LD LDDAVE10G2 User manual

1
LD DAVE G2 SERIES
PORTABLE PA SYSTEM ACTIVE
LDDAVE10G2 / LDDAVE12G2 / LDDAVE15G2
USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D`UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI

2
Thank you for choosing LD-Systems!
We have designed this product to operate reliably over many years. Therefore LD-Systems guarantees for high
quality products with its name and many years of experience as a producer.
Please, take a few moments to read these instructions carefully, as we want you to enjoy your new LD-Systems
products quickly and to the fullest.
For information about LD-Systems check out our website WWW.LD-SYSTEMS.COM
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI

3
LD DAVE G2 SERIES
PORTABLE PA SYSTEM ACTIVE
LDDAVE10G2 / LDDAVE12G2 / LDDAVE15G2
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI

4
PREVENTIVE MEASURES:
1. Please read the attached safety instructions as well as the following instructions carefully.
2. Please keep all the instructions.
3. Please use the device only as intended.
4. Please respect the valid waste management rules. Please deliver the packaging divided into plastic and paper/
cardboard to the recycling management.
5. Please refer all servicing to qualified personel only, if the device is damaged, exposed to liquid/rain or if it does
not operate normally.
6. Please, do not expose to any kind of heat such as ovens, radiators, or any other devices (incl. amplifiers).
Please check for enough distance between amplifiers and walls, racks, etc. to prevent overheating.
7. After connection please check the wiring to prevent any kind of accident or damage. Please never use any
kind of damaged cable and wiring.
8. Only use authorized and stable stands, brackets, shelfs, tables etc.. for installations. Please check for adequate
stability against collapse.
CAUTION:
To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer
servicing to qualified personnel.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of uninsulated “dangerous voltage” within the product´s enclosure that may be of
sufficient magnitude to constitute a risk to persons.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
CAUTION! HIGH VOLUME!
You will operate this system for professional use. Therefore the commercial use of this equipment is liable to the
rules and regulations of the Accident Prevention & Insurance Association of your industry sector. Adam Hall as a
manufacturer is bound to inform you formally about the existence of eventual sanitary risks.
These speakers are able to induce high acoustic sound pressure levels. 85 db is by law the maximum audio
pressure level which your ear can be exposed to during a work day. It was set according to the technical exper-
tise of the occupational medicine as a basis for the noise rating level. Higher sound levels or longer exposition
times could damage your ear. The time of exposition by higher sound pressure levels should be shortened in
order to prevent from ear damages. Here are a few reliable warning signals which show that you have exposed
yourself for a too long period to excessive sound pressure levels:
- You hear bell- or whistling sounds!
- You have the impression that you can’t hear high tones anymore!
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI

5
INSTALLATION & OPERATING:
TRANSPORT AND INSTALLATION
The powered system LD DAVE 10G² /12G² / 15G² is a very compact system and it can be easily moved. During
operation the systems must be placed on to the rubber feet. Please do never operate the items standing on
any kind of transportation board. Otherwise the system can be moved uncontrolled.This may cause accidents
or damaging.
Please check for enough distance between integrated amplifer and walls, racks etc. to prevent overheating for sure.
Please take care for a accurate wiring for the power wiring as for the speaker / input wiring. Please use only
undamaged cables of an adequate size (min. 2 x 1.5 mm² for speaker connection) as well as only completely
unrolled cable reels.
Please check the wiring for any kind of trip hazard etc. to prevent any kind of accidents or damage (Gaffa-Tape).
Please do not install the items directly beside an edge like a stage border. If a stand is used to place a satellite
upon the item please make sure to use only undameged stands (Ø 36 mm) fitting correctly into the support. It is
recommended to switch the system to ON as the last one and to OFF as the first one to prevent start-up noise
caused by a connected devices like mixer etc..
SATELLITES
The satellites of the LD DAVE 10G² /12G² / 15G² system should be placed on a stabile speaker stand (Speaker
Stand SPS56S recommended) or on the Speaker pole extendable Art. No. SPS822 with T-BAR Art. No. SPS823
OPERATING
The main level of the LD DAVE 10G² /12G² / 15G² amplifier can be adjusted as well as the subwoofer level can be
adjusted to the main level. The final main level should be adjusted at the source device (mixer etc.). The available
conectors are an asymmetrical input (RCA) and a symmetrical input (6.3 mm XLR). Please do NEVER use both
inputs simultaneously! This may cause a damaging of the connected devices!
LDDAVE 10G2
With the foward angled speaker
stand (5°) the satellites can be pos-
tioned in a good height making a
wide music reproduction possible.
LDDAVE 12G2 & 15G2
Die Satelliten des LD DAVE 12G² 15G² Systems sollten auf stabile Ständer
(empfohlen: Speaker Stand SPS56S) aufgestellt werden. Mit Hilfe des schwenk-
baren Boxenflansches am Satelliten (zum Patent angemeldet) kann dieser in +/-
4°Schritten ausgerichtet werden. (max.18°)
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI

6
PANEL DAVE10G2:
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI
123
6
87
5
4

7
PANEL DAVE10G2:
1MAIN LEVEL ADJUST
Preset of the main level of the system - subwoofer will be adjusted too, corresponding the preset of the SUB
LEVEL.
2SUB PHASE
Phase invertation switch to invert the Phase of the Subwoofer (0° / 180°) if necessary due to an difficult
installation.
3SUB LEVEL ADJUST
Preset subwoofer level proportionally to the satellite level. We recommend at the standard setting 12:00
o’clock level.
4INPUT RCA (LEFT / RIGHT)
Asymmetrical Line Input for RCA jack
5INPUT XLR (LEFT / RIGHT)
Symetrical Line Input for XLR connectors.
6SPEAKER OUTPUT (LEFT / RIGHT)
Speakon® compatible speaker output. Minimum impedance speaker 4 ohms. Used pins are: 1+ / 1-.
7POWER SWITCH
ON / OFF switch. Please switch connected devices to ON first and to OFF after switching the system.
8POWER CONNECTION SEAT
Power connection seat 240 V (IEC power connector) and fuse seat. Replacement of fuse only if power
connection is disconnected. If fuse blows repeatedly please contact authorized personel for servicing.
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI

8
PANEL DAVE12G2 & DAVE15G2:
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI
1
4
6
5
7
8
10
9
23

9
1MAIN LEVEL ADJUST
Preset of the main level of the system - subwoofer will be adjusted too, corresponding the preset of the SUB
LEVEL.
2SUB PHASE
Phase invertation switch to invert the Phase of the Subwoofer (0° / 180°) if necessary due to an difficult
installation.
3SUB LEVEL ADJUST
Preset subwoofer level proportionally to the satellite level. We recommend at the standard setting 12:00
o’clock level.
4PROTECT LED
Flashes RED if device switches to protect mode: Check cable for shortening or incorrect connection.
If protect mode continues please contact authorized personel for servicing.
5INPUT RCA (LEFT / RIGHT)
Asymmetrical Line Input for RCA jack.
6INPUT XLR / 3.6 mm jack (LEFT / RIGHT)
Symetrical Line Input for XLR connectors and 6.3 mm jacks.
7LINE DIRECT OUTPUT (LEFT / RIGHT)
Direct symetrical Line Input for XLR connectors.
8SPEAKER OUTPUT (LEFT / RIGHT)
Speakon® compatible speaker output. Minimum impedance speaker 4 ohms. Used pins are: 1+ / 1-.
9POWER SWITCH
ON / OFF switch. Please switch connected devices to ONfirst and to OFF after switching the system.
10 POWER CONNECTION SEAT
Power connection seat 240 V (IEC power connector) and fuse seat. Replacement of fuse only if power
connection is disconnected. If fuse blows repeatedly please contact authorized personel for servicing.
PANEL DAVE12G2 & DAVE15G2:
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI

10
LDDAVE 10G2LDDAVE 12G2LDDAVE 15G2
Model Name / Type: Subwoofer / Bass
Reflex
System / Satellite /
Sealed
Subwoofer / Bass
Reflex
System / Satellite /
Sealed
Subwoofer / Bass
Reflex
System / Satellite /
Sealed
Frequency Response System (Hz): 45 - 19000 40 - 19000 35 - 19000
Power Output RMS (W): 150 + 2 x 100 300 + 2 x 120 400+ 2 x 150
Amplification: Class A/B Class A/B Class A/B
Sensitivity (1W/ 1m) System (dB): 97 98 99
Max. SPL System (dB): 119 123 125
Impedance (Ω): - 4 - 4 - 4
LF Transducer : 10“ 5,25“ 12“ 6,5“ 15“ 8“
HF Transducer: - 1“ - 1“ - 1“
Dispersion: - 70° x 70° - 90° x 40° - 90° x 40°
Connectors: Input: XLR / 6,3mm
jack (combo), RCA,
Output: XLR Powered
output for passive
Speaker: DAVE12
Satellites
1 x SPKn Input: XLR / 6,3mm
jack (combo), RCA,
Output: XLR Powered
output for passive
Speaker: DAVE12
Satellites
1 x SPKn Input: XLR / 6,3mm jack
(combo), RCA, Output:
XLR Powered output
for passive Speaker:
DAVE15 Satellites
1 x SPKn
Controls: Volume, Sub Level,
180° Phase Reverse,
ON/OFF Switch
- Volume, Sub Level,
180° Phase Reverse,
ON/OFF Switch
- Volume, Sub Level,
180° Phase Reverse,
ON/OFF Switch
-
Indicators: Power, Protect - Power, Protect - Power, Protect -
Cabinet material: Painting / 18 mm
Plywood
Painting / 15 mm
Plywood
Painting / 18 mm
Plywood
Painting / 15 mm
Plywood
Painting / 18 mm
Plywood
Painting / 15 mm
Plywood
Dimensions W x H x D (mm): 345 x 430 x 460 200 x 300 x 230 450 x 515 x 520 250 x 400 x 250 450 x 570 x 635 250 x 400 x 250 mm
Weight (kg): 21 5 31,5 8,5 42,5 10,5 kg
Features: Ergonomic milled
handles, Threaded
flange (M20), Limiter
Ergonomic milled
handles, Stand support
adjustable vertically
(SM707)
Ergonomic milled
handles, Threaded
flange (M20), Limiter
Ergonomic milled
handles, Stand
support adjustable
vertically (SM707)
Ergonomic milled hand-
les, Threaded flange
(M20), Limiter
Ergonomic milled
handles, Stand support
adjustable vertically
(SM707)
SPECIFICATIONS:
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI
Since all our products are constantly controlled and improved,
technical changes are possible without prior notice.

11
LDDAVE 10G2LDDAVE 12G2LDDAVE 15G2
Model Name / Type: Subwoofer / Bass
Reflex
System / Satellite /
Sealed
Subwoofer / Bass
Reflex
System / Satellite /
Sealed
Subwoofer / Bass
Reflex
System / Satellite /
Sealed
Frequency Response System (Hz): 45 - 19000 40 - 19000 35 - 19000
Power Output RMS (W): 150 + 2 x 100 300 + 2 x 120 400+ 2 x 150
Amplification: Class A/B Class A/B Class A/B
Sensitivity (1W/ 1m) System (dB): 97 98 99
Max. SPL System (dB): 119 123 125
Impedance (Ω): - 4 - 4 - 4
LF Transducer : 10“ 5,25“ 12“ 6,5“ 15“ 8“
HF Transducer: - 1“ - 1“ - 1“
Dispersion: - 70° x 70° - 90° x 40° - 90° x 40°
Connectors: Input: XLR / 6,3mm
jack (combo), RCA,
Output: XLR Powered
output for passive
Speaker: DAVE12
Satellites
1 x SPKn Input: XLR / 6,3mm
jack (combo), RCA,
Output: XLR Powered
output for passive
Speaker: DAVE12
Satellites
1 x SPKn Input: XLR / 6,3mm jack
(combo), RCA, Output:
XLR Powered output
for passive Speaker:
DAVE15 Satellites
1 x SPKn
Controls: Volume, Sub Level,
180° Phase Reverse,
ON/OFF Switch
- Volume, Sub Level,
180° Phase Reverse,
ON/OFF Switch
- Volume, Sub Level,
180° Phase Reverse,
ON/OFF Switch
-
Indicators: Power, Protect - Power, Protect - Power, Protect -
Cabinet material: Painting / 18 mm
Plywood
Painting / 15 mm
Plywood
Painting / 18 mm
Plywood
Painting / 15 mm
Plywood
Painting / 18 mm
Plywood
Painting / 15 mm
Plywood
Dimensions W x H x D (mm): 345 x 430 x 460 200 x 300 x 230 450 x 515 x 520 250 x 400 x 250 450 x 570 x 635 250 x 400 x 250 mm
Weight (kg): 21 5 31,5 8,5 42,5 10,5 kg
Features: Ergonomic milled
handles, Threaded
flange (M20), Limiter
Ergonomic milled
handles, Stand support
adjustable vertically
(SM707)
Ergonomic milled
handles, Threaded
flange (M20), Limiter
Ergonomic milled
handles, Stand
support adjustable
vertically (SM707)
Ergonomic milled hand-
les, Threaded flange
(M20), Limiter
Ergonomic milled
handles, Stand support
adjustable vertically
(SM707)
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI
Since all our products are constantly controlled and improved,
technical changes are possible without prior notice.

