Lelit PL2SVX-EU User manual

English
EN
User manual
*PL2SVX-EU PL2SVX-AUS PL2SVX-UK PL2SVX-CUS
230 V
50 Hz
240 V
50 Hz
240 V
50 Hz
120 V
60 Hz
E+F I G B

GiuliettaX - PL2SVX*
2
THANK YOU FOR CHOOSING
A LELIT PRODUCT
LELIT has the right to make changes to the
machine according to the needs of the different individual
countries and according to the advancement of
the technical progress.
Save the box and
all the packing material!
LELIT has studied the external and internal packing of your coffee machine
to help you re-use it in case of maintenance or repair need.

English
3
EN
Index
Product overview 4
1. General information 5
2. Installation information 5
3. Electrical installation 6
4. Equipotential connection 6
5. Water mains connection 7
6. Getting the machine ready for use 7
7. Installation check-up 7
8. Information for end user/operator 8
9. Warnings 10
10. Maintenance and repairs 10
11. Turning the machine ON 11
12. Warming up phase 11
13. Coffee extraction 11
14. Dispensing other hot beverages 14
15. Cleaning and maintenance 14
16. Toubleshooting – Solving the most common problems 16
17. Advices – Tips – Useful Images 17
ATTENTION:
Read the safety notes carefully before using this product.

GiuliettaX - PL2SVX*
4
PIC. 1
Product overview
1. Power cord
2. Tube for water mains connection
3. Water discharge tube
4. Main switch
5. Selection panel
6. Manometer for steam boiler pressure
7. Manometer for pump pressure
8. Drip tray
9. LELIT58 lterholder with Coffee Slide chute
10. Steam wand
11. Hot water wand
12. Steam distribution knob
13. Hot water distribution knob
14. Cup warmer rail
15. Cup warmer
16. Coffee distribution group
17. Adjustable feet
Selection panels
Equipment
• 2 LELIT58 lterholders with
Coffee Slide spout (9)
• 2 LELIT58 2 doses lters (14-18 gr)
• 1 LELIT58 1 dose lter (9-11 gr)
• 1 LELIT58 blind lter for backushing
• Plastic coffee tamper
• Espresso cup rack
K1GR1 K2GR1 K3GR1 K4GR1 K5GR1 K1GR2 K2GR2 K3GR2 K4GR2 K5GR2
14 14
12
10
16
4
5
1
11
17
2
3
12
10
8
6
7
13
9
in the
equipment box

English
5
EN
1. General information
Attention. Please read the warnings and rules in this User’s Manual carefully before using or
handling the machine in any way because they provide important information regarding safety and
hygiene when operating the machine. Keep this booklet handy for easy reference.
The machine was designed only for preparing espresso, coffee and hot beverages using hot water
or steam, and for warming cups.
The machine must be installed in a place where it is only used by carefully trained staff that knows
the risks tied with using the machine.
The machine is for professional use only.
This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved.
Children must always be supervised to prevent them from playing with the machine.
Children shall not play with the appliance.
The machine must not be left unattended or used outdoors.
If the machine is stored in rooms where the temperature can drop below freezing, empty the boiler
and water circuit tubes.
Do not expose the machine to atmospheric agents (rain, sun, cold).
Do not clean the machine with water sprays / jets.
The machine noisiness does not overcome 70 dB(A).
Should the power cord be damaged, please let only authorized, technically qualied people replace
it, to avoid any risk.
If the machine is used improperly or for purposes other than those described above, it can be a
source of danger. The manufacturer will not be held responsible for damages caused by improper
use of the machine.
2. Installation information
THESE CHAPTERS IN THE MANUAL ARE JUST FOR QUALIFIED, AUTHORIZED TECHNICAL
STAFF ONLY.
Attention. Installation, dismantling and adjustments must only be performed by qualied and
authorized technicians. Carefully read the warnings and rules in this manual because they provide
important information regarding safe installation, use and maintenance of the machine, before
operating with it. Keep this booklet handy for easy reference.
Staff responsible for moving the machine must realize the risks in moving heavy loads. Move the
machine carefully, using the correct lifting equipment (fork lift, for example). In case of moving the
machine by hand, make sure: enough people are available for the task, depending on the machine
weight and handling. Always use the necessary safety equipment (shoes/gloves).
After removing the machine from its packing materials, make sure that the machine and its safety
devices are intact.
Packing materials (plastic bags, polystyrene foam, staples, etc.) must be kept out of the reach of
children because they are potentially hazardous.
Before plugging in the machine, make sure that the information on the data label (voltage, etc.)
matches that of the electrical and water systems.

