Larius GHIBLI 10:1 Operating instructions
www.larius.com
Manuale Cod. 150186
H2O Max 90°
REV. 02 - 06/2021
GHIBLI 10:1
PNEUMATIC
WASHING PUMP
LOW AND MEDIUM PRESSURE
WASH PUMPS
FOR INTENSIVE CLEANING
IN HAZARDOUS ENVIRONMENTS
USABLE WITH COLD
OR HOT WATER UP TO 90°
Trolley version Cod. 98690/1
Wall version Cod. 98691
Drum Version 200L Cod. 96661/1
OPERATING AND MAINTENANCE MANUAL
EN
Due to a constant product improvement programme, the factory reserves the right to modify
technical details mentioned in this manual without prior notice.
This manual is to be considered as an English language translation of the original manual in Italian.
The manufacturer shall bear no responsibility for any damages or inconveniences that may arise due to
the incorrect translation of the instructions contained within the original manual in Italian.
A
C
D
B
E
H
G
F
I
M
N
J
K
L
O
P
Q
R
S
T
U
V
W
X
Y
Z
www.larius.com
3
GHIBLI 10:1 PNEUMATIC WASHING PUMP
REV. 02 - 06/2021 - Cod. 150186
GHIBLI 10:1
Pneumatic washing pump
INDEX
WARNINGS ..................................................................................................................................................................4
WORKING PRINCIPLE .................................................................................................................................................5
TECHNICAL DATA ........................................................................................................................................................6
DESCRIPTION OF THE EQUIPMENT ..........................................................................................................................6
TRANSPORT AND UNPACKING..................................................................................................................................8
CONDITIONS OF GUARANTEE ...................................................................................................................................8
SAFETY RULES............................................................................................................................................................8
GROUNDING................................................................................................................................................................9
WORKING ....................................................................................................................................................................9
SETTING UP AND CONNECTION..............................................................................................................................10
TYPES OF INSTALLATION .........................................................................................................................................10
CLEANING AT THE END OF THE WORK...................................................................................................................11
ROUTINE MAINTENAINCE ........................................................................................................................................11
TROUBLESHOOTING ................................................................................................................................................12
MANUAL RESET OF THE PNEUMATIC MOTOR .......................................................................................................13
DISASSEMBLY OF PNEUMATIC MOTOR..................................................................................................................13
DISASSEMBLY OF THE SUCTION VALVE ................................................................................................................14
REPLACEMENT OF THE LOWER GASKETS............................................................................................................15
REPLACEMENT OF THE UPPER GASKETS.............................................................................................................15
SPARE PARTS - COMPLETE PNEUMATIC MOTOR .................................................................................................18
SPARE PARTS - COMPLETE PUMPING GROUP SPLIT STAINLESS STEEL............................................................20
SPARE PARTS - COMPLETE TROLLEY.....................................................................................................................22
SPARE PARTS - AIR GROUP - TROLLEY VERSION ................................................................................................23
SPARE PARTS - AIR GROUP - WALL VERSION.......................................................................................................24
ACCESSORIES...........................................................................................................................................................24
ATEX CERTIFICATION ................................................................................................................................................24
DECLARATION OF CONFORMITY.............................................................................................................................27
WE ADVISE THE USE OF THIS EQUIPMENT ONLY BY PROFESSIONAL OPERATORS.
ONLY USE THIS MACHINE FOR USAGE SPECIFICALLY MENTIONED IN THIS MANUAL.
Thank you for choosing a LARIUS S.R.L. product.
As well as the product purchased, you will receive a range of support services
enabling you to achieve the results desired, quickly and professionally.
GHIBLI 10:1 PNEUMATIC WASHING PUMP
A
AA
www.larius.com
4
REV. 02 - 06/2021 - Cod. 150186
The table below provides the meaning of the symbols used in this manual in relation to using, earthing, operating, maintaining, and
repairing of this equipment.
WARNINGS
Read this operator’s manual carefully before using the equipment.
An improper use of this machine can cause injuries to people or things.
Do not use this machine when under the inuence of drugs or alcohol.
