LD LDDAVE10G3 User manual

LD DAVE G³ SERIES
ACTIVE 2.1 DSP BASED PA SYSTEM
LDDAVE10G³ / LDDAVE12G³ / LDDAVE15G³
USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D`UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
MANUALE D‘ USO

Thank you for choosing LD-Systems!
We have designed this product to operate reliably over many years. Therefore LD-Systems guarantees for high
quality products with its name and many years of experience as a producer.
Please, take a few moments to read these instructions carefully, as we want you to enjoy your new LD-Systems
products quickly and to the fullest.
For information about LD-Systems check out our website WWW.LD-SYSTEMS.COM
Introduction
The LD Systems Dave G³ series loudspeakers are designed for professional use. They offer DSP based 2.1 sound re-
inforcement units with high quality components, powerful amplification and a well balanced sound across the entire
range of frequencies, all at a very fair price.
This series includes three 2.1 subwoofer/satellite systems of different size. The LDDAVE10G3 with a 10“ subwoofer
and 350W RMS system power, the LDDAVE12G3 with a 12“ subwoofer and 500W RMS system power and the
LDDAVE15G3 with a 15“ subwoofer and 700W RMS system power.
The internal LD LECC DSP offers digital sound processing such as crossover, equalizing, compressor and limiter
functionality which is perfectly adjusted for all LD DAVE G³ models to maintain the system´s best audio performance.
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
2

LD DAVE G³ SERIES
ACTIVE 2.1 DSP BASED PA SYSTEM
LDDAVE10G³ / LDDAVE12G³ / LDDAVE15G³
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
3

04
PREVENTIVE MEASURES:
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
4
1. Please read this information carefully.
2. Keep all information and instructions in a safe place.
3. Please follow the instructions.
4. Please observe all warnings. Don‘t remove safety instructions or any other information located on the device.
5. Use the device only in the intended manner.
6. Use only stable and appropriate stands and/or mounts when the device is permanently installed. Make certain
that wall brackets are firmly secured. Make certain that the unit is installed securely and cannot fall down.
7. When installing please observe the corresponding safety standards for your country.
8. Do not install the device near radiators, heat accumulators, ovens or other sources of heat. Make certain that
the device is always installed so that is cooled sufficiently and cannot overheat.
9. Do not place open sources of ignition, e.g., burning candles, on the device.
10. Do not cover ventilation slots.
11. Do not operate the device in the immediate vicinity of water. Do not expose this equipment to combustible
materials, liquids or gases.
12. Please make certain that dripping or splashing water cannot get inside the device. Do not put objects filled
with fluids, such as vases or drinking vessels, on top of the device.
13. Make certain that objects cannot fall into the device.
14. Use the device only with accessories with which the manufacturer intends the device to be used.
15. CAUTION: If this device has a mains connector equipped with protective earth, it must be connected to a
mains socket with a protective ground connection. Never disable the function of the protective ground connection
of the included power cord.
16. Do not turn on the device immediately if it was exposed to strong temperature fluctuations (for example after
transportation). Moisture and condensation may damage the device. Leave the device switched off until it has
reached room temperature.
17. Do not open the device and do not make any changes to the device.
18. Before connecting to mains power, make certain that the mains voltage and the mains frequency are the
same as the operating values of the device (see type label). If the device is equipped with a supply voltage selec-
tor switch, make certain that the values of the device match the values of the mains power before connecting.
If the plug on the included cord does not fit your mains outlet, contact your electrician.
19. Make certain that the power cord is not stepped on. Protect the power cord against pinching, especially at
the device plug and the power plug.
20. In order to prevent damage or accidents, for example, due to tripping hazards, check all connections once
you have connected the device.
21. When connecting the device, make certain that the power plug remains readily accessible.
Always pull out the power plug when the device is not in use or when you clean the device. Disconnect the
power cord by pulling the plug not the cable.
22. Avoid switching the device on and off at short intervals, because it may shorten the durability of the device.
23. IMPORTANT: Replace fuse only by fuse of same type and rating! If fuse blows repeatedly please contact
authorized service center!
24. In order to disconnect the device completely from the mains voltage, the power plug must be unplugged.
25. If your device is equipped with a Volex power connector, the matching Volex device plug must be unlocked
in order to disconnect it. This also means that a tug on the power cord can pull the device out of place, thus
causing personal injuries and/or property damage. Thus please make certain to route your cables carefully.
26. If there is a risk of lightning strike or during extended periods of disuse, unplug the power plug.

PREVENTIVE MEASURES:
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
5
27. During transport, make certain that the equipment being transported cannot fall down and possibly
cause personal injuries and/or property damage.
28. If your device no longer works properly, if it has been exposed to liquids or an object has fallen inside it or
if it has been damaged in some other manner, turn the device off immediately und unplug the power plug. This
device should be repaired only by authorized experts.
29. Use only a dry cloth to clean the device.
30. Comply with all of the disposal laws that are applicable in your country. During disposal, please separate
plastic and paper/cardboard.
31. Plastic bags must be kept out of the reach of children.
CAUTION:
To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer
servicing to qualified personnel.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product´s enclosure that may be
of sufficient magnitude to constitute a risk to persons.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
CAUTION! HIGH VOLUME!
You will operate this system for professional use. Therefore the commercial use of this equipment is liable to the
rules and regulations of the Accident Prevention & Insurance Association of your industry sector. Adam Hall as a
manufacturer is bound to inform you formally about the existence of eventual sanitary risks.
Risk of hearing damage due to prolonged exposure to excessive volumes: The loudspeaker is easily capable of
generating sound pressure levels (SPL) sufficient to cause permanent hearing damage to performers, production
crew and audience members. Caution should be taken to avoid prolonged exposure SPL in excess of 90 dB.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

INSTALLATION & OPERATING:
INSTALLATION
Please place subwoofers and satellite speaker stands on stable and even ground. Do not place subwoofers and
satellite speakers on mobility carts, chairs, tables or something similar in order to prevent accidents.
We recommend Adam Hall speaker stand SPS56 or speaker pole SPS822 (M20 thread, mounted on subwoofer)
and mounting fork for speaker stands SPS823 for use with the LD DAVE G³ satellites.
The LDDAVE10G³ satellites are equipped with a speaker stand flange of 5° slope for best sound distribution.
The LDDAVE12G³ and LDDAVE15G³ satellites are equipped with the patented SM707 speaker stand flange
with variable slope. For slope angle adjustment lift the satellite speaker slightly and carefully from the latching
mechanism (approximately 1/2 cm), turn into desired angle and lower the cabinet.
OPERATING
In order to prevent unpleasant start-up noise caused by connected devices like mixers etc., the LD DAVE G³
system should be the last to be switched on and the first to be switched off.
Before switching power on, the main level control should be set to minimum.
Centre of Rotation
+/- 13,5 °
Lift cabinet
Attention! Please hold the
cabinet firmly!
Turn the cabinet into the
required angle.
Lower the cabinet.
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
6

OPTIONAL ACCESSORIES:
CASTOR BOARD
38110G3
38112G3
38115G3
CASTOR BOARD + PROTECTIVE COVER FOR
SUBWOOFERS AND SATELLITES
LDDAVE10G3SET
LDDAVE12G3SET
LDDAVE15G3SET
PROTECTIVE COVERS FOR SATELLITES
LDD10G3SATBAG
LDD12G3SATBAG
LDD15G3SATBAG
PROTECTIVE COVER FOR SUBWOOFER
LDD10G3SUBBAG
LDD12G3SUBBAG
LDD15G3SUBBAG
2 X SPEAKER STANDS WITH TRANSPORT BAG
SPS023SET
2 X SPEAKER STANDS WITH TRANSPORT BAG
+ 2 X SPEAKER CABLES
(2 X 1,5MM² SPEAKON COMPATIBLE/
SPEAKON COMPATIBLE, 5M)
SPS023SET2
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
7

BACK PANEL LDDAVE10G³:
2
1
4
3
6
57 85
9 10 11
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
8

CONTROL ELEMENTS:
1MAIN LEVEL
Main volume control of the 2.1 loudspeaker system. Volume of subwoofer and satellites affected in same
way.
2SUB PHASE
Inverts the phase of subwoofer (0°, 180°).
3SUB LEVEL
Volume control of subwoofer. Adjust the volume of the subwoofer in relation to satellites. Recommended
setting centre position (12:00h).
4LINE INPUT (LEFT/RIGHT)
Unbalanced RCA line input.
5LINE INPUT (LEFT/RIGHT)
Balanced XLR/6.3 mm jack (combo) line input.
6SAT POWER OUT (LEFT/RIGHT)
Powered Speakon compatible output for LD DAVE G³ series.
7POWER
Power ON/OFF switch. Before switching power on, all level controls should be set to minimum.
8MAINS SOCKET (VOLEX POWER PLUG)
With built-in fuse holder AC connection via IEC connector (220 - 240V AC).
A power cord with a lockable Volex connector is supplied with this unit.
IMPORTANT: Replace fuse only by fuse of same type and rating! If fuse blows repeatedly please contact
authorized service center!
9ON LED
Lights up when power is switched on and mains cable is connected correctly.
10 SIGNAL LED
Lights up when the unit receives an audio signal.
11 LIMIT LED
Lights up when the loudspeaker is operated at its limit. Short-term blinking of the LED is not critical.If the
limiter LED lights up longer than a brief moment or permanently (= over-driving the system), reduce the
volume of the connected signal source. Non-co mpliance will lead to unpleasant and distorted sound and
may cause malfunction of the speaker system.
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
9

BACK PANEL LDDAVE12G³ (shown) & LDDAVE15G³:
2
1
4
3
66
55
77
89
1MAIN LEVEL
Main volume control of the 2.1 loudspeaker system. Volume of subwoofer and satellites affected in same
way.
2SUB PHASE
Inverts the phase of subwoofer (0°, 180°).
3SUB LEVEL
Volume control of subwoofer. Adjust the volume of the subwoofer in relation to satellites. Recommended
setting centre position (12:00h).
10 11 12 13
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
10

CONTROL ELEMENTS:
4LINE INPUT (LEFT/RIGHT)
Unbalanced RCA line input.
5LINE INPUT (LEFT/RIGHT)
Balanced XLR/6.3 mm jack (combo) line input.
6SAT POWER OUT (LEFT/RIGHT)
Powered Speakon compatible output for LD DAVE G³ series.
7LINE DIRECT OUTPUT (LEFT / RIGHT)
Balanced XLR output which allows you to connect active loudspeakers etc. Provides same signal as input
signal.
8POWER
Power ON/OFF switch. Before switching power on, all level controls should be set to minimum.
9MAINS SOCKET (VOLEX POWER PLUG)
With built-in fuse holder AC connection via IEC connector (220 - 240V AC).
A power cord with a lockable Volex connector is supplied with this unit.
IMPORTANT: Replace fuse only by fuse of same type and rating! If fuse blows repeatedly please contact
authorized service center!
10 ON LED
Lights up when power is switched on and mains cable is connected correctly.
11 SIGNAL LED
Lights up when the unit receives an audio signal.
12 LIMIT LED
Lights up when the loudspeaker is operated at it‘s limit. Short-term blinking of the LED is not critical.If the
limiter LED lights up longer than a brief moment or permanently (= over-driving the system), reduce the
volume of the connected signal source. Non-compliance will lead to unpleasant and distorted sound and
may cause malfunction of the speaker system.
13 PROTECT LED
Lights up in case of unit overload/overheating. Amplifier switches to mute automatically. The unit will return
to operation mode under normal conditions after a few minutes.
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
11

LDDAVE15G3 LDDAVE12G3 LDDAVE10G3
Product Sort: PA complete system PA complete system PA complete system Type: powered, DSP controlled powered, DSP controlled powered, DSP controlled Max. SPL Continuous: dB 121 119 115 Max. SPL Peak: 132 130 126 Frequency Range: Hz 35 - 19.000 40 - 19.000 45 - 19.000 Dispersion (H x V): ° 90 x 40 90 x 40 70 x 70 SUBWOOFER Woofer Size: " 15 12 10 Woofer Size: mm 381 304,8 254 Woofer Magnet: ferrit ferrit ferrit Woofer Brand: custom made custom made custom made Woofer Voice Coil: " 3 2,5 2 Woofer Voice Coil: mm 76,2 63,5 50,8 Cabinet design: bass reflex bass reflex bass reflex Cabinet Material: 18 mm plywood 15 mm plywood 15 mm MDF Cabinet Surface: texture paint texture paint texture paint Width: mm 480 435 345 Height: mm 570 500 430 Depth: mm 635 540 460 Weight: kg 41,5 31,5 19,5 Features: LD SYSTEMS evolutive hand-
les, threaded flange (M20)
LD SYSTEMS evolutive hand- les, threaded flange (M20)
LD SYSTEMS evolutive handles, threaded flange (M20)
MID/HI SYSTEM Midrange Speaker Size: " 8 6,5 5,25 Midrange Speaker Size: mm 203,2 165,1 133,4 Midrange Speaker Magnet: ferrit ferrit ferrit Midrange Speaker Brand: custom made custom made custom made Midrange Speaker Voice Coil: " 1,5 1,75 1 Midrange Speaker Voice Coil: mm 38,1 44,5 25,4 Horn: CD horn CD horn radial HF Driver Size: " 1 1 1 HF Driver Size: mm 25,4 25,4 25,4 HF Driver Magnet: ferrit ferrit neodymium HF Driver Brand: custom made custom made custom made HF Driver Voice Coil: " 1 1 1 HF Driver Voice Coil: mm 25,4 25,4 25,4 Impedance Mid/Hi System: Ohm 4 4 4 Mid/Hi Input Connector Speaker: Speakon compatible Speakon compatible Speakon compatible Cabinet Design Mid/Hi: sealed sealed sealed Cabinet Material Mid/Hi System: 15 mm plywood 15 mm plywood 12 mm MDF Cabinet Surface Mid/Hi System: texture paint texture paint texture paint Width: mm 275 250 200 Height: mm 430 400 300 Depth: mm 260 250 230
SPECIFICATIONS:
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
12

LDDAVE15G3 LDDAVE12G3 LDDAVE10G3
Product Sort: PA complete system PA complete system PA complete system Type: powered, DSP controlled powered, DSP controlled powered, DSP controlled Max. SPL Continuous: dB 121 119 115 Max. SPL Peak: 132 130 126 Frequency Range: Hz 35 - 19.000 40 - 19.000 45 - 19.000 Dispersion (H x V): ° 90 x 40 90 x 40 70 x 70 SUBWOOFER Woofer Size: " 15 12 10 Woofer Size: mm 381 304,8 254 Woofer Magnet: ferrit ferrit ferrit Woofer Brand: custom made custom made custom made Woofer Voice Coil: " 3 2,5 2 Woofer Voice Coil: mm 76,2 63,5 50,8 Cabinet design: bass reflex bass reflex bass reflex Cabinet Material: 18 mm plywood 15 mm plywood 15 mm MDF Cabinet Surface: texture paint texture paint texture paint Width: mm 480 435 345 Height: mm 570 500 430 Depth: mm 635 540 460 Weight: kg 41,5 31,5 19,5 Features: LD SYSTEMS evolutive hand-
les, threaded flange (M20)
LD SYSTEMS evolutive hand- les, threaded flange (M20)
LD SYSTEMS evolutive handles, threaded flange (M20)
MID/HI SYSTEM Midrange Speaker Size: " 8 6,5 5,25 Midrange Speaker Size: mm 203,2 165,1 133,4 Midrange Speaker Magnet: ferrit ferrit ferrit Midrange Speaker Brand: custom made custom made custom made Midrange Speaker Voice Coil: " 1,5 1,75 1 Midrange Speaker Voice Coil: mm 38,1 44,5 25,4 Horn: CD horn CD horn radial HF Driver Size: " 1 1 1 HF Driver Size: mm 25,4 25,4 25,4 HF Driver Magnet: ferrit ferrit neodymium HF Driver Brand: custom made custom made custom made HF Driver Voice Coil: " 1 1 1 HF Driver Voice Coil: mm 25,4 25,4 25,4 Impedance Mid/Hi System: Ohm 4 4 4 Mid/Hi Input Connector Speaker: Speakon compatible Speakon compatible Speakon compatible Cabinet Design Mid/Hi: sealed sealed sealed Cabinet Material Mid/Hi System: 15 mm plywood 15 mm plywood 12 mm MDF Cabinet Surface Mid/Hi System: texture paint texture paint texture paint Width: mm 275 250 200 Height: mm 430 400 300 Depth: mm 260 250 230
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
13

Weight: kg 9,7 8,5 4 Features Mid/Hi System:
ergonomic milled handles, stand support adjustable vertically (SM707)
ergonomic milled handle, stand support adjustable vertically (SM707)
ergonomic milled handle, stand support (5° sloped)
AMP MODULE (INTEGRATED IN SUBWOOFER) Amplification: Class A / B Class A / B Class A / B Power System (RMS): W 700 500 350 Power System (Peak): W 2.800 2.000 1.400 Protection: short circuit, over-current,
limiter
short circuit, over-current, limiter
short circuit, over-current, limiter
Cooling System: fan fan heatsink Controls:
Volume, Sub Level, 180° Phase Reverse, On / Off Switch
Volume, Sub Level, 180° Pha- se Reverse, On / Off Switch
Volume, Sub Level, 180° Phase Reverse, On / Off Switch
Indicators: On, Signal, Limit, Protect On, Signal, Limit, Protect On, Signal, Limit Power Supply: transformer transformer transformer Operating Voltage: 220 V AC - 240 V AC 220 V AC - 240 V AC 220 V AC - 240 V AC Stereo Line Inputs: XLR/Jack 6,3 mm (combo),
RCA
XLR/Jack 6,3 mm (combo), RCA
XLR/Jack 6,3 mm (combo), RCA
Stereo Line Outputs: XLR XLR Stereo Powered Outputs Mid/Hi: Speakon compatible Speakon compatible Speakon compatible
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
14

Weight: kg 9,7 8,5 4 Features Mid/Hi System:
ergonomic milled handles, stand support adjustable vertically (SM707)
ergonomic milled handle, stand support adjustable vertically (SM707)
ergonomic milled handle, stand support (5° sloped)
AMP MODULE (INTEGRATED IN SUBWOOFER) Amplification: Class A / B Class A / B Class A / B Power System (RMS): W 700 500 350 Power System (Peak): W 2.800 2.000 1.400 Protection: short circuit, over-current,
limiter
short circuit, over-current, limiter
short circuit, over-current, limiter
Cooling System: fan fan heatsink Controls:
Volume, Sub Level, 180° Phase Reverse, On / Off Switch
Volume, Sub Level, 180° Pha- se Reverse, On / Off Switch
Volume, Sub Level, 180° Phase Reverse, On / Off Switch
Indicators: On, Signal, Limit, Protect On, Signal, Limit, Protect On, Signal, Limit Power Supply: transformer transformer transformer Operating Voltage: 220 V AC - 240 V AC 220 V AC - 240 V AC 220 V AC - 240 V AC Stereo Line Inputs: XLR/Jack 6,3 mm (combo),
RCA
XLR/Jack 6,3 mm (combo), RCA
XLR/Jack 6,3 mm (combo), RCA
Stereo Line Outputs: XLR XLR Stereo Powered Outputs Mid/Hi: Speakon compatible Speakon compatible Speakon compatible
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
15
MANUFACTURER´S DECLARATIONS:
LIMITED WARRANTY
This Limited Warranty applies to the Adam Hall, LD Systems, Defender, Palmer, Cameo and Eminence branded
products.
The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies, additional
independent warranty claims towards Adam Hall.
Adam Hall warrants that the Adam Hall product you have purchased from Adam Hall or from an Adam Hall autho-
rized reseller is free from defects in materials or workmanship under normal use for a period of 2 or 3 years from
the date of purchase.
The Limited Warranty Period starts on the date of purchase. In order to receive warranty services you are requi-
red to provide proof of the purchase date. Your dated sales or delivery receipt, showing the date of purchase,
is your proof of the purchase date. Should products of the brands named above be in need of repair within the
limited warranty period, you are entitled to warranty services according to the terms and conditions stated in this
document.
This Limited Warranty extends only to the original purchaser of this Adam Hall branded product and is not trans-
ferable to anyone who obtains ownership of the Adam Hall branded product from the original purchaser. During
the Limited Warranty Period, Adam Hall will repair or replace the defective component parts or the product. All
component parts or hardware products removed under this Limited Warranty become the property of Adam Hall.
In the unlikely event that your Adam Hall product has a recurring failure,Adam Hall, at its discretion, may elect to
provide you with a replacement unit of Adam Hall´s choice that is at least equivalent to your Adam Hall branded
product in hardware performance.
Adam Hall does not warrant that the operation of this product will be uninterrupted or error-free. Adam Hall is not
responsible for damage that occurs as a result of your failure to follow the instructions included with the Adam
Hall branded product.
This Limited Warranty does not apply,
- to wear parts (e.g. accumulator)
- to any product from which the serial number has been removed or that has been damaged or rendered defecti-
ve as the result of an accident
- in case of, misuse, abuse, or other external causes
- by operation outside the usage parameters stated in the user´s documentation shipped with the product by use
of spare parts not manufactured or sold by Adam Hall
- by modification or service by anyone other than Adam Hall
These terms and conditions constitute the complete and exclusive warranty agreement between you and Adam
Hall regarding the Adam Hall branded product you have purchased.

ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
16
MANUFACTURER´S DECLARATIONS:
LIMITATION OF LIABILITY
If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy
shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited
to the lesser of the price you have paid for the product or the cost of repair or replacement of any hardware
components that malfunction in conditions of normal use.
Adam Hall is not liable for any damages caused by the product or the failure of the product, including any lost
profits or savings or special, incidental, or consequential damages. Adam Hall is not liable for any claim made by
a third party or made by you for a third party.
This limitation of liability applies whether damages are sought, or claims are made, under this Limited Warranty
or as a tort claim (including negligence and strict product liability), a contract claim, or any other claim. This limi-
tation of liability cannot be waived or amended by any person. This limitation of liability will be effective even if
you have advised Adam Hall of an authorized representative of Adam Hall of the possibility of any such damages.
This limitation of liability however, will not apply to claims for personal injury.
This Limited Warranty gives you specific legal rights. You may also have other rights that may vary from state to
state or from country to country. You are advised to consult applicable state or country laws for a full determina-
tion of your rights.
REQUESTING WARRANTY-SERVICE
To request warranty service for the product, contact Adam Hall or the Adam Hall authorized reseller from which
you purchased the product.
EC DECLARATION OF CONFORMITY
These devices meet the essential requirements and further relevant specifications of Directives 2004/108/EC
(EMC) and 2006/95/EC (LVD). For more information, see www.adamhall.com.
CORRECT DISPOSAL OF THIS PRODUCT (ELECTRICAL WASTE)
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other household
wastes at the end of its working life. To prevent possible harm to the environment or human health from uncon-
trolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details on where and how they can recycle this item in an enviromentally friendly manner.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal.

ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
17
MANUFACTURER´S DECLARATIONS:
WEEE-DECLARATION
Your LD-Systems product was developed and manufactured with high quality materials and components wich
can be recycled and/or reused. This symbol indicates that electrical and electronic equipment must be disposed
of separately from normal waste at the end of its operational lifetime.
Please dispose of this product by bringing it to your local collection point or recycling centre for such equipment.
This will help to protect the environment in which we all live.
BATTERIES AND ACCUMULATORS
The supplied batteries or rechargeable batteries can be recycled. Please dispose of them as special waste or
return them to your specialist dealer. In order to protect the environment, only dispose exhausted batteries.
ECOLOGY AND ENERGY SAVING
Saving electric energy helps to protect the environment. Please turn off all electrical equipment when it is not in
use. To avoid power consuption in idle mode, disconnect all electrical equipment from mains when not in use.
Adam Hall GmbH, all rights reserved. The technical data and the functional product characteristics can be subject
to modifications. The photocopying, the translation, and all other forms of copying of fragments or of the integral-
ity of this user’s manual is prohibited.

Mit einem Produkt von LD Systems haben Sie die richtige Wahl getroffen!
Dieses Gerät wurde unter hohen Qualitätsanforderungen entwickelt und gefertigt, um viele Jahre einen
reibungslosen Betrieb zu gewährleisten. Dafür steht LD Systems mit seinem Namen und der langjährigen
Erfahrung als Hersteller hochwertiger Audioprodukte.
Bitte lesen Sie diese Bedienungsanleitung sorgfältig, damit Sie Ihr neues Produkt von LD Systems schnell
optimal einsetzen können.
Weitere Informationen zu Produkten von LD Systems erhalten Sie auf unserer Internet-Seite
WWW.LD-SYSTEMS.COM.
Einführung
Die Lautsprecher der Dave G³ Serie von LD System wurden für den professionellen Einsatz konzipiert. Die
integrierten leistungsfähigen 2.1 DSP-Endstufenmodule bieten mit ihren hochwertigen Komponenten über das
gesamte Frequenzspektrum einen ausgewogenen Klang - und all das zu einem fairen Preis.
Die Serie umfasst drei unterschiedlich dimensionierte 2.1 Systeme mit jeweils einem Subwoofer und zwei
Satelliten: Das LDDAVE10G3 mit einem 10''-Subwoofer und 350 W (RMS) Endstufe, das LDDAVE12G3 mit einem
12''-Subwoofer und 500 W (RMS) Endstufe und das LDDAVE15G3 mit einem 15''-Subwoofer und 700 W (RMS)
Endstufenleistung.
Die digitale Signalbearbeitung des LD LECC DSP umfasst Funktionen wie Frequenzweiche, Equalizer und Limiter
und ist speziell auf die LD DAVE G³ Modelle abgestimmt, um jederzeit optimale Audio-Leistung zur Verfügung zu
stellen.
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
18

LD DAVE G³ SERIE
AKTIVES 2.1 PA-SYSTEM MIT DSP
LDDAVE10G³ / LDDAVE12G³ / LDDAVE15G³
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
19

04
SICHERHEITSHINWEISE:
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
20
1. Lesen Sie diese Anleitung bitte sorgfältig durch.
2. Bewahren Sie alle Informationen und Anleitungen an einem sicheren Ort auf.
3. Befolgen Sie die Anweisungen.
4. Beachten Sie alle Warnhinweise. Entfernen Sie keine Sicherheitshinweise oder andere Informationen vom
Gerät.
5. Verwenden Sie das Gerät nur in der vorgesehenen Art und Weise.
6. Verwenden Sie ausschließlich stabile und passende Stative bzw. Befestigungen (bei Festinstallationen). Stellen
Sie sicher, dass Wandhalterungen ordnungsgemäß installiert und gesichert sind. Stellen Sie sicher, dass das
Gerät sicher installiert ist und nicht herunterfallen kann.
7. Beachten Sie bei der Installation die für Ihr Land geltenden Sicherheitsvorschriften.
8. Installieren und betreiben Sie das Gerät nicht in der Nähe von Heizkörpern, Wärmespeichern, Öfen oder
sonstigen Wärmequellen. Sorgen Sie dafür, dass das Gerät immer so installiert ist, dass es ausreichend gekühlt
wird und nicht überhitzen kann.
9. Platzieren Sie keine Zündquellen wie z. B brennende Kerzen auf dem Gerät.
10. Die Lüftungsschlitze dürfen nicht blockiert werden
11. Betreiben Sie das Gerät nicht in unmittelbarer Nähe von Wasser. Bringen Sie das Gerät nicht mit brennbaren
Materialien, Flüssigkeiten oder Gasen in Berührung.
12. Sorgen Sie dafür, dass kein Tropf- oder Spritzwasser in das Gerät eindringt. Stellen Sie keine mit Flüssigkeit
gefüllten Behältnisse wie Vasen oder Trinkgefäße auf das Gerät.
13. Sorgen Sie dafür, dass keine Gegenstände in das Gerät fallen können.
14. Betreiben Sie das Gerät nur mit dem vom Hersteller empfohlenen und vorgesehenen Zubehör.
15. ACHTUNG: Wenn das Stromkabel des Geräts mit einem Schutzkontakt ausgestattet ist, muss es an einer
Steckdose mit Schutzleiter angeschlossen werden. Deaktivieren Sie niemals den Schutzleiter des mitgelieferten
Kaltgerätekabels.
16. Schalten Sie das Gerät nicht sofort ein, wenn es starken Temperaturschwankungen ausgesetzt war (bei-
spielsweise nach dem Transport). Feuchtigkeit und Kondensat könnten das Gerät beschädigen. Schalten Sie das
Gerät erst ein, wenn es Zimmertemperatur erreicht hat.
17. Öffnen Sie das Gerät nicht und verändern Sie es nicht.
18. Bevor Sie das Gerät an die Steckdose anschließen, prüfen Sie zuerst, ob die Spannung und die Frequenz
des Stromnetzes mit den auf dem Gerät angegebenen Werten übereinstimmen. Verfügt das Gerät über einen
Spannungswahlschalter, schließen Sie das Gerät nur an die Steckdose an, wenn die Gerätewerte mit den Werten
des Stromnetzes übereinstimmen.
Wenn das mitgelieferte Netzkabel nicht in Ihre Netzsteckdose passt, wenden Sie sich an Ihren Elektriker.
19. Treten Sie nicht auf das Kaltgerätekabel. Sorgen Sie dafür, dass das Kaltgerätekabel speziell an der Netz- und
der Gerätebuchse nicht geknickt wird.
20. Überprüfen Sie nach dem Anschluss des Geräts alle Kabelwege, um Schäden oder Unfälle, z. B. durch
Stolperfallen zu vermeiden.
21. Achten Sie bei der Verkabelung des Geräts immer darauf, dass das Netzkabel stets frei zugänglich ist.
Ziehen Sie immer den Netzstecker, wenn das Gerät nicht benutzt wird, oder Sie das Gerät reinigen möchten.
Ziehen Sie das Kaltgerätekabel immer am Stecker und nicht am Kabel aus der Steckdose.
22. Schalten Sie das Gerät möglichst nicht schnell hintereinander ein und aus, da sonst die Lebensdauer des
Geräts beeinträchtigt werden könnte.
23. WICHTIGER HINWEIS: Ersetzen Sie die Sicherung ausschließlich durch eine Sicherung des gleichen Typs
