Lantronix MatchPort b/g Quick setup guide

Part Number 900-485
Revision D December 2011
MatchPort b/g
Integration Guide

MatchPort b/g Integration Guide
Copyright and Trademark
© 2011 Lantronix. All rights reserved. No part of the contents of this book may be
transmitted or reproduced in any form or by any means without the written permission
of Lantronix. Printed in the United States of America.
MatchPort®, with its patent-pending technology, is a trademark of Lantronix. Ethernet
is a trademark of XEROX Corporation. UNIX is a registered trademark of The Open
Group. Windows is a trademark of Microsoft Corporation.
Contacts Lantronix Corporate Headquarters
167 Technology Drive
Irvine, CA 92618, USA
Phone: [phone]
Fax: [phone]
Technical Support
Online: www.lantronix.com/support
Email/Chat: www.lantronix.com/support
Sales Offices
For a current list of our domestic and international sales offices go to the Lantronix
web site at www.lantronix.com/about/contact/.
Disclaimer This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
This device is intended only for OEM Integrators. The OEM integrator should be
aware of the following important issues.
Labeling of the End Product
The label on the end product incorporating the MatchPort b/g module must clearly
state that it contains an FCC-approved RF module. For example, “This product
contains an RF transmitter ID# (put FCC or IC module grant number here).” The
actual grant number is on the MatchPort b/g label.

MatchPort b/g Integration Guide 3
RSS-GEN Sections 7.1.4 and 7.1.5 Statement for Devices with Detachable
Antennas
This device has been designed to operate with the antennas listed in the Certificate,
and having a maximum gain of 5 dBi. Antennas not included in this list or having a
gain greater than 5 dBi are strictly prohibited for use with this device, unless system-
level FCC approval is gained. The required antenna impedance is 50 ohms.
To reduce potential radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropically radiated power (EIRP) is not
more than that required for successful communication.
Integration Note
a) This module is authorized under limited module approval specified to mobile host
equipment. So, the antenna must be installed such that 20cm is maintained between
the antenna and users.
b) The transmitter module may not be co-located with any other transmitter or
antenna.
As long as the two conditions above are met, further transmitter testing will not be
required. However, the OEM integrator is still responsible for testing their end product
for any additional compliance requirements required with this module installed (for
example, digital device emission, PC peripheral requirements, etc.)
Note: In the event that these conditions cannot be met (for example certain
laptop configurations, general purpose PCMCIA or similar cards, or co-
location with another transmitter), then the FCC authorization is no longer
considered valid and the FCC ID cannot be used on the final product
(including the transmitter) and obtaining a separate FCC authorization.
Note: Changes or modifications to this device not explicitly approved by Lantronix will
void the user's authority to operate this device.
Revision Table
Date
Rev.
Comments
March 2007
A
Initial Draft
June 2007
B
Updated content related to demo board jumper configuration,
recommended operating conditions, technical specifications
and the PCB interface signal.
June 2008
C
Updated the RoHS table, configuration switch bank, and
tolerance information.
December 2011 D Updated absolute maximum ratings and recommended
supply voltage information.

