LEGRAND LCS2 User manual

87045 LIMOGES Cedex
Telephone: [phone] - Fax: [phone]
Technical data sheet: F01424EN/01
Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
Updated on: 24/10/2014 Created on: 21/02/2012
1/31
19" LCS2freestanding cabinets
1. GENERAL FEATURES
19"LSC2freestanding cabinets are intended for digital infrastructures.
19" LCS2cabinets are metal and provide IP20 - IK08 protection. They
have a single or double screen-printed curved glass door and are
finished throughout in charcoal grey RAL 7016.
19"LSC2cabinets can be joined together, either directly or via a
cabling unit, and can be equipped with a modular plinth.
Equipment and accessories for cable management, vertical extension,
thermal management, etc. complete the range.
1.1 Presentation
The main parts of 19"LCS2freestanding cabinets are:
- A framework consisting of 4 uprights and 2 end plates
- A single or double screen-printed curved glass front door
- 2 side panels (excluding extension cabinets)
- A rear panel
- 4 x 19"uprights
CONTENTS Page
1. General features.................1
2. Range.........................3
3. Technical features ...............4
4. Dimensions.....................5
5. Baying........................10
6. Plinths........................12
7. Cable management .............17
8. Vertical extension ...............20
9. Thermal management ...........21
10. Accessories ...................22
11. 19" equipment .................24
12. Power distribution...............27
1. GENERAL FEATURES (continued)
1.1 Presentation (continued)
The 4 structural uprights and the 2 end plates form a metal framework
that is screwed together. The cabinet can be dismantled completely if
access is difficult.
The end plates contain the cabinet's cable entries. Their configuration,
which is identical for the top and the bottom, is dependent on the
dimensions of the cabinet:
(mm) Width 600 Width 800
Depth 600
Depth 800
Depth 1000
Each cable entry is pre-cut in 19"format in order to be equipped with
a cable entry plate (see section 7.1).
The whole structure stands on 4 levelling feet that can be adjusted
from the inside and the outside of the cabinet.

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
2/31
CONTENTS
1. GENERAL FEATURES (continued)
1.1 Presentation (continued)
The single front door comprises:
- Curved colourless transparent glass with "pixel" screen-printing on
the vertical edges
- A handle equipped with a 2433A key lock
- 2 metal hinges (3 for 47U height)
The double front door comprises:
- Two half-doors made of curved colourless transparent glass with
"pixel" screen-printing on the external vertical edges
- A locking bolt located at the top of each half-door
- Two metal hinges on each half-door
Doors are removable and single door is reversible.
Locks are compatible with key barrels (other key codes) and inserts
Cat. Nos. 0 368 13/16/17/18/19/20/22/23/24/25/26/27.
For a perfect finish, 2 fascia trims, clipped onto the end plates,
continue the "pixel" design from the door. The upper trim carries the
Legrand name.
The side and rear metal panels are equipped with:
- A 2433A locking bolt
- A stainless steel equipotential link clip
Each panel is removable for total accessibility:
1. GENERAL FEATURES (continued)
1.1 Presentation (continued)
The four 19"uprights have dual marking of the Us and assistance with
depth adjustment for easy installation.
The adjustment is continuous with markings at 12.5 mm intervals:
The dual marking of the Us enables location in relation to the top or
the bottom of the cabinet:
In the above example, the marking indicates that this is U no. 14 from
the top and U no. 29 from the bottom of the cabinet.
The 19"uprights are perforated with 9.5 x 9.5 mm square holes.
The clip automatically provides continuity of the metal conductive parts
between the panels and the rest of the cabinet (no risk of this being
forgotten).
The lock is compatible with key barrels (other key codes) and inserts
Cat. Nos. 0 368 13/16/17/18/19/20/22/23/24/25/26/27.
12.5 mm
A
A
B
B

