April 2014
Revision: EB70_01.2

HDR-60 Base Board – Revision B

User’s Guide

2
HDR-60 Base Board – Revision B
Introduction
The HDR-60 Base Board provides a low-cost evaluation and demonstration platform to evaluate, test and debug
image signal processing user designs or IP, including High Dynamic Range (HDR) cores targeted for the
LatticeECP3™-70 FPGA. The HDR-60 Base Board and NanoVesta Head Board have been designed to work
together as part of the HDR-60 Video Camera Development Kit. Connections are available on the HDR-60 Base
Board for the A-1000 HDRI sensor from Aptina, scalable to future sensors from Aptina, and adaptable to sensors
from other manufacturers by redesigning the add-on NanoVesta Head Board. The HDR-60 Base Board features a
LatticeECP3-70 FPGA in the 484-ball fpBGA package. The LatticeECP3 I/Os are connected to a rich variety of
both generic and application-specific interfaces described later in this document.
Important: This document (including the schematics in Appendix A) describes the HDR-60 Base Board marked as
Revision B. This marking can be seen on the silkscreen of the printed circuit board, under the Lattice Semiconduc-
tor logo. The following are the changes from Revision A to Revision B.
• Added R136 and R137
• Installed R130 and R131
• Moved DVI_DDC_SCL signal to U2 pin D22
• Moved DVI_DDC_SDA signal to U2 pin G19
• Moved DVI_HPD signal to U2 pin C22
The LatticeECP3 is a third-generation device utilizing reconfigurable SRAM logic technology optimized to deliver
high-performance features such as an enhanced DSP architecture, high-speed SERDES and high-speed source
synchronous interfaces in an economical FPGA fabric. The LatticeECP3 devices also provide popular building
blocks such as LUT-based logic, distributed and embedded memory, Phase Locked Loops (PLLs), Delay Locked
Loops (DLLs), and advanced configuration support, including encryption, multi-boot capabilities and TransFR™
field upgrade features. The LatticeECP3 SERDES dedicated PCS functions, high jitter tolerance and low transmit
jitter allow the SERDES plus PCS blocks to be configured to support an array of popular data protocols including
PCI Express, SMPTE, Ethernet (XAUI, GbE, and SGMII), SATA I/II, OBSAI and CPRI. Transmit Pre-emphasis and
Receive Equalization settings make the SERDES suitable for transmission and reception over various forms of
media.
For a full description of the LatticeECP3 FPGA, including data sheet, technical notes and more, see the Lattice
web site at www.latticesemi.com/products/fpga/ecp3.
Some common uses for the HDR-60 Base Board include:
• Security/surveillance and automotive camera applications
• Evaluation of the Helion NanoVesta Head Board and other camera sensors
• Applications using Aptina Head Boards
• Evaluation of Helion IONOS Imaging Pipeline IP cores
• Ethernet IP camera applications
• Evaluation of Teradek H.264 compression modules
Features
Key features of the HDR-60 Base Board include:
• SPI serial Flash device included for low-cost, non-volatile configuration storage
• DDR2 SDRAM: 16-bit data over a 32M address space
• Tri-speed (10/100/1000 Mbit) Ethernet PHY with RJ-45 (includes 12 core magnetics)

3
HDR-60 Base Board – Revision B
• Built-in USB 2.0 download to LatticeECP3
• Can be configured for a flywire ispDOWNLOAD™ cable connection
• HiSPi and parallel video data path connections with selectable VCCIO (1.8 V/2.5 V/3.3 V)
• Connectors for Aptina standard Head Board with USB 2.0 interface
• Connector for Teradek Capella H.264 codec board
• Test point connections to 19 I/O pins for prototyping
• Two MEMS and two crystal oscillators
• HDMI/DVI output using four channels (one quad) of differential SERDES
• 5.0 V, 3.3 V, 2.5 V, 1.8 V, 1.2 V voltages are generated from a single 12 V power source
• ispVM™ System programming support
General Description
The heart of the HDR-60 Base Board is the LatticeECP3 FPGA. The devices and connectors attached to the
LatticeECP3 provide a means to investigate applications developed for High Dynamic Range image signal pro-
cessing. The board also provides several different interconnections and support devices that permit it to be used
for a variety of purposes. The HiSPi and parallel video input, DDR2 memory, Tri-speed Ethernet PHY, and HDMI
output are useful for applications using Lattice IP cores. A modest number of test points were added around the
board for general purpose LatticeECP3 I/O usage. The SPI memory showcases the fail-safe capabilities of the
LatticeECP3. Figure 1 is the block diagram for the HDR-60 Video Camera Development Kit.
Figure 1. HDR-60 Video Camera Development Kit Block Diagram
Refclk
Quad
A
Bank 6 Bank 7
Bank 0
Bank 1
Bank 2Bank 3
SERDES
Ch3
Ch2
Ch1
Ch0
Teradek MPEG Ethernet
Aptina
Head Board
NanoVesta
Head Board
LatticeECP3
-70EA
484 fpBGA
HDMI
DDR2 SDRAM
27 MHz 25MHz