Do not modify the equipment under any circumstances.
Use products and solvents that are compatible with the various parts of the equipment, and read the manufacturer’s warnings carefully.
See the Technical Details for the equipment given in the Manual.
Check the equipment for worn parts once a day. If any worn parts are found, replace them using ONLY original spare parts.
Keep children and animals away from work area.
Comply with all safety standards.
It indicates an accident risk or serious damage to equipment if this warning is not followed.
FIRE AND EXPLOSION HAZARD
Solvent and paint fumes in work area can ignite or explode.
To help prevent fire and explosion:
- Use equipment ONLY in well ventilated area.
- Eliminate all ignition sources, such as pilot lights, cigarettes and plastic drop cloths (potential static arc).
- Ground equipment and conductive objects.
- Use only grounded hoses.
- Do not use trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or uids containing such solvents in
pressurized aluminium equipment. Such use can cause serious chemical reaction and equipment rupture, and result in death,
serious injury, and property damage.
- Do not form connections or switch light switches on or off if the air contains inammable fumes.
If electrical shocks or discharges are encountered the operation being carried out using the equipment must be stopped immediately.
Keep a re extinguisher at hand in the immediate vicinity of the work area.
any risk of the equipment starting unexpectedly.
Report any risk of chemical reaction or explosion if this warning has not been given.
(IF PROVIDED) There is a risk of injury or serious lesion related to contact with the jet from the spray gun. If this should occur, IMME-
DIATELY contact a doctor, indicating the type of product injected.
(IF PROVIDED) Do not spray before the guard has been placed over the nozzle and the trigger on the spray gun.
(IF PROVIDED) Do not put your ngers in the spray gun nozzle.
Once work has been completed, before carrying out any maintenance, complete the decompression procedure.
It indicates important recommendations about disposal and recycling process of products in accordance with the environmental
regulations.
Mark any clamps attached to earth cables.
Use ONLY 3-wire extension cords and grounded electrical outlets.
Before starting work make sure that the electrical system is grounded and that it complies with safety standards.
High-pressure uid from gun, hose leaks, or ruptured components will pierce skin.
To help prevent injection, always:
- (IF PROVIDED) Engage trigger lock when not spraying.
- (IF PROVIDED) Do not put your hand over the spray tip. Do not stop or deect leaks with your hand, body or other.
- (IF PROVIDED) Do not point gun at anyone or at any part of the body.
- (IF PROVIDED) Never spray without tip guard.
- Do pressure relief if you stop spraying or being servicing sprayer and before any maintenance operations.
- Do not use components rated less than sprayer Maximum Working Pressure.
- Never allow children to use this unit
- (IF PROVIDED) Brace yourself; gun may recoil when triggered.
If high pressure fluid pierces your skin, the injury might look like “just a cut”, but it is a serious wound!
Get immediate medical attention.
It is obligatory to wear suitable clothing as gloves, goggles and face shield.
Wear clothing that complies with the safety standards in force in the country in which the equipment is used.
Do not wear bracelets, earrings, rings, chains, or anything else that may hinder the operator’s work.
Do not wear clothing with wide sleeves, scarves, ties, or any other piece of clothing that could get tangled up in moving parts of the
equipment during the work, inspection, or maintenance cycles.
B
Fig. 1B
www.larius.com
5
GHIBLI 10:1 PNEUMATIC WASHING PUMP
REV. 02 - 06/2021 - Cod. 150186
WORKING PRINCIPLE
GHIBLI 10:1 PNEUMATIC WASHING PUMP is a low and medium
pressure pneumatic pump for professional use to be used for
cleaning with water.
GHIBLI pump is essentially constituted of an air motor and a
structure called «pumping group» .
In the pneumatic motor, compressed air causes the vertical
reciprocating movement of the motor piston; this movement is
transmitted through a connecting rod to the material pumping
piston which allows to suck water.
The ratio 10:1 means that the outlet pressure of water is 10 times
higher than the pump feed air pressure.
Pump feed air intel
Connection for nozzle
water outlet
Water inlet
