Ledj VersiMove 24 User manual

Order code: LEDJ320
VersiMove 24 DMX Controller
User Manual
A
B
C
MANUAL
MUSIC
AUTO
0
100
80
60
40
20
D R G B W A UV
0
100
80
60
40
20
1
9
17
8
16
24
7
15
23
6
14
22
5
13
21
4
12
20
3
11
19
2
10
18
0
100
80
60
40
20
0
100
80
60
40
20
0
100
80
60
40
20
0
100
80
60
40
20
0
100
80
60
40
20
0% 100% 0% 100%
R
BG VersiMove 24
FADE TIME
0
SEC
30
SEC
MASTER
0
100
80
60
40
20
WAIT TIME
10
MIN
0.1
SEC
DRGBW
FADE TIME
Page Up
Page Down
Clear
REC
ENTER
MENUS
ESC
BLACKOUT
DEL
RUN MODE
SWAP
H
PAN TILT
S V
FIXTURE
1 3 4 5 6 7 8 PAGE2
A
B
C
WHEEL TO
PAN/TILT
DMX FOG
MOVEMENT
COLOUR
EFFECT 1
COLOUR
EFFECT 2
COLOUR
EFFECT 3
COLOUR
EFFECT 4
CHASE SCENE PAGE
1234
5678
910 11 12
INSERT
DMX OUTPUT
1 = Ground
2 = Data -
3 = Data +
1
2
3
DC INPUT
DC 9V-12V
300mA min
POWER
ON OFF
VersiMove 24
www.prolight.co.uk
IO

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Before your initial start-up, please make sure that there is no damage caused during transportation.
• Should there be any damage, consult your dealer and do not use the equipment.
• To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
• Please note that damages caused by user modications to this equipment are not subject to warranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and
the warranty becomes void. Incorrect operation may lead to danger e.g: short-circuit, burns and electric shocks etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and/or property.
CAUTION!
KEEP THIS EQUIPMENT
AWAY FROM RAIN,
MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!
• Never let the power cable come into contact with other
cables. Handle the power cable and all mains voltage
connections with particular caution!
• Never remove warning or informative labels from the unit.
• Do not open the equipment and do not modify the unit.
• Do not connect this equipment to a dimmer pack.
• Do not switch the equipment on and off in short intervals,
as this will reduce the system’s life.
• Only use the equipment indoors.
• Do not expose to ammable sources, liquids or gases.
• Always disconnect the power from the mains when
equipment is not in use or before cleaning! Only handle
the power-cable by the plug. Never pull out the plug by
pulling the power-cable.
• Make sure that the available mains supply voltage is
between 100~240V AC, 50/60Hz.
• Make sure that the power cable is never crimped or
damaged. Check the equipment and the power cable
periodically.
• If the equipment is dropped or damaged, disconnect the
mains power supply immediately and have a qualied
engineer inspect the equipment before operating again.
• If the equipment has been exposed to drastic
temperature uctuation (e.g. after transportation),
do not connect power or switch it on immediately.
The arising condensation might damage the equipment.
Leave the equipment switched off until it has reached
room temperature.
• If your product fails to function correctly, stop use
immediately. Pack the unit securely (preferably in the
original packing material), and return it to your Prolight
dealer for service.
• Only use fuses of same type and rating.
• Repairs, servicing and power connection must only be
carried out by a qualied technician. THIS UNIT CONTAINS
NO USER SERVICEABLE PARTS.
• This xture is for professional use only - it is not designed
for or suitable for household use. The product must be
installed by a qualied technician in accordance with local
territory regulations. The safety of the installation is the
responsibility of the installer. The xture presents risks of
severe injury or death due to re hazards, electric shock
and falls.
• WARRANTY: One year from date of purchase.