4
HDR-60 Base Board – Revision B
Initial Setup and Handling
The following is recommended reading prior to removing the evaluation board from the static shielding bag and
may or may not apply to your particular use of the board.
CAUTION: The devices on the board can be damaged by improper handling.
The devices on the evaluation board contain fairly robust ESD (Electro Static Discharge) protection structures
within them, able to withstand typical static discharges (see the “Human Body Model” specification for an example
of ESD characterization requirements). Even so, the devices are static sensitive to conditions that exceed their
designed in protection. For example: higher static voltages, as well as lower voltages with lower series resistance
or larger capacitance than the respective ESD specifications can potentially damage or degrade the devices on the
evaluation board.
As such, it is recommended that you wear an approved and functioning grounded wrist strap at all times while han-
dling the evaluation board when it is removed from the static shielding bag. If you will not be using the board for a
while, it is best to put it back in the static shielding bag. Please save the static shielding bag and packing box for
future storage of the board when it is not in use.
When reaching for the board, it is recommended that you first touch the ground plane of the board (for example, the
metal shielding of the HDMI connector). This will neutralize any static voltage difference between your body and the
board prior to any contact with signal I/O.
CAUTION: To minimize the possibility of ESD damage, the first and last electrical connections to the board should
always be from test equipment chassis ground to the ground plane of the board.
Before connecting signals or power to the board, attach a cable from chassis ground on grounded test equipment
to the ground plane of the board. Connecting the board ground to test equipment chassis ground will decrease the
risk of ESD damage to the I/O on the board as the initial connections to the board are made. Likewise, when
unplugging cables from the evaluation board, the last connection unplugged, should be the chassis GND connec-
tion to the evaluation board GND. If you have a signal source that is floating with respect to chassis GND, attempt
to neutralize any static charge on that signal source prior to attaching it to the evaluation board.
If you are holding or carrying the board when it is not in a static shielding bag, please keep one finger on the ground
plane of the board, for example the metal shielding of the HDMI connector. This will keep the board at the same
voltage potential as your body until you can pick up the static shielding bag and put the board back in it.
Electrical, Mechanical, and Environmental Specifications
The nominal board dimensions are 203.2 mm x 42 mm (8.000” x 1.654”). Additional mechanical board dimension
information is included on the mechanical drawing shown in Appendix A, Figure 24. On the physical board itself,
connectors include pin 1 indictors as either an arrow, or triangle point near pin 1 on the outer layer silk screen. The
environmental specifications are as follows:
• Operating temperature: 0 °C to 55 °C
• Storage temperature: -40 °C to 75 °C
• Humidity: <95% without condensation
• 11 V to 18 V DC (20 watts max.)

5
HDR-60 Base Board – Revision B
Functional Description
Figure 2. HDR-60 Base Board, Top View
HDMI
RJ45 &
2x USB
BNC (Not present
on all boards.
See note below)
Discera MEMs
based oscillator
(on reverse side
of board)
12 V
DC
Input
LatticeECP3-70
FPGA
ISSI
DDR2
Broadcom
Broadreach
PHY
FTDI
USB
Aptina
Headboard
Connector
Head Board
Connector
(HiSPi)
Head Board
Connector
(Parallel)
Note: The BNC connector (J11), and Delta Filter (U8) are designed for Ethernet-over-BNC.
This is an unsupported feature. These components are not populated on most manufacturing runs of this board.
LatticeECP3 Device
This board features a LatticeECP3-70 FPGA with a 1.2 V DC core in a 484-ball fpBGA package. The LatticeECP3-
35, -70 and -95 device densities in this package can be accommodated with no change in pin connections. A com-
plete description of this device can be found on the Lattice web site at www.latticesemi.com/products/fpga/ecp3.
Power Connector (J10)
The board is supplied by a single 12 V DC power supply at J10. On-board step-down switching regulators then pro-
vide the necessary supply voltages: 3.3 V, 2.5 V, 1.8 V, 1.2 V. For proper operation, the 12 V DC power applied at
J10 should be within the range of +11 V min. to +18 V max. The requirements for the J10 power jack itself are listed
in Ta b l e 1.
Table 1. Power Jack J10 Specifications
Polarity Positive Center
Inside Diameter 0.1” (2.5mm)
Outside Diameter 0.218” (5.5mm)
Current Capacity Up to 2.5A
The on-board switching regulator output voltages can be measured at test points located around the board as
shown in Table 2.
Table 2. Test Points for On-Board Regulator Voltages
Supply Switching Regulator Test Point Resistor Ratio Comment
5.0 V U15 PP7 R123/R122
3.3 V U10 (side 2) PP1 R46/R45
2.5 V U10 (side 1) PP2 R53/R5 (default)
(R56 and R51 modify ratio)
1.8 V: jumper on J4 pins 1-2
2.5 V: no jumper on J4 (default)
3.3 V: jumper on J4 pins 2-3
1.8 V U11 (side 2) PP3 R55/R6
1.2 V U11 (side 1) PP4 R54/R52
Each of the step-down switching regulators, U10, U11, and U15, incorporate typical resistor divider voltage feed-
back to divide down the regulator output voltage and compare it against an internal reference voltage. The regula-
tor then adjusts the output voltage higher or lower such that the resistor divided voltage matches the internal