MatchPort b/g Integration Guide 4
Contents
Copyright and Trademark__________________________________________________2
Contacts _______________________________________________________________2
Disclaimer______________________________________________________________2
Revision Table __________________________________________________________3
List of Figures___________________________________________________________5
List of Tables ___________________________________________________________5
1: Introduction 6
About the Integration Guide ________________________________________________6
Additional Documentation__________________________________________________6
2: Description and Specifications 7
MatchPort b/g Overview___________________________________________________7
MatchPort b/g Block Diagram_______________________________________________8
PCB Interface___________________________________________________________9
Mating Connector ________________________________________________________9
Serial Input/Output ______________________________________________________10
Sample Layouts for RS-485 Connectivity_____________________________________11
WLAN Input/Output _____________________________________________________12
MatchPort b/g_____________________________________________________________ 12
Power, Ground, and Reset________________________________________________13
Absolute Maximum Ratings _______________________________________________13
Recommended Operating Conditions _______________________________________13
Wireless Specifications___________________________________________________14
Technical Specifications__________________________________________________15
Dimensions____________________________________________________________16
Recommended PCB Layout_______________________________________________18
Product Information Label ________________________________________________19
3: Demonstration Kit 20
Contents of the Kit ______________________________________________________20
Demo Board Description _________________________________________________20
Serial Interfaces ________________________________________________________20
Power Supply __________________________________________________________21
General Control ________________________________________________________21
Configuration Switch Bank ________________________________________________21
Demo Board Layout _____________________________________________________23
Demo Board Schematics _________________________________________________24
A: Compliance and Warranty Information 28
Compliance Information __________________________________________________28
Warranty______________________________________________________________29

MatchPort b/g Integration Guide 5
List of Figures
Figure 2-1. MatchPort b/g Block Diagram ____________________________________________8
Figure 2-2. Reverse-SMA to U.FL (P/N 500-180-R) ____________________________________9
Figure 2-3. U.FL to U.FL Cable (P/N 500-181-R) _____________________________________10
Figure 2-4. Combined RS-232/422 Transceiver ______________________________________11
Figure 2-5. Separate RS-232/422 Transceivers ______________________________________11
Figure 2-6. Separate RS-422 Transceivers for 2-Wire and 4-Wire Setups__________________12
Figure 2-7. Side Views _________________________________________________________16
Figure 2-8. Top View___________________________________________________________17
Figure 2-9. Bottom View ________________________________________________________17
Figure 2-10. Wireless Connector Dimensions________________________________________18
Figure 2-11. PCB Layout (Top View) ______________________________________________18
Figure 2-12. Product Label ______________________________________________________19
Figure 3-1. MatchPort b/g Demo Board Layout_______________________________________23
Figure 3-2. Demo Board Schematics ______________________________________________24
List of Tables
Table 2-1. PCB Interface Signals __________________________________________________9
Table 2-2. RS232 Connections ___________________________________________________10
Table 2-3. JP9 RS-422/485 Connections ___________________________________________11
Table 2-4. WLAN Signals _______________________________________________________12
Table 2-5. Power, Ground, and Reset Pins__________________________________________13
Table 2-6. Absolute Maximum Ratings _____________________________________________13
Table 2-7. Operating Conditions, Serial Ports, & Configurable Pins_______________________13
Table 2-8. Wireless Specifications ________________________________________________14
Table 2-9. Technical Specifications________________________________________________15
Table 3-1. RS-232 Signals ______________________________________________________21
Table 3-2. RS-485 4-Wire Connector ______________________________________________21
Table 3-3. Demo Board JP1 Jumper Configuration ___________________________________21
Table 3-4. Demo Board JP7 Jumper Configuration for CON1 ___________________________22
Table 3-5. Demo Board JP8 Jumper Configuration for CON2 ___________________________22
Table 3-6. Demo Board JP5 Jumper Configuration ___________________________________22
Table 3-7. Demo Board Configurable Pin Jumper Configurations.________________________22

MatchPort b/g Integration Guide 6
1: Introduction
About the Integration Guide
This guide provides the information needed to integrate the MatchPort b/g device
server within another product. The intended audiences are the engineers responsible
for integrating the MatchPort b/g into their product.
Additional Documentation
The following guides are available on the product CD and the Lantronix Web site
(www.lantronix.com)
MatchPort b/g
Demonstration Kit Quick
Start Guide
Briefly explains the basics to get the MatchPort
b/g up and running.
MatchPort b/g User Guide Provides information needed to configure, use,
and update the MatchPort b/g firmware.