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
3/31
CONTENTS
1. GENERAL FEATURES (continued)
1.2 Standards
19" LCS2freestanding cabinets comply with the following standards:
IEC 60529
EN 60529
(NF C 20-010) Degrees of protection provided by
enclosures (IP code)
IEC 62262
EN 62262
(NF EN 50102, NF C 20-015) Degrees of
protection provided by enclosures for electrical
equipment against external mechanical impacts
(IK code)
IEC 60950-1
EN 60950-1
C 77-210-1
Safety of information technology equipment
EIA-310-E Cabinets, racks, panels and associated
equipment (ANSI/EIA/310-E-2005)
IEC 60297-3-100
DIN 41414-7
(NF C 20-150, NF C 20-151) Dimensions of
mechanical structures of the 482.6 mm series
(19 in)
19" LCS2freestanding cabinets can be integrated in installations
complying with the following standards:
EN 50173-1 Information technology -
Generic cabling systems
EN 50174-1 & 2
C 90-480-1 & 2
Information technology - Cabling installation
ISO IEC 11801 Information technology - Generic cabling for
customer premises
NF C 15-100
Part 4-41
Low voltage electrical installations -
recommendations
IEC 60364-4-41 Low voltage electrical installations
- Protection for safety
- Protection against electric shock
(1)
Designated dimensions. See section 4.1 for overall dimensions.
2. RANGE
2.1 Cabinet with single front door
Catalogue
Number
Capacity Width (1)
(mm)
Depth (1)
(mm)
0 463 00 24U 600 600
0 463 06 29U 600 600
0 463 12 33U 600 600
0 463 18 42U 600 600
0 463 19 42U 600 800
0 463 21 42U 800 600
0 463 22 42U 800 800
0 463 23 42U 800 1 000
0 463 28 47U 800 800
0 463 29 47U 800 1 000
Two extension freestanding cabinets complete the range. These are
supplied without side panels and with a baying kit:
19" LCS2extension cabinets
Catalogue
Number
Capacity Width (1)
(mm)
Depth (1)
(mm)
0 463 30 42U 600 600
0 463 33 42U 800 800
2.2 Cabinet with double front door
Door opening suitable for small spaces
Catalogue
Number
Capacity Width (1)
(mm)
Depth (1)
(mm)
0 463 41 42U 800 600
0 463 42 42U 800 800
0 463 43 42U 800 1 000
To meet specific requirements, the made-to-measure department
offers 40 sizes and various configurations: front and rear door
(microperforations, metal double door…), mounting of equipment,
other colours, etc.

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
4/31
CONTENTS
3. TECHNICAL FEATURES
3.1 Index of protection
- IP20 in accordance with IEC EN 60529
Protected against solid objects whose diameter is larger than 12.5 mm
- IK08 in accordance with IEC EN 62262
Protected against mechanical impact with an energy of 5 joules
3.2 Mechanical performance
- Permissible load: 420 kg
- Resistance to shock acceleration and vibration in accordance with
IEC 61587-1: level DL4
3.3 Design
- Structural uprights and upper end plate 1.5 mm thick
galvanised steel + paint finish
- Lower end plate 1.5 mm thick Z140 MB-C galvanised steel
- Curved front door made of 5 mm thick colourless transparent
safety glass.
Charcoal grey RAL 7016 internal screen-printing on the vertical
edges: 2 x 143 mm in 600 mm width, 2 x 243 mm in 800 mm width.
- Single door handle charcoal grey RAL 7016 polyamide
- Door hinges zamak + paint finish
- Fascia trims charcoal grey RAL 7016 ABS.
Legrand marked in relief + pad printed in aluminium grey RAL 9006.
- Panels 1.2 mm thick sheet steel + paint finish
- Single door and panels bolt charcoal grey RAL 7016 polyamide
- 19"uprights 1.5 mm thick galvanised steel.
Number of U marked using black inkjet marking.
- Levelling feet zinc-plated steel with black polypropylene fixed base
3.4 Corrosion resistance
- Corrosion class of the environment:
C2 according to EN ISO 12944-2,
3K3 according to IEC EN 60721-3-3
- Salt spray test according to ISO 9227 (NSS test) and
IEC EN 60068-2-11 (test Ka) for 168 hours:
degree of rusting Ri1 according to ISO 4628-3,
propagation 1 mm according to ISO 4628-8
- Sulphur dioxide (SO2) test according to EN ISO 6988 for 48 hours:
degree of rusting Ri1 according to ISO 4628-3,
ISO 10289 annex A class 8 type image
3.5 Properties of the paint coating
- Thermosetting polyester paint applied by electrostatic dusting
- Charcoal grey RAL 7016
- Textured satin appearance
- 60 to 80 m thick
- Excellent impact and scratch resistance
- Excellent resistance to cleaning agents (excluding strong chlorinated,
fluorinated and ketone solvents).
Some products may change the appearance. It is therefore advisable
to carry out a test first.
- Light exposure test (xenon-arc lamp) according to
ISO 4892-2 method B for 500 hours: no visible fading
3. TECHNICAL FEATURES (continued)
3.6 Electrical continuity of the conductive parts
Continuity of the metal conductive parts of the cabinet is achieved
by construction. For the panels, a stainless steel clip automatically
provides the equipotential link by pressing against the lower end plate
with galvanised steel finish.
3.7 Weight
Net weight excluding packaging.
Cabinet catalogue number Weight (kg)
0 463 00 69
0 463 06 77
0 463 12 84
0 463 18 (extension 0 463 30) 99 (72)
0 463 19 110
0 463 21/41 114
0 463 22/42 (extension 0 463 33) 127 (90)
0 463 23/43 151
0 463 28 138
0 463 29 163
Note: 19"LCS2cabinets are delivered on a 125 mm high pallet.