6
HDR-60 Base Board – Revision B
reference. By doing this, the regulator output voltage remains at a constant voltage value independent of the load
driven. Each regulator output voltage follows this equation:
Vout = (1 + resistor ratio) x (regulator internal reference voltage)
See the LT3503 and LT3508 device data sheets for additional details about these devices.
The 2.5 V regulator output voltage can also be set to 1.8 V or 3.3 V by adding a shorting jumper on J4, as shown in
Tabl e 2. With no jumper on J4, the voltage divider is set by R53 and R5 and this divider sets up a nominal 2.5 V
output voltage. When a shorting jumper is added to J4, the R56 and R51 resistors will be placed in parallel with
either R53 or R5, which then changes the resistor divider ratio, and this changes side 1 of the U10 regulator output
voltage to become 1.8 V or 3.3 V depending on the placement of the shorting jumper on J4.
The SERDES 1.2 V regulators (U4) are low dropout linear types that deliver a constant 1.2 V output voltage when
powered by the 3.3 V input voltage. In contrast to the switching regulators discussed above, the U4 linear regulars
do not generate switching noise, so they are a good choice for powering the LatticeECP3 SERDES to give the low-
est jitter generation. Also, U4 does not use resistor divider networks to set the output voltage, instead U4 is set up
to directly copy its own internal 1.215 V reference voltage to its outputs. The U4 regulator outputs are available for
testing at test points PP5 and PP6. See the LT3029 device data sheets for additional details about this device.
When using the various I/O test points located around the board, be sure to not exceed the LatticeECP3 Family
Data Sheet specified absolute maximum rating for Output Supply Voltage VCCIO range of -0.5 V to +3.75 V, or
damage to the device may occur. Also, for I/O input capability of the various I/O standards supported by the
LatticeECP3 sysIO structures, see the LatticeECP3 sysIO Usage Guide.
LatticeECP3 I/O Bank Voltages
Most of the bank voltages on the LatticeECP3 (U2) have been hard-wired to specific power supply values. Excep-
tions to this are banks 1 and 2 which can be set to other values used to power the sensor boards that plug into the
parallel connector (J2) and HiSPi connector (J1). This is shown in Ta b l e 3.
Table 3. LatticeECP3 (U2) Bank Voltage Settings
LatticeECP3 Bank VCCIO Voltage Comment
03.3 V Aptina Head Board
1 and 2 Adjustable
Sensor attached to J1 and J2
1.8 V: Jumper on J4 pins 1-2
2.5 V: No jumper on J4 (default)
3.3 V: Jumper on J4 pins 2-3
31.8 V DDR2
Quad A 1.2 V SERDES
63.3 V Teradek MPEG Encoder
73.3 V Ethernet
83.3 V LatticeECP3 programming

7
HDR-60 Base Board – Revision B
Default Jumper Settings
Figure 3. Default Jumpers
LatticeECP3
Aptina Head Board
Cypress Device
SCL
SDA
On: 1.8V
J4 J5 J6
Off: 2.5V
On: 3.3V
VDDIO
Figure 3 shows the HDR-60 Base Board default jumpers settings for VDDIO set to 2.5 V. By installing a jumper on
J4 in the upper position, the VDDIO will change to 1.8 V and on the lower position, the VDDIO will change to 3.3 V.
Only when using the Aptina Head Board, do the serial clock and data signals, J5 and J6 need to be of concern. J5
and J6 select whether the Aptina Head Board will be sourced from the Cypress device (U6) directly or from the
LatticeECP3. Moving the jumpers from the lower position on J5 and J6 to the upper position will change the source
of the serial clock and data to be from the LatticeECP3 device (U2).
Prototype Areas
For general purpose I/O testing or monitoring, 19 unconnected test points with reference labels TP1, 2, … are pro-
vided for direct access to the LatticeECP3 device. OtherI/Os on the LatticeECP3 are brought to dedicated connec-
tors such as J1, J2, J7, J8 and J9, which could also be considered as available prototype connectors when they are
not in use.
Crystal Oscillators
There are two crystal oscillators and two MEMS-based oscillators on the HDR-60 Base Board. The two crystals are
used for the two USB port connections. One MEMS-based oscillator is used to set the reference frequency for the
Ethernet PHY, while the other is used to drive inputs to the LatticeECP3 (U2). Table 4 shows the oscillator usage.
Locations Y1 and Y4 are the MEMS-based oscillators.
Table 4. Crystal Oscillators Used on the HDR-60 Base Board
Location Frequency Comment
LatticeECP3 Input
I/O Setting
Y1 27.000 MHz DDR2 U2 pin R17
MPEG U2 pin T3
SSTL18 (no term)
LVC MOS 33
Y2 6.000 MHz USB FTD2232D U5 pin 43
(upper USB port at J12) —
Y3 24.000 MHz USB Cypress U6 pin 11
(lower USB port at J12) —
Y4 25.000 MHz Ethernet PHY U3 pin F1 —
DVI Video Output
The LatticeECP3 (U2) SERDES Quad A outputs drive the HDMI connector (J13) through inline AC coupling capac-
itors C55, C56, C57, C58, C218, C219, C220, and C221. The SERDES signal paths are 50 ohms between the
LatticeECP3 outputs to the HDMI connector on the HDR-60 Base Board. The DVI signal connections between the
LatticeECP3 device and the HDMI connector are shown in Ta b l e 5.

