Lark SKIMMERPLUS SFX330 User manual

Sold & Distributed by Lark Outdoors, Austin, TX USA. Assembly & Service by Polygroup Trading Limited Unit 606, 6th Floor, Fairmont House, No.8 Cotton Tree Drive, Central, Hong Kong.
If you need help or encounter any problems, please call us at [phone], between 8am - 5pm MST (extended operating hours may be available during holiday and peak seasons).
© 2020
®OWNER’S MANUAL
SKIMMERPLUS®
FILTER PUMP
FOR ABOVE GROUND SWIMMING POOLS
SFX330 Model
Thank you for your Lark Outdoors purchase! Should you encounter any problems, please DO NOT return the product to your place of purchase.
For assitance with product setup, parts or troubleshooting, please visit support.polygroupstore.com, or call our customer service team at [phone].
All warranty claims and parts requests must be made directly to our service & support partner, Polygroup. Depending on the nature of the concern, you may
be asked to return all or part of the product for inspection or repair. Making it right is our top priority!
READ AND KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
For answers to common questions, setup videos and troubleshooting tips,
please visit our support center at: support.polygroupstore.com,
or call Customer Service at: [phone]
To order parts, accessories,
and to learn more about our
products, please visit:
www.larkoutdoors.com
DO NOT RETURN PRODUCT TO STORE

Polygroup®Trading Limited (hereinafter “Polygroup®”) makes products at the best quality we are able to offer. All Polygroup®products
have been inspected against defects in materials and workmanship prior to leaving factory. Polygroup®is happy to offer warranty for the
repair or replacement of pool products for 180 days from the date of purchase. The provisions of this Limited Warranty only apply to the
original purchaser. Please keep your original store sales receipt, as this proof of purchase will be required and must accompany warranty
claims to Polygroup®or its designated agents. This Limited Warranty does not apply without proof of purchase; or should the purchaser
modify or repair the product themselves or by unauthorized people; use non-Polygroup®parts or accessories with the product; use the
product in contravention of the manufacturer’s instructions; use improper voltage; abuse the product in any way; or through accident or
negligence. This Limited Warranty will not cover consequential damages, including claims for loss of water, pool chemicals, damage, or
labor, normal wear-and-tear; nor acts of God outside the control of Polygroup®. Non-manufacturing defects, such as grasses that may
grow through the ground cloth and/or pool liner are examples of which Polygoup®cannot be held responsible for.
IN NO EVENT SHALL Polygroup®, ITS AUTHORIZED AGENTS, RELATED ENTITIES, OR EMPLOYEES BE LIABLE TO THE BUYER
OR ANY OTHER PARTY FOR DIRECT OR CONSEQUENTIAL DAMAGES. Some states or countries, or other jurisdictions, do not allow
the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
This Limited Warranty is not extended to close-outs, factory seconds, or resold products (i.e. garage sales, online auctions, or online
retailers unaffiliated with Lark Outdoors or Polygroup®). Any issues with items purchased from these types of vendors / sellers will need to
be addressed through these stores. Items purchased from seasonal stores will be treated with an “All Sales Final” Policy instead.
Limited Warranty
2
®
Warnings
Preliminary steps, Important notes & Pump power info
Parts list
Setup instructions & Use of pump
Pump motor care & maintenance
Filter cartridge use & care
Pool water care
Pump disassembly & storage
Pump servicing instructions
Troubleshooting guide
Replacement parts ordering info
3 ~ 6
7
7 ~ 8
9 ~ 10
11
11
12
12
13 ~ 16
17
18
TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS
When installing and using this electrical equipment, basic safety precautions should always be followed, including the following:
READ AND FOLLOW ALL INSTRUCTIONS
Keep for future reference. Failure to follow these warnings and instructions can result in serious injury or death to users, especially children.
NOTICE: CUSTOMERS WHO PURCHASE POOLS MAY BE REQUIRED BY LOCAL OR STATE LAW TO INCUR ADDITIONAL EXPENSES WHEN INSTALLING A POOL,
IN ORDER TO COMPLY WITH STATE OR LOCAL LAWS REGARDING FENCING AND OTHER SAFETY REQUIREMENTS. CUSTOMERS SHOULD CONTACT THEIR LOCAL
BUILDING CODE ENFORCEMENT OFFICE FOR FURTHER DETAILS. POLYGROUP®IS NOT RESPONSIBLE FOR ANY ADDITIONAL EXPENSES THAT YOU MAY INCUR.
WARNING
DO NOT SIT ON
OR LAY OVER
POOL WALL
YOU CAN BE PERMANENTLY
INJURED.
WARNING
AVOID ENTRAPMENT!
STAY AWAY FROM DRAINS & SUCTION
FITTINGS. YOUR HAIR, BODY & JEWELRY
CAN GET SUCKED INTO THE DRAIN. YOU
COULD BE HELD UNDER WATER & DROWN. DO
NOTUSE POOL IF DRAIN OR SUCTION OUTLET
COVER IS MISSING OR BROKEN.
DANGER
PREVENT DROWNING!
WATCH CHILDREN WHO ARE IN OR
NEAR THIS POOL CLOSELY. CHILDREN
UNDER 5 ARE AT HIGHEST RISK OR
DROWNING. EMPTY POOL OR PREVENT
ACCESS WHEN NOT IN USE.
NO DIVING!
SHALLOW WATER
YOU CAN BREAK
YOUR NECK AND BE
PARALYSED.
Safety Care for Children
1. Children, especially children younger than five years, are at high risk of drowning. Drowning occurs silently and quickly and can occur in as little as 2 in (5 cm) of water.
2. Keep children in your direct sight, stay close, and actively supervise them when they are in or near this pool and when you are filling and emptying this pool.
3. When searching for a missing child, check the pool first, even if the child is thought to be in the house.
4. Locate pumps and filters in such a way that children cannot climb on them and gain access to the pool.
5. WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times.
Swimming Pool Barriers
Very Important:
Swimming pool barriers, which restrict access to the pool by small children, may be required by law. A barrier is necessary to provide protection against potential
drowning and near drowning. Barriers are not a substitute for constant supervision of children. Check state or local laws and codes before setting up the pool.
Swimming Pool Equipment
1. The use of artificial pool lighting is at the discretion of the pool owner. Lighting, when installed, should be in accordance with Article 680 of the National Electrical
Code (NEC
®
) or its latest approved edition and in consultation with a licensed electrical professional.
2. Keep all electrical lines, radios, speakers, and other electrical appliances away from the pool.
3. Do not place the pool near or under overhead electrical lines.
4. All electrical components installed in and/or adjacent to an above-ground/on-ground residential swimming pool shall be installed in accordance with and shall comply
with the requirements of the latest published edition of NFPA 70, National Electrical Code (NEC®) Article 680 "Swimming Pools, Fountains, and Similar Installations",
and any state or local code.
Filter Pump Awareness
1. WARNING: Risk of electric shock. Connect only to a grounding type receptacle. This product is provided with a ground-fault circuit-interrupter. If replacement of
the plug or cord is needed, use only identical replacement parts.
2. WARNING: To reduce the risk of electric shock, replace damaged cord immediately.
3. WARNING: To reduce the risk of electric shock, do not use the extension cord to connect the unit to the electric supply; provide a properly located outlet.
4. CAUTION: To reduce the risk of electric shock, the pool must be installed no closer than 6 feet (1.83 m) from any electrical outlet. Do not place portable appliances
closer than 5 feet (1.5 m) to the pool.
5. CAUTION: This pump is for use with storable pools only. Do not use with permanently-installed pools. A storable pool is constructed so that it is capable of being
readily disassembled for storage and reassembled to its original integrity. A permanently-installed pool is constructed in or on the ground or in a building such that
it cannot be readily disassembled for storage.
3
OWNER’S MANUAL

6. CAUTION: For continued protection against possible electric shock, this unit is to be mounted to the base in accordance with the installation instructions.
7. Do not bury the cord. Locate cord to minimize abuse from lawn mowers, hedge trimmers, and other equipment.
8. The unit is provided with a ground-fault circuit-interrupter (GFCI). To test the GFCI, push the test button. The GFCI should interrupt power. Push the reset button.
Power should be restored. If the GFCI fails to operate in this manner, the GFCI is defective. If the GFCI interrupts power to the pump without the test button being
pushed, a ground current is flowing, indicating the possibility of an electric shock. Do not use this pump. Disconnect the pump, and have the problem corrected by
a qualified service representative before using.
9. The Filter Pump is to be assembled by an adult; care should be taken in the unpacking and assembling of the Filter Pump. This pool may contain accessible
potentially hazardous sharp edges or sharp points that are a necessary part of the function of the Filter Pump.
10. If a drain or suction outlet cover is missing or broken, do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, evisceration,
or drowning. Repair or replace the drain or suction outlet cover before allowing the pool to be used. During nighttime pool use, artificial lighting shall be used to
illuminate all safety signs, ladders, steps, deck surfaces, and walks.
11. The floor of the pool shall be visible at all times from the outside perimeter of the pool.
12. Post a list of emergency telephone numbers such as the nearest available police, fire, ambulance, and/or rescue unit. These numbers are to be kept near the
telephone that is closest to the pool.
13. Basic lifesaving equipment, including one of the following should be on hand at all times:
• A light, strong, rigid pole (shepherd's crook) not less than twelve feet (12’) [366 cm] long.
• A minimum one-fourth inch (¼”) [6.35 mm] diameter rope as long as one and one half (1 ½) times the maximum width of the pool or fifty feet (50’) [15.24 meters],
whichever is less, which has been firmly attached to a Coast Guard-approved ring buoy having an outside diameter of approximately fifteen inches (15”) [38.1 cm],
or similarly approved flotation device.
14. Pool shall be located at a minimum distance of 6 ft (1.83 m) from any receptacle, and all 125-volt 15- and 20-ampere receptacles located within 20 ft (6.0 m) of
the pool shall be protected by a ground fault circuit interrupter (GFCI), where distances are by measuring the shortest path the supply cord of an appliance
connected to the receptacle would follow, without piercing a floor, wall, ceiling, doorway with hinged or sliding door, window opening, or other effective permanent
barrier, to the inside pool wall.
Circulation Systems
1. The installer shall follow written instructions regarding positioning of all equipment connected to the circulation systems.
2. The installer shall follow written instructions provided for operating the circulation system components.
3. All circulation system components and pump that require replacement or servicing shall be installed according to the pump’s instruction manual.
4. Circulation equipment shall be installed per manufacturer’s instructions to provide proper mounting and support, to prevent damage from misalignment, settlement,
and vibration, and to minimize the potential for the accumulation of debris and moisture. Please refer to pump’s instruction manual.
Chemicals
For safety sake, ensure the deepest part of the pool is always visible. The user must properly maintain the clarity of the pool water at all times. Check the pH and
chlorine levels periodically and make sure they are within the recommended limits. Additional water treatment chemicals might be needed from time to time. Have
the water sample tested by a local pool supply store to determine if additional chemical is needed. Turn on the pump for the recommended hours daily. If you are
unsure of the time frames please refer to support.polygroupstore.com for the recommended Pump Operation Hours based on pool types and sizes. Clean and
replace filter cartridge frequently. Replace only with a genuine Polygroup®/ Summer Waves®Brand filter cartridge. Refer to the Filter Pump manual for additional
water care information.
Risk of Entrapment
1. Entrapment Avoidance: There shall be no protrusions or other obstruction in the swimming area, which may cause entrapment or entanglement of the user. If
a suction outlet cover is missing or broken, do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, evisceration, or drowning.
Repair or replace the suction outlet cover before allowing the pool to be used.
2. DANGER! TO AVOID SERIOUS INJURY OR DEATH, CLOSE THE POOL OR SPA TO BATHERS IF ANY SUCTION OUTLET COVER/GRATE IS MISSING,
BROKEN, OR INOPERATIVE.
3. Never play or swim near drains or suction fittings. Your body or hair may be trapped causing permanent injury or drowning.
4. Never enter the pool or spa if a suction fitting or drain cover is loose, broken, or missing.
5. Immediately notify the pool/spa owner or operator if you find a drain cover loose, broken, or missing.
Risk of Drowning
1. Keep unsupervised children from accessing the pool by installing fencing or other approved barriers around all sides of pool. State or local laws or codes may
require fencing or other approved barriers. Check state or local laws and codes before setting up the pool.
2. Toys, chairs, tables, or similar objects that a young child could climb shall be at least four feet (4’) [121.92 cm] from the pool. The pump filter system shall be positioned
so as to prevent it being used as a means of access to the pool by young children. Do not leave toys inside pool when no longer in use, as toys and similar items
might attract a child to the pool.
3. Position furniture (for example: tables, chairs) away from pool and so that children cannot climb on it to gain access to the pool.
Risk of Electrocution
1. Keep all electrical lines, radios, speakers, and other electrical appliances away from the pool.
2. Do not place the pool near or under overhead electrical lines.
4
®

First Aid
1. Keep a working phone and a list of emergency numbers near the pool.
2. Become certified in cardiopulmonary resuscitation (CPR). In the event of an emergency, immediate use of CPR can make a lifesaving difference.
Special Warning
1. Local building codes may require obtaining a building or electrical permit. Installer shall follow regulations on setback, barriers, devices, and other conditions.
2. Safety signs shall comply with requirements of ANSI-Z535 and use signal wording.
3. DO NOT attempt to assemble this pool in adverse weather conditions, windy conditions, or when the temperature is below 60°F.
4. This is a storable filter pump, which should be disassembled and stored when temperatures are expected to fall below 32°F.
Extra Safety Warning
1. Adult supervision is always required.
2. Parents should learn CPR.
3. Keep all electrical radios, speakers, and other appliances away from the swimming pool.
4. When you touch the filter, pump, or electrical parts, be sure the ground under your feet is “Bone Dry.”
5. All electrical outlets should have a GFCI, and connections should be a minimum of 6 feet (1.83 m) from the outside perimeter of the wall of the pool.
From 6–10 feet (1.83–3.05 m), there should be either a fixed connection (outlet box) or twistlock connection with a GFCI.
6. Connect power cords to a 3-wire grounding-type outlet only.
7. Keep all breakable objects out of the pool area.
8. Alcohol consumption and pool activities do not mix. Never allow anyone to swim, dive, or slide under the influence of alcohol or drugs.
9. Severe electrical shock could result if you install your pump or filter on a deck. The pump or filter could fall into the water, causing severe shock or electrocution.
10. Do not install on a deck or other surface at, above, or slightly below the top rail of the pool.
11. Do not use the filter pump during severe weather conditions, i.e. electrical storms, tornadoes, etc.
12. Be aware of overhead power lines when vacuuming your pool or using a telescoping pole.
13. Check regularly for signs of wear or loose bolts that could make the deck unsafe.
14. Please contact pool site dealer or manufacturer for additional safety signs if deemed necessary.
15. For pool service, select a certified pool professional. For additional safety information, see www.APSP.org
Consumer Awareness Booklets and Information Source
Contact: U.S. Consumer Product Safety Commission at www.cpsc.gov/safety-education/safety-guides/pools-and-spas, Pub. #362 “Safety Barrier Guidelines for Home Pools.”
1. The Sensible Way to Enjoy Your Above-ground/On-ground Swimming Pool.
2. Children Aren’t Waterproof.
3. Layers of Protection.
4. Pool and Spa Emergency Procedures for Infants and Children.
5. Be Safety Aware.
Copies of the above brochures are available free from the APSP at www.APSP.org
Safety Education Programs and Materials
Educational programs and materials (i.e., seminars, workshops, brochures, videos, instructional guides) are available from the APSP, other aquatic safety groups,
and from private firms. As a means of communicating useful safety information to pool owners/operators, and users, industry members are permitted to provide such
information to owners/operators and to request or require owners/operators to sign a statement that they have received, read, and will follow the guidelines.
Other sources of safety information:
• www.cdc.gov
• www.cpsc.gov
• www.drowningpreventionalliance.com
• www.nspf.org
• www.safekids.org
ANSI American National Standards Institute
25 West 43rd Street, New York NY 10036
Contact: 212-642-4900
www.ansi.org
APSP Association of Pool & Spa Professionals
(formerly National Spa and Pool Institute)
2111 Eisenhower Avenue, Suite 500
Alexandria VA 22314-4679
Contact: 703-838-0083
www.apsp.org
5
OWNER’S MANUAL

SAVE THESE INSTRUCTIONS
ASME American Society of Mechanical Engineers
Two Park Avenue, New York NY 10016-5990
Contact: 800-843-2763 (U.S. & Canada) 973-882-1170 (outside North America)
www.asme.org
NSPI National Spa and Pool Institute (see APSP)
UL Underwriters Laboratories
333 Pfingsten Road,Northbrook IL 60062-2096
Contact: 877-854-3577 or 847-272-8800
www.ul.com
NSF NSF International
P.O. Box 130140
789 N. Dixboro Road
Ann Arbor MI 48105
Contact: 800-673-6275 or 734-769-8010
www.nsf.org
ASTM ASTM International (formerly American Society of Testing & Materials)
100 Barr Harbor Drive, P.O. BOX C700
West Conshohocken, PA 19428-2959
Contact: 877-909-2786 (USA & Canada) or 610-832-9585 (International)
www.astm.org
NEC National Electrical Code (see NFPA)
NFPA National Fire Protection Association
1 Batterymarch Park, Quincy MA 02169-7471
Contact: 800-344-3555 (U.S. & Canada) or 617-770-3000 (International)
www.nfpa.org
Filtration Systems
Any equipment connected to the circulation systems shall be positioned so as to prevent their being used as a means of access to the pool by young children. (See
the latest published edition of ANSI/APSP-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
Barriers
Barriers are necessary to provide protection against potential drowning and near drowning, and barriers are not a substitute for the constant supervision of children.
(See latest published edition of ANSI/APSP-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
Risk of Drowning, Entrapment, and Diving Accidents
Publications are available that describe the risk of drowning, entrapment, and diving accidents. Available publications related to pool safety include the Association
of Pool and Spa Professionals’ (APSP) booklets entitled: The Sensible Way to Enjoy Your Above-ground/On-ground Swimming Pool, Children Aren’t Waterproof,
Pool and Spa Emergency Procedures for Infants and Children, Layers of Protection, and the latest published edition of ANSI/APSP-8 Model Barrier Code for
Residential Swimming Pools, Spas, and Hot Tubs.
Installer Responsibilities
All of these components shall be positioned so as to prevent their being used as a means of access to the pool by young children.
(See Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
6
®

7
OWNER’S MANUAL
Model
SFX330
Wattage
30 Watts
Amperage
0.5 Amps
FILTER PUMP POWER INFO
PARTS LIST
Qty. Qty.
1
1
1
1
1
1
1
1
1
2
2
1
1
Parts Name
Motor Seal Nut
Rubber Nozzle
Pump Motor Assembly
Canister Gasket / Motor Seal
Top Cover
Weir Foam
Filter Cartridge
Weir
Skimmer Canister
Hose Connection O-Ring
Hose Clamp
Return Hose
90° Elbow
1
1
1
1
1
1
1
1
1
1
1
1
1
RF Nut
RF Thrust Washer
Pool Wall (for reference only)
RF Gasket (black)
Return Fitting (RF), threaded
RF Diverter
RF Locking Ring, threaded
Service Plug
Skimmer Seal Ring
Water Stopper
SFX Skimmer Strainer Basket
Skimmer Gasket Rubber Seal
GFCI Power Cord Set
Item Item Parts Name
1
2
3
4
5
6
7
8
9
1. The installer shall follow the written instructions provided for the operation of the filter pump system.
2. All electrical components shall be installed in accordance with Article 680 of the 2017 National Electrical Code®(NEC®) or its latest approved edition.
3. This Filter Pump is manufactured by Polygroup®and ETL control number 4000608 and 4006317 – double insulated and grounded – 120VAC 60Hz. All units must
have a minimum of 105VAC to start and run properly.
PRELIMINARY STEPS
FILTER PUMP IMPORTANT NOTES
1. READ ALL INSTRUCTIONS CAREFULLY and get a thorough understanding of what is required to assemble your Filter Pump.
2. It is recommended to have some petroleum jelly (not included) on hand for lubricating the gaskets and o-rings.

8
®
6
9
5
3
4
2
1
8
7
Outside Pool Wall
Inside Pool Wall

9
OWNER’S MANUAL
SETUP INSTRUCTIONS
Skimmer Installation
1. Set up your pool following the pool Owner’s Manual instructions. Do NOT fill
water until the Filter Pump is properly installed. Locate the Skimmer Opening
on the pool wall.
Return Fitting Installation
5. Assemble the Return Fitting
o
as indicated below.
3. Turn counterclockwise to remove the Skimmer Seal Ring
d
. Make sure
that the Skimmer Gasket Rubber Seal
h
is in the correct position.
6. Now the Pump should be installed outside the pool wall as below.
2. Slide open the Top Cover
5
and take out the parts inside.
WARNING: CLIMBING HAZARD! PLEASE PREVENT CHILDREN FROM CLIMBING ON THE FILTER CANISTER TO GAIN ACCESS TO THE POOL.
Before assembly, take a few minutes to identify and become familiar with all the parts.
No gap here
Pool Inlet
Skimmer Opening
Inside Pool Wall
Inside Pool Wall Inside Pool Wall
Outside Pool Wall
5
The protruding edge of the
Skimmer Canister
9
fits
in-between the two keys of
the Gasket
h
.
thread slots
4. Insert the threaded part of the Skimmer Canister
9
through the Skimmer
Opening, and then secure with the Skimmer Seal Ring
d
.
Make sure that the pool liner is
placed tight on the Gasket
h
and is NOT trapped in the threads;
otherwise leaks may occur.
Make sure the Hose Clamps
w
seals tightly over both
the Return Hose
e
and
O-Rings
q
.
To optimize water circulation,
twist the RF Diverter
p
so
that it faces up and away
from the Skimmer Opening.

10
®
IMPORTANT: Do NOT connect to a timer device!
USE OF PUMP
9. You can now fill the pool with water up to between the MIN and MAX markings on the inside of Skimmer Seal Ring
d
.
Pump Installation
7. From inside the Skimmer Canister
9
, snap the pins of the Weir
8
into
the pivot slots, one after another. The Weir should now stand upright but
not stuck.
8. Slide close the Top Cover
5
onto the Skimmer Canister
9
.
5
9
Inside Pool Wall
Weir installation
finished.
a) Insert one Weir
pin into one hole.
b) Push to secure
the connection.
c) Repeat for another pin.
Push here
Push-in
Max. Level
Min. Level
The water level should be
between the min and max
markers located inside the
Skimmer Seal Ring.
Inside Pool Wall
Press
"RESET"
Button
To Start
Pump
Operation
How to use the GFCI plug
*Do not connect
to a timer device
1. Plug the GFCI Power Cord Set
j
to a grounded receptacle at least 15 feet (4.5m) away from the pool.
2. To turn on the Pump, press the RESET button of the GFCI Plug.
3. From inside the pool, check if the water flow from the RF Diverter
p
is correct. It should feel like a solid stream of water
returning to the pool. If not, or if you feel a reduction in flow, clean or replace the Filter Cartridge
7
. For details, see
FILTER CARTRIDGE USE & CARE (p. 11) as well as Symptom 2 of TROUBLESHOOTING GUIDE (p. 17).
4. To turn the Pump off, press the TEST button of the GFCI Plug, and unplug it from the power outlet.
5. VERY IMPORTANT: Check and adjust the pH and chlorine levels daily. FILTER PUMP ALONE
WILL NOT PREVENT ALGAE FROM GROWING IN POOL WATER; THIS CAN ONLY BE DONE
BY MAINTAINING PROPER CHLORINE AND pH LEVELS AT ALL TIMES. For details,
see POOL WATER CARE (p. 12).

11
OWNER’S MANUAL
PUMP MOTOR CARE
FILTER CARTRIDGE USE & CARE
24
7
5
1. To clean the Filter Cartridge
7
:
a. Turn off and unplug the Pump. Slide open the Top Cover
5
, and take out the Strainer Basket
g
and Filter Cartridge.
b. Pressure wash the Cartridge thoroughly (including between the
pleats) with a garden hose to remove larger debris. Then allow
the Cartridge to dry, and carefully brush away smaller and fine
particles of dirt. Do NOT scrub the pleats, or the Cartridge will
wear out faster than it should.
c. To ensure pool water stays clean,please clean the filter
cartridge every day and change when required.
d. Reassemble the parts in reverse order. Then you can restart the Pump.
2. You may need to clean or replace the Filter Cartridge when it’s dirty, or before the correct chlorine and
pH levels are attained. Therefore, it’s recommended to keep at least one spare cartridge on hand at all
times. A clean, well-maintained cartridge assures that your pump will always be ready to operate at
peak efficiency.
3. Suntan oils, body oils and algae can quickly build up and clog the pleats of the Cartridge, reducing the
filtration efficiency. Therefore, it is imperative to remove such films of oils and/or algae.
To remove oils: mix 1 pound of tri-sodium phosphate (TSP, or any other strong detergent) and 5 gallons
of water, and soak the Cartridge for 12 hours.
To remove oils AND algae: same as above, and add ½ pint of pool chlorine or 1 pint of liquid household
bleach to the solution ONE HOUR BEFORE removing the Cartridge from the solution.
Thoroughly rinse the Cartridge before reusing it.
4. Excessive calcium and/or mineral deposits may also build up in the Cartridge, and it requires to be handled
differently. Contact and consult your local pool supplies store for solutions/treatment, and maintain an
adequate pH level of pool water (see POOL WATER CARE, p. 12).
5. Dispose of any used filter media in accordance with applicable regulations/legislation.
6. Always use genuine Polygroup®Summer Waves®Filter Cartridges; they are available at where you
purchased your pool or from polygroupstore.com
1. Check the pump output daily. If water flow reduces, see Symptom 2 of TROUBLESHOOTING GUIDE (p. 17).
2. Check the Pump, Hoses and Fittings for leaks. If a leak is found, see Symptom 4 of TROUBLESHOOTING GUIDE.
3. It’s essential to replace any damaged parts as soon as possible. Use only spare parts from approved, reliable dealers, or from
polygroupstore.com
4. Inspect the filter and all filter media regularly to ensure that there’s no build-up of detritus that prevents good filtration. See FILTER CARTRIDGE
USE & CARE below.
5. Run the Pump for the recommended number of hours daily. If you are unsure of the time frame, please see Pump Operation Hours at
support.polygroupstore.com
PUMP MAINTENANCE
IMPORTANT! This Skimmer Filter Pump is protected by a thermal switch, a safety device that stops the pump from running when it's overheated, to
prevent pump damage and prolong service life. If your pump turns off automatically, it’s likely the pool water temperature is too high or the water flow
through the pump is insufficient for cooling the pump down. Check and correct the water flow, make sure motor rest 15 minutes at least and then
restart the pump by pressing the RESET button of the GFCI Plug, or run the pump at night when the temperature is lower. If pump turns off
automatically again, insepct your pump rotor block by dirt.

12
®
POOL WATER CARE
PUMP DISASSEMBLY & STORAGE
1. Turn off the Pump, and unplug it from the power outlet.
2. Slide open the Skimmer Top Cover
5
, remove the Strainer Basket
g
, Filter Cartridge
7
and the Weir
8
.
3. Turn counterclockwise the Skimmer Seal Ring
d
to remove the Skimmer Canister
9
from the pool. Clean and dry parts
5
-
9
and
g
, and reassemble them
back into the Canister in reverse order.
4. Loosen all the Hose Clamps
w
, remove the Hose
e
, and drain any remaining water.
5. Remove and clean the return fittings
r
-
p
. Lubricate the RF Gasket
i
with petroleum jelly. Then snap all the parts together in sequence.
6. Turn clockwise to remove the Motor Seal Nut
1
and take out the Pump Motor Assembly
3
. Clean and dry completely the Pump. Then see STEP 3: Pump
Replacement/Reassembly (p. 15) to reassemble the Motor into the Canister.
7. Store all the parts in a dry place that remains above 32°F (0°C) at all times.
1. The following items are required to get your pool ready for use. They are available at polygroupstore.com or your local pool supplies stores:
a. Test kit – for checking the chlorine and pH levels of the pool water
b. Floating chlorine dispenser (not included) and chlorine tablet – for water disinfection and prevention of the growth of algae
c. pH control chemicals – for adjusting the pH level up (soda ash) or down (acid)
d. Algaecides – to eliminate algae
e. Superchlorinator – to destroy (“shock”) the combined chlorine, ammonia, nitrogen, and organic compounds that build up in pool water over time and with
extended use
f. Leaf net with handle – for removing leaves, trash, insects, etc. from the pool
2. IMPORTANT: it is a MUST to maintain the chlorine and pH levels at all times:
a. Check and adjust the pH and chlorine levels daily. FILTER PUMP ALONE WILL NOT PREVENT ALGAE FROM GROWING IN POOL WATER; THIS CAN ONLY
BE DONE BY MAINTAINING PROPER CHLORINE AND pH LEVELS AT ALL TIMES.
b. Recommended pH level: between 7.3 and 7.8
c. Recommended chlorine level: between 1.0 and 1.6 ppm
d. Superchlorinate your pool at least every other week.
e. Hot weather and heavy use may require the pH and chlorine levels to be maintained on the upper side of the scale as well as a weekly superchlorination.
f. Using a pool and/or solar cover will help maintain the pH and chlorine levels by reducing evaporation of pool water.
g. CAUTION: High chlorine concentration and low pH level will damage the pool/pool liner. You must follow the instructions on quantity and safe usage
of the pool chemicals you use.
NEVER drop lumps or pellets of chemicals into the pool – this may present a hazard to the swimmers and/or damage your pool liner.
3. Clean your pool regularly using a maintenance kit with vacuum. You can get the kit from polygroupstore.com
4. Using a foot bath prior to entering the pool will help keep the pool clean.
5. Avoid using well water. If you must use well water, always seek professional advice from your local pool chemical suppliers before chemicals into it.
6. Find out the water capacity (in gallon) of your pool from the pool Owner’s Manual. You will need it to determine the amount of chemicals required, or when you
contact a pool supplies expert for water testing and advice on safe use of chemicals.
NOTE: Always follow the manufacturer label directions of the chemicals you choose to use.

13
OWNER’S MANUAL
PUMP SERVICING INSTRUCTIONS
The most efficient way to troubleshoot or replace the Pump is to disassemble the entire filtration system. Please drain the water level to below the pool’s Skimmer
Opening, then disassemble the system following the steps below.
CAUTION:
1. You may get wet.
2. Please read and follow the instructions carefully. Incorrect handling may cause damages resulting in leaks between the Skimmer Canister
9
and the pool wall.
3. REMEMBER TO KEEP ALL THE PARTS IN A SAFE PLACE FOR REASSEMBLY LATER.
STEP 1: Removal of Motor Assembly 3
1. Turn the Pump off, and unplug it from the power outlet.
2. Slide open the Skimmer Top Cover 5, remove the Strainer Basket and the Filter Cartridge.
3. At the Return Fitting o:
a. Unscrew and remove the RF Locking Ring and RF Diverter. Then insert the Service Plug to block the water flow.
b. Loosen the Hose Clamp attaching to the 90° Elbow r. Carefully detach the Hose, and let the water drain from the Hose and the Canister.
NOTE: you may also detach the other end of Hose attaching to the Canister, but it is not required.
4. Unscrew the Skimmer Seal Ring dto remove the entire filtration system from the pool.
5. Flip the Canister upside down. Unscrew the Motor Seal Nut 1and take out the Motor Assembly.
IF YOU PREFER TO LEAVE THE SYSTEM ATTACHED TO THE POOL, please follow the process
below instead.
CAUTION: you will need two people for some of the steps. Incorrect handling may cause damages resulting in leaks between the Skimmer Canister
9
and
the pool wall.
3. Put a water container (not included) under the Skimmer to collect water.
Slide open the Top Cover
5
, and take out the Strainer Basket
g
and
Filter Cartridge
7
.
4. Have one person holding the Water Stopper and Skimmer Canister
9
,
while the other person unscrews the Motor Seal Nut
1
.
CAUTION: DO NOT PUSH OR PULL THE CANISTER as this may cause
damage between the Canister and pool liner.
1. Turn the Pump off, then unplug it from the power outlet.
2. Block the water flow:
a. Unscrew and remove the RF Locking Ring
a
and RF Diverter
p
.
Then insert the Service Plug
s
to block the water flow.
b. Push the Water Stopper
f
tightly into the Skimmer Seal Ring
d
.
9
1

14
®
5. Slowly take out the Motor Assembly
3
. Be careful not to lose the
Rubber Nozzle
2
or Canister Gasket
4
.
2
Rotor Assembly Parts
Shaft End Cap
Washer
Impeller
Magnet Axle
Rotor Shaft
(This shaft should go through
all the parts and into both
Shaft End Caps)
Washer
Shaft End Cap
You may need to reach inside the
Canister to free the Pump Motor.
2
3
4
30
28
29
27
STEP 2: Rotor Inspection/Replacement
The Pump
3
is consisted of a Rotor Assembly
k
and its related parts. If the Rotor and/or its parts is/are broken, or the Rotor, even in perfect condition, is not
seated in place between the Volute Cover
l
and Pump Body
z
, the Pump will not function properly.
1. Loosen the Volute Cover Screws
;
, and remove the Volute Cover
l
.
2. Pull the Rotor Assembly
k
out from the Pump Body
z
.
Inspect the Rotor (see image below) to make sure that the Rotor Shaft, Magnet Axle, Impeller and other parts are intact. If either of them is broken, you can
purchase a new Rotor Assembly at polygroupstore.com without having to replace the whole Pump.
For more details, please see Pool Support – Filtration System Troubleshooting at support.polygroupstore.com
3. Once the inspection or replacement is done, carefully insert the Rotor Assembly
k
back into the Pump Body
z
The force of the magnet will pull the Rotor
down in place.
4. Align the Volute Cover
l
with the top Shaft End Cap, then tighten with the Volute Cover Screws
;
.
5. Attach the Rubber Nozzle
2
to the outlet of the Pump Body
z
.

15
OWNER’S MANUAL
TOP VIEW
Make sure arcs
are aligned.
Outlet of Canister and
Rubber Nozzle
2
on the
pump should be aligned.
4
9
STEP 3: Pump Replacement/Reassembly
1. Lubricate the Canister Gasket
4
. Turn the Skimmer Canister
9
upside
down, place the Gasket into the inner groove at the bottom.
2a. If your Pump is removed from the pool, slowly insert the Motor Assembly
back into the upside-down Canister. There's a rib on the inside of
Canister (only visible from bottom), which needs to be aligned with an
indent at the bottom of the Motor.
2b. If your Pump is left attached to the pool, reach in through the Canister to
pull the Motor Assembly up and insert it back into the Canister. Make sure
to align the Rubber Nozzle
2
with the hose opening of the Canister,
otherwise the Pump may leak even already locked in place.
IMPORTANT: make sure that the cord of the
Motor Assembly
3
is placed through the Motor
Seal Nut
1
BEFORE replacing the Pump.
Close Up
BOTTOM VIEW OF PUMP & CANISTER
1
2
3
4

16
®
1
3. Once the Motor is correctly aligned, match the threads of the Motor Seal
Nut
1
to that of the Canister, and tighten by twisting the Nut counterclockwise.
IMPORTANT: make sure the Nut and Canister are not cross-threaded;
otherwise leaks may occur.

17
OWNER’S MANUAL
TROUBLESHOOTING GUIDE
Problem Cause Solution
2. No or slow water
flow from the Return
Fitting
o
3. Pump is not cleaning
the pool properly e.g.
cloudy/green water
4. Water leakage at
1. Motor 3doesn’t start,
or kicks on and off
A Plug the GFCI Power Cord Set
j
to a grounded power outlet. Then press the RESET
button to start the Pump.
B Reset your circuit breaker on the electrical panel. If problem persists, have the circuit checked
by a qualified electrician.
C Check and make sure the line voltage is between 105V and 125V.
A Water level must be between the MIN and MAX lines on the Skimmer Seal Ring
d
.
B GFCI Power Cord Set
j
and/or circuit breaker tripped
C Low voltage
A Low pool water level
D Refer to pump servicing instructions to clean dirt.
D Motor Rotor block by dirt
B Check for obstructions at the Strainer Basket
g
, Filter Cartridge
7
, Hose
e
or Return
Fitting
o
.
C Clean or replace the Cartridge following the steps of FILTER CARTRIDGE USE & CARE (p. 11).
A Maintain the chlorine level between 1.0 and 1.6 ppm.
B Clogged water inlet/outlet
C The Filter Cartridge
7
is too dirty
A Pump not plugged in
A Inadequate chlorine level
B Maintain the pH level between 7.3 and 7.8
B Inadequate pH level
C Clean or replace the Cartridge following the steps of FILTER CARTRIDGE USE & CARE (p. 11).
C The Filter Cartridge
7
is too dirty
D Inspect the Cartridge for holes or tears. If it’s visibly damaged, replace it with a new one.
D The Filter Cartridge
7
is damaged
E Check for obstructions at the Strainer Basket
g
, Filter Cartridge
7
, Hose
e
or Return
Fitting
o
.
E Water flow is slow
F Have your pool water sample tested by a pool supplies store. You may need to add other
chemicals since water quality varies in different localities.
F Other chemicals required
G Chemicals are essential to keep the pool water clean. Clean the pool and filter more often.
G Pool water is too dirty
A Hose
e
connection points –
loose Hose Clamps
w
C See SETUP INSTRUCTIONS (3) & (4), p. 9 and make sure that:
C1 The two keys of the Gasket Rubber Seal
h
are at the top.
C2 The pool liner is not trapped in the threads.
C3 There is NO gap between the Gasket and the Canister.
C4 The Skimmer Seal Ring
d
is firmly tightened onto the Canister.
B See STEP 3: Pump Replace/Reassembly, p. 15-16:
B1 The Canister Gasket
4
must sit in the inner groove at the bottom of the Canister before
installing the pump.
B2 Check Pump alignment. The arrow of the Pump indent (marked "ALIGN") MUST point to
the Canister indent (only visible from bottom).
B3 Make sure that the Motor Seal Nut
1
is not cross-threaded.
B Bottom of Canister
9
– incorrect
installation/reassembly
C Between Canister
9
and pool
wall – incorrect installation
A Check that the Clamps are properly secured over both the Hose and the O-rings
q
; adjust
and retighten if necessary. Also, check the Hose for cracks or holes and replace as needed.

18
®
REPLACEMENT PARTS ORDERING INFORMATION
Key
Description Part #
Motor Seal Nut
Rubber Nozzle
Pump Motor Assembly
Canister Gasket / Motor Seal
Top Cover
Weir Foam
Filter Cartridge
Weir
Skimmer Canister
Hose Connection O-Ring
Hose Clamp
Return Hose
90° Elbow
RF Nut
RF Thrust Washer
Pool Wall (for reference only)
RF Gasket (black)
Return Fitting (RF), threaded
RF Diverter
RF Locking Ring, threaded
Service Plug
Skimmer Seal Ring
Water Stopper
SFX Skimmer Strainer Basket
Skimmer Gasket Rubber Seal
Rotor Assembly
Volute Cover
For SFX Series Filter Pump sold separately
P58PP4511W05
P58PP45118UN
P58PP45117CN
P58P4179AK01
P58X0330C000
P58105001K01
P58PP4509W05
P58PP45098UN
P58PP45097CN
P58SFX000W01
P581031035PR
P58PP1956W05
P58PP19568UN
P58PP19567CN
P58PP4510W05
P58PP45108UN
P58PP45107CN
P58030001K01
P58220221W05
P582202218UN
P582202217CN
P58125009W01
P58PF1740W05
P58PF17408UN
P58PF17407CN
P58PF1690W05
P58PF16908UN
P58PF16907CN
P58PF2960W05
P58PF29608UN
P58PF29607CN
- -
P58PF1730K01
P58PF1680W05
P58PF16808UN
P58PF16807CN
P58PF1721W05
P58PF17218UN
P58PF17217CN
P58PF1710W05
P58PF17108UN
P58PF17107CN
P58PF0620K01
P58PP1953W05
P58PP19538UN
P58PP19537CN
P58PP2163K01
P58PP4512P01
P58PP50400K1
P581160049B1
P58P4122AK01
P53FX0339W05
P53FX03398UN
P53FX03397CN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
27
28
*