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
5/31
CONTENTS
4. DIMENSIONS (suite)
4.1 Dimensions (suite)
Single front door cabinets
Cat. No. Capacity W D Overall dimensions
H1 H2 min./max. W D A B
0 463 00 24U 600 600 1226 1241/1271 610 659 1138 1208
0 463 06 29U 600 600 1448 1463/1493 610 659 1138 1208
0 463 12 33U 600 600 1626 1641/1671 610 659 1138 1208
0 463 18 42U 600 600 2026 2041/2071 610 659 1138 1208
0 463 19 42U 600 800 2026 2041/2071 610 859 1138 1408
0 463 21 42U 800 600 2026 2041/2071 810 657 1525 1408
0 463 22 42U 800 800 2026 2041/2071 810 857 1525 1608
0 463 23 42U 800 1000 2026 2041/2071 810 1057 1525 1808
0 463 28 47U 800 800 2248 2263/2293 810 857 1525 1608
0 463 29 47U 800 1000 2248 2263/2293 810 1057 1525 1808
Extension cabinets
0 463 30 42U 600 600 2026 2041/2071 600 659 1138 1208
0 463 33 42U 800 800 2026 2041/2071 800 857 1525 1608
Double front door cabinets
Cat. No. Capacity W D Overall dimensions
H1 H2 min / max W D A B C
0 463 41 42U 800 600 2026 2041 / 2071 810 657 1165 815 1535
0 463 42 42U 800 800 2026 2041 / 2071 810 857 1165 1015 1535
0 463 43 42U 800 1000 2026 2041 / 2071 810 1057 1165 1215 1535
4. DIMENSIONS
4.1 Dimensions
Model shown: 600 x 600 mm cabinet / 800 x 800 mm double door cabinet
FRONT VIEW
VIEW FROM ABOVE
VIEW FROM ABOVE
160°
160°160°
REAR VIEWSIDE VIEW
Overall D
W
A
A
C
H1 H2
B
B
D W
(1)
(1)
(2)
(2)
(1)
Without level adjustment feet
(2)
With level adjustment feet (+15 to 45 mm)
All dimensions are in mm.

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
6/31
CONTENTS
4. DIMENSIONS (continued)
4.2 Usable dimensions
4.2.1 600 mm wide freestanding cabinets
600 mm wide cabinets are available in 4 heights:
24U, 29U, 33U and 42U
FRONT VIEW (without door)
Capacity 24U/29U/33U/42U
Usable space 1086/1308/1486/1886
7070
AA
600
Usable space 450
Usable space 490
4. DIMENSIONS (continued)
4.2 Usable dimensions (continued)
4.2.1 600 mm wide freestanding cabinets (continued)
600 mm wide cabinets are available in 2 depths: 600 and 800 mm
Model shown: 600 x 600 mm cabinet
SIDE VIEW
Capacity 24U/29U/33U/42U
Usable space 996/1218/1396/1796
115 115
600 / 800
659 / 859
425 max / 625 max
Continuous
adjustment with
markings at 12.5 mm
intervals
(6 x 12.5 mm)
Fixing centre
391 max./591 max.
Fixing centre
337 max./537 max.
Usable space 490/690
Oblongs
7 x 50
Fixing centre 1038/1260/1438/1838

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
7/31
CONTENTS
4. DIMENSIONS (continued)
4.2 Usable dimensions (continued)
4.2.1 600 mm wide freestanding cabinets (continued)
A-A CROSS-SECTION VIEW(3) (with door)
VIEW FROM ABOVE
(1)
Dimension below door at 19" uprights
(2)
Continuous adjustment with markings at 12.5 mm intervals
(3)
See front view on page 6
75
600
451
600/800
9096/296 133133
79
213
346
9.5 x 9.5
118 (193 max.) 87 (162 max.)
41
600
600/800
487/687
425 max./625 max.
465
Fixing centre 465 (19")
Usable space 450
(2)(1) (2)
Note: The dimensions of the upper and lower end plates are identical.
4. DIMENSIONS (continued)
4.2 Usable dimensions (continued)
4.2.2 800 mm wide freestanding cabinets
800 mm wide cabinets are available in 2 heights:
42U and 47U
FRONT VIEW (without door)
Usable space 690
Usable space 1886/2018
Capacity 42U/47U
7070
AA
800
Usable space 450
88

