LAZBOY Sears Bethany 7PC Dining Set User manual

1
USE AND CARE GUIDE
Sears Lucas 7pc Dining Set
* Swivel Rocker
Product Code: D71 M34951
UPC Code: 7 22938 10463 5
Date of Purchase: __ / __ / __
La-Z-Boy® is a registered trademark of La-Z-Boy Incorporated and is used under license to BJI, Inc.
© 2015 La-Z-Boy Incorporated.

2
Thank you for your purchase
THANK YOU FOR YOUR PURCHASE!
We are pleased that you have chosen Sears for your outdoor furniture purchase. We hope that you
enjoy the unmatched quality, comfort, and style of your new patio set. Every piece is meticulously
considered all the way down to the smallest details, exclusively for you, by our world class design
team. We know you have a choice when it comes to your patio furniture needs, so from our team to
yours, thank you for letting us be a part of your outdoors.
Table of Contents
Table of Contents..........................................2
Safety Information ........................................ 3
Set up your furniture properly...................... 3
Examine your furniture................................ 3
Warranty ........................................................ 3
What is covered .......................................... 3
What is not covered .................................... 3
Care and Maintenance.................................. 4
Pre-Assembly................................................ 5
Planning assembly...................................... 5
Observe weight limits.................................. 5
Hardware included ...................................... 5
Package contents ....................................... 6
Assembly Instruction ................................... 7
Customer Service ......................................... 9

3
SET UP YOUR FURNITURE
PROPERLY
□Ensure that all parts are assembled
properly and fully tightened as per the
instructions.
□When placing in the desired location,
ensure that all legs are resting on the same
surface. You may adjust the legs levelers
as required to ensure that the item stands
in a rigid position.
EXAMINE YOUR FURNITURE
□Examine occasionally to ensure that there
are no loose parts. If loose parts are found,
they must be retightened fully before
additional use.
WARNING: Do not sit or stand on the table.
WARNING: Do not place heavy items on the
table top.
WARNING: An umbrella base must be used
at all times.
Umbrella should not be used in the event of
wind, rain, hail, sleet, snow or any other
inclement weather.
Warranty
THIS IS A RESIDENTIAL WARRANTY AND DOES NOT APPLY FOR
COMMERCIAL USE.
7 YEARS WARRANTY FOR FRAME.
WHAT IS COVERED
We warrant the frame to be free of manufacturing defects to the original purchaser for 7 years.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service
center.
This warranty does not cover commercial use, hardware, acts of nature, fire, freezing and abusive
use.
Discoloration or fading of the finish or fabrics as a result of chemicals or spills is not covered.
Glass table top breakage and corrosion or rusting of hardware are not covered.
In addition, purchase parts are not covered under this warranty.
Proof of purchase (dated register receipt) is required for warranty claims.
Safety Information

4
We reserve the right to make substitutions with similar merchandise, if the model in question is no
longer in production.
For a copy of our full limited warranty, please contact our customer service team below.
Contact the Customer Service Team at 1-866-391-4868 or visit www.bjifurniture.com.
Care and Maintenance
□Do not allow water to build up in frames. This will cause corrosion and possible freezing damage
in cold climates.
□Use a mild soap and water for normal cleaning. DO NOT use janitorial or alcohol based cleaners.
Some cleaners may be marked as natural, but some ingredients can cause discoloration or have
adverse reaction to your finish.
□Rinse with clean water and dry with a soft, absorbent cloth towel.
□Cushions, slings, and/or an umbrella may be cleaned by hand with a solution of soap and water
with a clean water rinse. Never machine wash as this will result in shrinking or damage. After
cleaning, tip on end and allow to drip dry. Never use a commercial or home dryer to tumble dry
fabric goods.
□Treat frames with liquid wax for maximum protection against UV rays and /or salty, damp air.
□Umbrella should be closed when not in use. Umbrella should be removed and stored in the event
of wind, rain, hail, sleet, snow, or any other inclement weather. To prevent damage to your table,
always use an umbrella base with your umbrella. Store indoors during winter months.
□Use and operation: To prolong the life of your outdoor furniture, cover when not in use. Store
indoors during winter months.
Warranty (continued)

5
Pre-Assembly
PLANNING ASSEMBLY
PLEASE READ COMPLETE USE AND CARE GUIDE PRIOR TO ASSEMBLY!
Identify all parts packed in the carton against the parts list. Remove all protective materials and place
the parts on a nonabrasive surface to avoid scratching. It takes about 45 minutes for three persons to
complete all the assembly.
OBSERVE WEIGHT LIMITS
The recommended weight limit for each item is listed below:
□Swivel Rocker: 300lbs
□Dining Chair: 300lbs
HARDWARE INCLUDED
NOTE: Hardware not shown to actual
size.
Part Description Quantity
AA M8*40mm hex bolt 8
BB M8 washer 16
CC Lock washer 8
DD M8 PE cap 8
EE Nut 8
FF Nut cap 8
GG Steel plate 8
HH Hex wrench 2
NOTE: More than one person may be
required to complete the assembly of this
product.

