Lantech IGS-2206C User manual

Lantech
IGS-2206C
6 10/100/1000T + 2 10/100/1000T/Dual Speed SFP
Combo w/Pro-Ring Managed Industrial Switch
User Manual

This manual contents are based on the below table listing
software kernel version, hardware version, and firmware version.
If the switch functions have any different from the manual
contents description, please contact the local sale dealer for
more information.
Firmware Version
V1.00
Kernel Version
V3.48
Hardware Version
---------
Notice

FCC Warning
This Equipment has been tested and found to comply with the limits for a
Class-A digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CE Mark Warning
This is a Class-A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.

Content
Introduction................................................................ 1
Benefits.................................................................... 1
Package Contents.................................................... 3
Hardware Description ............................................... 4
Physical Dimension.................................................. 4
Front Panel .............................................................. 4
Bottom View............................................................. 5
LED Indicators ......................................................... 5
Ports......................................................................... 7
Cabling................................................................... 12
Wiring the Power Inputs......................................... 13
Wiring the Fault Alarm Contact.............................. 13
Mounting Installation .............................................. 15
DIN-Rail Mounting.................................................. 15
Wall Mount Plate Mounting.................................... 17
Hardware Installation .............................................. 18
Installation Steps.................................................... 18
Network Application................................................ 19
X-Ring Application ................................................. 20
Coupling Ring Application...................................... 21
Dual Homing Application........................................ 21
Console Management ............................................. 23
Connecting to the Console Port............................. 23
Pin Assignment...................................................... 23

Login in the Console Interface............................... 24
CLI Management ................................................... 25
Commands Level............................................................ 26
Commands Set List......................................................... 27
System Commands Set.................................................. 27
Port Commands Set........................................................ 30
Trunk Commands Set..................................................... 32
VLAN Commands Set..................................................... 34
Spanning Tree Commands Set....................................... 35
QOS Commands Set...................................................... 38
IGMP Commands Set..................................................... 39
Mac / Filter Table Commands Set................................... 39
SNMP Commands Set.................................................... 40
Port Mirroring Commands Set......................................... 42
802.1x Commands Set ................................................... 43
TFTP Commands Set..................................................... 45
SystemLog, SMTP and Event Commands Set................ 46
SNTP Commands Set..................................................... 48
Pro-ring Commands Set ................................................. 49
Web-Based Management........................................ 51
About Web-based Management............................ 51
Preparing for Web Management............................ 51
System Login ......................................................... 52
Main Page.............................................................. 53
System Information................................................ 54
IP Configuration ..................................................... 54
DHCP Server –System configuration.................... 55

DHCP Client –Client Entries................................. 56
DHCP Server - Port and IP Bindings ..................... 57
TFTP - Update Firmware ....................................... 57
TFTP –Restore Configuration............................... 58
TFTP - Backup Configuration ................................ 58
System Event Log –Syslog Configuration............. 59
System Event Log - SMTP Configuration.............. 60
System Event Log - Event Configuration............... 61
Fault Relay Alarm .................................................. 63
SNTP Configuration............................................... 64
IP Security.............................................................. 67
User Authentication................................................ 68
Port Statistics......................................................... 69
Port Control............................................................ 70
Port Trunk .............................................................. 71
Aggregator setting .......................................................... 71
Aggregator Information................................................... 73
State Activity................................................................... 74
Port Mirroring ......................................................... 74
Rate Limiting.......................................................... 75
VLAN configuration................................................ 76
VLAN configuration - Port-based VLAN.......................... 77
802.1Q VLAN.................................................................. 80
Rapid Spanning Tree............................................. 83
RSTP - System Configuration......................................... 83
RSTP - Port Configuration.............................................. 84

SNMP Configuration.............................................. 85
System Configuration...................................................... 86
Trap Configuration.......................................................... 87
SNMPV3 Configuration................................................... 88
QoS Configuration ................................................. 91
QoS Policy and Priority Type.......................................... 91
Port Base Priority............................................................ 93
COS Configuration.......................................................... 93
TOS Configuration.......................................................... 93
IGMP Configuration ............................................... 93
Pro-Ring System.................................................... 95
802.1X/Radius Configuration.......................................... 98
MAC Address Table...................................................... 101
Factory Default..................................................... 104
Save Configuration .............................................. 104
System Reboot .................................................... 104
Troubles shooting ................................................. 106
Technical Specification......................................... 107