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
8/31
CONTENTS
4. DIMENSIONS (continued)
4.2 Usable dimensions (continued)
4.2.2 800 mm wide freestanding cabinets (continued)
800 mm wide cabinets are available in 3 depths: 600, 800 and
1000 mm
Model shown: 800 x 800 mm single door cabinet
SIDE VIEW
Capacity 42U/47U
Usable space 1796/2018
115 115
600/800/1000
657/857/1057
425 max./625 max./825 max.
Continuous
adjustment of the
four 19" uprights
with markings at
12.5 mm intervals
(6 x 12.5 mm)
Fixing centre
391 max./591 max./791 max.
Fixing centre
337 max./537 max./737 max.
Usable space 490/690/890
Oblongs
7 x 50
Fixing centre 1838/2060
4. DIMENSIONS (continued)
4.2 Usable dimensions (continued)
4.2.2 800 mm wide freestanding cabinets (continued)
Model shown: 800 x 800 mm single door cabinet
A-A CROSS-SECTION VIEW (3) (with door)
B-B CROSS-SECTION
(1)
Dimension below door at 19" uprights
(2)
Continuous adjustment with markings at 12.5 mm intervals
(3)
See front view page 7
122 (197 max.) 87 (162 max.)
Usable space 97
800
141
600/800/1000
487/687/887
425 max./625 max./825 max.
465
Fixing centre 465 (19")
Fixing centre 465 (19")
Usable space 450
(2)(1) (2)
Usable space 67
Usable space 97
800
141
Fixing centre 465 (19")
9.5 x 9.5
800 mm wide 19"LCS2cabinets enable 19"equipment to be fixed
horizontally in the upper and lower parts.
BB

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
9/31
CONTENTS
4. DIMENSIONS (continued)
4.2 Usable dimensions (continued)
4.2.2 800 mm wide freestanding cabinets (continued)
4.2.3 19"uprights
75/104/104
41
175
800
90 451
600/800/1000
451
VIEW FROM ABOVE
90
213
346
133133
96/296/496 79
9.5 x 9.5
Note: The dimensions of the upper and lower end plates are identical.
52
32
31,25
23,5
Ø 9
44,45 44,45
44,45 15,87 15,87
23,8
16
8,25
52
17
2510,5
4644,4544,45
47U / 42U / 33U / 29U / 24U
44,45
15,8715,87 23,8
44,45
2092 / 1870 / 1470 / 1292 / 1070
16
8,5
7,5
1,5
9,5
9,5
4. DIMENSIONS (continued)
4.3 Positioning of supports on the floor
The cabinets are equipped with 4 levelling feet.
Accessories can be used to modify the link with the floor
(see sections 10.1 to 10.3).
47
100 100
600/800
400/600
600/800/1000
507/707/907
Ø38 feet
VIEW FROM BELOW

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
10/31
CONTENTS
5. BAYING
5.1 Direct baying
19" LCS2freestanding cabinets can be joined laterally together using
a baying kit:
The crosspieces provide protection against dust and maintain the IP20
protection of the cabinets.
Note: The LCS2range includes extension cabinets (single door) for
the 42U x 600 x 600 and 42U x 800 x 800 sizes. These special
cabinets are supplied with the baying kit and without side
panels.
A baying kit comprises:
- 2 galvanised steel lugs
- 2 steel crosspieces + paint finish (same as cabinets)
- Fixing screws
VIEW OF A COMBINATION FROM ABOVE
Cat. No. For cabinets depth (mm)
0 463 37 600
0 463 38 800
0 463 39 1000
800 800
1600 (1610 overall)
5. BAYING (continued)
5.2 Baying via cabling unit
5.2.1 Presentation
The LCS2cabling unit is used to join laterally two 42U 19"LCS2
freestanding cabinets together, and provides easier management of
cables and patch cords.
The cabling unit is available in 2 depths:
Cat. No. For 42U cabinets depth (mm)
0 463 34 600
0 463 35 800
Joined to 2 x 600 mm wide cabinets, the cabling unit is an
alternative solution to an assembly of 2 x 800 mm wide cabinets
and has smaller dimensions.
Note: The LCS2range includes extension cabinets (single door) for
the 42U x 600 x 600 and 42U x 800 x 800 sizes. These special
cabinets are supplied without side panels.
A cabling unit principally comprises:
- 2 identical end plates
- 2 identical doors
The cabling unit can only be installed between 2 cabinets.
It cannot be mounted at the end.