6
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
A Chair seat 2
B Chair base 2
C Stem bracket 2
□EVERY BOLT NEEDS TO BE USED WITH A WASHER.
□DO NOT FULLY TIGHTEN BOLT UNTIL INDICATED IN STEP 3.
Safety Information
B
C

7
Assembly Instruction
1 Attaching the stem bracket
NOTE: Do not fully tighten the bolts.
□Place the chair seat (A) on a soft, non-abrasive surface carefully.
□Attach the stem bracket (C) to the bottom of cross bar under the chair seat (A) by using M8 hex
bolt (AA). Sequence should be M8 hex bolt (AA), M8 washer (BB), steel plate (GG), Chair seat
(A), Stem bracket (C), steel plate (GG), M8 washer (BB), M8 lock washer (CC) and M8 nut
(EE).
□Check the alignment and then tighten all the bolts and nuts with hex wrench (HH). Cover the
bolts with M8 PE caps (DD) and cover all nuts with M8 nut caps (FF).

8
Assembly Instruction
(continued)
2 Inserting the chair bucket
□Place the chair base (B) on a flat surface and align the stem under the seat frame with the hole
on the base. Push down firmly to connect both pieces. Make sure the seat bottoms out in the
base for safety.

9
Please refer to part number when reordering
Questions, problems, missing parts? Before returning to the store,
call our Customer Service
8 a.m. - 5 p.m., EST, Monday-Thursday
8 a.m. – 4 p.m., EST, Friday
1-866-391-4868
Made in/ Hecho en CHINA
Distributed by Sears, Roebuck and Co., Hoffman Estates, IL60179
See our extensive assortment of outdoor living products on-line
at www.sears.com and www.kmart.com
Retain this manual for future use.

USE AND CARE GUIDE
Sears Lucas 7Pc Dining Set
*Dining Table
Product Code: D71 M34951
UPC Code: 7-22938-10463-5
Date of Purchase: __ / __ / __
La-Z-Boy® is a registered trademark of La-Z-Boy Incorporated and is used under license to BJI, Inc.
© 2015 La-Z-Boy Incorporated.

2
Thank you for your purchase
THANK YOU FOR YOUR PURCHASE!
We are pleased that you have chosen Sears for your outdoor furniture purchase. We hope that you
enjoy the unmatched quality, comfort, and style of your new patio set. Every piece is meticulously
considered all the way down to the smallest details, exclusively for you, by our world class design
team. We know you have a choice when it comes to your patio furniture needs, so from our team to
yours, thank you for letting us be a part of your outdoors.
Table of Contents..........................................2
Safety Information ........................................ 3
Set up your furniture properly...................... 3
Examine your furniture................................ 3
Warranty ........................................................ 3
What is covered .......................................... 3
What is not covered .................................... 3
Care and Maintenance.................................. 4
Pre-Assembly................................................ 5
Planning assembly...................................... 5
Observe weight limits.................................. 5
Hardware included ...................................... 5
Package contents ....................................... 6
Assembly Instruction ................................... 7
Customer Service ......................................... 9
Table of Contents

3
SET UP YOUR FURNITURE
PROPERLY
□Ensure that all parts are assembled
properly and fully tightened as per the
instructions.
□When placing in the desired location,
ensure that all legs are resting on the same
surface. You may adjust the legs levelers
as required to ensure that the item stands
in a rigid position.
EXAMINE YOUR FURNITURE
□Examine occasionally to ensure that there
are no loose parts. If loose parts are found,
they must be retightened fully before
additional use.
THIS IS A RESIDENTIAL WARRANTY AND DOES NOT APPLY FOR
COMMERCIAL USE.
7 YEARS WARRANTY FOR FRAME, 1 YEAR WARRANTY FOR CUSHIONS
WHAT IS COVERED
We warrant the frame to be free of manufacturing defects to the original purchaser for 7 years.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service
center.
This warranty does not cover commercial use, hardware, acts of nature, fire, freezing and abusive
use.
Discoloration or fading of the finish or fabrics as a result of chemicals or spills is not covered.
Glass table top breakage and corrosion or rusting of hardware are not covered.
Safety Information
WARNING:
1. Do not crawl, stand, or sit on table tops.
2. Do not set or lay heavy items on table
tops.
3. Avoid extreme hot & cold items being
placed on table tops.
CAUTION: Read all of the instructions in
this manual before you begin assembly.
Failure to do so may result in faulty
assembly and potential injury!
Warranty