GiuliettaX - PL2SVX*
6
Completely unwind the power supply cord. Should the power cord be damaged, please let only
authorized, technically qualied people replace it.
The coffee machine should sit on a at, stable surface at least 20 mm from walls and from the
counter. Keep in mind that the highest surface on the machine (the cup warmer) should sit at a height
of at least 1.2 meters. Make sure there is a shelf nearby for the accessories.
Room temperature must range between 10° and 32°C (50°F and 90°F).
An electrical outlet, plumbing connections and a drain with siphon must be in the immediate vicinity.
Do not install in rooms (kitchens) that are cleaned with jets of water.
Do not obstruct openings or ventilation and heat vents.
Do not install the machine outdoors.
3. Electrical installation
Prior to installation, make sure there is a circuit breaker installed with a distance between the contacts
that allows for complete disconnection when there is a category III overload and that provides
protection against current leakage equal to 30 mA. The circuit breaker must be installed on the power
supply in compliance with installation rules. If the power supply is not working properly, the machine
can cause transitory voltage drops.
The electrical safety of this machine is only ensured when it is correctly connected to an efcient
earthing system in compliance with the electrical safety laws in force. This fundamental safety
requirement must be veried. If in doubt, require that a qualied electrician inspects the system. The
manufacturer cannot be held responsible for any damage caused by the lack of an earthing system
on the electrical supply.
It is unadvisable to use adaptors, multiple plugs, and/or extension cords. If their use is indispensable,
only use simple or multiple adaptor plugs and extension cords that are in compliance with safety laws.
Make sure that these devices do not exceed the voltage capacity marked on the simple adaptor and
on extension cords, and the maximum voltage marked on the multiple adaptor.
Check that the type of connection and voltage correspond with the information on the technical data label.
4. Equipotential connection
4.1
1This type of connection, required by some laws, prevents
differences in the electric potential level between the earthing
connections of equipment installed in the same room. This
machine is provided with a clamp (1) UNDERNEATH THE
BASE for the connection of an external equipotential
conductor. After installation, this type of connection MUST be
made (Pic. 4.1).
Use a conductor with a nominal section in compliance with
the laws in force.
Connect one end of the conductor to the clamp and the other
end to the earthing of adjacent equipment.
Failure to follow this safety norm releases the manufacturer from any responsibility for machine
breakdowns or damage to people or property.
Attention. Do not connect to the power supply earthing because it is not considered an equipotential
cable connection. Bear in mind that Gemme Italian Producers srl is not responsible for damage caused by
improper electrical connections, and that the installer is responsible for any damage.

English
7
EN
5. Water mains connection
Water used in coffee machines must be potable and suitable for human consumption (see laws and
regulations in force).
Check that the water pH level is 6-8°F and complies with the laws in force and that the chloride value
is less than 100 mg/l.
If the values do not fall within the limits, an appropriate water treatment device must be inserted
(respecting the local laws and compatible with the machine).
If the machine uses water with a hardness exceeding 8°F (4.5 °D), a specic maintenance plan must
be implemented according to the hardness detected and machine usage.
Use only the supplied parts for the connection: water inlet and outlet tubes, clamp for the water outlet tube.
If other parts are installed, they must be new (not used) and they must be able to come in contact with
potable water suitable for human consumption, according to any national rules that may be applicable.
Place the machine on a at surface and stabilize it by adjusting and securing the feet.
Hook up the water connections respecting the hygiene, water safety, and antipollution laws in the
country of installation.
If the water pressure can rise above 6 bar / 0.6 MPa, install a pressure reducer set at 3 bar / 0.3 MPa.
Place the end of the water draining tube in a drain with a siphon for inspection and cleaning.
The curves of the draining tube must NOT bend.
6. Getting the machine ready for use
Once the hydraulic and electrical installations are over, proceed to get the machine ready for use.
Open the tap of the water mains and close the general protection switch.
Switch on the main switch I/O: the relative pilot light will go on.
The self-levelling device will start working in order to ll the boiler with water until the right level is
automatically reached. During the rst lling of the boiler, it’s recommended to open the steam tap
and close the tap at the end of this operation to let eventual air come out from the wand.
Once the water has been automatically pumped into the boiler, the boiler heating element will start heating it.
Dispense half a litre of water from each extraction group.
Wait until the machine has reached the exercise nominal temperature.
The machine is now ready for use.
If after turning on the machine, the display shows the written “OFF”, select and press the K3GR1
button to start on the machine.
7. Installation check-up
Once the installation is over, check if the machine is working properly.
Verify that there are no leaks from the connections or tubes.
Verify that boiler and operating pressure comply with the nominal values, between 1 and 2 bar.
Verify that the pressure gauge and the pump pressure are working properly.
Verify that the self-leveling device is working properly.
Verify that the expansion valve is working properly.