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
11/31
CONTENTS
5. BAYING (continued)
5.2 Baying via cabling unit (continued)
5.2.1 Presentation (continued)
Each door is reversible and easy to remove.
The end plates have cut-outs for cable entries.
The installation of a side cable tray optimises cable management (see
section 7.2).
The cabling units are the same colour as 19"LCS2cabinets, enabling
attractive assemblies to be created.
5.2.2 Features
- IK08
- IP20 maintained when joined
- Doors with handle equipped with a 2433A key lock (same as single
door cabinets)
- End plates 1.5 mm thick galvanised steel + paint finish (same as
cabinets)
- Doors 1.2 mm thick sheet steel + paint finish
(same as cabinets)
- Supplied with earthing kit and complete set of screws
- Feet zinc-plated steel with black polypropylene fixed base
5. BAYING (continued)
5.2 Baying via cabling unit (continued)
5.2.2 Features (continued)
Combination shown with two 600 x 600 mm cabinets.
250
2026
W
5252
FRONT VIEW
REAR VIEW
Type of baying WOverall W
With 2 cab. width 600 1450 1460
With 1 cab. width 600 & 1 cab. width 800 1650 1660
With 2 cab. width 800 1850 1860

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
12/31
CONTENTS
5. BAYING (continued)
5.2 Baying via cabling unit (continued)
5.2.2 Features (continued)
VIEW FROM ABOVE
DETAILED VIEW FROM ABOVE
21
675/875 overall
600/800
600/800
610/810
180/280
310
100
250
202
293
40
120
65
INTERNAL CROSS-SECTION VIEW
600/800
160/260
570/770
Usable space 250(1)
288
(1)
Usable height: 1922 mm
6. PLINTHS
6.1 Freestanding cabinet plinths
6.1.1 Presentation
19" LCS2cabinets can be equipped with a 100 or 200 mm high metal
plinth.
LCS2plinths comprise 4 one-piece corner blocks and 4 traps, height
100 mm, providing total accessibility on all 4 sides.
The plinths are the same colour as the cabinets so that they match
perfectly (charcoal grey RAL 7016).
A plinth is fixed directly to the end plate of the cabinet:
Note: It is also possible to place 2 x 100 mm high plinths one on top of
the other.

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
13/31
CONTENTS
6. PLINTHS (continued)
6.1 Freestanding cabinet plinths (continued)
6.1.1 Presentation (continued)
The following is required to create a plinth:
- The correct plinth kit for the width of the cabinet (corner blocks +
solid front and rear traps)
- The correct set of 2 solid side traps for the depth of the cabinet
(2 sets for a 200 mm high plinth)
W
H
D
Set of 2 solid side traps (mm)
H= 100 D= 600 Cat. No. 0 464 54
D= 800 Cat. No. 0 464 56
D= 1000 Cat. No. 0 464 58
H= 200 D= 600 2 x Cat. No. 0 464 54
D= 800 2 x Cat. No. 0 464 56
D= 1000 2 x Cat. No. 0 464 58
Plinth kit (mm)
H= 100 W= 600 Cat. No.
0 464 50
W= 800 Cat. No.
0 464 51
H= 200 W= 600 Cat. No.
0 464 52
W= 800 Cat. No.
0 464 53
W
D
Ventilated trap Trap with brushes
W/D = 600 Cat. No. 0 464 60 Cat. No. 0 464 62
W/D = 800 Cat. No. 0 464 61 Cat. No. 0 464 63
The solid traps can be replaced by:
- Either a ventilated trap for natural ventilation
- Or a trap with brushes for cable entry on one side of the plinth
These special traps, also 100 mm high, are supplied singly.
6. PLINTHS (continued)
6.1 Freestanding cabinet plinths (continued)
6.1.1 Presentation (continued)
If cabinets are joined together directly, their plinths can be joined
together mechanically (screws not supplied).
Cross bars
Cat. No. For depth (mm)
0 476 93 600
0 476 94 800
0 476 95 1000
U-shaped cable trays
Cat. No. Internal width x height (mm)
0 464 69 200 x 54
0 464 70 400 x 54
The plinths can be equipped with cross bars. Fixed between 2 corner
blocks, they can be used for clamping cables and, in a 200 mm high
plinth, for fixing a U-shaped cable tray.
0 476 93/94/95

