Leclerc baby User manual

1
EN
Instruction Manual
Read all instructions carefully before
assembly and the use of this product

Congratulations on the purchase of your
Leclerc Baby stroller. It doesn’t get easier
At Leclerc Baby we are focused on innovative products and
designs that breath ultimate comfort and are extremely user
friendly, convenient and low weight.
The Leclerc Baby strollers are an expression of lifestyle and
offer great comfort for the parent(s) and child.

CONTENTS
Parts
Warnings
How to use?
Operation
Safety
Fold
Warranty
Service
Washing Instructions

PARTS
Push bar with
folding button
Sun canopy with mesh
window circulation
Base frame
Shopping basket
Stroller Shoulder strap
travel bag Wheels
Bumper bar
Seat
Safety harness
ONE TOUCH
SAFETY STRAP

WARNINGS
WARNINGS!
Please read the instructions carefully before assembling
and using the stroller and save it for future reference.
1. Ensure that all locking devices are engaged before use.
2. Never leave your child unattended.
3. Keep your child away from all the moving parts when
folding, unfolding or adjusting the stroller.
4. Never lift the stroller or use escalators or stairs while
the child is in the stroller.
5. Never use the stroller in dangerous places such as
rugged ground.
6. Never allow your child to stand or climb on the stroller.
7. The maximum load for the stroller is 22 KG.
8. The maximum weight for the basket is 3 KG.
9. Clean the plastic parts of the stroller with a damp cloth,
do not use abrasives or bleach.
10. Do not use your stroller in case parts are missing,
damaged or if the stroller is unstable.
11. Keep away from re. Never use the stroller near an open re
or exposed ame
12. Compliant with EN1888:2018 + A1:2022 EN
13. Do not use the sun canopy in the extended position in
combination with the rain cover. Suffocation hazard.
14. The brake of the stroller must be engaged when placing
and removing a child.
15. Always use the safety harness when a child inside.
16. Any load attached to the handlebar and/or on the back of
the backrest and/or on the sides of the stroller will affect
the stability of the stroller.
17. Never use the stroller as an unsupervised sleeping
environment.
18. The stroller is designed for use on at or gently sloping
surfaces and may be unstable on higher sloping and
uneven surfaces, resulting in the possibility of the vehicle
tipping over.
19. USE THE SAFETY STRAP TO STOP THE PRAM OR STROLLER ROLLING
AWAY.

In this user guide we make use of a
visual language. Below you can nd the
meaning of all visuals used.
visual check OK
visual check wrong
audible click
movement in the indicated direction
Care must be taken when unfolding
the stroller to prevent nger entrapment.
Make sure the frame is locked in
before you use it! Do not allow children near stroller while unfolding!
Front wheel installation and removal
Installation: insert the front wheel into the front wheel
bracket until you hear the “click” sound indicating the
bracket is in place.
Press the button and then pull the wheel out to remove.
Bumper bar installation and removal
lnstallation: lnsert the front bar into the inside of the frame
following the arrow direction until you hear the “click” sound
indicating the bar is in place.
Never hold the bumper bar to lift up
the stroller when your baby is in the seat.
Removal: Press two buttons on the both sides of the frame at
the same time, then lift up follow the arrow direction.
HOW TO USE?
1. 2.
WARNING!
WARNING!
WARNING: WARNING:
Remove stroller from box,
to unfold stroller.
1. Unhook the latch on the side to unfold
the stroller.
2. As shown in the picture , hold the handle
up and lift the rear to open.
3. Listen for the “click” sound, which
indicates that the frame is open correctly.

Leg-rest adjustment
As shown in picture: pull the adjusting
device below the leg-rest to adjust the
angle of the leg-rest up and down.
Always use the lowest backrest position
(most at position) for a child that is
0 - 6 months old.
Safety harness must always be used
when the child is in the stroller
Do not adjust the backrest when
the child is in the stroller.
Backrest adjustment
Pull the backrest adjustment lever up. The
stroller will adjust from a lay-at position
(image 2) to a sitting position (image 1).
To release back to a lay-at position, pull
the lever down.
OPERATION
WARNING!
WARNING!
WARNING!
Rotatable bumper bar
Remove one side of the Bumper Bar
and rotate as needed.
180°
1. 2.