8
HDR-60 Base Board – Revision B
Table 5. LatticeECP3 (U2) Connections to HDMI Output (J13)
J13 Pin LatticeECP3 I/O Polarity sysIO Bank Signal Name
10 AB15 PQuad A DVI_HDOUTP0
12 AB14 NQuad A DVI_HDOUTN0
7AB12 PQuad A DVI_HDOUTP1
9AB13 NQuad A DVI_HDOUTN1
4AB11 PQuad A DVI_HDOUTP2
6AB10 NQuad A DVI_HDOUTN2
1AB8 PQuad A DVI_HDOUTP3
3AB9 NQuad A DVI_HDOUTN3
13 — — — CEC_OUT
15 E18 — 8 DVI_DDC_SCL
16 E17 — 8 DVI_DDC_SDA
19 A20 — 8 DVI_HPD
HiSPi Connector (J1)
The LatticeECP3 (U2) banks 1 and 2 can receive HiSPi sub-LVDS video signals from connector J1. When receiv-
ing HiSPi signals, you will need to set the LatticeECP3 input type to LVDS with differential 100 ohm termination.
The signal connections between the LatticeECP3 device and the HiSPi connector are shown in Ta bl e 6.
Table 6. LatticeECP3 (U2) Interface to HiSPi Connector J1
J1 Pin
LatticeECP3
I/O BGA Ball Polarity sysIO Bank
Differential
Signal Parallel Signal
13 K21 P 2 SLVS_0P —
11 L21 N 2 SLVS_0N —
29 L22 P 2 SLVS_1P —
27 M22 N 2 SLVS_1N —
21 P21 P 2 SLVS_2P —
19 N22 N 2 SLVS_2N —
26 M18 P 2 SLVS_3P —
24 N17 N 2 SLVS_3N —
14 L18 P 2 SLVS_4P —
12 L19 N 2 SLVS_4N HISPI_LED
22 K20 P 2 SLVS_5P —
20 K19 N 2 SLVS_5N —
17 K17 P 2 SLVS_6P —
15 K18 N 2 SLVS_6N —
25 H21 P 2 SLVS_7P —
23 H22 N 2 SLVS_7N —
18 M21 P 2 SLVS_CP —
16 M20 N 2 SLVS_CN —
10 C13 — 1 — HISPI_RESETN
28 K22 — 2 Note 1 RESERVED_1
30 J22 — 2 Note 1 HISPI_SDATA
32 C14 — 1 — HISPI_SCLK
4A13 — 1 — VDDIO_rH
1. Routed on the HDR-60 Base Board as a differential pair.

9
HDR-60 Base Board – Revision B
Parallel Connector (J2)
The LatticeECP3 (U2) bank 1 receives parallel video signals from connector J2. The signal connections between
the LatticeECP3 device and the HiSPi connector are shown in Ta b l e 7.
Table 7. LatticeECP3 (U2) Interface to Parallel Connector J2
J2 Pin
LatticeECP3
I/O BGA Ball sysIO Bank Parallel Signal Differential Signal
16 J20 2DOUT0 SLVS_8N
20 G22 2DOUT1 SLVS_9N
15 F22 2DOUT2 SLVS_11N
19 J18 2DOUT3 SLVS_10N
14 A16 1DOUT4 —
18 J19 2DOUT5 SLVS_8P
13 C16 1DOUT6 —
17 E22 2DOUT7 SLVS_11P
22 G21 2DOUT8 SLVS_9P
24 G14 1DOUT9 —
21 J17 2DOUT10 SLVS_10P
23 C17 1DOUT11 —
10 C12 1PIXCLK —
9A19 1EXTCLK_FPGA —
11 A18 1LINE_VALID —
12 B16 1FRAME_VALID —
25 B18 1TRIGGER —
27 A17 1RESET_BAR —
29 F16 1OUTPUT_EN_BAR —
31 F15 1STANDBY —
26 G15 1SADDR —
28 D15 1SCLK —
30 C15 1SDATA —
32 E15 1 OSC_ENABLE —
4A12 1VDDIO_rP —
Aptina Head Board Connector
Connectors J7 and J8 make up the Aptina Head Board connector. They are described below. Note that jumpers J5
and J6 may be required to be in the 2 and 3 positions if using Aptina DevWare software. Contact Aptina for details
on running DevWare on the HDR-60 Base Board.
Dual Row Connector (J7)
The LatticeECP3 (U2) bank 0 interfaces to the Aptina dual row connector (J7) as shown in Ta b l e 8.
Table 8. LatticeECP3 (U2) Interface to Aptina Dual Row Connector (J7)
J7 Pin LatticeECP3 I/O BGA Ball sysIO Bank Signal
1C8 0HEAD_DOUT0
2C7 0HEAD_DOUT1
3F9 0HEAD_DOUT2
4E9 0HEAD_DOUT3
5C9 0HEAD_DOUT4

