LD EB 82 User manual

LD STINGER SERIES
LD EB 82/102/122/152 -ACTIVE & PASSIVE SYSTEMS
USER´S MANUAL
BEDIENUNGSANLEITUNG
MODE D´EMPLOI

Thank you for choosing LD-Systems!
We have designed this product to operate reliably over many years. Therefore LD-Systems guarantees for high
quality products with its name and many years of experience as a producer.
Please, take a few moments to read these instructions carefully, as we want you to enjoy your new LD-Systems
products quickly and to the fullest.
For information about LD-Systems check out our website WWW.LD-SYSTEMS.COM
02
ENGLISHDEUTSCHFRANCAIS

03
ENGLISHDEUTSCHFRANCAIS
LD STINGER SERIES
LD EB 82/102/122/152 -ACTIVE & PASSIVE SYSTEMS

04
ENGLISHDEUTSCHFRANCAIS
PREVENTIVE MEASURES:
1. Please read the attached safety instructions as well as the following instructions carefully.
2. Please keep all the instructions.
3. Please use the device only as intended.
4. Please respect the valid waste management rules. Please deliver the packaging divided into plastic and
paper/ cardboard to the recycling management.
5. Please refer all servicing to qualified personel only if the device is damaged, exposed to liquid/rain or if it does
not operate normally.
6. Please, do not expose to any kind of heat such as ovens, radiators, or any other devices (incl. amplifiers).
Please check for enough distance between amplifiers and walls, racks, etc. to prevent overheating.
7. After connection please check the wiring to prevent any kind of accident or damage.
Please never use any kind of damaged cable and wiring.
8. Only use authorized and stable stands, brackets, shelfs, tables etc.. for installations. Please check for
adequate stability against collapse.
CAUTION:
To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer
servicing to qualified personnel.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product´s enclosure that may be
of sufficient magnitude to constitute a risk to persons.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
CAUTION! HIGH VOLUME!
You will operate this system for professional use. Therefore the commercial use of this equipment is liable to the
rules and regulations of the Accident Prevention & Insurance Association of your industry sector. Adam Hall as a
manufacturer is bound to inform you formally about the existence of eventual sanitary risks.
These speakers are able to induce high acoustic sound pressure levels. 85 db is by law the maximum audio
pressure level which your ear can be exposed to during a work day. It was set according to the technical exper-
tise of the occupational medicine as a basis for the noise rating level. Higher sound levels or longer exposition
times could damage your ear. The time of exposition by higher sound pressure levels should be shortened in
order to prevent from ear damages. Here are a few reliable warning signals which show that you have exposed
yourself for a too long period to excessive sound pressure levels:
- You hear bell- or whistling sounds!
- You have the impression that you can’t hear high tones anymore!
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT O PEN

05
ENGLISHDEUTSCHFRANCAIS
INSTALLATION & PLACEMENT:
INTRODUCTION
The LDEB Series was designed in response to customer demands for high-quality multi-functional speakers. They are
equipped with selected components; feature a custom crossover and a very complete protection circuit.
MOUNTING OF THE FLYWARE COMPONENTS
The LDEB122/152 are designed to allow the mounting of the Adam Hall 5720 flyware components. To mount these
components on the speaker first remove the flyware covers (“BMS Inside” and “Powered by Eminence” banners). With
the passing mounting screws you can install the Flyware rails (5720) in the pre-drilled cutouts. We also recommend
the use of back plates on the inner side of the speaker. In order to fit those back plates (like the 5730) on the speaker
box you must unscrew the front grid and build out the woofer.
Security advice: Adam Hall assumes no liability for the mounting of flyware components!
APPLICATION NOTICE FOR SM707 ADJUSTABLE STANd RECEPTACLE
(LdEB122/152 PASSIvE ANd ACTIvE):
The built-in, patented SM707 adjustable speaker stand receptacle offers unparalleled possibilities for adjustment +/-
16° in 4° increments. To do this, simply lift the cabinet slightly on the speaker stand, causing the set angle to loosen,
and lower the cabinet on the stand again to cause it to engage at the desired angle (see drawing).
Centre of Rotation
+/- 16°
Lift cabinet
Attention! Please hold the
cabinet rmly!
Turn the cabinet into the
required angle.
Lower the cabinet.

