LeCavist LCS200VN2Z2D User manual

www.lecavist.com MODEL: LCS200VN2Z2D
WINE COOLER
DOUBLE DOOR

TABLE OF CONTENTS
Additional information on products, accessories,
warranty, replacement parts and services can be
found at www.lecavist.com
2
www.lecavist.com
Correct Conditions of Use
The appliance is intended for use in the home and similar
environments only. It is not intended for commercial use.
The appliance is not suitable for outdoor use, non-stationary
installation.
Installation must comply with the valid standards,
regulations and laws. All safety and warning
information and the operating and installation
instructions must be complied with.
This wine cooler can be only used to store various types
of wines
6. Care and maintenance ............................
6.1 Cleaning
6.2 Power failure
6.3 Vacation time
6.4 Transporting your Wine Cooler
7. Troubleshooting guide............................
8. Environmental tips ...................................
8.1 Disposal considerations
8.2 Disposing yourold appliance
9. Warranty and After sales........................
9.1 Warranty
9.2 After sales service
9.3 Replacement of spare parts
Adherence to the directions for use in this manual is
extremely important for health and safety. Failure to strictly
adhere to the requirements in this manual may result in
personal injury, property damageand affect yourability to
make a claim under the LeCavist manufacturer’s warranty
provided with yourproduct. Products must beused,
installed and operated in accordance with this manual.
You may not beable to claim onthe LeCavist
manufacturer’s warranty in the event that yourproduct
fault is dueto failure to adhere this manual.
CONGRATULATIONS
Congratulations and thank you for choosing
LeCavist for your wine storage solution.
This appliance complies with all relevant safety
requirements in Australia. Inappropriate use
can, however, lead to personal injury and
damage to property.
In order to operate the unit correctly and safely,
please read this instruction manual carefully
before installation and use. This user manual
which provides you with all required instructions
related to safety, installation, use and
maintenance of the appliance.
For future reference, please store this booklet in
a safe place and ensure that all users are familiar
with the contents. Pass them on to any future
owner of the appliance.
Record Model & Serial Number
Model:...........................................................................................
Serial Number ........................................................................
Register your product at www.lecavist.com
1. General Information ..............................
1.1 Appliance information
2. General Safety Instructions ....................
2.1 General safety information
2.2 Safety instruction - Installation
2.3 Correction use & Operation .....................
2.4 Disassembling and Disposal
ofthe Appliance
2.5 Accessories and Spare parts
3. Installation instructions ..........................
4. Technical data sheet ..............................
5. Operating your wine cooler...................
03 06
06
07
08
03
04
04
05
05

Cleaning & Maintenance
1. GENERAL INFORMATION
2. GENERAL SAFETY
A damaged appliance can be dangerous. If you find the
appliance is damaged or marked, you must report it within
7 days if you wish to claim for damage/marks under the
manufacturer’s warranty. This does not affect your statutory
rights. Do not use a damaged appliance.
The manufacturer's warranty will be invalidated if the
appliance is not repaired by a LeCavist approved service
technician.
Faulty components must only be replaced by genuine
LeCavist spare parts. The manufacturer can only guarantee
the safety of the appliance when LeCavist replacement
parts are used.
If the power cord is damaged, it must only be replaced by a
LeCavist
LeCavist
authorised service technician or suitably qualified
electrician in order to avoid a hazard.
ac nnot be held liable for non- compliance with
these instructions, resulting from incorrect or improper use
or operation.
1.1 Appliance Information
Unauthorised Modifications
Unauthorised modifications can cause the appliance to
pose risks. Do not conduct any modifications to the
appliance.
The device must be cleaned regularly. Dirt can lead to
damage or the build up of odours.
Always clean the appliance exactly as indicated in
the operating instructions.
Always ensure the appliance is switched off before
cleaning or replacing parts.
There is a risk of fire if cleaning is not carried out as
described in these operating instructions.