10
HDR-60 Base Board – Revision B
Aptina Single Row Connector (J8)
The LatticeECP3 (U2) bank 0 interfaces to the Aptina single row connector (J8) as shown in Table 9.
Table 9. LatticeECP3 (U2) Interface to Aptina Single Row Connector (J8)
J2 Pin LatticeECP3 I/O BGA Ball sysIO Bank Signal
1F10 0HEAD_DOUT10
2E10 0HEAD_DOUT11
3A9 0HEAD_DOUT12
4B10 0HEAD_DOUT13
5A10 0HEAD_DOUT14
6A11 0HEAD_DOUT15
7C5 0HEAD_SP0
8B4 0HEAD_SP1
9E6 0HEAD_SP2
10 D5 0HEAD_GSHT_CTL
11 C6 0HEAD_TRIGGER
Teradek MPEG Encoder Connector
The LatticeECP3 (U2) bank 6 I/Os connect to the Teradek MPEG Encoder Connector (J9). The signal connections
are shown in Tabl e 10.
6C10 0HEAD_DOUT5
7B7 0HEAD_DOUT6
8A7 0HEAD_DOUT7
9B8 0HEAD_DOUT8
10 A8 0HEAD_DOUT9
13 A3 0HEAD_LINE_VALID
14 B6 0HEAD_SP5
15 G9 0HEAD_SP7
16 F7 0HEAD_SENSOR_RESETN
17 A4 0HEAD_FRAME_VALID
19 E7 0HEAD_SHIP_CLK
20 F8 0HEAD_SP6
23 F11 0HEAD_PIXCLK
26 D6 0HEAD_MCLK
Table 10. LatticeECP3 (U2) Connections to Teradek MPEG Encoder (J9)
J9 Pin LatticeECP3 I/O sysIO Bank Signal Name
4N3 6MG_VID00
6P3 6MG_VID01
8N5 6MG_VID02
10 P6 6MG_VID03
12 P1 6MG_VID04
14 R1 6MG_VID05
16 R3 6MG_VID06
Table 8. LatticeECP3 (U2) Interface to Aptina Dual Row Connector (J7) (Continued)
J7 Pin LatticeECP3 I/O BGA Ball sysIO Bank Signal

11
HDR-60 Base Board – Revision B
SPI Serial Flash
The U9 SPI Flash device used on this board is a 16-pin, 64-Mbit device, sufficient to store two bitstreams simulta-
neously in order to support SPIm mode. The HDR-60 Base Board is configured to download bitstreams stored in
the SPI Flash (U9) into the LatticeECP3 when the +12 V power is applied at connector J10. The SPI Flash device
is a Numonyx SPI-M25P64 in a 16-pin SOIC package.
Downloading Bitstreams into the LatticeECP3 (U2)
In order to download bitstreams into the LatticeECP3 (U2) device, the HDR-60 Video Camera Development Kit
includes two USB-A to USB-A cables that can connect a PC with ispVM System software installed, to the HDR-60
Base Board. Each USB-A to USB-A cable is 6’ (1.83 m) in length. As both ends of the USB cables are the same,
either end can plug into a PC’s USB port, while the other end connects to the HDR-60 Base Board J12 upper USB
port. The J12 upper USB port connects to a FTD2232D USB transceiver (U5) that can produce JTAG signals able
to drive the LatticeECP3 device (U2). Given this, the ispVM System software can detect the LatticeECP3 device,
download bitstreams directly into the LatticeECP3 SRAM, or bitstreams can be downloaded into the on board SPI
Flash (U9).
Note that the J12 lower USB port has no USB-to-JTAG signal path connections to any Lattice device, so the ispVM
System software will not detect any devices at the J12 lower USB port.
18 R2 6MG_VID07
3W2 6MG_VID08
5Y1 6MG_VID09
7T4 6MG_VID10
9U4 6MG_VID11
11 AA1 6MG_VID12
13 Y2 6MG_VID13
15 Y3 6MG_VID14
17 AA2 6MG_VID15
20 P5 6MG_VID0_PIXCLK
19 T6 6MG_VID1_PIXCLK
22 U1 6VGPIO1
26 U2 6VGPIO2
30 R7 6VGPIO3
23 N1 6MG_VSYNC
24 N2 6MG_HSYNC
25 R4 6MG_FIELD
27 V3 6VIDEO_SCL
28 W1 6VIDEO_SDA
31 L4 6MG_MCLK_IN
32 W3 6MG_LRCLK_IN
33 M5 6MG_BCLK_IN
35 T5 6MG_SPDIF
34 P7 6MG_IDAT0
36 V1 6MG_IDAT1
Table 10. LatticeECP3 (U2) Connections to Teradek MPEG Encoder (J9) (Continued)
J9 Pin LatticeECP3 I/O sysIO Bank Signal Name