1
Introduction
The 6 10/100/1000T + 2 10/100/1000T/Dual Speed SFP Combo w/ Pro-Ring Managed
Industrial Switch is a cost-effective solution and meets the high reliability requirements
demanded by industrial applications. The 6 10/100/1000T + 2 10/100/1000T/Dual Speed
SFP Combo w/ Pro-Ring Managed Industrial Switch can be easily managed through the
Web GUI. Using fiber port can extend the connection distance that increases the
network elasticity and performance. It also provides the Pro-Ring system that can
prevent the network connection failure.
Benefits
System Interface/Performance
RJ-45 ports support auto MDI/MDI-X function
SFP (Mini-GBIC) supports 100/1000 Dual Mode
Store-and-Forward switching architecture
Back-plane (Switching Fabric): 16Gbps
1Mbits Packet Buffer
8K MAC Address Table
Power Supply
Input Power Isolation design for Telcom application, Pass Hi-Pot test~1.5KV
Wide-range Redundant Power Design
VLAN
Port Based VLAN
Supports 802.1Q Tag VLAN
GVRP
Double Tag VLAN (Q in Q)*
Private VLAN**
Port Trunk with LACP
QoS (Quality of Service)
Supports IEEE 802.1p Class of Service
Per port provides 4 priority queues

2
Port Base, Tag Base and Type of Service Priority
Port Mirror: Monitor traffic in switched networks
TX Packet only
RX Packet only
Both of TX and RX Packet
Security
Port Security: MAC address entries/filter
IP Security: IP address security management to prevent unauthorized intruder
Login Security: IEEE 802.1X/RADIUS
IGMP with Query mode for Multi Media Application
Case/Installation
IP-30 Protection
DIN Rail and Wall Mount Design
Spanning Tree
Support IEEE 802.1d Spanning Tree
Support IEEE 802.1w Rapid Spanning Tree
Pro-ring
X-ring, Dual Homing, and Couple Ring Topology
Provide redundant backup feature and the recovery time below10ms
Bandwidth Control
Ingress Packet Filter and Egress Rate Limit
Broadcast/Multicast Packet Filter Control
System Event Log
System Log Server/Client
SMTP e-mail Alert
Relay Alarm Output System Events
SNMP Trap
Device cold start
Power status
Authentication failure
X-ring topology changed
Port Link up/Link down
TFTP Firmware Update and System Configuration Restore and Backup

3
Package Contents
Please refer to the package content list below to verify them against the checklist.
6 10/100/1000T + 2 10/100/1000T/Dual Speed SFP Combo w/ Pro-Ring Managed
Industrial Switch
User manual
RS-232/RJ-45 cable
Pluggable Terminal Block
2 wall mount plates and 6 screws
One DIN-Rail (attached on the switch)
6 10/100/1000T + 2 10/100/1000T/Dual Speed SFP Combo User Manual
w/ Pro-Ring Managed Industrial Switch
RS-232-RJ-45 connector cable Pluggable Terminal Block
Wall Mount Plate Screws DIN-Rail
Compare the contents of the industrial switch with the standard checklist above. If any
item is damaged or missing, please contact the local dealer for service.

4
Hardware Description
In this paragraph, it will describe the Industrial switch‘s hardware spec, port, cabling
information, and wiring installation.
Physical Dimension
6 10/100/1000T + 2 10/100/1000T/Dual Speed SFP Combo w/ Pro-Ring Managed
Industrial Switch dimension (W x D x H) is 72mm x 105mm x 152mm
Front Panel
Here is the front panel of the 6 10/100/1000T + 2 10/100/1000T/Dual Speed SFP
Combo w/ Pro-Ring Managed Industrial Switch shown as below.
Front Panel of the industrial switch

5
Bottom View
The bottom panel of the 6 10/100/1000T + 2 10/100/1000T/Dual Speed SFP Combo w/
Pro-Ring Managed Industrial Switch has one terminal block connector in which has two
DC power inputs.
Bottom Panel of the industrial switch
LED Indicators
There are diagnostic LED indicators located on the front panel of the industrial switch.
They provide real-time information of system and optional status. The following table
provides description of the LED status and their meanings for the switch.
LED
Status
Description
PWR
Green
System power on
Off
No power input
R.M.
Green
The industrial switch is the master of the X-
Ring group