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
14/31
CONTENTS
6. PLINTHS (continued)
6.1 Freestanding cabinet plinths (continued)
6.1.2 Features
6.1.2.1 Cabinet plinths (plinth kit + side traps)
- Plinth fixed using M12 screws
- Traps fixed using black zinc-plated M6 screws
- Corner blocks 2 mm thick steel + paint finish (same as cabinets)
- Traps 1.5 mm thick steel + paint finish (same as cabinets) with
double fold reinforcement on floor side
- Supplied with complete set of screws for the equipotential link with
the cabinet
- Can be fixed to the floor (screws not supplied)
6.1.2.2 Ventilated traps/with brushes
- Height 100 mm
- Steel thick 1.5 mm + paint finish (same as cabinets) with double fold
reinforcement on floor side
- Supplied with black zinc-plated M6 fixing screws
The ventilated traps have Ø5 mm perforations:
The traps with brushes are supplied with a black stiff brush and a
black flexible brush (polyamide fibres).
The usable feedthrough area of the cable entry with brushes is:
- 424 x 45 mm for width/depth 600 mm
- 624 x 45 mm for width/depth 800 mm
Dimensions (mm)
Overall Fixings Usable area
W x D W D A B C D
600 x 600 599 599 478 478 449 449
600 x 800 599 799 478 678 449 649
800 x 600 799 599 678 478 649 449
800 x 800 799 799 678 678 649 649
800 x 1000 799 999 678 878 649 849
W
D
B
B
D
A
A
C
14
14
100
or
200
6. PLINTHS (continued)
6.1 Freestanding cabinet plinths (continued)
6.1.2 Features (continued)
6.1.2.3 Cross bars
- 2 mm thick galvanised steel
- Supplied singly with fixing screws
6.1.2.4 U-shaped cable trays
- Length 3 m
- Frame 100 x 50 mm
- Zinc-plated steel
- Supplied with screws for fixing on the cross bars
Cat. No. A B
0 476 93 444 375
0 476 94 644 575
0 476 95 844 775
Cat. No. Overall dimensions (mm) Wire diameter (mm)
0 464 69 218 x 64 4.4
0 464 70 424 x 64 3.9 and 5.9
A
25
Ø8.5
Ø4.5
25
16
12.5 9
B

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
15/31
CONTENTS
6. PLINTHS (continued)
6.2 Plinth for cabling unit
When joining 19"LCS2freestanding cabinets via a cabling unit,
Cat. No. 0 464 64 is used to link the plinths of the joined cabinets (at
the front and/or rear).
Cat. No. 0 464 64 comprises a 100 mm high trap.
For a height of 200 mm, the number of traps must be doubled.
100
200
Cat. No. 0 464 64
Cat. No.
0 464 64 x 2
The trap is made of 1.5 mm thick steel with paint finish (same as
cabinets) and supplied with its fixing screws.
6.3 Linking interface
6.3.1 Presentation
The linking interface Cat. No. 0 464 66 provides protection and a
finish for the link between freestanding cabinets and cable ducts. It is
positioned to the right or left of a 600 mm deep cabinet equipped with
a 200 mm high plinth.
It is mechanically joined to the cabinet plinth.
The interface comprises:
- 3 corner blocks
- A front panel trap
- A cover
Its reversible cover with cut-outs allows for different cable entry
configurations.
6. PLINTHS (continued)
6.3 Linking interface (continued)
6.3.1 Presentation (continued)
The linking interface helps to maintain the bending radius of the
cables:
U-shaped cable tray, see section 6.1.
6.3.2 Features
- Corner blocks and cover 2 mm thick steel + paint finish
(same as cabinets)
- Trap 1.5 mm thick steel + paint finish (same as cabinets)
- Supplied with black cable entry brushes (polyamide fibres)
and complete set of screws (apart from those for fixing to the floor)
(1)
Usable feedthrough area with brush: 110 x 435 mm
Fixing to the floor
600
600
120
(1)
160
120
(1)
435
435
75
200
478
478
14

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
16/31
CONTENTS
6. PLINTHS (continued)
6.4 Adjustable height plinths
6.4.1 Presentation
Adjustable height plinths are used in rooms equipped with a raised
floor composed of tiles. The plinth transfers the load of the cabinet
directly to the ground.
Adjustable height plinth
Cat. No. For cabinet width / depth (mm)
0 464 30 600 x 600
0 464 31 600 x 800
0 464 32 600 x 1000
0 464 34 800 x 600
0 464 35 800 x 800
0 464 36 800 x 1000
Each plinth is supplied with front and rear floor tile support brackets.
Side tile support brackets must be order separately for the end of the
cabinets:
Set of 2 side tile support brackets
Cat. No. For plinth depth (mm)
0 464 38 600
0 464 39 800
0 464 40 1000
6. PLINTHS (continued)
6.4 Adjustable height plinths (continued)
6.4.2 Features
- For floor tiles 30 or 38 mm thick
- Height adjustable from 200 to 350 mm in 25 mm steps + fine
adjustement by levelling feet
- Permissible load: 1 000 kg
- Direct fixing to the end plate of the cabinet by M12 screws
- Can be fixed to the floor (screws not supplied)
- Plinth 2 mm thick galvanised steel
- Tile support brackets 1.5 mm thick galvanised steel
- Levelling feet zinc-plated steel with block polypropylene fixed base
- Supplied with complete set of screws for the equipotential link with
the cabinet
Set of
2 lateral
tile support
brackets
Cat. Nos
0 464 38/
39/40
30
or 38
(tile
thickness)
15
25
Ø9
14
Width
A
C
H
Depth 31
(tile
support
area)
B
D
Cat. No. Width x
Depth
H(1) Usable area Distance
(width x depth)
Min. Max. A B C D With
cabinet
To the
ground
0 464 30 600 x 600
200 350
530
530
435
435 478 x 478 520 x 520
0 464 31 600 x 800 730 635 478 x 678 520 x 720
0 464 32 600 x 1000 930 835 478 x 878 520 x 920
0 464 34 800 x 600
730
530
635
435 678 x 478 720 x 520
0 464 35 800 x 800 730 635 678 x 678 720 x 720
0 464 36 800 x 1000 930 835 678 x 878 720 x 920
(1)
Ajustable in 25 mm steps + fine adjustement