12
ACCESSORIES FOR TRANSPORT & INSTALLATION:
SPEAKER STAND
Art. No. SPS56B /
SPS56S
T-BAR
Art. No. SPS823
SPEAKER POLE
EXTENDABLE
Art. No. SPS822
BOXCOVER
Art. No. LD10SATBAG / LDD10SUBBAG
Art. No. LD12SATBAG / LDD12SUBBAG
Art. No. LD15SATBAG / LDD15SUBBAG
CASTOR BOARD
INCL. FIXING BELT
Art. No. 38112
Art. No. 38115
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI

13
LIMITED WARRANTY
This Limited Warranty applies to the Adam Hall, LD Systems, Defender, Palmer and Eminence branded products.
The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies, additional
independent warranty claims towards Adam Hall.
Adam Hall warrants that the Adam Hall product you have purchased from Adam Hall or from an Adam Hall autho-
rized reseller is free from defects in materials or workmanship under normal use for a period of 2 or 3 years from
the date of purchase.
The Limited Warranty Period starts on the date of purchase. In order to receive warranty services you are required
to provide proof of the purchase date. Your dated sales or delivery receipt, showing the date of purchase, is your
proof of the purchase date. Should products of the brands named above be in need of repair within the limited war-
ranty period, you are entitled to warranty services according to the terms and conditions stated in this document.
This Limited Warranty extends only to the original purchaser of this Adam Hall branded product and is not transfe-
rable to anyone, who obtains ownership of the Adam Hall branded product from the original purchaser. During the
Limited Warranty Period,Adam Hall will repair or replace the defective component parts or the product.All compo-
nent parts or hardware products removed under this Limited Warranty become the property of Adam Hall.
In the unlikely event that your Adam Hall product has a recurring failure, Adam Hall, at its discretion, may elect to
provide you with a replacement unit of Adam Hall´s choice that is at least equivalent to your Adam Hall branded
product in hardware performance.
Adam Hall does not warrant that the operation of this product will be uninterrupted or error-free. Adam Hall is not
responsible for damage that occurs as a result of your failure to follow the instructions included with the Adam
Hall branded product.
This Limited Warranty does not apply,
- to wear parts (e.g. accumulator)
- to any product from which the serial number has been removed or that has been damaged or rendered defective
as the result of an accident
- in case of, misuse, abuse, or other external causes
- by operation outside the usage parameters stated in the user´s documentation shipped with the product
- by use of spare parts not manufactured or sold by Adam Hall
- by modification or service by anyone other than Adam Hall
These terms and conditions constitute the complete and exclusive warranty agreement between you and Adam
Hall regarding the Adam Hall branded product you have purchased.
MANUFACTURER´S DECLARATIONS:
CASTOR BOARD
INCL. FIXING BELT
Art. No. 38112
Art. No. 38115
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI

14
LIMITATION OF LIABILITY
If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy
shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited
to the lesser of the price you have paid for the product or the cost of repair or replacement of any hardware
components that malfunction in conditions of normal use.
Adam Hall is not liable for any damages caused by the product or the failure of the product, including any lost
profits or savings or special, incidental, or consequential damages. Adam Hall is not liable for any claim made by
a third party or made by you for a third party.
This limitation of liability applies whether damages are sought, or claims are made, under this Limited Warranty
or as a tort claim (including negligence and strict product liability), a contract claim, or any other claim. This limi-
tation of liability cannot be waived or amended by any person. This limitation of liability will be effective even if
you have advised Adam Hall of an authorized representative of Adam Hall of the possibility of any such damages.
This limitation of liability however, will not apply to claims for personal injury.
This Limited Warranty gives you specific legal rights. You may also have other rights that may vary from state to
state or from country to country. You are advised to consult applicable state or country laws for a full determina-
tion of your rights.
REQUESTING WARRANTY-SERVICE
To request warranty service for the product, contact Adam Hall or the Adam Hall authorized reseller from which
you purchased the product.
EC DECLARATION OF CONFORMITY
These devices meet the essential requirements and further relevant specifications of Directives 2004/108/EC
(EMC) and 2006/95/EC (LVD). For more information, see www.adamhall.com.
CORRECT DISPOSAL OF THIS PRODUCT (ELECTRICAL WASTE)
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other household
wastes at the end of its working life. To prevent possible harm to the environment or human health from uncon-
trolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details on where and how they can recycle this item in an enviromentally friendly manner.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI

15
WEEE-DECLARATION
Your LD-Systems product was developed and manufactured with high quality materials and components wich
can be recycled and/or reused. This symbol indicates that electrical and electronic equipment must be disposed
of separately from normal waste at the end of its operational lifetime.
Please dispose of this product by bringing it to your local collection point or recycling centre for such equipment.
This will help to protect the environment in which we all live.
BATTERIES AND ACCUMULATORS
The supplied batteries or rechargeable batteries can be recycled. Please dispose of them as special waste or return
them to your specialist dealer. In order to protect the environment, only dispose exhausted batteries.
Adam Hall GmbH, all rights reserved. The technical data and the functional product characteristics can be subject
to modifications. The photocopying, the translation, and all other forms of copying of fragments or of the integral-
ity of this user’s manual is prohibited.
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI

16
Sie haben die richtige Wahl getroffen!
Diese LD-Systems Produkte werden Sie lange Jahre durch Zuverlässigkeit, Wirtschaftlichkeit und einfaches
Handling überzeugen. Dafür garantiert LD-Systems mit seinem Namen und seiner in vielen Jahren erworbenen
Kompetenz als Hersteller hochwertiger Geräte.
Nehmen Sie sich nun ein paar Minuten Zeit, diese Anleitung zu lesen. Wir möchten, dass Sie einfach
und schnell in den Genuss dieser Technik kommen.
Mehr Informationen zu LD-SYSTEMS finden Sie auf unserer Internetseite WWW.LD-SYSTEMS.COM
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI

17
LD DAVE G2 SERIES
PORTABLE PA SYSTEM ACTIVE
LDDAVE10G2 / LDDAVE12G2 / LDDAVE15G2
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI

18
1. Bitte beachten Sie die Sicherheitshinweise und studieren Sie diese Anleitung sorgfältig.
2. Bewahren Sie alle Hinweise und Anleitungen sicher auf.
3. Verwenden Sie das Gerät nur in der vorgesehenen Art und Weise.
4. Beachten Sie die in Ihrem Land geltenden Entsorgungsgesetze. Trennen Sie bei der Entsorgung bitte Plastik
und Papier bzw. Kartonagen von einander.
5. Sollte Ihr Gerät nicht mehr ordnungsgemäß funktionieren, Flüssigkeiten ausgesetzt worden oder auf sonstige Art
und Weise beschädigt sein, überlassen Sie bitte jegliche Reparaturen ausschließlich autorisiertem Fachpersonal.
6. Halten Sie das Gerät von Hitzequellen wie z.B. Ofen, Heizkörper, oder sonstige Quellen (auch Verstärker) fern.
Sorgen Sie dafür dass das Gerät immer so installiert ist, dass es ausreichend gekühlt wird und nicht überhitzt.
7. Überprüfen Sie alle Verbindungen nach dem Sie das Gerät angeschlossen haben, um Schäden oder Unfälle zu
vermeiden.
8. Verwenden Sie ausschließlich stabile und passende Stative bzw. Befestigungen, wenn das Gerät fest installiert
wird. Stellen Sie sicher, dass das Gerät sicher installiert ist und nicht herunterfallen kann.
ACHTUNG:
Entfernen Sie niemals die Abdeckung, da sonst die Gefahr eines elektrischen Schocks besteht.
Im Inneren des Gerätes befinden sich keine Teile, die vom Bediener gewartet oder repariert werden können.
Lassen Sie Reparaturen ausschließlich von qualifiziertem Servicepersonal durchführen.
Dieses Symbol warnt vor nichtisolierten, gefährlichen Spannungen im Geräteinneren,
die einen gefährlichen Schlag verursachen können.
Dieses Symbol kennzeichnet wichtige Bedienungs- und Wartungshinweise.
Vorsicht! Hohe Lautstärke!
Diese Übertragungsanlage wird von Ihnen professionell eingesetzt. Daher unterliegt der Gebrauch bei gewerbli-
cher Nutzung den Regeln und Vorschriften der zuständigen Berufsgenossenschaft. Adam Hall als Hersteller ist
daher verpflichtet, Sie auf möglicherweise bestehende gesundheitliche Risiken ausdrücklich hinzuweisen.
Mit diesen Lautsprechern können hohe Schalldrücke erzeugt werden. 85db ist der Schalldruck, der laut Gesetz
als maximal zulässiger Wert über die Dauer eines Arbeitstages auf Ihr Gehör einwirken darf. Er wird nach den
Erkenntnissen der Arbeitsmedizin als Berurteilungspegel zu Grunde gelegt. Höhere Lautstärken oder längere
Einwirkzeit können Ihr Gehör schädigen. Bei höheren Lautstärken muss die Hörzeit verkürzt werden, um eine
Schädigung auszuschließen. Sichere Warnsignale dafür, dass Sie sich zu lange zu lautem Geräusch ausgesetzt
haben, sind:
- Sie hören Klingel- oder Pfeifgeräusche in den Ohren!
- Sie haben den Eindruck, hohe Töne nicht mehr wahrzunehmen!
VORSICHTSMASSNAHMEN:
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT O PEN
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI

19
AUFSTELLUNG, ANSCHLUSS UND INBETRIEBNAHME:
TRANSPORT UND AUFSTELLUNG
Das Aktivsystem LD DAVE 12G² kann sehr leicht mit Hilfe des empfohlenen LD Sytems Castorboards
(Art. Nr.: 38112) transportiert werden. Zum Betrieb muss der Subwoofer auf die Gummifüsse gestellt werden. Bitte
nehmen Sie das System NIE auf auf einem Transportwagen stehend in Betrieb! Es besteht die Gefahr einer unkon-
trollierten Bewegung des ganzen Gerätes. Dieses kann zu Unfällen und Beschädigungen führen. Der eingebaute
Verstärke muss in mindestens 50 cm Abstand zu Wänden, Racks etc. aufgestellt werden, um eine Überhitzung
sicher zu vermeiden.
Bitte achten Sie auf eine einwandfreie Verkabelung sowohl für die Stromzufuhr als auch mit den Lautsprechern
sowie mit dem angeschlossenen Zuspielgerät (Mixer etc.). Verwenden Sie nur unbeschädigte Kabel mit ausreichen-
dem Querschnitt (mindestens 2 x 1.5 mm² für die Lautsprecher) sowie nur vollständig abgewickelte Kabelrollen.
Verlegen Sie die Kabel so, das keine Stolperfallen entstehen können (Gaffa-Tape).
Das Gerät sollte nie direkt an eine Kante gestellt werden (z. B. Bühnenrand). Wird der Hochständerflansch verwendet
dürfen nur einwandfreie, unbeschädigte Standrohre (Ø 36 mm) verwendet werden.
Es empfiehlt sich, das Gerät immer als letztes ein- sowie als erstes auszuschalten, um laute Ein- und Ausschalt-
knackser durch die angeschlossenen Geräte zu vermeiden.
DIE SATELLITEN
Die Satelliten des LD DAVE 12G² Systems sollten auf stabile Ständer (empfohlen: Speaker Stand SPS56S) aufge-
stellt werden. Mit Hilfe des schwenkbaren Boxenflansches am Satelliten (zum Patent angemeldet) kann dieser in
+/- 4°Schritten ausgerichtet werden. (max.18°)
OPERATING
The main level of the LD DAVE 10G² /12G² / 15G² amplifier can be adjusted as well as the subwoofer level can be
adjusted to the main level. The final main level should be adjusted at the source device (mixer etc.). The available
conectors are an asymmetrical input (RCA) and a symmetrical input (6.3 mm XLR). Please do NEVER use both
inputs simultaneously! This may cause a damaging of the connected devices!
LDDAVE 10G2
With the foward angled speaker
stand (5°) the satellites can be pos-
tioned in a good height making a
wide music reproduction possible.
LDDAVE 12G2 & 15G2
Die Satelliten des LD DAVE 12G² 15G² Systems sollten auf stabile Ständer
(empfohlen: Speaker Stand SPS56S) aufgestellt werden. Mit Hilfe des schwenk-
baren Boxenflansches am Satelliten (zum Patent angemeldet) kann dieser in
+/- 4°Schritten ausgerichtet werden. (max.18°)
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI

20
PANEL DAVE10G2:
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKI
123
6
87
5
4