MIC GAIN
MIC
IN
LINE GAIN
VOLUME
TREBLE
BASS
STINGER 12A
LINE
IN
LINE
OUT
SPEAKER
OUT
8 Ω ONL Y
06
ENGLISHDEUTSCHFRANCAIS
ACTIVE SYSTEMS FEATURES:
12
11
10
9
12
3
4
6
5
7
15 8
14
13

07
ENGLISHDEUTSCHFRANCAIS
1MICROPHONE INPUT
Balanced XLR microphone input.
2GAIN MICRO
Adjust the input sensitivity of the microphone input with this gain control. Please regard that microphones
needing phantom power (condenser microphones for example) will not work at these inputs since they do
not supply a phantom power.
3LINE INPUTS
Balanced XLR line input (mono).
4GAIN LINE
Adjust the input sensitivity of the line input with this gain control.
5LINE OUTPUTS
Balanced XLR output (mono). The two inputs (mic and line inputs) are mixed together according to the adjus-
ted levels and sent to this output. You can use this output to split the mixed inputs out to another active
speaker or amplifier.
6VOLUME MASTER
This is the master volume control. You can adjust the overall volume of the amplifier–unit.
7TREBLE
The treble control allows you to pad or boost high frequencies by -12dB respectively +12dB. (This function is
not available on the 8” and 10” models)
8 BASS
The bass control allows you to pad or boost low frequencies by -12dB respectively +12dB.
9 PROTECT
This LED lights up in case of a over-heating of the systems. The amplification module is then automatically
shut off. If this problem should occur often please contact your dealer or the servicing department.
10 CLIP
This LED indicates the Class D power amps’ peak limiter has engaged to attenuate a maximum output
voltage excursion, or put simply, a clipping signal.
11 SIGNAL
This LED lights up when the unit detects an incoming signal
ACTIVE SYSTEMS FEATURES:

ACTIVE SYSTEMS FEATURES:
12 POWER
The power LED lights up green when the device is turned on. The red Clip-LED starts blinking when the
amplifier reaches its clipping threshold. This should be avoided, to do so, reduce the master level (control
nr. 7 on the diagram) until the LED stops blinking.
13 VOLEX POWER PLUG
Special lockable mains socket (Volex Power Plug). Connect an IEC plug to this socket. The Fuse can be found
in the little compartment directly below this socket. To change fuses, pull out the little drawer. You will find
two fuses, one is in use and the other spare.
IMPORTANT NOTE: Only use suitable fuses. Never bridge the fuse contacts.
14 POWER SWITCH
Mains switch. Before switching on the power to the unit, all level controls should be set to minimum. Other
wise, microphones already connected to the system may cause undesired feedback.
15 SPEAKON OUTPUT
This additional speaker output (no impedance < 8) is split out from the amplification unit. That means you
can connect a passive speaker (e.g. the passive version of this speaker, the LDE122) to this output and thus
drive two speakers with a single amplifierunit.
08
ENGLISHDEUTSCHFRANCAIS

09
ENGLISHDEUTSCHFRANCAIS
PASSIVE SYSTEMS FEATURES:
1SPEAKON INPUT
2SPEAKON OUTPUT
The input signal is looped
through to this output.
12” / 1” Multifunctional Cabinet
350 W RMS / 8 Ω
INPUT
OUTPUT
1
2

10
ENGLISHDEUTSCHFRANCAIS
82 “ PASSIVE 102“ PASSIVE 122“ PASSIVE 152“ PASSIVE
Type Bassreflex Bassreflex Bassreflex Bassreflex
LF Transducer 8“ Woofer 10“ Woofer 12“ Woofer 15“ Woofer
HF Transducer 1“ CD-Horn 1“ CD-Horn 1“ CD-Horn 1“ CD-Horn
Compression driver BMS5424 BMS5424 BMS5424 BMS5424
Dimensions (mm) 287 x 450 x 290 332 x 500 x 292 390 x 570 x 370 500 x 650 x 438
Weight kg 9 12 19 25
Impendance ohm 8 8 8 8
Rated System Power
(continuous / peak) (W) 200 / 400 250 / 500 350 / 700 500 / 1000
SPL 1W/1m 95 96 99 100
SPL max dB 118 120 124 127
Frequency range Hz 70-19.000 65-19.000 58-19.000 50-19.000
HF horn dispersion ° 100 x 110 100 x 110 100 x 110 100 x 110
In-Output 2 x SPKn
Features
Ergonomic milled handles,
LDEB82 / LDEB102: aluminium stand support
LDEB122 / LDEB152: stand support adjustable vertically SM707
Rubber feet
SPECIFICATIONS PASSIVE:

SPECIFICATIONS ACTIVE:
11
ENGLISHDEUTSCHFRANCAIS
82 “ PASSIVE 102“ PASSIVE 122“ PASSIVE 152“ PASSIVE
Type Bassreflex Bassreflex Bassreflex Bassreflex
LF Transducer 8“ Woofer 10“ Woofer 12“ Woofer 15“ Woofer
HF Transducer 1“ CD-Horn 1“ CD-Horn 1“ CD-Horn 1“ CD-Horn
Compression driver BMS5424 BMS5424 BMS5424 BMS5424
Dimensions (mm) 287 x 450 x 290 332 x 500 x 292 390 x 570 x 370 500 x 650 x 438
Weight kg 9 12 19 25
Impendance ohm 8 8 8 8
Rated System Power
(continuous / peak) (W) 200 / 400 250 / 500 350 / 700 500 / 1000
SPL 1W/1m 95 96 99 100
SPL max dB 118 120 124 127
Frequency range Hz 70-19.000 65-19.000 58-19.000 50-19.000
HF horn dispersion ° 100 x 110 100 x 110 100 x 110 100 x 110
In-Output 2 x SPKn
Features
Ergonomic milled handles,
LDEB82 / LDEB102: aluminium stand support
LDEB122 / LDEB152: stand support adjustable vertically SM707
Rubber feet
82 “ ACTIVE 102“ ACTIVE 122“ ACTIVE 152“ ACTIVE
Type Bassreflex Bassreflex Bassreflex Bassreflex
LF Transducer 8“ Woofer 10“ Woofer 12“ Woofer 15“ Woofer
HF Transducer 1“ CD-Horn 1“ CD-Horn 1“ CD-Horn 1“ CD-Horn
Compression driver BMS4524 BMS4524 BMS4524 BMS4524
Dimensions (mm) 287 x 450 x 290 332 x 500 x 292 390 x 570 x 370 500 x 650 x 438
Weight kg 11 14 25 28
Power Output
(W RMS / ohm) 170 / 4 170 / 4 450 / 4 500 / 4
Amplification ICE power 50ASX2 ICE power 50ASX2 ICE power 125ASX2 ICE power ASP1000
SPL 1W/1m 95 96 99 100
SPL max dB 118 120 124 127
Frequency range Hz 70-19.000 65-19.000 58-19.000 50-19.000
HF horn dispersion ° 100 x 110 100 x 110 100 x 110 100 x 110
Indicators / Controls Power, Clip / Volume, Line Gain, Mic Gain, High, Low
Connectors Input: XLR Mic in, XLR Line in, XLR Line out, SPKn powered output for passive speakers load: >8 ohms
Features
Ergonomic milled handles,
LDEB82 / LDEB102: aluminium stand support
LDEB122 / LDEB152: stand support adjustable vertically SM707
Rubber feet

12
ENGLISHDEUTSCHFRANCAIS
MANUFACTURER´S DECLARATIONS:
LIMITED wARRANTY
This Limited Warranty applies to the Adam Hall, LD Systems, Defender, Palmer and Eminence branded products.
The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies, additional
independent warranty claims towards Adam Hall.
Adam Hall warrants that the Adam Hall product you have purchased from Adam Hall or from an Adam Hall autho-
rized reseller is free from defects in materials or workmanship under normal use for a period of 2 or 5 years from
the date of purchase.
The Limited Warranty Period starts on the date of purchase. In order to receive warranty services you are required
to provide proof of the purchase date. Your dated sales or delivery receipt, showing the date of purchase, is your
proof of the purchase date. Should products of the brands named above be in need of repair within the limited war-
ranty period, you are entitled to warranty services according to the terms and conditions stated in this document.
This Limited Warranty extends only to the original purchaser of this Adam Hall branded product and is not transfe-
rable to anyone who obtains ownership of the Adam Hall branded product from the original purchaser. During the
Limited Warranty Period, Adam Hall will repair or replace the defective component parts or the product. All compo-
nent parts or hardware products removed under this Limited Warranty become the property of Adam Hall.
In the unlikely event that your Adam Hall product has a recurring failure, Adam Hall, at its discretion, may elect to
provide you with a replacement unit of Adam Hall´s choice that is at least equivalent to your Adam Hall branded
product in hardware performance.
Adam Hall does not warrant that the operation of this product will be uninterrupted or error-free. Adam Hall is not
responsible for damage that occurs as a result of your failure to follow the instructions included with the Adam
Hall branded product.
This Limited Warranty does not apply,
- to wear parts (e.g. accumulator)
- to any product from which the serial number has been removed or that has been damaged or rendered defec
tive as the result of an accident
- in case of, misuse, abuse, or other external causes
- by operation outside the usage parameters stated in the user´s documentation shipped with the
product
- by use of spare parts not manufactured or sold by Adam Hall
- by modification or service by anyone other than Adam Hall
These terms and conditions constitute the complete and exclusive warranty agreement between you and Adam
Hall regarding the Adam Hall branded product you have purchased.

