED THREADS 250 FT.-LBS.
DRY THREADS 500 FT.-LBS.
SHOCK ABSORBER MOUNTING 150 FT.-LBS.
AIR SPRING MOUNTING:
1/2” 35 FT.-LBS.
3/4” 35 FT.-LBS.
WHEEL FASTENERS - ALL MODELS:
OUTER SPINDLE NUTS 250 - 400 FT.-LBS.
PILOT WHEEL NUTS 450 - 500 FT.-LBS.
* CAPACITY RATINGS ARE FRAME CAPACITIES ONLY. ACTUAL LOAD CAPACITIES MAY BE RESTRICTED BY
FACTORS SUCH AS GROSS AXLE WEIGHT RATINGS (GAWR) OR STATE AND FEDERAL REGULATIONS. TIRE,
BRAKE, AXLE, OR WHEEL SELECTION MAY ALSO LIMIT CAPACITY.

2-4 F-486-1011 Edition
STANDARD SPECIFICATIONS
Table 2-1: General Torque Specifications
LANDOLL CORPORATION
GENERAL TORQUE SPECIFICATIONS (REV. 4/97)
THIS CHART PROVIDES TIGHTENING TORQUES FOR GENERAL PURPOSE APPLICATIONS WHEN SPECIAL TORQUES ARE NOT SPECIFIED ON PROCESS
OR DRAWING.
ASSEMBLY TORQUES APPLY TO PLATED NUTS AND CAPSCREWS ASSEMBLED WITHOUT SUPPLEMENTAL LUBRICATION (AS RECEIVED CONDITION). THEY
DO NOT APPLY IF SPECIAL GRAPHITE MOLY-DISULFIDE OR OTHER EXTREME PRESSURE LUBRICANTS ARE USED.
WHEN FASTENERS ARE DRY (SOLVENT CLEANED), ADD 33% TO AS RECEIVED CONDITION TORQUE.
BOLT HEAD IDENTIFICATION MARKS INDICATE GRADE AND MAY VARY FROM MANUFACTURER TO MANUFACTURER.
THICK NUTS MUST BE USED ON GRADE 8 CAPSCREWS.
USE VALUE IN [ ] IF USING PREVAILING TORQUE NUTS.
TORQUE IS SPECIFIED IN FOOT POUNDS
UNC
Size
SAE Grade
2
SAE Grade
5
SAE Grade
8
UNF
Size
SAE Grade
2
SAE Grade
5
SAE Grade
8
1/4-20 4 [5] 6 [7] 9 [11] 1/4-28 5 [6] 7 [9] 10 [12]
5/16-18 8 [10] 13 [16] 18 [22] 5/16-24 9 [11] 14 [17] 20 [25]
3/8-16 15 [19] 23 [29] 35 [43] 3/8-24 17 [21] 25 [31] 35 [44]
7/16-14 24 [30] 35 [43] 55 [62] 7/16-20 27 [34] 40 [50] 60 [75]
1/2-13 35 [43] 55 [62] 80 [100] 1/2-20 40 [50] 65 [81] 90 [112]
9/16-12 55 [62] 80 [100] 110 [137] 9/16-18 60 [75] 90 [112] 130 [162]
5/8-11 75 [94] 110 [137] 170 [212] 5/8-18 85 [106] 130 [162] 180 [225]
3/4-10 130 [162] 200 [250] 280 [350] 3/4-16 150 [188] 220 [275] 320 [400]
7/8-9 125 [156] 320 [400] 460 [575] 7/8-14 140 [175] 360 [450] 500 [625]
1-8 190 [237] 408 [506] 680 [850] 1-14 210 [263] 540 [675] 760 [950]
1-1/8-7 270 [337] 600 [750] 960 [1200] 1-1/8-12 300 [375] 660 [825] 1080 [1350]
1-1/4-7 380 [475] 840 [1050] 1426 [1782] 1-1/4-12 420 [525] 920 [1150] 1500 [1875]
1-3/8-6 490 [612] 110 [1375] 1780 [2225] 1-3/8-12 560 [700] 1260 [1575] 2010 [2512]
1-1/2-6 650 [812] 1460 [1825] 2360 [2950] 1-1/2-12 730 [912] 1640 [2050] 2660 [3325]
1-3/4-5 736 [920] 1651 [2063] 2678 [3347] 1-3/4-12 920 [1150] 2063 [2579] 3347 [4183]
METRIC
COARSE THREAD METRIC CLASS 10.9 FASTENERS AND CLASS 10.0 NUTS AND THROUGH HARDENED FLAT WASHERS, PHOSPHATE COATED, ROCKWELL
“C” 38-45.
USE VALUE IN [ ] IF USING PREVAILING TORQUE NUTS.
Nominal
Thread
Diameter
mm
Standard Torque Nominal
Thread
Diameter
mm
Standard Torque
Newton-
Meters
Foot-
Pounds
Newton-
Meters
Foot-
Pounds
6 10 [14] 7 [10] 20 385 [450] 290 [335]
7 16 [22] 12 [16] 24 670 [775] 500 [625]
8 23 [32] 17 [24] 27 980 [1105] 730 [825]
10 46 [60] 34 [47] 30 1330 [1470] 990 [1090]
12 80 [101] 60 [75] 33 1790 [1950] 1340 [1450]
14 125 [155] 90 [115] 36 2325 [2515] 1730 [1870]
16 200 [240] 150 [180] 39 3010 [3210] 2240 [2380]
18 275 [330] 205 [245]