6
Off
The industrial switch is not the ring master in
the X-Ring group
PWR1
Green
Power input 1 is active
Off
Power input 1 is inactive
PWR2
Green
Power input 2 is active
Off
Power input 2 is inactive
Fault
Red
Power input 1 or 2 is inactive or port link
failure (depends on Fault Relay Alarm
configuration)
Off
Power input 1 and 2 are both active, or no
power inputs
LNK/ACT
(for P7, P8 SFP)
Green
SFP port is linking
Blinking
Data is transmitting or receiving
Off
Not connected to network
P1 ~ P8 (RJ-45)
Green
(upper LED)
Connected to network
Blinking
(upper LED)
Networking is active
Off
(lower LED)
No connected to network
Green
(lower LED)
The port is operating at speed of 1000M
Off
(lower LED)
The port is disconnected or working at speed
of 10/100M

7
Ports
RJ-45 ports
There are 10/100/1000Mbps ports for 10Base-T, 100Base-TX or 1000Base-T devices
connection which UTP ports will auto-sense. Auto MDI/MDIX means that the switch can
connect to another switch or workstation without changing straight through or crossover
cabling. See the figures below for straight through and crossover cable schematic.
RJ-45 Pin Assignments
Pin Number
Assignment
1
Tx+
2
Tx-
3
Rx+
6
Rx-
[NOTE] ―+‖ and ―-‖ signs represent the polarity of the wires that make up each wire pair.
All ports on this industrial switch support automatic MDI/MDI-X operation, user can use
straight-through cables (See figure below) for all network connections to PCs or servers,
or to other switches/hubs. In straight-through cable, pins 1, 2, 3, and 6, at one end of the
cable, are connected straight through to pins 1, 2, 3 and 6 at the other end of the cable.
The table below shows the 10BASE-T/100BASE-TX/1000BASE-T MDI and MDI-X port
pin outs.
Pin MDI-X
Signal Name
MDI Signal Name
1
Receive Data plus (RD+)
Transmit Data plus (TD+)
2
Receive Data minus (RD-)
Transmit Data minus (TD-)
3
Transmit Data plus (TD+)
Receive Data plus (RD+)
6
Transmit Data minus (TD-)
Receive Data minus (RD-)

8
Straight Through Cable Schematic
Cross Over Cable Schematic
2 Gigabit Copper/SFP (mini-GBIC) combo port:
The Industrial switch has two auto-detect Giga port—UTP/Fiber combo ports. The
Gigabit Copper (10/100/1000T) ports should use Category 5e or above UTP/STP cable
for connection. The SFP slots are for connecting to the network segment with single or
multi-mode fiber. You can choose appropriate mini-GBIC module to plug into the slots.
Make sure the module is aligned correctly and then slide the module into the SFP slot
until a click is heard. You can use proper multi-mode or single-mode fiber according to
the used SFP module. With fiber optic, it transmits speed up to 1000 Mbps and you can
prevent noise interference from the system and transmission distance up to 110 km,
depending on the mini-GBIC module.
The small form-factor pluggable (SFP) is a compact optical transceiver used in optical
communications for both telecommunication and data communications applications.
To connect the transceiver and LC cable, please follow the steps shown below:

9
First, insert the transceiver into the SFP slot. Notice that the triangle mark is the bottom
of the slot.
Figure 2.8: Transceiver to the SFP slot
Figure 2.9: Transceiver Inserted

10
Second, insert the fiber cable of LC connector into the transceiver.
Figure 2.10: LC connector to the transceiver

11
To remove the LC connector from the transceiver, please follow the steps shown below:
First, press the upper side of the LC connector to release from the transceiver and pull it
out.
Figure 2.11: Remove LC connector
Second, push down the metal loop and pull the transceiver out by the plastic handle.
Figure 2.12: Pull out from the transceiver

12
Cabling
Using four twisted-pair, Category 5e/above cabling for RJ-45 port connection. The
cable between the switch and the link partner (switch, hub, workstation, etc.) must
be less than 100 meters (328 ft.) long.
Fiber segment using single-mode connector type must use 9/125 µm single-mode
fiber cable.
Fiber segment using multi-mode connector type must use 50 or 62.5/125 µm multi-
mode fiber cable.

13
Wiring the Power Inputs
Please follow the steps below to insert the power wire.
Insert the positive and negative wires into the V+ and V- contacts on the terminal block
connector.
Tighten the wire-clamp screws for preventing the wires from loosing.
Wiring the Fault Alarm Contact
The fault alarm contact is in the middle of the terminal block connector as the picture
shows below. Inserting the wires, it will detect the fault status including port link failure
(managed industrial switch only) or power failure and form an open circuit. An
application example for the fault alarm contact is shown as below:
