Replacement Sprayer Pump for IND-MD-DF-ESF-R1 Electrostatic Sprayer -
Sprayer Disassembly Required for Installation
Instruction Manual
Thankyou for your purchase of the Larson Electronics IND-MD-DF-ESF-R1-SP0009.
WARNING:
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CRITICAL SAFETY INSTRUCTIONS:
•INSTALLATION SHOULD ONLY BE CONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY
RELEVANT LOCAL BUILDING CODES.
•RISK OF FIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF LUMINAIRES ELECTRICAL
SYSTEMS. IF NOT QUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.
•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE RATED LUMINAIRE FIXTURES VOLTAGE.
•TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP
OBJECTS. SUITABLE FOR DAMP LOCATIONS.
•This sprayer should only be operated and maintained by someone who is familiar with it's operation and correct maintenance
practices as outlined in this manual.
•Larson Electronics is not liable for decreased reliability, damages, or injuries due to improper maintenance or modifications to the
sprayer.
•Do not use this sprayer in an explosive or flammable environment.
•Always keep the sprayer dry and clean. Do not submerge in water or use in overly wet location to protect the motor and
electronics from water damage.
•PLEASE NOTE: Disassembly of sprayers REQUIRED for battery replacement. Replacement batteries are for maintenance and
NOT for swapping while in the field to extend spray time.
oCAUTION: Battery contains high voltage and may cause electric shock.
Warnings and Safety
•Make sure unit is turned off. It is recommended to
wear rubber gloves while replacing battery to avoid
electric shock while replacing battery.
•Remove bottom panel of unit by laying unit on its side
and unscrewing the seven (7) screws on the bottom.
IND-MD-DF-ESF-R1-SP0009 is a Replacement Sprayer Pump for IND-MD-DF-ESF-R1 Electrostatic Sprayer. This
electric pump is installed in the base of the unit.
Replacement Instructions

IND-MD-DF-ESF-R1-SP0009
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 2of 3
•Carefully set bottom panel out of the way and gently
remove the hose and electrical connections from the
old pump. Make note of their locations and
orientations for replacement on the new pump.
•Unmount old pump via 4 mounting tabs at the base
and remove from sprayer.
•Replace old pump and follow the previous
instructions in reverse for installation making sure to
install the new pump in the same orientation and
reconnect the hoses and electrical connections as
they were previously.
•Align and screw in the bottom panel of the unit.
The sprayer is now ready for use.

IND-MD-DF-ESF-R1-SP0009
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 3of 3
USE AND CARE
Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.
Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of
children when not in use.Inspect for good working condition prior to storage and before re-use.
REPLACEMENT PARTS
The IND-MD-DF-ESF-R1-SP0009 is designed to provide years of reliable performance. Should the need for replacement
parts arise, please contact Larson Electronics.
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.
SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT
[e-mail] OR BY PHONE AT 1-800-369-6671 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