STANDARD SPECIFICATIONS
2-5
Table 2-2: Hydraulic Fitting Torque Specifications
LANDOLL CORPORATION
HYDRAULIC FITTING TORQUE SPECIFICATIONS
37oJIC, ORS, & ORB (REV. 10/97)
THIS CHART PROVIDES TIGHTENING TORQUES FOR HYDRAULIC FITTING APPLICATIONS WHEN SPECIAL TORQUES ARE NOT SPECIFIED ON PROCESS
OR DRAWING.
ASSEMBLY TORQUES APPLY TO PLATED CARBON STEEL AND STAINLESS STEEL FITTINGS ASSEMBLED WITHOUT SUPPLEMENTAL LUBRICATION (AS
RECEIVED CONDITION).THEY DO NOT APPLY IF SPECIAL GRAPHITE MOLY-DISULFIDE OR OTHER EXTREME PRESSURE LUBRICANTS ARE USED.
BRASS FITTINGS AND ADAPTERS - 65% OF THE TORQUE VALUE FOR STEEL. STAINLESS STEEL, ALUMINUM AND MONEL - THREADS ARE TO BE
LUBRICATED.
TORQUE IS SPECIFIED IN FOOT POUNDS
PARKER BRAND FITTINGS
Dash Size 37 Degree JIC O-Ring (ORS) O-Ring Boss (ORB)
-4 11-13 15-17 13-15
-5 14-16 — 21-23
-6 20-22 34-36 25-29
-8 43-47 58-62 40-44
-10 55-65 100-110 57.5-62.5
-12 80-90 134-146 75-85
-16 115-125 202-218 109-121
-20 160-180 248-272 213-237
-24 185-215 303-327 238-262
-32 250-290 — 310-340
GATES BRAND FITTINGS
Dash Size 37 Degree JIC O-Ring (ORS) O-Ring Boss (ORB)
-4 10-11 10-12 14-16
-5 13-15 — —
-6 17-19 18-20 24-26
-8 34-38 32-40 37-44
-10 50-56 46-56 50-60
-12 70-78 65-80 75-83
-14 — 65-80 —
-16 94-104 92-105 111-125
-20 124-138 125-140 133-152
-24 156-173 150-180 156-184
-32 219-243 — —
AEROQUIP BRAND FITTINGS
Dash Size 37 Degree JIC O-Ring (ORS) O-Ring Boss (ORB)
-4 11-12 10-12 14-16
-5 15-16 — 18-20
-6 18-20 18-20 24-26
-8 38-42 32-35 50-60
-10 57-62 46-50 72-80
-12 79-87 65-70 125-135
-14 — — 160-180
-16 108-113 92-100 200-220
-20 127-133 125-140 210-280
-24 158-167 150-165 270-360
-32 245-258 — —

2-6 F-486-1011 Edition
STANDARD SPECIFICATIONS

3-1
Chapter 3
Operating Instructions
General
This section supplies information for operation of the
semitrailer. It describes and locates controls and gives
general operation procedures. Read all instructions,
warnings, cautions, and danger notes before attempting
to operate the semitrailer. Operators must have proper
training before operating the semitrailer.

WARNING

WARNING
Landing Gear
The landing gear consists of two legs with a tube
telescoping within another tube. Pin drop style is
standard. Crank or hydraulically operated are optional.
Parking Brake
The parking brakes are automatically applied by spring
pressure with the air actuators of the braking system
when air pressure in the emergency line drops below 50
psi. This may be done within the truck using the trailer
parking/emergency valve or be disconnecting the
emergency gladhand.
Air Brake System
The air brake system of the semitrailer is operated from
the towing vehicle after coupling. The towing vehicle’s air
system must be coupled to the semitrailer and charged to
90 psi minimum before the brakes can adequately
function.
Anti-Lock Brake System (ABS)
The Anti-Lock Brake System of the semitrailer is constant
powered by the auxiliary (blue) circuit of the seven way
electrical connector, with backup power from the stop
lamp (red) circuit, and ground through the white wire. It is
necessary that the blue circuit is hot when the tractor key
switch is on. The blue circuit on the trailer may also not
be used to power any additional auxiliary devices while
the semitrailer is moving forward. If a fault exists in the
ABS, normal braking will occur, but the wheels may lock.
Service the ABS as soon as possible.