Make sure no water penetrates inside the device when
cleaning. Do not use a steam cleaning appliance to
clean this appliance. The steam could reach electrical
components and cause a short circuit.
In areas which may be subject to infestation by
cockroaches or other vermin, pay particular attention to
keeping the machine and its surroundings in a clean
condition at all times. Any damage which may be
caused by cockroaches or other vermin will not be
covered by the machine warranty.
2.1 General Safety Instructions
Children and People with Special Needs
2.2 Safety Instructions - Installation
The appliance is NOT suitable for use by children
without supervision.
Young children should be supervised near the appliance
to ensure they do not play with this appliance.
Children may be able to wrap themselves in packing
material or pull it over their heads with the risk of
suffocation. Keep children away from any packing
material.
In order to avoid any potential hazard, the installation
instructions must be followed.
Observe all regional regulations for the installation of
ventilation systems.
During installation, maintenance and repair work, the
appliance must be disconnected from the mains
electricity supply. It is only completely isolated from the
electricity supply when:
– the mains circuit breaker is switched off, or
– it is switched off at the wall socket and the plug is
withdrawn from the socket.
Do not pull the mains connection cable but the mains
plug to disconnect your appliance from the mains
electricity supply.
Do not connect the appliance to the mains electricity
supply by a multi-socket unit or an extension lead.
3
The appliance complies with the stipulated safety
requirements in Australia. The user is responsible for
appliance cleaning and maintenance as well as its safe
use. Improper use can lead to personal injury and
damage to property.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabi-
lities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Extension leads are a fire hazard and do not guarantee
the required safety of the appliance.
Tampering with electrical connections or components
and mechanical parts is highly dangerous to the user
and can cause operational faults. Only open the housing
as described in the instructions given in “Installation”
section of this booklet. Under no circumstances should
any other parts of the housing be opened.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not damage the refrigerant circuit.
After the wine cooler is installed in place, the plug shall
be easily accessible to facilitate the removal of the cooler
plug in case of any accident.
INSTRUCTIONS
www.lecavist.com
THIS APPLIANCE MUST BE PROPERLY EARTHED. It is
most important that this basic safety requirement is
present and tested regularly and, where there is any
doubt, the household wiring system should be inspected
by a qualified electrician.
LeCavist cannot be held liable for noncompliance with
these instructions, resulting from incorrect or improper
use or operation.

2.3 Correct use and Operation
4
For safety reasons, this appliance may only be used after
it has been installed.
Reliable and safe operation of this appliance can only be
assured if it has been connected to the main electricity
supply.
Before using the appliance, ensure that all packaging
materials are removed from the appliance and make
sure that the connection data on the data plate [voltage
(V) and frequency (Hz)] indicated on the appliance
corresponds to the voltage and frequency of the power
supply in your household. Consult a qualified electrician
if in doubt.
D
Cracks, fissures or fractures in the panels can damage the
underlying electronics. Switch off and disconnect the
appliance immediately.
After the cooler is put into operation, never touch its inner
surface, especially when your hand is wet; otherwise
the skin may stick onto the inner surface to get injured.
O NOT store or spray flammable materials in the
appliance or near this appliance while it is in operation
(e.g. aerosols). WARNING
Regularly clean surfaces that can come in contact with
food and accessible drainage systems. If the refrigerating
appliance is left empty for long periods, switch off,
clean, dry, and leave the door open to prevent mould
developing within the appliance.
Opening the door for long periods can cause a significant
increase of the temperature in the compartments of the
appliance.
The refrigerant isobutane (R600a) is contained within the
refrigerant circuit of the appliance, a natural gas with a
high level of environmental compatibility, which is
nevertheless flammable. During transportation and
installation of the appliance, ensure that none of the
components of the refrigerant circuit becomes damaged.
2.4 Disassembling and Disposal of the
Appliance
2.5 Accessories and Spare parts
(see the “Environmental Tips” section for best practices on
disposing of this appliance).
The device must only be disassembled by trained
specialists who are familiar with and comply with the
standard national regulations and supplementary
regulations of the local utility companies.
Work on electrical components must only be conducted by
trained electrical personnel.
Incorrect components can lead to personal injury or
damage to the appliance. Only use original Lecavist spare
parts for repairs.
Modifications, additions or alterations to the appliance
can lead to safety risks. If spare parts or accessories from
other manufacturers are used, the warranty will be
invalidated, and Lecavist cannot accept liability.
Please check www.lecavist.com for more information.
www.lecavist.com
3. INSTALLATION INSTRUCTIONS
Before Using Your Wine Cooler
Remove the exterior and interior packing.
Before connecting the Wine Cooler to the power
source, let it stand upright for approximately 2 hours.
This will reduce the possibility of a malfunction in the
cooling system from handling during transportation.
Clean the interior surface with lukewarm water using
a soft cloth.
Install the handle on the left side of the door.
Defrosting:
While running, wine cooler has got one time defrosting
process every 8 hours and defrosting will last about 30
minutes. The defrosting water will collected in the drip
tray before evaporating.
At this process, the temperature display may be higher
than the setting temperature.
Installation of Your Wine Cooler
This appliance is designed for free standing or built-in
(full recessed) installation.
Place your Wine Cooler on a floor that is strong enough
to support it when it is fully loaded. To level your Wine
Cooler, adjust the front leveling legs at the bottom of
the Wine Cooler.
Locate the Wine Cellar away from direct sunlight and
sources of heat (stove, heater, radiator, etc.). Direct
sunlight may affect the acrylic coating and heat sources
may increase electrical consumption. Extreme cold
ambient temperatures may also cause the unit not to
perform properly.
Avoid locating the unit in moist areas.
Plug the Wine Cooler into an exclusive, properly installed-
grounded wall outlet. Do not under any circumstances
cut or remove the third (ground) prong from the power
cord. Any questions concerning power and/or grounding
should be directed toward a certified or an authorised
products service center.
Prevent water ingress. Never sprinkle or flush the cooler
using water, place the cooler in an area exposed to
moisture or water sprinkling, or fill the cooler
with water, so as to avoid impairment of the electric
insulation of the cooler. Furthermore, failing to follow
such requirements may lead to electric shock and fire,
or other accidents.

www.lecavist.com
4. TECHNICAL DATA SHEET
Product model
Voltage/frequency
Refrigerant/weight
Effective volume
Loading capacity
Net weight
Unit dimension (WxDxH)
Packing dimension
(WxDxH)
LCS200VN2Z2D
220-240VAC, 50Hz
R600a/48g
500 L
Approx. 184 bottles
128kg
885×600×1750mm
935×665×1795mm
The written temperatures may vary slightly depending on
whether or not the interior bulb is ON or OFF or whether
the bottles are located on the upper/middle or
lower section.
1. Up ,(4) button is on -- this keypad can raise the temperature
by 1°C or 1°F. The max temperature of left side is 18°C or 65°F,
the max temperature of the right side is 18°C or 65°C.
2. Down , (4) button is on – this keypad can lower the temperature
by 1°C or 1°F. The minimum temperature of the left side is 4°C or
39°F. The minimum temperature of the right side is 4°C or 39°F.
3. The °C/°F display will show the actual temperature in Celsius or
Fahrenheit.
4. to adjust the temperature, press the Up or Down keys.
After 5 seconds, the setting finished.
Recommended temperatures for Chilling Wine
5.1 OPERATING INSTRUCTIONS
> To prevent damaging the door gasket, make sure the door is
fully open when pulling shelves out of the rail compartment.
>For easy access to the stored bottles, pull the shelves out
approximately 1/3 of the way. The shelves are designed with
an emergency stop to prevent them from being pulled out too
far when loaded.
>All shelves are adjustable. The shelves have been designed
to adjust to a range of heights.
SHELVES
This Wine cooler comes with a lock and key combination.
The keys are located the plastic bag containing
the Owner’s Manual. To unlock the door, insert the key into
the lock and turn it counter-clockwise. To lock the door, insert
the key and turn clockwise, make sure that the metal pin is
fully engaged.
Note: *Note: Bottle capacities are approximate.
This wine cooler is designed to store approximately
156 standard Bordeaux 750ml bottles. Storing
large and/or oddly shaped bottles (including
Champagne and sparkling wine bottles) will
decrease the capacity of your wine cooler.
• When adding a bottle to the wine cooler, make
sure there is no contact with the back interior
of the cooler.
• Make sure that no bottles are placed directly
onto the electronic board of the control panel.
Always place bottles on the shelves only.
• To avoid damage to the shelves and ensure
the cooler maintains a consistent temperature,
do not overfill the wine cooler
DOOR LOCK
Red Wines: 15-18°C (59-64.4°F)
Dry /White Wines: 9-14°C (48.2-57.2°F)
Sparkling Wine: 5-8°C (41-46.4°F)
12 3 4 5 6
5. To use the LED light key, press once to turn on,
press once to turn off.
6. Turning the Power key on and off: Press the
button for 2 seconds to turn on, press it once
to power off. The unit should turn off after
5 seconds (the display will count down).
Note:
This wine cooler has a memory function – the
temperature will display the same temperature
when it was last turned off.
5
5. OPERATING YOUR WINE COOLER
5.2 STORING WINE

6
www.lecavist.com
6. CARE AND MAINTENANCE
7. TROUBLESHOOTING GUIDE
You can solve many common Wine Cooler problems easily, saving you the cost of a possible service call.
Try the suggestions below to see if you can solve the problem before calling the servicer.
Wine Coolerdoes
not operate.
-Not plugged in / Turned OFF.
- Tripped circuit breaker/ Blown fuse
- Tripped circuit breaker/ Blown fuse
-Turn it On, or re-plug the appliance.
- Check circuit breaker and fuse if working.
-Turn it On, or re-plugged the appliance.
- Check circuit breaker and fuse if working.
- Check and press the light button.
- Reset temperature, wait a few minutes.
Environment and weather may requirea higher setting.
- Reset temperature, wait a few minutes.
Environment and weather may requirea higher setting.
- Check the door for damages. Replace door seal.
- Check the door for damages. Replace door seal.
Temperature is
not cold enough.
- Temperature control not set correctly.
- The door is opened too often/ or not
properly closed.
- The door is opened too often/ or not
properly closed.
- Damageor loose door seal.
- Damageor loose door seal.
Turns On and Off
too often.
- Wrong temperature setting.
- Large contents added to wine cooler.
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
The light does not
work.
-Not plugged in/ Turned OFF.
- The light button is “OFF”.
- Check and adjust wine cooler feet.
- Check and adjust wine cooler feet.
- Check and adjust wine cooler feet.
Choose an even/flat surface.
- Re-install the door.
- Replace the door seal.
-Position the seal correctly.
-The Wine cooler is not level.Vibrations.
Making too much
noise.
The door does
not close
properly.
- As each cycle ends, you may hear
gurgling sounds caused by the flow
of refrigerant. Some noise may come
from the flow, which is normal.
- Contraction and expansion of the
insidewalls may cause popping
and crackling noises.
- The Wine Cooler is not level.
- The Wine Cooler is not level.
- Door is reversed and/ or not
installed correctly.
- Dirty door seal.
- Shelves are not place correctly.
Turn off the power, unplug the appliance, and remove all items including shelves and racks.
Wash the inside surfaces with a warm water and baking soda solution. The solution should be about 2
tablespoons of baking soda to a quart of water.
Wash the shelves with a mild detergent solution.
Dry excesswater out with a sponge or cloth when cleaning controlpanels or any electrical parts.