MatchPort b/g Integration Guide 7
2: Description and Specifications
The MatchPort b/g wireless embedded device server is a complete network-enabling
solution based on the IEEE 802.11b/g wireless standard, with 802.11i (PSK), WPA,
and WEP capabilities. MatchPort b/g allows Original Equipment Manufacturers
(OEMs) to add wireless connectivity to their products by incorporating it onto a circuit
board with minimal engineering.
The MatchPort b/g functions independently of a PC, providing an integrated solution
that combines a processor, memory, 802.11b/g transceiver, a 10/100 Mbps Ethernet
transceiver, and two high-speed serial ports into a single compact module. It includes
a wireless connection, an operating system, an embedded Web server, and a full
TCP/IP protocol stack. In addition, the MatchPort b/g sends email alerts and supports
numerous other network communication protocols, including ARP, UDP, TCP, ICMP,
Telnet, AutoIP, DHCP, HTTP and SNMP.
MatchPort b/g Overview
The MatchPort b/g contains Lantronix’s own DSTni controller with 256 Kbytes of
internal zero wait state SRAM and 16 Kbytes of boot ROM.
The MatchPort b/g also contains the following:
Two 3.3 volt, CMOS level, asynchronous serial interfaces (5 volt tolerant)
Support for RS-232 and RS-485 up to 921 Kbps
16 Mbit flash memory
26 (low), 48 (regular), 88 (high) MHz clock
802.11b/g interface
10/100 Mbps Ethernet transceiver (requires external magnetics and RJ45)
8 configurable pins
The MatchPort b/g requires +3.3-volt power and is designed to operate within a
temperature range of -40ºC to +70ºC.

2: Description and Specifications
MatchPort b/g Integration Guide 8
MatchPort b/g Block Diagram
The following drawing is a block diagram of the MatchPort b/g showing the
relationships of the components.
Figure 2-1. MatchPort b/g Block Diagram

2: Description and Specifications
MatchPort b/g Integration Guide 9
PCB Interface
Table 2-1. PCB Interface Signals
Pin #
Name
Function
Pin #
Name
Function
1
Reset IN#
Active low Reset. Min reset
input 2 ms. Leave floating if
unused.
2
GND
Signal Ground
3
NC
No Connect
4
NC
No Connect
5
TXD1
Transmit data output (logic
level), port 0
6
TX+
Ethernet TX+
7
RTS1
Request to Send output
(logic level), port 0
8
TX-
Ethernet TX-
9 RXD1 Receive data input (logic
level), port 0
10 TXCT Ethernet TX center tap
11 CTS1 Clear to Send input (logic
level), port 0
12 RXCT Ethernet RX center tap
13
CP1
Configurable pin
14
RX+
Ethernet RX+
15
CP2
Configurable pin
16
RX-
Ethernet RX-
17
CP3
Configurable pin
18
ELED1
Ethernet Link (active low)
19
CP4
Configurable pin
20
ELED2
Ethernet Activity (active low)
21
TXD2
Transmit data output (logic
level), port 1
22
WLAN
LED
Wireless LAN status LED
output (4mA) Active low
23 RTS2 Request to Send output
(logic level), port 1
24 NC No connect
25 RXD2 Receive data input (logic
level), port 1
26 NC No connect
27
CTS2
Clear to Send input (logic
level), port 1
28
RES
Reserved for future use
29
CP5
Configurable pin
30
RES
Reserved for future use
31
CP6
Configurable pin
32
NC
No connect
33
CP7
Configurable pin
34
NC
No connect
35
CP8
Configurable pin
36
NC
No connect
37
3.3V
3.3V power input
38
NC
No connect
39
GND
Signal Ground
40
NC
No connect
Note: For all the configurable pins, see the MatchPort b/g User Guide for
selectable functions.
Mating Connector
MatchPort can be soldered directly to the PCB using the footprint shown in Figure
2-10. If a socket is required, two 2 mm 20-pin sockets spaced 1.42" apart can be
used (e.g., Samtec P/N SMM-120-02-S-S-TR).
An antenna connection is made via the U.FL style connector on the MatchPort.
Lantronix offers two cable options, reverse-SMA to U.FL (P/N 500-180-R) or U.FL to
U.FL (P/N 500-181-R).
Figure 2-2. Reverse-SMA to U.FL (P/N 500-180-R)