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 3
Product overview & technical specications
The VersiMove 24 from LEDJ is designed to offer control of intelligent lighting xtures including dimmers, moving
lights, LED par cans and haze machines. The DMX controller follows an intuitive layout using a combination of
faders and rotary encoders together with a 2-line LCD display.
To speed up the programming process the VersiMove 24 features a built in shape generator and HSV/RGBWAUV
colour mixing coupled with full channel assignment across each xture allocating the channels to faders and
encoders with dedicated functions.
VersiMove 24 DMX Controller
• Can control 20 xtures,
each with up to 26 channels
• All channels may be patched to
suit your xtures DMX proles
• Pan & Tilt jog wheels
(also fully patchable)
• 36 Scenes and 36 Chases
• 8 Built in movement shape
generator with size and
speed control
• 4 built in colour effects/chases
• Data load/save function via USB
• Instant Hue, Saturation and
Brightness controls (for LED
xtures)
• Fog machine control for 1 or 2
channel fog machines including
manual or timed triggering
• Supplied with USB
gooseneck light
Specications VersiMove 24
Power supply DC 9V-12V, 300mA min
(by adaptor included)
Dimensions 95 x 483 x 135mm
Weight 2.3kg
Order code LEDJ320
01 - Fixture buttons 1 to 8
02 - Fixture page selection
button
03 - Pan/Tilt button
04 - DMX Fog/haze Machine
button
05 - Movement button
06 - Number buttons
07 - Chase button
08 - Scene button
09 - Page select button
10 - Pan wheel
11 - Tilt wheel
12 - Channel Faders
13 - Page Down/Clear button
14 - Page Up/Fade time
button
15 - Wait time fader
16 - Fade Time fader
17 - Master fader
18 - Hue control
19 - Saturation control
20 - Brightness control
21 - REC/Enter button
22 - Menu/Escape button
23 - Blackout/Delete button
24 - Run mode/Swap button
25 - USB socket
26 - 3-Pin DMX output
27 - DC power input
(centre +ve)
28 - Power on/off switch
In the box:
1 x controller,
1 x USB gooseneck
light
1 x power adaptor
& 1 x user manual
A
B
C
MANUAL
MUSIC
AUTO
0
100
80
60
40
20
D R G B W A UV
0
100
80
60
40
20
1
9
17
8
16
24
7
15
23
6
14
22
5
13
21
4
12
20
3
11
19
2
10
18
0
100
80
60
40
20
0
100
80
60
40
20
0
100
80
60
40
20
0
100
80
60
40
20
0
100
80
60
40
20
0% 100% 0% 100%
R
BG VersiMove 24
FADE TIME
0
SEC
30
SEC
MASTER
0
100
80
60
40
20
WAIT TIME
10
MIN
0.1
SEC
DRGBW
FADE TIME
Page Up
Page Down
Clear
REC
ENTER
MENUS
ESC
BLACKOUT
DEL
RUN MODE
SWAP
H
PAN TILT
S V
FIXTURE
1 3 4 5 6 7 8 PAGE2
A
B
C
WHEEL TO
PAN/TILT
DMX FOG
MOVEMENT
COLOUR
EFFECT 1
COLOUR
EFFECT 2
COLOUR
EFFECT 3
COLOUR
EFFECT 4
CHASE SCENE PAGE
1234
5678
910 11 12
INSERT
DMX OUTPUT
1 = Ground
2 = Data -
3 = Data +
1
2
3
DC INPUT
DC 9V-12V
300mA min
POWER
ON OFF
VersiMove 24
www.prolight.co.uk
IO
12
27 2826
01
06 07 08 10 110302 04
14 16 17 18 20 21 22 23 24 250905
13
1915

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 4
01) Fixture buttons 1 to 8:
Fixture buttons 1 to 8 with 3 pages giving a total of 24 xtures. Please note: depending on the channel
count of each xture, only 20 xtures may be used at any one time due to the 512 channel limit of a
DMX universe. To allow full use of all 24 xture’s on the desk, any unused DMX channels can be deleted
thus maximising the xture count. For example: if you use a xture that only has 16 channels the next
xture can start at the 17th channel address thus saving 10 of the 26 channels on that xture button.
02) Fixture page selection button:
Use this button to select one of the 3 pages.
03) Pan/Tilt button:
Use the Pan/Tilt button when its LED is ashing. This allows you to adjust the pan and tilt using the jog
wheels (10/11). If the LED is not ashing then the jog wheels will control other functions. Please note:
the Pan/Tilt wheels must be assigned to your xtures DMX prole for them to function correctly.
04) DMX Fog Machine button:
The fog function will control fog/haze machines with either one or two DMX channels. The DMX address
and output value for each channel may be preset independently from 0-255 in the menu system
(see page 10).
05) Movement button:
When activated you can choose one of the 8 built in movement patterns, buttons 1 to 8.
For this function to operate, you must rst assign your Pan/Tilt channels.
06) Number button:
You have 12 number buttons that select different functions in different modes.
07) Chase button:
When pressed you can then select Page A, B or C followed by the desired chase number using
buttons 1 to 12. Please note: You must rst save your chases before you can recall them.
08) Scene button:
When pressed you can then select Page A, B or C followed by the desired scene number using
buttons 1 to 12. Please note: You must rst save your scenes before you can recall them.
09) Page selection button:
Use this to select Page A, B or C when using chase or scene mode.
10) Pan wheel:
Used to adjust the position of moving heads or scanner mirrors. When using the Pan wheel the display
will show the DMX value being sent to the xture.
11) Tilt wheel:
Used to adjust the position of moving heads or scanner mirrors. When using the Tilt wheel the display
will show the DMX value being sent to the xture.
Operating instructions