CAUTION

CAUTION
Do not operate the semitrailer with any known
fault that might endanger the occupants, nearby
workers, other traffic, the load, or the equipment.
Do not operate the semitrailer until you have read
the operator’s manual and completely understand
the proper use and function of all controls.
Improper use can cause personal injury, damage
to your semitrailer and cargo, and cause
time-consuming breakdowns. The auxiliary (blue) circuit is for powering the
semitrailer ABS. This circuit must be hot when
the tractor key switch is on. No other electrical
devices may be powered by this circuit while the
semitrailer is moving forward.
If a fault exists in the semitrailer ABS, normal
braking will occur, but wheels may lock. Service
the ABS as soon as possible.

3-2 F-486-1011 Edition
OPERATING INSTRUCTIONS
Figure 3-1: Front Trailer Terminology
Figure 3-2: Rear Trailer Terminology
SERVICE
HOOKUPS
KINGPIN
HITCH TUBE
ASSEMBLY
LOCKABLE CHAIN RACK (OPTION)
BULKHEAD (OPTION)
WINCH, UPPER DECK
STORAGE COMPARTMENT
UPPER DECK
PARKING STANDS
FRONT SIDE MARKER
ENGINE CONTROLS
(OPTION)
HYDRAULIC CONTROLS
LANDING GEAR HANDLE
WINCH, LOWER DECK
HYDRAULIC CONTROLS
INSTRUCTION DECAL
LOWER DECK
DOCK LEVELER
SELECTOR (OPTION)
REMOTE RECEPTACLE
(OPTION)
AIR WEIGH
(OPTION)
317d frnt
FRONT
REAR
LOWER DECK
OUTER BEAM
SLIDING
UNDERCARRIAGE
REAR SIDE
MARKER
ABS LIGHT
DOCK LEVELER
(OPTION)
APPROACH
PLATE
REAR IMPACT
GUARD
ENERGY PACK
REMOTE CONTROL
RECEPTACLE
(OPTION)
CURBSIDE LOCATION
FOR ABS DIAGNOSTIC
BLINK LIGHT
317d rear

OPERATING INSTRUCTIONS
3-3
Electrical
The only electrical operation required of the operator is
interconnection of the towing vehicle electrical cable plug
with the semitrailer electrical receptacle.
It is necessary that the tractor blue wire is connected to
the appropriate electrical source on the tractor.
Hydraulic
Most controls are located on the driver’s side of the
trailer. A hydraulic pump must be coupled to the trailer
hydraulic system, or the optional hydraulic engine
package started, before any hydraulic controls can
function. The hydraulic system is designed to operate at
2500 psi maximum pressure and approximately 17 gpm
flow capacity.
Pre-Coupling of Semitrailer and
Tractor
1. Slowly back the tractor/truck (towing vehicle) up to
the front end of the semitrailer so the kingpin of the
semitrailer is centered between the tractor fifth wheel
jaws. Stop the towing vehicle just inches ahead of the
semitrailer. Set tractor parking brake.
2. Check the semitrailer king pin plate height. The king
pin plate should be the same height, to slightly lower,
than the latch area of the fifth wheel plate of the
towing vehicle. If necessary, connect the tractor
hydraulic lines, or start the semitrailer hydraulic
power engine. Use the TRAILER TILT lever (For
operating instructions of the TRAILER TILT lever,
see “Trailer Tilt Lever” on page 3-9 ) to raise or
lower the kingpin plate sufficiently to allow proper
coupling. Drain all air and moisture from the towing
vehicle air brake system following towing vehicle
manufacturer’s instructions.
3. Connect the service and emergency air hoses of the
towing vehicle to their respective gladhand on the
front of the semitrailer; red emergency line to the
gladhand with the “EMERGENCY” tag, and the blue
service line to the gladhand with the “SERVICE” tag
(See Figure 3-3.) Chock the semitrailer wheels
before activating the semitrailer air supply valve in
the towing vehicle. Set the parking brakes.
Figure 3-3: Service Hookups
317d service hookups
HYDRAULIC HOOKUPS
SERVICE AIR HOOKUP
ELECTRICAL HOOKUP
EMERGENCY AIR HOOKUP