12
HDR-60 Base Board – Revision B
See the “Configuring/Programming the Board” section of this document for details on how to download bitstreams
into the LatticeECP3 device. See www.latticesemi.com/hdr60 for additional downloadable project files and bit-
streams designed for use with this board.
LEDs
There are three LEDs on the HDR-60 Base Board that are used to show the programming state of the
LatticeECP3. See Tabl e 11 for information on the programming state LEDs.
Table 11. Programming LEDs
LED Pin Color Function
LED1 PROGRAMN Red On when signal is low
LED2 INITN Red On when initializing
LED3 DONE Green On when configuration is complete
DDR2 Memory
The HDR-60 Base Board is equipped with an 84-ball BGA DDR2 SDRAM such as the IS43DR16320B, which pro-
vides memory resources with16 bits of data width that span a 32M address space. The DDR2 memory is powered
by an on-board 1.8 V regulator with a 0.9 V midpoint bias termination regulator (U12). The evaluation board
includes terminations for address, command and data signals. The suggested configuration is to set the DDR2
SDRAM (U1) for internal 150 ohms ODT, and the LatticeECP3 (U2) address, control and data signals to slow slew,
8 ma, with no ODT. This gives a low-noise, low-power DDR2 memory configuration usable to over 400 MT/s.
Tabl e 12 shows the pin connections for both the LatticeECP3 (U2) and DDR2 SDRAM (U1).
Table 12. LatticeECP3 Interface to DDR2 SDRAM
Signal Name LatticeECP3 I/O Pin (U2) sysIO Bank DDR2 SDRAM Pin (U1)
DDR2_DQ0 R22 3G8
DDR2_DQ1 R20 3G2
DDR2_DQ2 T20 3H7
DDR2_DQ3 T22 3H3
DDR2_DQ4 R21 3H1
DDR2_DQ5 N19 3H9
DDR2_DQ6 P22 3F1
DDR2_DQ7 M19 3F9
DDR2_DM0 N20 3F3
DDR2_DQS0_P N18 3F7
DDR2_DQS0_N P19 3E8
DDR2_DQ8 Y21 3C8
DDR2_DQ9 V22 3C2
DDR2_DQ10 W22 3D7
DDR2_DQ11 W21 3D3
DDR2_DQ12 U22 3D1
DDR2_DQ13 Y22 3D9
DDR2_DQ14 R16 3B1
DDR2_DQ15 P17 3B9
DDR2_DM1 R18 3B3
DDR2_DQS1_P T21 3B7
DDR2_DQS1_N U20 3A8
DDR2_VREF P20 3 J2

13
HDR-60 Base Board – Revision B
Ethernet PHY
To the right of the LatticeECP3 FPGA is U3, a Broadcom BCM54810 triple-speed 10/100/1000BASE-T Gigabit
Ethernet (GbE) transceiver. The LatticeECP3 FPGA interacts with the PHY over a 3.3 V Gigabit Media Indepen-
dent Interface (GMII). The PHY is connected to an RJ45 connector J12 at the Media Dependent Interface (MDI).
The RJ45 connector J12 has built-in magnetics and link activity indicator LEDs driven by the PHY. The J12 PHY
link LEDs are set to indicate the link status, as shown in Ta bl e 13.
Table 13. J12 Link Status LEDs
J12 LED Color Link Status
Orange and Green 1000Base-T
Orange 100Base-T
Green 10Base-T
Ye l l o w Activity
(off) No link
The PHY is available on the board in order to demonstrate the Lattice Ethernet Media Access (MAC) IP core. How-
ever, it is also possible to use the PHY to evaluate a custom MAC solution.
During power-up, the resistors R21, R22, R23, R24, R25, R103, R105, and R107 set the initialized PHY configura-
tion to: auto-negotiate, full duplex, 10/100/1000Base-T. The PHY can also be programmed after power-up to use a
new configuration. The PHY signal path is factory-configured to send and receive 10/100/1000Base-T Ethernet
signals at the RJ45 connector (J12). It is possible to change the configuration of the PHY signal path to instead
DDR2_A0 AB19 3M8
DDR2_A1 R14 3M3
DDR2_A2 AA21 3M7
DDR2_A3 V17 3N2
DDR2_A4 AB17 3N8
DDR2_A5 W17 3N3
DDR2_A6 Y17 3N7
DDR2_A7 W18 3P2
DDR2_A8 AB18 3P8
DDR2_A9 U18 3P3
DDR2_A10 T19 3M2
DDR2_A11 AA17 3P7
DDR2_A12 Y19 3R2
DDR2_BA0 Y18 3L2
DDR2_BA1 U15 3L3
DDR2_CK_P AA22 3 J8
DDR2_CK_N AB21 3K8
DDR2_CKE T18 3K2
DDR2_RASN T14 3K7
DDR2_CASN V18 3L7
DDR2_WEN U16 3K3
DDR2_ODT R19 3K9
DDR2_CSN U19 3L8
Table 12. LatticeECP3 Interface to DDR2 SDRAM (Continued)
Signal Name LatticeECP3 I/O Pin (U2) sysIO Bank DDR2 SDRAM Pin (U1)