Using the sun canopy
The canopy has a small window on the top, it can
be used for watching the child or adding more air
ow into the seat.
Using the travel bag
Remove the Bumper Bar and fold the stroller
completely. Then place the stroller and
Bumper Bar into the travel bag.
The strap on the bag can be dangerous. To avoid
danger of suffocation, keep this bag away from
babies and children.
Cup holder installation*
Align the hole on the back of the cup
holder to the pin on the frame as shown
in the right illustration, instert vertically
downward to install till you hear the
“click” sound. *if applicable
DO NOT put hot liquid in the cup holder!
Max. weight: 0,3 kg
OPERATION
WARNING!
WARNING!

SAFETY
BRAKES
Always engage the brakes when stroller is not being pushed to
prevent the stroller from rolling away. NEVER leave the stroller
unattended on a hill or incline as it may slide down the hill.
To engage brakes, apply downward pressure to the brake levers
located on the rear axle. The stroller may require forward or
backward movement in order to engage the brake.
TO SECURE THE CHILD
Never let the child sit on the backrest to avoid serious injury
from stroller tipping backwards. Ensure the child remains
seated on the seat only.
Always use the safety harness to avoid serious injury from
falling or sliding out.
STRANGULATION HAZARD
Loose straps can cause strangulation. Never leave the child
in the seat when straps are loose or undone.
WARNING!
WARNING!
WARNING!
P

SAFETY
Seat belt adjustment
• To adjust the height, unhook the shoulder
strap from the crotch buckle.
Feed the shoulder strap through the
harness spread slots. Feed shoulder strap
through appropriate slot and reattach
shoulder strap buckle.
• Carefully place the child in the stroller seat
and bring the safety harness around the
child’s waist and over the shoulders. Place
the crotch strap between the child’s legs.
Insert the male end of each shoulder/ waist
belt into the buckle on the crotch strap.
• To release the harness, push the button on
the centre clasp. The buckles will pop free.
• To shorten the straps, pull the straps in the
opposite direction of the arrow.
WARNING:
11
2
2
Seat belt must always be used when the child
is in the stroller.
Never to leave the harness buckled when not
tting the child in the stroller! The harness can
form loops which may pose a strangulation
hazard.

SAFETY
Adjustment of shoulder belt
• Shoulder belts have 3 height positions
for different sized children.
• Disassemble the square buckle on the
rear of the seatback and webbing. Turn
the buckle 90 degrees to slot it through
the hole and then pull out the webbing.
• Insert the square buckle into the correct
hole for the required position.
• Turn the buckle 90 degrees to x
it in place.
Before use, try to pull the shoulder belts to
check if the square buckles are x well on
the seat back.
WARNING:
1
2
3

FOLD
How to fold the stroller
• As shown in the picture, slide
the thumb trigger to the left
and squeeze the centre button
while giving the bar a little push.
The stroller will automatically release
the handle downwards.
• The stroller will fold itself and
close fully.
* For unfolding please check the rst
section of the how to use page
LSC Europe B.V.
Westplein 55, 3016BM Rotterdam
The Netherlands
leclercbaby
facebook.com/leclercbaby
leclercbaby
Find us at leclercbaby.com
WARRANTY
Please register your purchase and read the warranty
policy on our website www.leclercbaby.com for more
details.
SERVICE
Check out the product information on our website or
contact our servicedesk via: support@leclercbaby.
com
WASHING INSTRUCTIONS
Clean fabric with lukewarm water and soap. Rinse
with fresh water and leave to dry. Never use bleach
or other chemical detergents. Periodically treat the
wheels and metal parts with Teon or silicon spray to
ensure the pushchair continues to run smoothly.
You will nd more washing instructions on our
website under the FAQ section.