4
In addition, purchase parts are not covered under this warranty.
Proof of purchase (dated register receipt) is required for warranty claims.
We reserve the right to make substitutions with similar merchandise, if the model in question is no
longer in production.
For a copy of our full limited warranty, please contact our customer service team below.
Contact the Customer Service Team at 1-866-391-4868 or visit www.bjifurniture.com.
Care and Maintenance
□Do not allow water to build up in frames. This will cause corrosion and possible freezing damage
in cold climates.
□Use a mild soap and water for normal cleaning. DO NOT use janitorial or alcohol based cleaners.
Some cleaners may be marked as natural, but some ingredients can cause discoloration or have
adverse reaction to your finish.
□Rinse with clean water and dry with a soft, absorbent cloth towel.
□Cushions, slings, and/or an umbrella may be cleaned by hand with a solution of soap and water
with a clean water rinse. Never machine wash as this will result in shrinking or damage. After
cleaning, tip on end and allow to drip dry. Never use a commercial or home dryer to tumble dry
fabric goods.
□Treat frames with liquid wax for maximum protection against UV rays and /or salty, damp air.
□Umbrella should be closed when not in use. Umbrella should be removed and stored in the event
of wind, rain, hail, sleet, snow, or any other inclement weather. To prevent damage to your table,
always use an umbrella base with your umbrella. Store indoors during winter months.
□Use and operation: To prolong the life of your outdoor furniture, cover when not in use. Store
indoors during winter months.
Warranty (continued)

5
Pre-Assembly
PLANNING ASSEMBLY
PLEASE READ COMPLETE USE AND CARE GUIDE PRIOR TO ASSEMBLY!
Identify all parts packed in the carton against the parts list. Remove all protective materials and place
the parts on a nonabrasive surface to avoid scratching. It takes about 45 minutes for 3 persons to
complete all the assembly.
NOTE: More than one person may be
required to complete the assembly of this
product.
OBSERVE WEIGHT LIMITS
The recommended weight limit for each item is listed below:
□Stationary dining chair:300lbs
□Swivel rocker: 300lbs
HARDWARE INCLUDED
NOTE: Hardware not shown to actual
size.
Part Description Quantity
AA M6*20mm Hex Bolt 16
BB M6 washer 16
CC M6 PE cap 16
DD Hex wrench 1

6
PACKAGE CONTENTS
□EVERY BOLT NEEDS TO BE USED WITH A WASHER.
□DO NOT FULLY TIGHTEN BOLT UNTIL INDICATED IN STEP 1.
Pre-Assembly (continued)
Part Description Quantity
A Table rim 1
B Table leg 4
C Tile in small size 2
D Tile in large size 4
Safety Information

7
Assembly Instruction
1 Attaching the table rim
□Carefully place the table rim (A) upside down on a soft, flat and non-abrasive surface.
□Attach the leg (B) to the table rim (A) using hex bolt (AA) and washers (BB).
□Tighten all M6 hex bolts (AA) with the hex wrench (DD). Attach the M6 PE caps (CC).

8
Assembly Instruction
(continued)
2 Replacing the ceramic tile top
WARNING:
1. Do not crawl, stand, or sit on tile table
tops.
2. Do not set or lay heavy items on tile table
tops.
3. Avoid extreme hot &cold items being
placed on tile table tops.
□With the assistance of another person carefully turn the table over and set it down on its
legs.
□Place the tile top (C) & (D) onto the table.
□The dining table is ready for your enjoyment.

9
Please refer to part number when reordering
Questions, problems, missing parts? Before returning to the store,
call our Customer Service
8 a.m. - 5 p.m., EST, Monday-Thursday
8 a.m. – 4 p.m., EST, Friday
1-866-391-4868
Made in/ Hecho en CHINA
Distributed by Sears, Roebuck and Co., Hoffman Estates, IL60179
See our extensive assortment of outdoor living products on-line
at www.sears.com and www.kmart.com
Retain this manual for future use.