2: Description and Specifications
MatchPort b/g Integration Guide 10
Figure 2-3. U.FL to U.FL Cable (P/N 500-181-R)
Note: The antenna cable is included in the MatchPort b/g sample. For
production, it can be purchased from Lantronix or a cable supplier.
Serial Input/Output
The unit has two serial ports compatible with RS232 serial standards at data rates
up to 921 Kbps. The serial I/O signals are 3.3V CMOS logic level and pins are 5V
tolerant. Serial signals connect to the OEM CPU/UART. For evaluation and prototype
work, it is convenient to have an external RS-232 interface that can connect to the
serial port on a PC. The MatchPort Demo Board has RS-232/422/485 transceivers to
implement this external interface.
If desired, use the CPs to create a DTE or DCE-style interface using any three
available CPs. To create these interfaces, connect the signals according to Table 2-2
and Table 2-4.
Note: CPx, and CPy are any of the available CPs.
Table 2-2. RS232 Connections
MatchPort b/g
DCE Connector
DTE Connector
Signal
(Logic)
Description
DB9
DB25
Signal
DB9
DB25
Signal
RXDx
Data In
2
3
RXDx
3
2
TXDx
TXDx
Data Out
3
2
TXDx
2
3
RXDx
RTSx
H/W Flow Control
Output
7
4
RTSx
8
5
CTSx
CTSx
H/W Flow Control Input
8
5
CTSx
7
4
RTSx
CPx
Modem Control Input
1
8
DCDx
4
20
DTRx
CPy
Modem Control Output
4
20
DTRx
1
8
DCDx
Table 2-4. JP6 RS422/485 Connections
MatchPort
b/g Signal
(logic)
Description
RS485
Signal
JP6
Pin
DB25
4
Wire
DB25
2
Wire
DB9
4 wire
DB9
2 wire
TXD1
Data Out
TX+485
4
14
14
7
7
TXD1
Data Out
TX-485
3
15
15
3
3
RXD1
Data In
RX+485
2
21
14
2
7
RXD1
Data In
RX-485
1
22
15
8
3
RTS1
TX Enable
CP3 RS485 Select
CP4 RS485 2-wire

2: Description and Specifications
MatchPort b/g Integration Guide 11
Table 2-3. JP9 RS-422/485 Connections
MatchPort
b/g Signal
(logic)
Description
RS-485
Signal
JP9
Pin
DB25
4
Wire
DB25
2
Wire
DB9
4 wire
DB9
2 wire
TXD2 Data Out
TX+485
4
14
14
7
7
TXD2
Data Out
TX-485
3
15
15
3
3
RXD2
Data In
RX+485
2
21
14
2
7
RXD2 Data In
RX-485
1
22
15
8
3
RTS2
TX Enable
CP7
RS-485 Select
CP8
RS-485 2-wire
Sample Layouts for RS-485 Connectivity
Figure 2-4. Combined RS-232/422 Transceiver
Figure 2-5. Separate RS-232/422 Transceivers

2: Description and Specifications
MatchPort b/g Integration Guide 12
Figure 2-6. Separate RS-422 Transceivers for 2-Wire and 4-Wire Setups
WLAN Input/Output
The following table displays the WLAN LED functions.
Table 2-4. WLAN Signals
Pin Number
Pin Function
22
WLAN LED
MatchPort b/g
Output WLAN LED can be used to drive an external LED to monitor the activity of the
radio. The output is active when the receiver and or transmitter are on. The output is
active low and can drive an LED with 10mA. The LED shall be connected between
the output and 3.3V with a series resistor of 220 ohm.
Note: If you have questions or concerns, please contact Lantronix Technical
Support at [phone] (US only) or [phone].
If power management is disabled, and when the unit is associated with a network, the
receiver will always be on and thus any LED output, that indicates the receiver or
transmitter being on will be active continuously.

