Leica Monovid 8x20 User manual

LEICA MONOVID 8x20
Anleitung
Instructions
Notice d’utilisation
Gebruiksaanwijzing
Istruzioni
Instrucciones
取扱説明書
Leica Camera AG
I
Oskar-Barnack-Straße 11
I
35606 SOLMS
I
DEUTSCHLAND
Telefon [phone]
I
Telefax [phone]
I
www.leica-camera.com
93 304 VI/09/DX/B

7
english
CONTENTS
Foreword ���������������������������������������������������������������������� 6
Items supplied �������������������������������������������������������������� 6
Designation of parts������������������������������������������������������ 6
Attaching the carrying strap and
the eyepiece protective cap�������������������������������������� 8
Adjusting the eye cups/
Using with and without glasses ��������������������������������� 8
Adjusting the focus ������������������������������������������������������� 8
Using the close up lens ������������������������������������������������� 8
Care/cleaning �������������������������������������������������������������� 9
Spare parts������������������������������������������������������������������� 9
Technical data ������������������������������������������������������������ 10
Leica on the Internet and Leica Academy �������������������� 11
Leica Information Service�������������������������������������������� 11
Leica Customer Care �������������������������������������������������� 11 WARNING INFORMATION
• Never look at the sun or other bright light sources
through the monocular� This can cause injury to
the eye�
• Never look through the monocular while walking.
You could miss obstructions�

ATTACHING THE CARRYING STRAP AND
THE EYEPIECE PROTECTIVE CAP
(See also Figure 1a/1b on the inside rear cover)
Note that the carrying strap has two loops:
– a shorter loop for attaching to the eyelet on the
monocular
– a longer loop for attaching the eyepiece protective cap
ADJUSTING THE EYE CUP/
USING WITH AND WITHOUT GLASSES
The eyepiece eye cup (1) is adjustable� It should be
extended (1a) for viewing without and retracted for view-
ing with glasses (1b)�
ADJUSTING THE FOCUS
The focus is adjusted for objects at different distances
using the focusing ring (3)�
USING THE CLOSE UP LENS
The LEICA MONOVID 8x20 can also be used to provide a
magnified view of objects that are at close range�
To do this, the close up lens (5) supplied is screwed into
the inner thread (5a) on the monocular lens (clockwise)�
Depending on the position of the focusing ring, this
results in a viewing distance of around 25–30cm with an
identical magnification�
8

9
english
CARE/CLEANING
Your LEICA MONOVID 8x20 does not require any
special care� Coarse dirt particles, such as sand, should
be removed with a hair pencil or blown off� Fingerprints
etc� on the lens and the eyepiece lenses can be wiped off
with a soft, clean leather or lint free cloth� The best way
to remove spots of water on the lens and eyepiece lenses
is with a cloth moistened with water�
Caution:
When wiping heavily soiled lens surfaces, do not exert
excessive force� Although the coating is highly abrasion
resistant, it can be damaged by sand or salt crystals�
SPARE PARTS
If you require any spare parts for your LEICA MONOVID
8x20, e�g� eye cups or the carrying strap, contact our
Customer Care department or the Leica office in your
country� The addresses are listed on the Warranty Card�

LEICA MONOVID 8x20
Magnification/with close up lens 8x/8x
Lens diameter 20mm/25
/
32“
Exit pupil 2�5mm/3
/
32“
Twilight factor 12�65
Field of vision 110m/yds/1000 m/yds
6�3°
Close up limit/with close up lens approx� 1�8m/6’11“/approx� 25–30cm/11“–12“
(at 0 dioptr�)
Exit pupil longitudinal distance 15mm/19
/
32“
Prism type Roof
Coating
on lenses High Durable Coating (HDC™) and water repellent Aqua-Dura coating
on outer lenses (not on close up lens)
on prisms High Lux System (HLS™) and phase correction coating P40
Operating temperature –25° – +55°/–13°F –131°F
Storage temperature –40° – +70°/–40°F – 158°F
Waterproofing 0�3bar (approx� 3m/yds water depth)
Housing material Aluminum
Dimensions/with close up lens approx� 35�5x97�9/105mm/113
/
32“ x 327
/
32“/41
/
8“
(Ø x L, eye cup retracted)
Weight/with close up lens approx� 112/126g/3�9/4�4oz�
TECHNICAL DATA
Note: The technical data and the design are subject to change�
10

english
11
LEICA INFORMATION SERVICE
The Leica Information Service can answer your technical
questions about applications of the Leica range in writing,
by telephone, by fax or by e-mail:
Leica Camera AG
Information Service
Postfach 1180
D 35599 Solms
Tel: [phone]
Fax: [phone]
info@leica-camera�com
LEICA CUSTOMER CARE
Leica AG’s Customer Care department or the repair
service provided by Leica national offices are available to
deal with maintenance of your Leica equipment or in case
of damage (see address list on Warranty Card)�
Leica Camera AG
Customer Care
Solmser Gewerbepark 8
D 35606 Solms
Tel: [phone]
Fax: [phone]
customer�care@leica-camera�com