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
17/31
CONTENTS
7. CABLE MANAGEMENT
7.1 Cable entry plates
7.1.1 Presentation
19" LCS2freestanding cabinets have pre-cut 19"format top and
bottom cable entries.
600
800
After cutting out the cable entries, they can be equipped with
feedthroughs with brushes using the following 19"equipment:
The plastic plates Cat. Nos. 0 465 28/29 clip directly onto the cable
entries. They require a flat screwdriver for removal.
Cat. No. Plate with brushes
0 465 28 Plastic 1U
0 465 29 Plastic 2U
0 465 30 Metal 1U
0 465 31 Metal 2U
CLICK
7. CABLE MANAGEMENT (continued)
7.1 Cable entry plates (continued)
7.1.1 Presentation (continued)
The metal plates are equipped with 2 quick fixings that do not require
any screws or tools.
The 3U cable entries also enable the installation of plates with fans
Cat. Nos. 0 464 87/88 for thermal management of the cabinet (see
section 9.1).
7.1.2 Features
7.1.2.1 Plastic plates
ABS plates equipped with a flexible brush (2 brushes for 2U height).
Black RAL 9005
1U plate Cat. No. 0 465 28 (above):
- 2 feedthroughs 125 x 25 mm
- 1 central feedthrough 113 x 25 mm
2U plate Cat. No. 0 465 29:
- 2 feedthroughs 125 x 45 mm
- 1 central feedthrough 113 x 45 mm
1
2
Cat. No. 0 364 54
At the top of LCS2cabinets, the metal plates must be fixed
using screws and cage nuts with pins in order to provide
the equipotential link between the plate and the painted end
plate of the cabinet.

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
18/31
CONTENTS
7. CABLE MANAGEMENT (continued)
7.1 Cable entry plates (continued)
7.1.2 Features (continued)
7.1.2.2 Metal plates
Plates 1.5 mm thick steel equipped with a flexible brush
(2 brushes for 2U height).
Black RAL 9005.
1U plate Cat. No. 0 465 30:
- 1 feedthrough 400 x 23 mm
2U plate Cat. No. 0 465 31 (above):
- 1 feedthrough 400 x 66 mm
7.2 Cable trays
7.2.1 Presentation
With the cable management supports, a side and/or rear cable tray
can be installed in 19"LCS2freestanding cabinets.
The advantage of the flat cable tray over the U-shaped tray is that the
cables flow more easily (no edges).
PL
Cat. No. Set of 3 supports
0 464 72 For cabinet width/depth 600 mm
0 464 73 For cabinet width/depth 800 mm
0 464 74 For cabinet depth 1000 mm
Cat. No. Flat cable trays
0 464 76 For 33U cabinet
0 464 77 For 42U cabinet
7. CABLE MANAGEMENT (continued)
7.2 Cable trays (continued)
7.2.1 Presentation (continued)
The supports are fixed onto the structural uprights of the cabinet, and
the tray is mounted without screws:
PL
1
2
42U 19"LCS2cabinets can also be joined via a cabling unit,
providing a solution for easy management of cables and cords (see
section 5.2).
7.2.2 Features
7.2.2.1 Cable management supports
- Supplied in sets of 3
- For fixing using self-tapping screws
- Max. diameter of grid wire: 6 mm
- 1.5 mm thick galvanised steel
PL
W
50
9.5 x 9.5
6.5 x 11.5
Cat. No. W (mm) No. of tray fixing points Fixing centre
0 464 72 450 9 510
0 464 73 650 13 710
0 464 74 850 17 910