14
HDR-60 Base Board – Revision B
provide a legacy Ethernet coaxial link using the BNC connector (J11) by removing three resistors off the HDR-60
Base Board and then add back on three resistors as shown in Tabl e 14. However, Ethernet-over-BNC is an unsup-
ported feature on this board. The BNC connector and Delta filter (U8) are unpopulated on most production runs of
this board. This information is provided as a reference only.
Table 14. Ethernet Connection at J11 or J12
Connector Cable LAN Speed PCB Configuration
J12 (RJ45) Cat5 10/100/1000Base-T
R31, R32 = 0 ohms
R23 = 4.7K ohms
R29, R30, R21 = open
J11 (BNC) Coaxial 10/100Base-T
R29, R30 = 0 ohms
R21 = 4.7K ohms
R31, R32, R23 = open
1
Refer to the HDR-60 Base Board schematic in Appendix A and the Broadcom BCM54810 Data Sheet for detailed
information about the operation of the Ethernet PHY interface on this device. Refer to Ta b l e 15 for a description of
the Ethernet PHY GMII connections to the LatticeECP3.
1. J11 (BNC) and U8 (Delta filter) are unpopulated on most manufacturing runs of this board. Ethernet-over-BNC is an
unsupported feature of this board. The information in this table is for reference only.
Table 15. LatticeECP3 Interface to Ethernet PHY
Signal Name LatticeECP3 I/O Pin (U2) sysIO Bank BCM54810 Pin (U3)
PHY_A0 E3 7H10
PHY_A1 D4 7J10
PHY_A2 E5 7 J9
PHY_A3 E4 7K10
PHY_A4 B2 7K9
GTXCLK F5 7A7
ECP3_GSRN F4 7--
PHY_LOWPWR G4 7F5
MDC G5 7E3
TXD0 B1 7C7
TXD1 G3 7C8
TXD2 H6 7B6
TXD3 C1 7B7
TXD4 H4 7B8
TXD5 E2 7B9
TXD6 F3 7B10
TXD7 H5 7A10
TX_EN J4 7 A8
TX_ER G2 7A9
CRS F1 7E5
COL H2 7D5
RESETN G1 7E4
RXD0 J1 7 D4
RXD1 K6 7D3
RXD2 J7 7 C3
RXD3 J3 7 C4
RXD4 J6 7 C5

15
HDR-60 Base Board – Revision B
Configuring/Programming the Board
Requirements
• PC with Lattice ispVM System software version 17.9 (or later) installed with USB driver. 
Note: An option to install this driver is included as part of the ispVM System setup.
For a complete discussion of the LatticeECP3 configuration and programming options, refer to the LatticeECP3
sysCONFIG Usage Guide.
Download Procedures for the Lattice HDR-60 Base Board
The download instructions described below show how to download bitstreams into the LatticeECP3 SRAM using
the ispVM System software. Downloads can be either direct through a cable connection to a PC, or indirect by first
programming the on-board SPI Flash and then downloading the bitstream to the LatticeECP3 SRAM from SPI
Flash. You can download bitstreams through a download cable to the LatticeECP3 SRAM at any time. After a bit-
stream has been downloaded to SPI Flash, you can download the bitstream from SPI Flash to the LatticeECP3
SRAM by cycling the power to the evaluation board.
The Lattice HDR-60 Base Board provides support for two types of download cable connections: a standard USB-A
to USB-A cable at J12, or a Lattice ispDOWNLOAD cable (USB type or parallel port type with flywire connections)
at J3 as described in Appendix C. Given that you might want to download to either the LatticeECP3 SRAM or the
SPI Flash, separate LatticeECP3 download procedures will follow that cover each type of download.
Note that the first download procedure shows the menus as viewed on a Windows XP operating system. Follow-on
download procedures are very similar and do not show the menus.
LatticeECP3 SRAM Configuration Using a Standard USB Cable at J12
The LatticeECP3 SRAM can be configured easily using the ispVM System software to download a bitstream via a
standard USB-A to USB-A cable. The LatticeECP3 device is SRAM based, so it must remain powered on to retain
its configuration when programming the SRAM.
1. Attach a ground connection from test equipment chassis ground to the ground plane of the board, for example,
on the metal HDMI connector.
2. Connect the USB-A to USB-A cable from your PC’s USB connector to the upper USB port on J12 on the HDR-
60 Base Board.
3. Connect the 12 V wall power adaptor cable to J10 and check to see that the wall power adapter is plugged in to
a 120 VAC source.
4. Start the ispVM System software. Select the menu items Options > Autoscan Options > Custom Scan as
shown in Figure 4.
RXD5 E1 7B5
RXD6 H3 7B4
RXD7 H1 7B3
RX_ER K3 7A1
TXC K4 7C6
MDIO K5 7F4
125MHz K1 7B1
RX_DV L1 7B2
RXC L5 7A2
Table 15. LatticeECP3 Interface to Ethernet PHY (Continued)
Signal Name LatticeECP3 I/O Pin (U2) sysIO Bank BCM54810 Pin (U3)