2: Description and Specifications
MatchPort b/g Integration Guide 13
Power, Ground, and Reset
Table 2-5. Power, Ground, and Reset Pins
Power
Ground
Reset
Pin 37
Pin 2
Pin 1
Pin 39
Driving the Reset In line low resets the MatchPort b/g. Minimum reset pulse width is
2 ms at IIL = -500uA.
Absolute Maximum Ratings
Table 2-6. Absolute Maximum Ratings
Parameter
Min
Max
Units
Supply Voltage
3.135
3.6
V
Input Voltage
-0.5
6
V
Output Voltage
-0.5
6
V
Operating Temperature
-40
70
ºC
Storage Temperature
-40
85
ºC
Recommended Operating Conditions
The following table illustrates the optimal and recommended operating conditions for
the MatchPort b/g device.
Table 2-7. Operating Conditions, Serial Ports, & Configurable Pins
Parameter
Min
Typical
Max
Units
Supply Voltage
3.135
3.3
3.45
V
Voltage Ripple
2
%
VIL Input Low Voltage*
-0.3
0.8
V
VIH Input High Voltage*
2
5.5
V
II Input Leakage Current* +/- 10 nA +/- 1
µA
VOL Output Low Voltage @ IOL max*
0.4
V
VOH Output High Voltage @ IOH max*
2.4
V
TXDx, RTSx IOL
Low Level Output Current @ VOL 0.4V
2.2
3.5
4.3
mA
CP1-CP8 Low Level Output Current
@VOL 0.4V
4.4
7.1
8.5
mA
TXDx, RTSx IOH
High Level Output Current @ VOH 2.4V
-3.2 -6.4 -10.0 mA
CP1-CP8 IOH
High Level Output Current @ VOH 2.4V
-3.2
-6.4
-10.0
mA
* For UART and CP pins

2: Description and Specifications
MatchPort b/g Integration Guide 14
Wireless Specifications
Refer to the following table for the MatchPort b/g’s wireless specifications:
Table 2-8. Wireless Specifications
Category
IEEE 802.11b/g
Frequency Range
2.400 – 2.484 GHz
Output Power 14 +2.0/- 1.5 dBm 1, 2, 5.5, 11
Mbps
12 +/- 1.5 dBm 6, 9, > 12 Mbps
Antenna Connector
1
Data Rates
1,2,5.5,11,6,9,12,18,24,36,48,54
Mbps
Radio
Number of
Selectable
Subchannels
US 1-11
CA 1-11
JP 1-14
FR 10-13
SP 10-11
OT 1-13 (OT=Others)
Modulation
DSSS,DBPSK,DQPSK,CCK,
OFDM, 16QAM, 64QAM
Antenna
Connector
1
Security
WEP 64/128,WPA, WPA2/802.11i
Maximum Receive Level
-10 dBm (with PER < 8%)
Receiver Sensitivity
-69 dBm for 54 Mbps
-88 dBm for 11 Mbps
-85 dBm for 6 Mbps
-91 dBm for 1.0 Mbps
WLAN LED Current
Max: 10 mA