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
19/31
CONTENTS
7. CABLE MANAGEMENT (continued)
7.2 Cable trays (continued)
7.2.2 Features (continued)
7.2.2.2 Flat cable trays
- Frame: 100 x 50 mm
- Zinc-plated steel
7.3 Vertical cable management grid
7.3.1 Presentation
800 mm wide 42U 19"LCS2freestanding cabinets can take the
vertical cable management grid Cat. No. 0 331 35, fixed onto the
outside of the 19"uprights.
The guide has articulated latches. As the latches are clipped on, their
direction of opening can be reversed.
7.3.2 Features
- Supplied singly
- Overall dimensions: H 1562 x W 100 X D 155 mm
- Wire diameter: 5 mm
- Steel wire + paint, ABS-PC latches
- Supplied with screws
- Black RAL 9005
Cat. No. Overall dimensions (mm) Wire diameter
(mm)
0 464 76 1405 x 255 4.4
0 464 77 1805 x 255 4.4
42U 19"LCS2cabinets can also be joined via a cabling unit,
providing a solution for easy management of cables and cords (see
section 5.2).
7. CABLE MANAGEMENT (continued)
7.4 Vertical cable manager
7.4.1 Presentation
800 mm wide 42U 19"LCS242U freestanding cabinets can be fitted
with the set of 2 vertical cable manager panels Cat. No. 0 464 80.
The panels are mounted on the outside of the 19"uprights. The wiring
is organised using feedthroughs with brushes, cable management
rings and slots for cable ties.
The management rings are plastic and radiate out to provide optimum
protection for cords (maintain the bending radius). Each ring clips on
horizontally or vertically:
42U 19"LCS2cabinets can also be joined via a cabling unit,
providing a solution for easy management of cables and cords (see
section 5.2).
CLICK

Catalogue number(s): 0 463 00/06/12/18/19/21/22/23
0 463 28/29/30/33/34/35/41/42/43
19" LCS2freestanding cabinets
Technical data sheet: F01424EN/01 Updated on: 24/10/2014 Created on: 21/02/2012
20/31
CONTENTS
7. CABLE MANAGEMENT (continued)
7.4 Vertical cable manager (continued)
7.4.2 Features
- Set of 2 panels
- For fixing on 19"uprights and framework
- Ability to adjust the depth of the 19"uprights retained
- Feedthroughs: 174 x 50 mm usable
- Supplied with 8 flexible brushes and 8 stiff brushes (black polyamide
fibres)
- Supplied with 10 cable management rings, usable cross-section
4070 mm2(Cat. No. 0 465 42)
- Supplied with 9 cable ties with tightening indicator:
3 x Cat. No. 0 331 94,
3 x Cat. No. 0 331 95 and 3 x Cat. No. 0 331 96
- Supplied with screws
- Overall panel dimensions: 1878 x 108 mm
- Panels 1.5 mm thick steel
- Polyamide rings
- Black RAL 9005
7.5 Cable ties
7.5.1 Cable ties with tightening indicator
Cable ties with tightening indicator are wide ties with a smooth inner
surface for optimum protection of cables. They incorporate a warning
system to prevent over-tightening: fusible crescent-shaped pins snap
one after the other and act as visual and audible indicators.
Hooks hold the excess strap in place.
The ties are released by pinching the head of the tie and can be re-
used.
- Tensile strength: > 100 N
- Fire resistance: UL 94 HB
- Black high impact PBT
7.5.2 Self-locking cable ties
Self-locking cable ties are repositionable textile ties that do not
damage cables.
- Tensile strength: > 220 N
- Fire resistance: UL 94 V2
- Double-sided textile with "loops"on one side and "hooks"on the other
Cat. No. Width (mm) Length (mm) Tightening Ø (mm)
Max. Min.
0 331 94 15 180 35 15
0 331 95 15 225 50 35
0 331 96 15 320 80 50
Cat. No. Colour Width (mm) Length (mm) Max. tighte-
ning Ø (mm)
0 331 84 Black 16 150 35
0 331 85 Red 16 150 35
0 331 86 Green 16 150 35
0 331 87 Black 16 300 80
0 331 88 Red 16 300 80
0 331 89 Green 16 300 80
8. VERTICAL EXTENSION
The set of 2 vertical extension uprights Cat. No. 0 464 81 increases
the capacity of 42U 800 mm wide 19" LCS2freestanding cabinets by
12 U, giving a total capacity of 54U.
The extension, mounted on either side of 19"uprights, has 6 x 2U
positions for mounting 19"equipment vertically (panels, 19"PDUs,
etc.).
The cable management rings are plastic and radiate out to provide
optimum protection for cords (maintain the bending radius). Each ring
clips on horizontally or vertically:
Features
- Set of 2 uprights
- For fixing on 19"uprights and framework (top, bottom and central)
- Ability to adjust the depth of the 19"uprights retained
- Positions for 19"equipment: usable area 450 x 90 mm, perforations
9.5 x 9.5 mm
- Supplied with 8 cable management rings, usable cross-section
4070 mm2(Cat. No. 0 465 42)
- Supplied with screws
- Overall dimensions of upright: 1878 x 108 mm
- Uprights 1.5 mm thick steel
- Polyamide rings
- Black RAL 9005
0 464 81
x 2
42U
800