13
ENGLISHDEUTSCHFRANCAIS
LIMITATION OF LIABILITY
If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy
shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited
to the lesser of the price you have paid for the product or the cost of repair or replacement of any hardware
components that malfunction in conditions of normal use.
Adam Hall is not liable for any damages caused by the product or the failure of the product, including any lost
profits or savings or special, incidental, or consequential damages. Adam Hall is not liable for any claim made by
a third party or made by you for a third party.
This limitation of liability applies whether damages are sought, or claims are made, under this Limited Warranty
or as a tort claim (including negligence and strict product liability), a contract claim, or any other claim. This limi-
tation of liability cannot be waived or amended by any person. This limitation of liability will be effective even if
you have advised Adam Hall of an authorized representative of Adam Hall of the possibility of any such damages.
This limitation of liability however, will not apply to claims for personal injury.
This Limited Warranty gives you specific legal rights. You may also have other rights that may vary from state to
state or from country to country. You are advised to consult applicable state or country laws for a full determina-
tion of your rights.
REQUESTING wARRANTY-SERVICE
To request warranty service for the product, contact Adam Hall or the Adam Hall authorized reseller from which
you purchased the product.
EG-DECLARATION OF CONFORMITY
These products meet the essential requirements as well as the further standards of the EU Directives 199/5/EU,
89/336/EU.
CORRECT DISPOSAL OF THIS PRODUCT (ELECTRICAL WASTE)
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other household
wastes at the end of its working life. To prevent possible harm to the environment or human health from uncon-
trolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details on where and how they can recycle this item in an enviromentally friendly manner.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal

14
ENGLISHDEUTSCHFRANCAIS
wEEE-DECLARATION
Your LD-Systems product was developed and manufactured with high quality materials and components wich
can be recycled and/or reused. This symbol indicates that electrical and electronic equipment must be disposed
of separately from normal waste at the end of its operational lifetime.
Please dispose of this product by bringing it to your local collection point or recycling centre for such equipment.
This will help to protect the environment in which we all live.
BATTERIES AND ACCUMULATORS
The supplied batteries or rechargeable batteries can be recycled. Please dispose of them as special waste or return
them to your specialist dealer. In order to protect the environment, only dispose exhausted batteries.
Adam Hall GmbH, all rights reserved. The technical data and the functional product characteristics can be subject
to modifications. The photocopying, the translation, and all other forms of copying of fragments or of the integral-
ity of this user’s manual is prohibited.

15
ENGLISHDEUTSCHFRANCAIS
NOTES:

Sie haben die richtige Wahl getroffen!
Diese LD-Systems Produkte werden Sie lange Jahre durch Zuverlässigkeit, Wirtschaftlichkeit und einfaches
Handling überzeugen. Dafür garantiert LD-Systems mit seinem Namen und seiner in vielen Jahren erworbenen
Kompetenz als Hersteller hochwertiger Geräte.
Nehmen Sie sich nun ein paar Minuten Zeit, diese Anleitung zu lesen. Wir möchten, dass Sie einfach
und schnell in den Genuss dieser Technik kommen.
Mehr Informationen zu LD-SYSTEMS finden Sie auf unserer Internetseite WWW.LD-SYSTEMS.COM
16
ENGLISHDEUTSCHFRANCAIS

