Laser PW-BT50AR User manual

PW-BT50AR QUICK START GUIDE
WHAT’S IN THE BOX PRODUCT CONNECTION AND USE
PW-BT50AR, 1 x Quick Start Guide
CHARGING A CONNECTED DEVICE
- Plug your PW-BT50AR into your car DC power outlet.
- Connect your portable device to the charger using a USB cable.
- Charging will begin automatically
PAIRING VIA BLUETOOTH
- By default, when your PW-BT50AR is turned on, it will enter
Bluetooth pairing mode automatically.(The blue coloured LED
indicator will be flashing rapidly.)
- Turn the Bluetooth feature on, from yourportable device and
search for your PW-BRT50AR.
-When located, pair and connectto thedevice.
FM MUSIC TRANSMITTER
- Connect yourportable music device via Bluetooth (see above)
-Pressthe FMSWITCHbutton on your PW-BT50AR.You can select eitherFM
band 101 or107.9.
(Note: Tune into each frequency to see which band has the best reception)
-You cannow playback music via thepre-selected radio station frequencies.
HANDS FREE
-Once you have paired your deviceusingBluetooth and to a suitableFM
radio frequency, you can use your SPK-BT50AR as a hands-free speaker.
- Incoming calls can be answered by pressing the POWER button.
- To end a call, simply press the POWER buttonagain.
3.5MM AUDIO OUTPUT VIA YOUR PW-BT50AR
For older carradios which maynot be Bluetooth enabled, audio can bestreamed via Bluetooth from yourportable deviceto
your PW-BT50AR then connected to your car radio.Simply connect a3.5mm audio cable from yourPW-BT50AR,to your car
radio 3.5mm socket and select the suitable audio source input for music playback.

PW-BT50AR QUICK START GUIDE
BUTTON OPERATIONS
BUTTON
ACTION
DESCRIPTION
/ - Previous Track / Decrease Volume
Press to goto the previous track
Press and hold to reduce volume
+/ Increase Volume /Next Track
Press to goto the next track
Press and hold to increase volume
/
Play Pause / Power ON OFF
Press
to Pause
Press and hold to turn ON OFF
During a call;
Press to answer, or
Then Press to hang up
FM FM Transmitter
Transmits sound and voice calls from your
portabledevice to presetradio station
frequencies. (101 or 107.9FM)
LED INDICATORS
COLOUR
INDICATOR
STATU
S
Blue
Fast
Bluetooth pairing mode
Blue
Flash every 4 seconds
Bluetooth devicepaired
Blue
Constant
Music playback
/ Hands free in use
Blue
Slow flash 3 times
(Once)
Power off
Red
Constant
Connected device is charging
PRODUCT SPECIFICATION
FEATURE
SPECIFICATION
Bluetooth Version
V4.0
FMFrequency
101.0 and 107.9FM
Transmission range
Up to 10m
Input
DC 12
–
24V
USB Output
DC5V 1
-
2.1A (Auto
-
sensing)
Safety protection Over-charge, over-discharge and short-circuit protection
For furtherproductinformationand instruction pleasevisitourproduct
web page at www.laserco.netor email [e-mail]

PW-BT50AR QUICK START GUIDE
Please note: As continual improvements are made to this product, slightoperational differences may occur.
For the most up-to-date user manual, please visit our web site.
Warranty Against Defects
Laser CorporationPty Ltd (“Laser”) warrants your newproductto be free from defects in materials and workmanship for12 months, from thedate of
purchase, provided that theproduct is used in accordancewithaccompanyingrecommendationsorinstructionswhereprovided. The benefitof this
warranty is in addition to your rights under the Australian ConsumerLaw and to other rights and remediesof the consumer under alaw in relation to
thegoods or services to which the warrantyrelates. Througha network of retailersand resellers,Laser willprovideyou with your choice of a repair,
exchange (where possible) or refund (within Deadon Arrivalperiod) for thisproductif itbecomesdefectivewithin thewarrantyperiod.
Thiswarranty will no longerapply where the defect is aresultof alteration, accident, misuse, abuse, normalwear and tear, neglect orimproper storage.
Pleaseretain yourreceiptasproof of purchase
How to makea product warrantyclaim:
Step 1: Findyourreceipt which provesthe dateof purchase. Where the dateof purchasecannot be verified, your placeof purchase orLaserwill make
an assessment based on thedateofmanufacture,the condition of theLaser Productand the typeof defect. Step 2a):Contactyour placeofpurchase.
They willassess the natureof the faultand repair,replace orfundtheproduct asper their storerefund or warranty policy. Step 2b): If your placeof
purchasecannot becontacted, then you can contactLaser. Customer Servicewith detailsofyour defectiveLaser Product:Phone:[phone]; or
Email: [e-mail] oronlinewww.laserco.com.au/support (click on “Consumers (End Users)”). Our business address is at 1/6-8 Byfield
Street, North Ryde,NSW 2113.Step 3: Laser willissueyou with a Return Authorisation (RA) numberwithin 48 hours. When requested,sendus the
defective Productand a copy of your receipt. Laser willcover thecost of the return delivery.
Step 4: Wait for us to contactyou.Oncewehavereceived your defectiveLaserProductfor inspection, wewill inform youof our assessmentof your
claim within 7 days. When wecontactyou,we will firstly letyou know whether you havea validclaimunder this Warranty, and if so, wewill inform you
whether your defectiveLaser Productwill be replaced or repaired, togetherwith the number of daysyou canexpect to wait to receive your replaced or
repairedLaser Product.Step 5: For further details on warranty cover and returns, please check Terms and Conditions for Warranty Returns section on
http://www.laserco.com.au/support. Our goods comewith guarantees that cannot beexcluded under theAustralian Consumer Law. You are entitled
to a replacement or refund for a major failure andcompensation for anyother reasonablyforeseeable loss or damage. You arealso entitled to have
thegoods repairedor replaced if the goods fail to beofacceptable quality and the failure doesnot amount to a major failure.
