Laser PJT-BYCBL-040 User manual

Quick Start Guide
Laser Backyard Cinema Bundle
PJT-BYCBL-040 SCAN FOR MANUAL
WHAT’S IN THE BOX:
ADDITIONAL ITEMS YOU MAY NEED FOR SETTING UP:
FOR BEST USE, PLEASE NOTE THE FOLLOWING:
SETTING UP:
Self-Inatable Screen
• Inatable screen with built-in blower
• Detachable white movie screen
• Carry Bag
• 6 x tie down ropes
• 6 x tether stakes
1. 2x AAA batteries for the projector remote control
2. Power extension cord with double adaptor
3. HDMI cable
4. 3RCA to 3.5mm AV cable (optional to connect with devices without an HDMI output)
When setting up the screen and projector outdoors, please be aware of wind conditions and
obstructions. The projector works best in dark conditions, so other light sources from street lighting,
backyard lights, and mobile devices may impact the clarity of the projected image. For an optimal
viewing experience, we recommend a 120-inch image or less, with the projector placed 3.6 metres
from the screen. A 144-inch screen is possible, however the projector would need to be 4.4 metres
from the screen, meaning brightness and image quality may be compromised.
1. Select an area large enough to erect the
projector screen.
2. Unpack the projector frame and lay it out on
the ground with the front of the screen facing
upwards, and without blocking the air pump.
Projector
• Projector
• Remote
• AC Power Adapter
• Lens cover
Soundbar
• Mini Bluetooth Soundbar
• USB-A to USB-C cable (for power)

3. Attach the white movie screen to the frame.
4. Connect the air pump to power and inate the screen.
5. Secure the inated screen to the ground using supplied stakes and ropes.
6. Unpack the projector and connect it to power. Use the rst illustration on the previous page as
a guide to position the projector.
7. Reposition the projector to get the best image on the screen. You can use Focus and
Keystone rotators on the projector to help you.
8. Connect the mini soundbar to power using the supplied USB-A to USB-C power cable. We
recommend that you use a 5V, 1A USB adaptor, however you can use the USB port on the
projector as well.
9. Turn on the mini soundbar by holding down the Mode/Power button. Bluetooth mode is the
default mode on the speaker. If not, press the Mode/Power button to switch to Bluetooth mode.
10.On the projector, go to Menu > Option > Bluetooth. Press the OK button on the remote to turn
on Bluetooth. Press the OK button again to go into Bluetooth menu and follow on-screen instruc-
tions to start searching for nearby Bluetooth devices. Select PJT-BYCBL-040-C and click OK to
connect. Audio played on the projector can now be heard through the mini soundbar.