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 5
12) Channel faders:
Used in conjunction with the page up/down buttons to control all the functions of your xtures, as you
move each fader in turn the display will show the DMX value being outputted.
13) Page down/Clear button:
Press this button to scroll down through the 3 pages of the fader channels.
14) Page up/Fade time button:
Press this button to scroll up through the 3 pages of fader channels. This button also enables you to
change the fade time. Keep the button pressed down and at the same time, use the wait time fader to
adjust the fade time. You will see the fade time displayed in the menu window.
Please note: This fade time is for the speed of fade using RGBW LEDs.
15) Wait time fader:
The wait time fader is used to adjust the chase wait time: move the “fade time” fader to adjust the
chase fade time.
16) Fade time fader:
This is used to select the speed of fade from one scene to the next when running chases.
17) Master fader:
This fader controls the output of D, R, G, B, W, A and UV faders.
18) Hue control:
Used to change the hue of selected R, G, B, W, A colours.
19) Saturation control:
Used to change the colour mixing of your selected xtures.
20) Brightness control:
A quick way of changing the brightness of any preselected colour mix.
21) REC/Enter button:
When in Program mode, this is used to record your settings, when in menu mode is used to enter
a command.
22) Menu/ESC button:
Press and hold for 3 seconds, this will activate menu mode. Press ESC to exit any of the menu modes.
23) Blackout/Delete button:
When the LED is ashing next to the Blackout button, all of your xtures will be blacked out.
This button also becomes the delete button when in program mode.
24) Run mode/Swap button:
This is used to select Manual, Music or Auto mode for running chases, also it can be used to Swap from
one selected movement to another (buttons 1 to 8).
Operating instructions

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 6
Operating instructions
25) USB socket:
Can be used to Save/Load show les. The USB socket is also used for factory software updates or your
USB gooseneck light.
26) 3-Pin DMX output:
3-Pin XLR socket output. Pin 1 = Ground, Pin 2 = data –ve, Pin 3 = data +ve
27) DC power input (centre +ve):
Centre positive type connection. 9-12VDC, 300mA minimum regulated type.
28) Power on/off switch:
Use this switch to power the controller on/off.
Pan/Tilt wheels:
With the “Wheel to Pan/Tilt” button pressed and its LED ashing the jog wheels can then be used to
adjust the Pan/Tilt position of your moving heads or scanners (once they have been assigned). With the
“Wheel to Pan/Tilt” button not pressed and the LED not ashing the Pan/Tilt jog wheels can be used to
adjust the Pan/Tilt range of the 8 built in shape generator movement macros.
Patching xtures:
To enable you to control your xtures you will rst have to patch the controller to the DMX proles of the
xtures you intend to control.
The controller can address 20 xtures, each with up to 26 channels when you rst power on from new
(or following a factory reset) the controller is patched in the following way for all 20 xtures.
You can now start to patch your xtures to the controller in the following way.
Press and hold the “Menu” button for 3 seconds, the screen will now show “01 Patch Fixtures”, now
press the enter button and the screen will display “Please select xture”. If you press the xture 1 but-
ton the display will show the xture number and its start address, now press the “Swap” button and the
screen show “CHANL: 1/D” and “DMX channel: 01” as you can see “DIMMER” is printed above fader 1,
so using the Tilt wheel set your xtures dimmer channel into the menu screen.
Fader DMX channel Fader DMX channel Fader DMX channel
1/D 1 10 10 19 19
2/R 2 11 11 20 20
3/G 3 12 12 21 21
4/B 4 13 13 22 22
5/W 5 14 14 23 23
6/A 6 15 15 24 24
7/UV 7 16 16 PAN 25
8 8 17 17 TILT 26
9 9 18 18

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 7
e.g. If your xture’s dimmer channel is number 5 then rotate the “tilt wheel” to show 05 on the display,
now press “enter” to conrm. Now rotate the “pan wheel” to show number 02 in the display, this is
fader 2 the “red” channel. If for example your xtures red channel is DMX channel 3 then rotate the tilt
wheel to show 03 in the display. Now press the Enter button to conrm.
For any unused channels, you can hit the “Blackout/Delete” button to change the channel value to
“NULL”. This will allow DMX xtures to be patched based on the xtures DMX channel count and allow
you to utilise the full 24 available xtures if required.
Now continue using the same process until all of the DMX channels on your xture have been assigned.
Don’t forget, Pan & Tilt should be assigned to numbers 25 and 26.
Continue the same process for each xture until all of your xtures have been patched into
the controller.
During the above patch process, it is possible to reverse the action of any fader (e.g. for shutter chan-
nels) by pressing the swap button, use the Tilt wheel to change. A second press of the swap button will
enable or disable the fade in/out time of the xtures colour channels just rotate the pan wheel left/right
for yes or no.
If you have 2 or more of the same xture you can patch the rst xture and then copy to a second xture
number by holding down the xture button for three seconds and while keeping the button pressed you
can press the xture button you wish to copy too. The display will conrm that the copy has taken place.
When you have nished all the patching press the “ESC” button to exit.
Saving scenes:
Press and hold the REC/Enter button to go into Program mode, then press the Scene button to
illuminate its LED. Now select a xture, then using the faders setup the xture to the desired setting.
Next select the Bank (A, B or C) using the Scene Page button you can then press the REC/Enter button
once. At this point the LEDs next to the number buttons will illuminate to show any existing scenes. Now
press the number button of the next available scene (unlit number button), when you do this all LEDs
will ash to register the save. Repeat this process and when you have completed saving your scenes
(maximum 36 scenes), press and hold the REC/Enter button to exit the program.
Saving chases:
Press and hold the REC/Enter button to go into Program Mode, then press the Chase Button.
Now press one of the number buttons in which to save your chase. The display will now show the
chase number and the step number, adjust your lighting xtures to the desired setting then press the
REC/Enter button. All the LEDs will ash and the step number will increase by one. Continue in this way
until your chase is complete, then press and hold the REC/Enter button to exit the program mode.
Deleting scenes:
Press and hold the REC/Enter button to go into Program Mode, then select the Chase/Scene using the
Page/Chase/Scene buttons (individual steps maybe selected using the PAN jog wheel). After selecting
the desired Step, press and hold the Blackout/Delete button, upon releasing the button all of the LEDs
on the controller will ash to conrm the step has been deleted.
Operating instructions

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 8
Operating instructions
Chase playback:
Press and hold the “Page Down/Clear” button for 3 seconds to clear the programmer of any manual
adjustments on the faders & controls, the LEDs on the controller will show one quick ash to conrm
the programmer is cleared. Press the “Chase” button and the LED alongside will illuminate. Press the
number button(s) to activate the required chases. Please note: a maximum of 5 chases may be replayed
simultaneously.
AUTO: Chases run in the sequence that they were saved, and can be controlled by both fade and wait
time faders.
MANUAL: Rotate the Pan wheel to run step by step, forward or backward.
MUSIC: The chases will be activated by sound. To adjust the sensitivity of sound activation in MUSIC
mode, press and hold the run mode/swap button and then rotate the Tilt wheel.
When two or more chases are running simultaneously, the chase that is adjustable shows a blinking
LED indicator. To adjust another chase, press the corresponding number buttons for two seconds until
its LED indicator blinks, then it is ready for adjustment.
Scene playback:
Press the Scene button and the LED alongside will illuminate. Press the number button(s) to activate the
required scenes.
HTP/LTP:
The controller will output DMX commands in the following priority order:
Manual fader adjustments > movement macros > scenes > chases.
This means, any changes to the faders/wheels will override the movement macros, scenes and chase
outputs.
Fade in/out time of the colour channels:
Press and hold “Page Up” and then move the “wait time fader” to adjust the fade in/out time of the
colour channels. Each xture can be set with individual fade in/out times. Fade in/out may also be
disabled for individual xtures in the Fixture Patch menu.
Other menu functions:
When in “Menu” mode, you can use the Pan or Tilt wheels to scroll through all the menu functions.
They are listed as follows:
1) Patch xtures
2) Reset factory settings
3) Delete all xture patches
4) Fade mode
5) RDM DMX address setup
6) Data backup
7) Data load
8) Send xture update le
9) Black-out mode
10) FOG machine control