3-4 F-486-1011 Edition
OPERATING INSTRUCTIONS

WARNING
4. Check the air brake operations of the semitrailer as
follows:
a. Apply brakes and inspect brake action on all
wheels for prompt application.
b. Release brakes. All brakes should release
immediately. Air pressure should discharge
quickly from the relay emergency valve.
c. Disconnect the emergency air line from the
semitrailer gladhand. Trailer brakes should
promptly set.
d. Re-connect the emergency air line to the
semitrailer and activate the semitrailer air supply
valve. The semitrailer brakes should set.
Coupling of the Tractor to the
Semitrailer

DANGER
1. Verify the semitrailer wheels are chocked and brakes
function properly.
2. Make certain the coupler of the towing vehicle’s fifth
wheel is open by pulling the latch handle.
3. Slowly back the towing vehicle so its fifth wheel
contacts the front of the king pin plate on the
semitrailer and slips under it. Continue backing until
the fifth wheel coupler locks onto the semitrailer
kingpin.

CAUTION
4. Verify the vehicle coupling is secure by attempting to
pull the tractor forward a few inches. If the tractor
disconnects from the semitrailer, locate source of
coupling failure; repair before continuing; and repeat
steps 3 and 4.
5. Check that the towing vehicle couples securely to the
semitrailer before setting towing vehicle and
semitrailer parking brakes.
IMPORTANT
Keep brakes engaged for remainder of hookup,
checkout procedures, and parking.
Failure to chock semitrailer wheels could allow
movement of the semitrailer resulting in serious
personal injury, death, or damage to property in
its path. Keep all personnel clear of front, rear, and sides
of towing vehicle and semitrailer during coupling,
component operations, and uncoupling. Failure
to stay clear can result in serious personal injury
or death.
Pushing the semitrailer backwards can damage
parking stands.

OPERATING INSTRUCTIONS
3-5
Connecting Tractor Services to
the Semitrailer
1. Connect the towing vehicle 7-pole electrical plug to
the electrical receptacle on the front of the semitrailer
(See Figure 3-3.)
IMPORTANT
The key on the plug and the keyway in the socket
must be properly aligned before inserting the plug
into the semitrailer socket.
2. If you have not already done so, connect the tractor
hydraulic lines to the semitrailer unless your
semitrailer is equipped with the self-contained
hydraulic power engine package.

CAUTION
IMPORTANT
Some oil may need to be removed from the tractor
reservoir to allow room for 12 gallons of additional oil
displaced from the trailer hydraulic system.
3. Air Lines: See “Pre-Coupling of Semitrailer and
Tractor” on page 3-3.
Tractor and Semitrailer
Check-Out

WARNING
1. With hydraulic power operating, raise landing gear:
a. For pin drop landing gear, activate the TRAILER
TILT lever “UP” until weight is off the landing gear
(See Figure 3-4.) Raise landing gear. (See
“Trailer Tilt Lever” on page 3-9 for operation
of TRAILER TILT lever.) Secure each leg with a
park stand retaining pin in the full “up” position
before transporting.

CAUTION
b. For crank landing gear, retract landing gear by
turning hand crank on control panel
counterclockwise. Use low gear until the load is
off the landing gear. Then shift to high gear and
continue cranking until fully retracted. Leave the
landing gear in high gear.
c. For hydraulic landing gear, remove the pin from
each landing gear leg. Retract landing gear using
lever (See Step 2) on engine control panel (See
Figure 3-4.) Secure each leg with a pin in fully
retracted position.
2. The LANDING GEAR lever is located on the left side
of the Engine Control Panel. It has three positions:
Operating pressures greater than 2500 psi can
cause damage to the trailer.
Failure to properly set and check parking brake,
and chock wheels when parking and during
storage, could allow movement of the
truck/semitrailer rig resulting in serious personal
injury, death, or damage to property in its path.
Always grip crank handle securely with both
hands. Never shift landing gear under load, leave
the gears in neutral or leave the crank unsecured.
RETRACT In this position, the landing gear are
pulled up off the ground.
CENTER This is neutral position.
EXTEND In this position, the landing gear are
lowered to the ground.

3-6 F-486-1011 Edition
OPERATING INSTRUCTIONS
Figure 3-4: Hydraulic Controls
LANDING GEAR
HANDLE
FRONT SIDE
MARKER
ENGINE
CONTROLS
HYDRAULIC LEVERS
3m410-011099
DOCK LEVELER
SELECTOR
REMOTE RECEPTACLE
HYDRAULIC LEVERS