16
HDR-60 Base Board – Revision B
Figure 4. Setting the ispVM Custom Scan Option
5. Select Options > Cable and I/O Port Setup. For the Cable Type, select USB2, then click OK.
6. Push the Scan button. You should now see the LFE3-95/70 device listed in the New Scan Configuration Setup
window. In the device list, left-click on the LatticeECP3 device to select it. If offered other selections, select
LFE3-70EA. See Figure 5.
Figure 5. ispVM New Scan Configuration Setup
7. Click Edit > Edit Device to edit the device. A Device Information window will be opened. Click the Select but-
ton and select the package type 484-ball fpBGA as shown in Figure 6, then click OK.
Figure 6. LatticeECP3 Package Size Selection
8. Check that the Device Access Options drop-down menu control selects the JTAG 1532 Mode. Check that the
Operation drop-down menu selects Fast Program.
9. Click the data file Browse button and select the path to the LatticeECP3 “.BIT” bitstream file as shown in
Figure 7, then click OK.

17
HDR-60 Base Board – Revision B
Figure 7. Bitstream Ready to Download into LatticeECP3 SRAM
10. Click Project >Download or the green Go button to download the bitstream into the LatticeECP3 device (U2).
A small window will appear as shown in Figure 8. It will take about 12 seconds to download the bitstream for a
PC with USB 2.0 ports. When the LatticeECP3 has loaded in correctly, the ispVM status window will report
“Operation Successful” as shown in Figure 9.
Figure 8. Bitstream Downloading into LatticeECP3
Figure 9. Bitstream Download Operation Successful
LatticeECP3 SRAM Configuration Using SPI Flash and USB Cable at J12
The LatticeECP3 SRAM can be configured easily using the ispVM System software to program the on-board SPI
Flash via a standard USB cable connected to the upper USB port at J12. The LatticeECP3 device is SRAM-based,
so it must remain powered on to retain its configuration when programming the SRAM. The on-board SPI Flash
retains its programmed bitstreams when power is off, and can quickly load programmed bitstreams into the
LatticeECP3 device when power is applied.
1. Attach a ground connection from test equipment chassis ground to the ground plane of the board, for example
on the metal HDMI connector.

18
HDR-60 Base Board – Revision B
2. Connect the USB-A to USB-A cable from your PC’s USB connector to the upper USB port on J12 on the HDR-
60 Base Board.
3. Connect the 12 V wall power adaptor cable to J10 and check to see that the wall power adapter is plugged in to
a 120 VAC source.
4. Start the ispVM System software. Select the menu items Options > Autoscan Options > Custom Scan.
5. Select Options > Cable and I/O Port Setup. For the Cable Type, select USB2, then click OK.
6. Push the Scan button. You should now see the LFE3-95/70 device listed in the New Scan Configuration Setup
window. In the device list, left-click on the LatticeECP3 device to select it. If offered other selections, select
LFE3-70EA.
7. Click Edit > Edit Device to edit the device. A Device Information window will be opened. Click the Select but-
ton and select the package type 484-ball fpBGA, then click OK.
8. Click the Device Access Options drop-down menu control and select SPI Flash Background Programming.
A SPI Serial Flash Device window will open.
9. Push the Select button and select the Vendor as Numonyx, the device as SPI-M25P64 and the package 16-
lead SOIC as shown in Figure 10. Push the OK button.
Figure 10. SPI Flash Device Selection
10. Click the data file Browse button and select the path to the LatticeECP3 “.BIT” bitstream file. Push the Load
From File button and then click OK to complete the SPI Flash device selection as shown in Figure 11. Again
click OK to exit the Device Information menu. The bitstream is now set up for downloading into the SPI Flash
as shown in Figure 12.

19
HDR-60 Base Board – Revision B
Figure 11. SPI Flash Device Setup Complete
Figure 12. Bitstream Ready to Download into SPI Flash
11. Click Project > Download or the green Go button to download the bitstream into the SPI Flash device (U9),
the bitstream download progress indictor will pop up as shown in Figure 13. When using the built-in USB down-
load cable, it will take about two minutes to erase, program and verify the bitstream loaded properly into the
SPI Flash for a PC with USB 2.0 ports. After the SPI Flash contents have been verified, the ispVM status win-
dow will report “Operation Successful” as shown in Figure 14.
Figure 13. Bitstream Download Progress Indicator
