Leick Home Claudette User manual

Left Side Frame
Shelf
Assembly Instructions, #9231
Claudette Hall Stand
---1/2---
Right Side Frame
Back Gallery
Thank you for purchasing Leick Furniture products.
Contact customer service for comments or concerns.
Sheboygan, WI 800-558-8700 [email protected] todaysdesignhouse.com
Allen Wrench
Flat Washers
Door Pulls
Top Assembly
Short Bolts
Long Bolts
Machine Screws
Note:
A packet with complete set of hardware can be found by pulling the red ribbon that's
easily visible upon opening the box.
Anti-tipping Kit
A
B
C
D
E
F
G
H
I
J
K
L
1
1
1
1
1
4
8
12
1
2
2
1
Parts List

---2/2---
Step 1 Step 2
Step 3
Place the table upright. Open the drawer from bottom with fingers to install
pulls.
Step 4
Furniture Tipping Restraint
Top
Wall
Furniture Tipping
Restraint must
always be used to
prevent serious harm
or death to children.
A
E
D
F
H
H
G
I
K
J
H
F
G
H
I
B
C
Fasten the top assembly to the right side frame with 2 long bolts and washers.
Lay the right side frame (B) on a soft surface, insert its tube to one end of the back
gallery (C), as shown on the drawing below, fasten with one short bolt and flat
washer.
1.1)
1.2) Put the top assembly (D) on, fitting the metal tube's end onto the right side frame's
assembly tube. Fasten with 1 short bolt and washer at the bottom of top assembly.
1.3)
E
Insert the tubes of the left side frame to the ends of back gallery (C), top assembly
(D) and shelf (E).
2.1)
Push to make sure all tubes are properly inserted, fasten with 4 short bolts on back
gallery, bottom of top assembly and shelf.
2.2)
Fasten the top assembly to the left side frame with 2 long bolts and washers.
2.3)
3.1)
3.2) Fasten the drawer pulls with 2 machine screws from inner face of drawer front.
Check to ensure the 2 of them are properly aligned before tightening the machine
screws.
Adjust the levelers at the bottom of legs if needed.
4.1)
4.2) Fasten one part of the anti-tipping kit onto the pre-drilled holes at back panel and
another part into the wall. Loop the strap through the holes of the fastened parts
and pull its end to tighten.
1.4) Insert shelf (E) onto metal side frame's tube,fasten with 2 short bolts.