2: Description and Specifications
MatchPort b/g Integration Guide 15
Technical Specifications
Table 2-9. Technical Specifications
Category
MatchPort b/g
CPU, Memory
Lantronix DSTni-EX 186 CPU, 256 KB zero
wait state SRAM
2048 KB Flash,16 KB Boot ROM
Firmware
Upgradeable via TFTP and serial port
Reset Circuit
Reset In is low active. Minimum reset pulse
width is 2 ms at IIL = -500 µA
Serial Interface
CMOS (Asynchronous) 3.3V - level signals
Speed software selectable (300 bps to 921
Kbps)
Serial Line Formats
7 or 8 data bits, 1-2 Stop bits, Parity: odd,
even, none
Modem Control
DTR, DCD
Flow Control
XON/XOFF (software), CTS/RTS
(hardware), none
Network Interface
802.11b/g, Ethernet 10Base-T or
100Base-T (auto sensing) (Ethernet with
external magnetics and RJ45)
Protocols Supported ARP, UDP, TCP, Telnet, ICMP, SNMP,
DHCP, BOOTP, Auto IP, HTTP, SMTP,
TFTP
Management
Internal web server, SNMP (read only)
Serial login, Telnet login, DeviceInstaller
software
Internal Web Server
Serves web pages
WEB storage capacity: 1.2 MB
Distance
Up to 328 feet Indoors
Average Power Consumption
(at 3.3V)
Wireless Mode Associated
850 mW (Reg performance. Data transfer at
230 Kbps.)
740 mW (Low performance. Data transfer at
230 Kbps.)
350 mW (Regular performance. No data
transfer.)
250 mW (Low performance. No data
transfer.)
1360 mW (High performance bridging
mode)
Peak Supply Current (at 3.3V)
360 mA (Reg performance, 230 Kbps data
transfer, Wireless mode); (550 mA high
performance bridging mode)
Security Password protection, locking features,
64/128 bit WEP, WPA, 802.11i (PSK)
Weight
14g
Cover Material
ABS
Temperature Operating range: -40°C to +70°C
Storage range: -40°C to +85°C (-40°F to
185°F)
Warranty
2-year limited warranty
Included Software
Windows™ 98/NT/2000/XP based Device
Installer configuration software and
Windows™ based Com Port Redirector,
DeviceInstaller, and Web-Manager.

2: Description and Specifications
MatchPort b/g Integration Guide 16
Dimensions
The MatchPort b/g dimensions are shown in the following diagrams. All tolerances
+-.005in unless otherwise noted.
Figure 2-7. Side Views

2: Description and Specifications
MatchPort b/g Integration Guide 17
Figure 2-8. Top View
Figure 2-9. Bottom View

2: Description and Specifications
MatchPort b/g Integration Guide 18
Figure 2-10. Wireless Connector Dimensions
Recommended PCB Layout
The hole pattern and mounting dimensions for the MatchPort b/g device server are
shown in the following drawing:
Figure 2-11. PCB Layout (Top View)

2: Description and Specifications
MatchPort b/g Integration Guide 19
Product Information Label
The product information label contains important information about your specific unit,
such as its product ID (name), bar code, part number, and MAC address.
Figure 2-12. Product Label
MAC Address
Revision
Manufacturing Code
Part Number

MatchPort b/g Integration Guide 20
3: Demonstration Kit
The MatchPort b/g Demonstration Kit includes everything needed to begin to
integrate the MatchPort b/g into a given product design.
Contents of the Kit
The Demonstration Kit contains the following items:
MatchPort Demo Board
3.6V Power Supply
RS-232 cable, DB9F/F, null modem
Ethernet cable
Antenna
Note: You must purchase the MatchPort b/g sample separately for use with
this Demonstration Kit.
Demo Board Description
The MatchPort Demo Board provides a test platform for the Lantronix MatchPort b/g
device server. It supplies 3.3V power. The MatchPort demo board provides access to
all signals to and from the MatchPort b/g device server. The demo board has two
serial port interfaces (CON1 and CON2). The MatchPort b/g demo board also
includes an RJ45 connector for use with wired Ethernet.
Serial Interfaces
The MatchPort b/g serial interface is 3.3V logic level and typically connected to a
Universal Asynchronous Receiver/Transmitter (UART). For connection to an external
device, the demo board has RS-232/422/485 transceivers. CON1 and CON2 support
RS-232/485. Connect to a PC using a null-modem serial cable with 9-pin connectors
(F/F).
The table below lists the RS-232 signals and corresponding pins on the MatchPort
b/g. All signals are level-shifted by the RS-232 transceivers.
