87045 Limoges Cedex
Telephone: (+33) 05 55 06 87 87 - Fax:(+33) 05 55 06 88 88
Technical data sheet:F02868EN/00 Updated: 20/08/2019 Created: 20/08/2019
GalionTM
Key card switches
Cat. No(s): 2 824 15/15m/18/18m
K8/32KTY-HK K8/32KTY/RF-HK
1. USE
Suitable for the control of hotel room power.Time delay of approx.30s
after card removal.Complete delivered.
(Supplied with M3.5 screws for BS boxes. Flush mounting or Surface
mounting.)
3. PREPARATION
3.1 General preparation
2. RANGE
Colours
- front: white/rose golden/champagne/dark silver
- rear: white/rose golden/champagne/dark silver
X XXX XX white
X XXX XX-C matt black
X XXX XX-C1 rose golden
X XXX XX-C2 champagne
X XXX XX-C3 dark silver
Designation
Key card
switch 220V
116
115 220-240VAC
220-240VAC
16A
16A
2 824 18/18m
2 824 15/15m
2 824 15/15m/18/18m
K8/32KTY-HK K8/32KTY/RF-HK
Key card
switch RFID
Cat. No. Weight
(g)
Characteristics
1/2
- flushing
mounting
box:
- surface
mounting
box:
CONTENTS
1. Use.......................................1
2. Range...................................1
3. Pr ep aration .. ....... ....... .. ....... 1
4. Overall dimensions.................1
5. Connection...........................2
6. Technical characteristics......2
7. Cleaning.................................2
8. Conformity - Approvals..................2
1
2
4. OVERALL DIMENSIONS
Profile Size: 86×88 mm
Distance of installation hole: 60.3 mm
Minimum depth of the box>35 mm
K8/32KTY-HK
K8/32KTY/RF-HK
88
86 28.3
22
9.2
14.6
5. CONNECTION
5.1 Terminals
Terminal capacity:
4 X 1.5
3 X 2.5
2 X 4
Recommended screwdriver size: 4 mm flat blade
Recommended stripping length: 12 mm
Recommended terminal tightening torque: 0.5Nm
5.2 Circuit diagrams
4 X 1 mm²
mm²
mm²
mm²
Technical data sheet:F02868EN/00 Updated: 20 Created: 2 /08/2019 0/08/2019
2/2
6. TECHNICAL CHARACTERISTICS
6.1 Material characteristics
Rocker: Polycarbonate
Frame: Polycarbonate
Base: Polyamide
Self-extinguishing:
+ 850° C / 30 s for insulating parts holding live parts in place
+ 650° C / 30 s for other parts made of insulating materials
6.2 Electrical characteristics
Voltage: 220-240VAC ~ 50/60Hz
Current: 16A
6.3 Climatic characteristics
Storage temperatures: -10℃ to +70℃
Operating temperatures: -5℃ to +45℃
6.4 Mechanical characteristics
Impact test: Ik04
Protection against liquids: Ip20
7. CLEANING
Surface cleaning with a soft, slightly damp cloth.
Do not use: acetone, tar remover, trichloroethylene
8. CONFORMITY - APPROVALS
Conform to IEC 60669-2-1.
Key card switches
GalionTM
Cat. No(s): 2 824 15/15m/18/18m
K8/32KTY-HK K8/32KTY/RF-HK
