LD SAT242 User manual

USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D`UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
LD SAT/SUBSERIES
INSTALLATIONS SPEAKER PASSIVE: SAT42 / SAT242 / SAT62 / SAT82 / SUB88
INSTALLATIONS SPEAKER ACTIVE: SAT62A / SUB10A / SUB88A

ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
2
Thank you for choosing LD-Systems!
We have designed this product to give you reliable operation over many years. Therefore LD-Systems underwrites
high quality products with its name and many years of experience as a producer.
Please, take a few moments to read these instructions carefully, as we want you to enjoy your new LD-Systems
products quickly and to the fullest.
Further information about LD-Systems check our website WWW.LD-SYSTEMS.COM

ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
3
LD SAT/SUBSERIES
INSTALLATIONS SPEAKER PASSIVE: SAT42 / SAT242 / SAT62 / SAT82 / SUB88
INSTALLATIONS SPEAKER ACTIVE: SAT62A / SUB10A / SUB88A

ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
4
PREVENTIVE MEASURES:
1. Please read this information carefully.
2. Keep all information and instructions in a safe place.
3. Please follow the instructions.
4. Please observe all warnings.
5. Use the device only in the intended manner.
6. Use only stable and appropriate stands and/or mounts when the device is permanently installed. Make certain
that wall brackets are firmly secured.
Make certain that the unit is installed securely and cannot fall down.
8. Do not install the device near radiators, heat accumulators, ovens or other sources of heat. Make certain that
the device is always installed so that is cooled sufficiently and cannot overheat.
9.Do not place open sources of ignition, e.g., burning candles, on the device.
10.Do not cover ventilation slots.
11.Do not operate the device in the immediate vicinity of water.
12. Please make certain that dripping or splashing water cannot get inside the device. Do not put objects filled
with fluids, such as vases or drinking vessels, on top of the device.
13. Make certain that objects cannot fall into the device.
14. Use the device only with accessories with which the manufacturer intends the device to be used.
15. CAUTION: If your device is equiped with an IEC socket (PROTECTION CLASS I), it must be connected to a
mains socket with a protective ground connection. Never disable the function of the protective ground connection
of the included power cord.
If the plug on the included cord does not fit your mains outlet, contact your electrician.
16. Make certain that the power cord is not stepped on. Protect the power cord against pinching, especially at
the device plug and the power plug.
17. In order to prevent damage or accidents, for example, due to tripping hazards, check all connections once
you have connected the device.
18. When connecting the device, make certain that the power plug remains readily accessible.
19. In order to disconnect the device completely from the mains voltage, the power plug must be unplugged.
20. If your device is equipped with a Volex power connector, the matching Volex device plug must be unlocked
in order to disconnect it. This also means that a tug on the power cord can pull the device out of place, thus
causing personal injuries and/or property damage. Thus please make certain to route your cables carefully.
21. If there is a risk of lighting strike or during extended periods of disuse, unplug the power plug.
22. During transport, make certain that the equipment being transported cannot fall down and possibly cause
personal injuries and/or property damage.
23. If your device no longer works properly, if it has been exposed to liquids or an object has fallen inside it or
if it has been damaged in some other manner, turn the device off immediately und unplug the power plug. This
device should be repaired only by authorized experts.
24. Use only a dry cloth to clean the device.
25. Comply with all of the disposal laws that are applicable in your country. During disposal, please separate
plastic and paper/cardboard.
26. Plastic bags must be kept out of the reach of children.

ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
5
CAUTION
RISK OF ELECTRIC S HOCK
DO NOT OPEN
CAUTION:
To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer
servicing to qualified personnel.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product´s enclosure that may be
of sufficient magnitude to constitute a risk to persons.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
CAUTION! HIGH VOLUME!
You will operate this transmission system for professional use. Therefore the commercial use of this equipment
is liable to the rules and regulations of the Accident Prevention & Insurance Association of your industry sector.
Adam Hall as a manufacturer is bound to inform you formally about the existence of eventual sanitary risks.
Hearing damage, prolonged exposure to excessive SPL, the loudspeaker is easily capable of generating sound
pressure levels (SPL) sufficient to cause permanent hearing damage to performers, production crew and audi-
ence members. Caution should be taken to avoid prolonged exposure SPL in excess of 90 dB.

ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
6
PASSIVE SPEAKER
LD SAT42(W) / SAT242(W)
Up to 4 SAT42(W) (up to 2 SAT242(W) ) loudspeakers per power amp output can be connected in parallel on 4
ohms. At the rear connection terminal, the loudspeaker signal is simply looped through to the next SAT42(W)
(SAT242(W) ) speaker.
LD SAT62(W)
Up to 4 SAT62(W) loudspeakers per power amp output can be connected in parallel 4 ohms. At the rear connec-
tion terminal, the loudspeaker signal is simply looped through to the next SAT62(W) speaker.
LD SAT82(W)
2 pieces of SAT82(W) loudspeakers per power amp output can be connected in parallel 4 ohms. At the rear
connection terminal, the loudspeaker signal is simply looped through to the next SAT82.
LD SUB88 in connection with the LD SAT 42/242/62(W)
Connect the loudspeaker cables coming from the power amplifier to the subwoofer connection terminals labelled
Input A and B. Then connect the satellites SAT42/242(W) or SAT62(W) to the connection terminals labelled Output
A and B. Up to 4 SAT42(W) / SAT62(W) or up to 2 SAT242(W) satellites can be connected in this combination on
4 ohms. We recommend loudspeaker cables such as the Adam Hall KLS 215, with a cross-section of at least 2 x
1.5 mm².
OPERATINg INfORMATION:
ACTIVE SPEAKER
LD SAT62A
MOUNTING / INSTALLATION
It is recommended to switch the system to ON as the last one and to OFF as the first one to prevent start-up
noise caused by a connected device like a mixer etc.. Additional connected LD SAT62A should be switched to ON
in order from the first to the last one and should be switched to OFF in reversed order. If the AUTO mode is used
the source should be turned to off only after 10 minutes without any signal to make sure, that the connected LD
SAT62A are in Standby mode.
CONNECTING AND OPERATING
To connect the LD SAT62A the device should be turned to OFF. There is a connection using 6.3 mm jacks (ba-
lanced triple pole / unbalanced two pole) possible as well as a balanced connection using triple pole XLR plugs.
After connecting all necessary cables and the MAIN LEVEL adjust is turned counterclockwise to left end stop the
source device can be turned to on. Then the LD SAT62A can be turned to ON too (see above). Please turn the
MAIN LEVEL adjust clockwise until designated level is reached. Please do so for additional LD SAT62A if used.
The Connection and operating elements of LD SAT62A are shown on the back panel active speakers page.
SIGNAL LOOPING
The LD SAT62A system is designed to loop the signal to additional devices via triple pole XLR cable. It is not
necessary to connect each device using an own connection to the source. Please make sure that XLR cables of a
good quality are used and that the cables are installed in safe way.

ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
7
SPECIFICATIONS:
LD SAT42(W) LD SAT242(W) LD SAT62(W) LD SAT82(W) LD SAT62A
Product Installation speaker Installation speaker Installation speaker Installation speaker Installation speaker
Type passive passive passive passive active/bass reflex
Loudspeaker 4“ woofer & 1“ silkdome
tweeter
2 x 4“ woofer & 1“ silkdo-
me tweeter
6.5“ woofer & 1“
silkdome tweeter
8“ woofer & 1“ horn
tweeter
6.5” woofer & 1“
silkdome tweeter
Amplifier - - - - Class A/B
Dispersion 60° x 60° 60° x 60° 60° x 60° 60° x 60° 60° x 60°
Load capacity (RMS
/ max.) 60/100W 100/180W 80/130W 120/200W 50W
Frequency range 75Hz-20.000Hz 75Hz-20.000Hz 55Hz-20.000Hz 50Hz-20.000Hz 55Hz-20.000Hz
SPL 85 dB 88 dB 89 dB 93 dB 89 dB
Max. SPL 103 dB 108 dB 108 dB 114 dB 108 dB
Protection circuit - - - - excess current
Line in - - - - sym. XLR / 6.3 mm
Jack
Line out - - - - sym. XLR
Power Input - - - - 220-240 V AC
Impedance 16ohms 8ohms 16ohms 8ohms -
Terminals Clamp-type connection Clamp-type connection Clamp-type connection Clamp-type connection -
Cabinet material 12 mm MDF 12 mm MDF 12 mm MDF 15 mm MDF 12 mm MDF
Cabinet surface textured paint textured paint textured paint textured paint textured paint
Dimension (WxHxD) 140 x 230 x 125 mm 140 x 378 x 135 mm 200 x 320 x 200 mm 247 x 410 x 243 mm 200 x 320 x 205 mm
Weight 2.7 kg 4.1 kg 4.1 kg 8.5 kg 6 kg
Accessories 4 M6 rigging/mounting
points, mounting brackets
4 M6 rigging/mounting
points, mounting brackets
4 M6 rigging/moun-
ting points, mounting
brackets
4 M6 rigging/mounting
points, mounting brackets
4 M6 rigging/moun-
ting points, mounting
brackets

ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
8
BACK PANEL ACTIVE SPEAKER:
LD SAT62A
1MAIN LEVEL
Adjusts the speakers volume
2POWER MODE
Switches to contineous on (ON) or to standby mode (AUTO). In position AUTO the amplifier is turned to ON
by receiving a signal. After several minutes without any signal the amplifier turns again to standby mode.
3POWER LED
Lights up RED if device is in STANDBY mode. Lights up GREEN if device is turned ON.
4INPUT XLR / 6.3 mm jack
Balanced Line Input for XLR connectors and 6.3 mm jacks.
5LINE DIRECT OUTPUT
Direct, balanced Line Ouput for XLR connectors. Should be used to loop the signal to another LD SAT62A.
6POWER SWITCH
ON / OFF switch.
7POWER CONNECTION SEAT
Power connection seat 240 V (IEC power connector) and fuse seat. Replacement of fuse only if mains power
is disconnected and only by fuse of same type and rating (T1A 250V AC). If fuse blows repeatedly please
contact authorized personel for servicing.
8OVERLOAD LED
Lights up when speaker is overloaded. Reduce volume immediately.

ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
9
BACK PANEL ACTIVE SPEAKER:
1
2
3
4
5
6
7

ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
10
LD SUB88A
MOUNTING / INSTALLATION
The powered system LD SUB88A can be either installed on ground or on a solid base with adequate load capaci-
ty. It is strictly recommended to install the LD SUB88A not in a height above 150 cm (risk of drop down). The LD
SUB88A can be installed either in horizontal positon or upright.
Please check for enough distance (> 20 cm) between integrated amplifer and walls, racks etc. to prevent over-
heating for sure. Especially if installed in a shelf or inside a bar etc.. It is important to take care for an adequate
ventilation of the integrated amplifier. Please take care for a accurate wiring for the power wiring as for the input
wiring. Please use only undamaged cables of an adequate size as well as only completely unrolled cable reels.
Please check the wiring for any kind of trip hazard etc. to prevent any kind of accident or damage.
Please do not install the items directly beside an edge like the border of the base.
CONNECTING AND OPERATING
To connect the LD SUB88A the device should be turned to OFF. There is a connection using 6.3 mm jacks (ba-
lanced triple pole / unbalanced two pole) possible as well as a balanced connection using triple pole XLR plugs.
After connecting all necessary cables and the MAIN LEVEL adjust is turned counterclockwise the source device
can be turned to on. Then the LD SUB88A can be turned to ON too. Please turn the MAIN LEVEL adjust clockwise
until designated level is reached. Using the SUB CROSSOVER adjust the frequency range can be limited to match
the LD SUB88 A with the used satellites. Also the PHASE switch can be used in combination with satellites if ne-
cessary. Please use switch position with the best sound. The Connection and operating elements of LD SUB88A
are shown on the back panel active speakers page. It is recommended to switch the system to ON as the last
one and to OFF as the first one to prevent start-up noise caused by a connected device like a mixer etc..
LD SUB10A
MOUNTING / INSTALLATION
The powered system LD SUB10A can be either installed on ground or on a solid base with adequate load capaci-
ty. It is strictly recommended to install the LD SUB10A not in a height above 150 cm (risk of drop down).
Please check for enough distance (> 20 cm) between integrated amplifer and walls, racks etc. to prevent over-
heating for sure. Especially if installed in a shelf or inside a bar etc.. It is important to take care for an adequate
ventilation of the integrated amplifier. Please take care for a accurate wiring for the power wiring as for the input
wiring. Please use only undamaged cables of an adequate size as well as only completely unrolled cable reels.
Please check the wiring for any kind of trip hazard etc. to prevent any kind of accident or damage.
Please do not install the items directly beside an edge like the border of the base.
CONNECTING
To connect the LD SUB10A the device should be turned to OFF.. It can be uses as an additional bass wuth full-
range speakers (Stinger 8“ oder Stinger 10“) or be implemented for installation applications. This subwoofer
features an integrated 3-channel power amplifier ( 3x 120 W RMS) allowing the connection of additional passive
full-range speakers, or of installation speakers such as the LD SAT series speaker.
OPERATINg INfORMATION:

ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
11
SPECIFICATIONS:
LD SUB88 LD SUB88A LD SUB10A
Product Installation speaker Installation speaker Installation speaker
Type passive active, bandpass active, bass reflex
Loudspeaker 2x8“ woofer 2x8“ woofer 10“ woofer
Amplifier - Class A/B Class A/B
Load capacity (RMS
/ max.) 2 x 100/180W 150W 3 x 120W
Frequency range 40Hz to 120Hz 40Hz-120Hz 40Hz-120Hz
SPL 92 dB 92 dB 97 dB
Max. SPL 115dB 115 dB 118 dB
Protection circuit - excess current Short circuit, Over
current, Clip Limiter
Line in - sym. XLR / 6.3 mm Jack -sym. XLR / 6.3 mm
Jack
Line out - - binding post-
Power Input - 220-240 V AC 220-240 VAC
Impedance 2 x 8ohms - -
Terminals Clamp-type connection - -
Cabinet material 15 mm MDF 15 mm MDF 15 mm MDF
Cabinet surface textured paint textured paint textured paint
Dimension (WxHxD) 600 x 250 x 350 mm 600 x 250 x 350 mm 505 x 345 x 425 mm
Weight 11 kg 4.1 kg 21 kg
Accessories - -
Ergonomic milled hand-
les, Threaded flange
(M20)

ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
12
BACK PANEL ACTIVE SPEAKER:
LD SUB88A
1POWER, SIGNAL, LIMIT LED POWER LED
Lights up green when device is turned to ON.
SIGNAL LED
Lights up green, when the unit receives an audio signal.
LIMIT LED
Lights up when loudspeaker is operated at its limit. Short-term blinking of the LED is not critical. If the limi-
ter LED lights up longer than a brief moment or permanently (=over-driving the system), reduce the volume
of the connected signal source or the volume of the active loudspeaker cabinet. Non-compliance will lead to
unpleasant and distorted sound and may cause malfunction of the speaker system.
2SUB CROSSOVER
Adjustable lowpass 80 - 200 Hz. Set the frequency to the lower cut off frequency of the connected satelli-
tes.
3SUB LEVEL
Adjusts the volume of the active subwoofer.
4INPUT XLR / 6.3 mm jack
Balanced Line Input for XLR
connectors and 6.3 mm jacks.
5SUB PHASE
Inverts the phase of the subwoofer (0°/180°) if necessary.
6POWER SWITCH
ON / OFF switch. Please switch connected devices to ON before switching the LD SUB88A to ON and to OFF
after switching the LD SUB88A to OFF.
7POWER CONNECTION SEAT
Power connection seat 240 V (IEC power connector) and fuse seat. Replacement of fuse only if mains power
is disconnected and only by fuse of same type and rating (T1A 250V AC). If fuse blows repeatedly please
contact authorized personel for servicing.

ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
13
INP U T
F US E
T 2. 0 A L 2 50VA C
R E P L AC E
AS MA R K E D
220-240V / 50-60HZ
MA X 20 0 VA / AC
LIMIT
S IG N A L
P O W E R
MIN MAX 80 H z 200 Hz
4
5
6
7
1
2
3
BACK PANEL ACTIVE SPEAKER:

ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
14
BACK PANEL ACTIVE SPEAKER:
LD SUB10A
1MAIN LEVEL
Preset of the main level of the system - subwoofer will be adjusted too, corresponding the preset of the SUB
LEVEL.
2SUB PHASE
Phase invertation switch to invert the Phase of the Subwoofer (0° / 180°) if necessary due to an difficult
installation.
3SUB LEVEL
Preset subwoofer level proportionally to the satellite level. We recommend at the standard setting 12:00
o‘clock.
4LINE DIRECT OUTPUT (LEFT / RIGHT)
Direct symetrical Line Input for XLR connectors.
5LINE INPUT
Symetrical Line Input for XLR connectors and 6.3 mm jacks.
6SPEAKER OUTPUT (LEFT / RIGHT)
7POWER CONNECTION SEAT
Power connection seat 240 V (IEC power connector) and fuse seat. Replacement of fuse only if power
connection is disconnected. If fuse blows repeatedly please contact authorized personel for servicing.
8POWER SWITCH
ON / OFF switch. Please switch connected devices to ON first and to OFF after switching the system.

ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
15
4
5
6
7
1
2
3
8
BACK PANEL ACTIVE SPEAKER:

ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
16
45
6
7
1
2
3
8
10
9
EXPLODED DRAWING BRACKET:
1Wall mount panel
2M6 bolt
3U-Bracket
4Washer
5Wing nut M8
6Rubber washer
7Allen screw M6 x 16
8Spring washer
9Metal washer
10 LD SAT Cabinet

ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
17
INSTALLATION COMBINATIONS:
LDSUB10A + 2 x 4 LDSAT42(W)

ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
18
LDSUB10A + 2 x2 LDSAT62(W)
INSTALLATION COMBINATIONS:

ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
19
LDSUB10A + 2 x2 LDSAT242(W)
INSTALLATION COMBINATIONS:

ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
20
MANUFACTURER´S DECLARATIONS:
LIMITED WARRANTY
This Limited Warranty applies to the Adam Hall, LD Systems, LD Premium, Defender, Palmer, Cameo and Eminence
branded products.
The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies, additional
independent warranty claims towards Adam Hall.
Adam Hall warrants that the Adam Hall product you have purchased from Adam Hall or from an Adam Hall autho-
rized reseller is free from defects in materials or workmanship under normal use for a period of 2 or 5 years from
the date of purchase.
The Limited Warranty Period starts on the date of purchase. In order to receive warranty services you are required
to provide proof of the purchase date. Your dated sales or delivery receipt, showing the date of purchase, is your
proof of the purchase date. Should products of the brands named above be in need of repair within the limited war-
ranty period, you are entitled to warranty services according to the terms and conditions stated in this document.
This Limited Warranty extends only to the original purchaser of this Adam Hall branded product and is not trans-
ferable to anyone who obtains ownership of the Adam Hall branded product from the original purchaser. During
the Limited Warranty Period, Adam Hall will repair or replace the defective component parts or the product. All
component parts or hardware products removed under this Limited Warranty become the property of Adam Hall.
In the unlikely event that your Adam Hall product has a recurring failure, Adam Hall, at its discretion, may elect to
provide you with a replacement unit of Adam Hall´s choice that is at least equivalent to your Adam Hall branded
product in hardware performance.
Adam Hall does not warrant that the operation of this product will be uninterrupted or error-free. Adam Hall is not
responsible for damage that occurs as a result of your failure to follow the instructions included with the Adam
Hall branded product.
This Limited Warranty does not apply,
- to wear parts (e.g. accumulator)
- to any product from which the serial number has been removed or that has been damaged or rendered defecti-
ve as the result of an accident
- in case of, misuse, abuse, or other external causes
- by operation outside the usage parameters stated in the user´s documentation shipped with theproduct by use
of spare parts not manufactured or sold by Adam Hall
- by modification or service by anyone other than Adam Hall
These terms and conditions constitute the complete and exclusive warranty agreement between you and Adam
Hall regarding the Adam Hall branded product you have purchased.