17
ENGLISHDEUTSCHFRANCAIS
LD STINGER SERIES
LD EB 82/102/122/152 -AkTIVE & PASSIVE SYSTEME

18
ENGLISHDEUTSCHFRANCAIS ENGLISHDEUTSCHFRANCAIS
1. Bitte beachten Sie die Sicherheitshinweise und studieren Sie diese Anleitung sorgfältig.
2. Bewahren Sie alle Hinweise und Anleitungen sicher auf.
3. Verwenden Sie das Gerät nur in der vorgesehenen Art und Weise.
4. Beachten die in Ihrem Land geltenden Entsorgungsgesetze. Trennen Sie bei der Entsorgung bitte Plastik und
Papier bzw. Kartonagen von einander.
5. Sollte Ihr Gerät nicht mehr ordnungsgemäß funktionieren, Flüssigkeiten ausgesetzt werden oder auf sonstige Art
und Weise beschädigt sein, überlassen Sie bitte jegliche Reparaturen ausschließlich autorisiertem Fachpersonal.
6. Halten Sie das Gerät von Hitzequellen wie z.B. Ofen, Heizkörper, oder sonstige Quellen (auch Verstärker) fern.
Sorgen Sie dafür dass das Gerät immer so installiert ist, dass es ausreichend gekühlt wird und nicht überhitzt.
7. Überprüfen Sie alle Verbindungen nach dem Sie das Gerät angeschossen haben um Schäden oder Unfälle zu
vermeiden.
8. Verwenden Sie ausschließlich stabile und passende Stative bzw. Befestigungen wenn das Gerät fest installiert
wird. Stellen Sie sicher, dass das Gerät sicher installiert ist und nicht herunterfallen kann.
ACHTUNG:
Entfernen Sie niemals die Abdeckung, da sonst die Gefahr eines elektrischen Schocks besteht.
Im Inneren des Gerätes befinden sich keine Teile, die vom Bediener gewartet oder repariert werden können.
Lassen Sie Reparaturen ausschließlich von qualifiziertem Servicepersonal durchführen.
Dieses Symbol warnt vor nichtisolierten, gefährlichen Spannungen im Geräteinneren,
die einen gefährlichen Schlag verursachen können.
Dieses Symbol kennzeichnet wichtige Bedienungs- und Wartungshinweise.
Vorsicht! Hohe Lautstärke!
Diese Übertragungsanlage wird von Ihnen professionell eingesetzt. Daher unterliegt der Gebrauch bei gewerbli-
cher Nutzung den Regeln und Vorschriften der zuständigen Berufsgenossenschaft. Adam Hall als Hersteller ist
daher verpflichtet, Sie auf möglicherweise bestehende gesundheitliche Risiken ausdrücklich hinzuweisen.
Mit diesen Lautsprechern können hohe Schalldrücke erzeugt werden. 85db ist der Schalldruck, der laut Gesetz
als maximal zulässiger Wert über die Dauer eines Arbeitstages auf Ihr Gehör einwirken darf. Er wird nach den
Erkenntnissen der Arbeitsmedizin als Berurteilungspegel zu Grunde gelegt. Höhere Lautstärken oder längere
Einwirkzeit können Ihr Gehör schädigen. Bei höheren Lautstärken muss die Hörzeit verkürzt werden, um eine
Schädigung auszuschließen. Sichere Warnsignale dafür, dass Sie sich zu lange zu lautem Geräusch ausgesetzt
haben, sind:
- Sie hören Klingel- oder Pfeifgeräusche in den Ohren!
- Sie haben den Eindruck, hohe Töne nicht mehr wahrzunehmen!
VORSICHTSMASSNAHMEN:
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

19
ENGLISHDEUTSCHFRANCAIS
MONTAGE & AUFSTELLUNG:
vORWORT
Mit der LDEB-Serie wurden Kundenwünsche nach einer hochwertigen Multifunktionsbox, bestückt mit ausge-
suchten Komponenten und einer speziell abgestimmten Frequenzweiche mit einer aufwendigen Schutzschaltung,
realisiert.
NACHTRÄGLICHE MONTAGE VON FLYWARE KOMPONENTEN
Die LDEB122/152 ist für die nachträgliche Montage der Adam Hall 5720 Flugschiene vorgesehen. Dafür
entfernen Sie bitte mit einem Schraubenzieher die Flywareblenden. In den passenden Ausfräsungen mit
vordefinierten Bohrlöchern können die 5720 Flugschienen mit passenden Montageschrauben montiert werden.
Wir empfehlen gehäuseinnenseitig Verstärkungsplatten, z.B. Adam Hall 5730 zu verwenden. Dafür muss das
Frontgitter abgeschraubt und der Lautsprecher ausgebaut werden.
Sicherheitshinweis : Für nachträglichen Einbau von Flyware Komponenten übernimmt Adam Hall keine
Haftung!
ANWENDUNGSHINWEIS ZUM VARIABLEN BOxENFLANSCh SM707
Mit dem eingebauten und patentierten Boxenflansch SM707 ergeben sich nie da gewesene Einstellungsmög-
lichkeiten von +/- 16° in jeweils 4° Schritten. Dafür die Box auf dem Lautsprecherstativ einfach leicht anheben
wobei sich der eingestellte Neigungspunkt löst und den gewünschten Neigungswinkel durch absenken der Box
auf das Stativ wieder einrasten lassen (siehe Skizze).
Drehpunkt
+/- 16°
Box anheben
Achtung: Die Box dabei
gut festhalten
Box in die gewünschte
Neigung drehen
Box wieder absenken

20
ENGLISHDEUTSCHFRANCAIS
AKTIVE SYSTEME FUNkTIONEN:
MIC GAIN
MIC
IN
LINE GAIN
VOLUME
TREBLE
BASS
STINGER 12A
LINE
IN
LINE
OUT
SPEAKER
OUT
8 Ω ONL Y
12
11
10
9
12
3
4
6
5
7
15 8
14
13