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 9
1) Patching xtures:
Please see previous description.
2) Reset factory settings:
Press and hold the Menu button to enter menu mode then rotate the Pan or Tilt wheels to show “02.
Factory Reset” on the display. Press the Enter button to conrm. You can then select Yes/No by rotating
the Pan or Tilt wheels and press enter to conrm.
NOTE: If you reset the controller to its factory settings, any patches, scenes and chases will be deleted.
3) Delete all xture patches:
Press and hold the Menu button to enter menu mode then rotate the Pan or Tilt wheels to show “03.
Delete All Fixture Patch” on the display. Press the Enter button to conrm, the display will now show “Del
all Patch”, you can now select Yes or No by using the Pan or Tilt wheel, then press Enter to conrm.
4) Fade mode:
Press and hold the Menu button to enter menu mode, then rotate the Pan or Tilt wheels to show “04.
Fade Mode” on the display. Press the Enter to conrm and then use the Pan or Tilt wheels to select
either “All Channels” or “Only Pan/Tilt”, then press enter to conrm your selection.
5) RDM DMX Address setup:
Press and hold the Menu button to enter menu mode then rotate the Pan or Tilt wheels to show “04.
RDM DMX Address Setup” on the display then press enter to conrm. The display will then show “DMX
ADDR SETUP”. Now using the Pan or Tilt wheels you can select Yes or No. If you select No, the controller
will return to the Menu mode, if you select Yes the display will show “Discover” as the controller search-
es the DMX chain for any RDM compliant xtures. If the controller nds any RDM compliant xtures it
will show the number of xtures found then by using the Pan wheel you can select the desired xture.
Once you have selected the desired xture you can then change/set its address by using the Tilt wheel
followed by pressing Enter to conrm. Repeat the process for all your RDM xtures. Note: RDM operation
within a DMX chain may be blocked/corrupted by none-compliant xtures and data repeaters. Please
check this carefully should the RDM setup fail to operate.
6) Data backup:
Press and hold the Menu button to enter menu mode then rotate the Pan or Tilt wheels to show “06.
Data Backup” on the display then press enter to conrm. The display will now show “Data Backup USB”,
you can now use the Pan or Tilt wheels to select Yes or No. If you select Yes, the display will now show
“Press Number Key Select File”. The number keys are the 1-12 keys, if any of the LEDs adjacent to the
number keys are illuminated this shows that a le exists on the USB memory stick. Please select from
one of the non-illuminated keys followed by the enter button to save the data onto the memory stick.
You can store up to a maximum of 12 data backups on any one USB memory stick.
Operating instructions

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 10
Operating instructions
7) Data load:
Press and hold the Menu button to enter menu mode then rotate the Pan or Tilt wheels to show “07.
Data Load” on the display then press the Enter button to conrm. The display will now show “Load USB
File”, using Pan or Tilt wheels you can now select Yes or No. If you select Yes and then press the Enter
button the display will show “Press Number Key Select File”, the number keys will now illuminate if there
is a data le saved into that location. Now select the number of the le you wish to load into the control-
ler. A progress bar chart will show on the display indicating the data loading into the controller, when
complete the screen will return to “07. Data Load”.
8) Send xture update le:
The Send Fixture Update File function is used only for initial software loading or for rmware updates
as required.
9) Blackout mode:
Press and hold the Menu button to enter the menu mode, use the pan or tilt wheels until the display
shows “09. Black-out mode” then press the Enter button to conrm. The display will then show
“Black-out mode” and give an option of either [All channels] or [Only dimmer], you can scroll thru
the options using the Pan or Tilt wheels and press enter to conrm.
10) Fog machine control:
Press and hold the Menu button to enter the menu mode, the display will show “10. Fog machine
Control”. Press the Run Mode/Swap button to change the display to each of the fog machine sub
menus:
- Auto FOG. Use the Pan or Tilt wheels to change from Off to On. If the menu option is set to “ON” the
controller will begin to output fog based on the on the “On/Off time”. If the Auto option is set to “Off” the
controller will only output a fog command upon the DMX FOG button being pressed manually.
- ON TIME: 010S / OFF TIMER: 060S. Pan wheel can be used to change the On timer (duration of fog
burst) and the Tilt wheel can be used to change the Off timer (interval between fog bursts)
- FOG CH1: Empty / VALUE: 255 Pan wheel can be used to change the DMX address and the Tilt wheel
can be used to change DMX output value.
- FOG CH2: Empty / VALUE: 255 Pan wheel can be used to change the DMX address and the Tilt wheel
can be used to change DMX output value.