Wash the outside with warm and mild liquid detergent. Rinse well and wipe dry with a clean soft cloth.
6.1 Cleaning
Most power failures are corrected withina few hours. Minimise opening the doorto maintain the temperature.
If your power is going to be off for a longer period, take the necessary steps to protect the contents and
your appliance.
6.2 Power Failure
Short vacations: Leave the Wine Cooler ON during vacations of less then three weeks.
If you turn off the Wine Cooler for extended periods, leave the door slightly open to prevent
bad odour from building inside the appliance.
6.3 Vacation Time
If you need to move your Wine Cooler once the box has been discarded:
Securely tape down all loose items (shelves) inside your appliance.
Turn the adjustable leg up to the base to avoid damage.
Tape the door shut.
Be sure the appliance stays secure in the upright position during transportation.
Also protect the outside of the appliance with a blanket, or similar item.
6.4 Transporting your Wine Cooler

7
8.2 Disposing of your old appliance
8. ENVIRONMENTAL TIPS
9. WARRANTY & AFTER SALES SERVICE
The transport and protective packaging has been selected
from materials which are environmentally friendly for
disposal, and can normally be recycled.
Recycling the packaging reduces the use of raw materials
in the manufacturing process and also reduces the
amount of waste in landfill sites. Ensure that any plastic
wrappings, bags etc. are disposed of safely and kept out
of the reach of babies and young children. Danger of
suffocation.
Observe all safety and warning information during
operation (see the “General Safety Instructions” section).
Observe all safety and warning information during
operation (see the “General Safety Instructions” section). Model:…………………………………………………………
Serial Number:.………………………………………………
Register your product www.lecavist.com
In the event of a fault which you cannot remedy yourself,
please contact LeCavist.
Electrical devices marked with this label may not be
disposed of in domestic waste at the end of their service
life.
Electrical and electronic appliances often contain valuable
materials. They also contain specific materials, compounds
and components, which were essential for their correct
function and safety. These could be hazardous to human
health and to the environment if disposed of with your
domestic waste or if handled incorrectly. Please do not,
therefore, dispose of your old appliance with your
household waste.
Please dispose of those materials by contacting your local
authorities and ask for the correct method of disposal.
Please ensure that your old appliance poses no risk to
children while being stored prior to disposal.
By disposing of this product in accordance with the
regulations, you protect the environment and the health of
those around you from negative consequences.
8.1 Disposal considerations
Record model & serial number
www.lecavist.com
Incorrect components can lead to personal injury or
damage to the appliance. Use only genuine original
Lecavist spare parts.
Modifications, additions or alterations to the appliance
can lead to safety risks. If spare parts or accessories from
other manufacturers are used, the warranty will be
invalidated, and Lecavist cannot accept liability.
Please check www.lecavist.com for more information.
The manufacturer’s warranty for this appliance is 2 years.
The contact details for LeCavist
LeCavist
are given at the beginning
and end of these instructions.
When contacting , please quote the model and
serial number of your appliance. These can be found on
the data plate at the back of the wine cooler.
9.1 Warranty 9.3 Replacement of spare parts
9.2 After sales service

LIKE TO
KNOW MORE?
For further information on all LeCavist products,
or to obtain detailed dimension and installation
information, phone or email our Customer Care
team or visit our website:
Operating and installation instructions: Original √ Translation
Osass Australia Pty Ltd.
ACN 005 635 398
ABN 96 005 635 398
www.lecavist.com
The distribution and duplication of this document, as well as the use and disclosure of its contents
are prohibited unless expressly authorised.
These operating and installation instructions have been drawn up with the greatest of care. But it
cannot be ruled out that subsequent technical modifications have not yet been incorporated or
the relevant content has not yet been adapted. Please accept our apologies in this eventuality. An
updated version can be requested from our team. Subject to printing errors and mistakes.
© LeCavist
All rights reserved.