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 11
Setting the DMX address:
The DMX mode enables the use of a universal DMX controller. Each xture requires a “start address”
from 1- 512. A xture requiring one or more channels for control begins to read the data on the channel
indicated by the start address. For example, a xture that occupies or uses 7 channels of DMX and was
addressed to start on DMX channel 100, would read data from channels: 100, 101, 102, 103, 104,
105 and 106. Choose a start address so that the channels used do not overlap. E.g. the next unit in
the chain starts at 107.
DMX 512:
DMX (Digital Multiplex) is a universal protocol used as a form of communication between intelligent
xtures and controllers. A DMX controller sends DMX data instructions form the controller to the xture.
DMX data is sent as serial data that travels from xture to xture via the DATA “IN” and DATA “OUT”
XLR terminals located on all DMX xtures (most controllers only have a data “out” terminal).
DMX linking:
DMX is a language allowing all makes and models of different manufactures to be linked together
and operate from a single controller, as long as all xtures and the controller are DMX compliant.
To ensure proper DMX data transmission, when using several DMX xtures try to use the shortest
cable path possible. The order in which xtures are connected in a DMX line does not inuence the
DMX addressing. For example; a xture assigned to a DMX address of 1 may be placed anywhere in
a DMX line, at the beginning, at the end, or anywhere in the middle. When a xture is assigned a
DMX address of 1, the DMX controller knows to send DATA assigned to address 1 to that unit,
no matter where it is located in the DMX chain.
DATA cable (DMX cable) requirements (for DMX operation):
This xture can be controlled via DMX-512 protocol. The DMX address is set on the back of the unit.
Your unit requires either a standard 3-pin or 5-pin XLR connector for data input/output,
see images below.
Also remember that DMX cable must be daisy chained and cannot be split.
DMX setup
Further DMX cables can be purchased from all good sound and lighting suppliers or Prolight Concepts dealers.
Please quote: CABL10 – 2m CABL11 – 5m CABL12 – 10m3-Pin:
CABL185 – 2m CABL187 – 5m CABL188 – 10m5-Pin:

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 12
Notice:
Be sure to follow the diagrams below when making your own cables.
Do not connect the cables shield conductor to the ground lug or
allow the shield conductor to come in contact with the XLRs
outer casing. Grounding the shield could cause a short circuit
and erratic behaviour.
Line termination:
When longer runs of cable are used,
you may need to use a terminator on
the last unit to avoid erratic behaviour.
Using a cable terminator will decrease
the possibilities of erratic behaviour.
(3-pin - Order ref: CABL90,
5-pin - Order ref: CABL89)
5-pin XLR DMX connectors:
Some manufactures use 5-pin XLR connectors for data transmission in place of 3-pin. 5-pin XLR xtures
may be implemented in a 3-pin XLR DMX line. When inserting standard 5-pin XLR connectors in to a
3-pin line a cable adaptor must be used. The diagram below details the correct cable conversion.
5-pin XLR (female)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-pin XLR (female)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
3-pin XLR (male)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
5-pin XLR (male)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
DMX setup
Termination reduces signal
transmission problems and
interference. It is always
advisable to connect a DMX
terminal, (resistance 120
Ohm 1/4W) between pin 2
(DMX-) and pin 3 (DMX+) of
the last xture.
5-Pin
1
2 4
5
3
3-Pin
1 2
3
Pin Conguration
3-Pin 5-Pin
Pin 1 - Ground
Pin 2 - Negative
Pin 3 - Positive
– Pin 4 - N/C
– Pin 5 - N/C
1
2
3
1
2
3
DMX 512
3-Pin XLR output
DMX 512
3-Pin XLR input
GROUND
DMX +
DMX –
DMX 512
5-Pin XLR output
DMX 512
5-Pin XLR input
1
2
45
3
12
4
5
3
GROUND
N/C
DMX –
N/C DMX +
1 ground
3 hot
2 cold
3-Pin XLR male 3-Pin XLR female
2 cold
3 hot
1 ground
2 cold
1 ground 5 N/C
3 hot 4 N/C
5-Pin XLR male 5-Pin XLR female
4 N/C
5 N/C 1 ground
3 hot 2 cold

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 13
WEEE notice
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed of
with other household wastes at the end of its working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please separate this from other
types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their
local government ofce, for details of where and how they can take this item for environmentally
safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product should not be mixed with other commercial wastes for disposal.

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 14

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 15

www.prolight.co.uk VersiMove 24 DMX Controller User Manual 16