GiuliettaX - PL2SVX*
8
Attention. Once the machine has been installed and is ready for use, before allowing the
operator to start using the machine, wash the internal components by following the instructions below.
EXTRACTION GROUPS
Hook up the lter holders to the groups (without coffee).
Let each group dispense water for about a minute.
HOT WATER
Continuously dispense hot water (by opening the relative knob) until at least 4 liters of water come
out of the machine.
STEAM
Dispense steam from the nozzles for about a minute, using the appropriate knob.
8. Information for end user/operator
8.1 First steps
Attention. Before you start operating
the machine, wash the internal components
following the instructions indicated below.
These steps must be repeated at least once
a day and when the machine has not been
operated for more than 8 hours.
Attention. For a correct programmed
cleaning procedure follow the indications
described in chapter “15. Cleaning and
maintenance”.
EXTRACTION GROUP
Hook up the lter holders to the groupsheads
(without coffee).
Let each group dispense water for about a
minute.
HOT WATER
Continuously dispense hot water (by opening
the relative knob) until at least 4 liters of water
come out of the machine.
STEAM
Dispense steam from the nozzles for about a
minute, using the appropriate knob.
8.2 During daily use
The machine can work on 3 different
temperature proles, according to the periods
of non-use.
OFF
(8.1)
Temperature
ENABLED
(8.2)
The temperature measure unit can be set
from the technical menu: enter the OFF mode
(Pic. 8.1) (K5GR1+K3GR1 and keep K5GR1
pressed for 10 seconds), scroll the menu by
pressing the K5GR1 until you reach the screen
13, where you have the possibility to enable or
disable the temperature function by pressing
K1GR1 or K2GR1. Conrm selection by
pressing K5GR1 (Pic. 8.2).
° c
Temperature
(8.3)
Boiler
1 2 5 ° C
Temperat.
(8.4)
In the following screen (screen 14) you can
choose the temperature measure unit (°C/°F)
by pressing K1GR1 or K2GR1 (Pic. 8.3).
Conrm selection by pressing K5GR1.
In the screen 15 you can use the K1GR1 and
K2GR1 to set the temperature value that the
boiler will reach during the use of the machine
(this value is between 110°C and 130°C).
Conrm selection by pressing K5GR1 (Pic. 8.4).
This temperature value will determine the steam

English
9
boiler pressure. During the use of the machine,
this value can uctuate (between 1 and 2 bar).
STEAM DISPENSING
Before heating the beverage (water, milk, etc.),
open the steam knob for at least 2 seconds and
let the condense water come out of the wand.
COFFEE EXTRACTIONS
If the machine has not been used for more
than 15 minutes, the operator can set a
lower temperature than the normal usage
temperature. In the screen 16, you can set the
value between 110°C and 130°C (Pic. 8.5).
> 1 5 m
1 2 0 ° c
T e m p e r a t .
(8.5)
If the machine has not been used for more than
an hour, before making coffee, dispense about
100 cc of water through the extraction group.
HOT WATER DISPENSING
If the machine has not been used for more than
an hour, before using the hot water, dispense
about 200 cc.
CLEANING THE COFFEE CIRCUITS
Please read the specic section to learn more
about this.
ENERGY SAVING
You can enable the Energy Saving/Stand
by function in screen 19: if the machine has
not been used for more than 240 minutes, the
boiler temperature drops until it reaches the
default value, 110°C.
This last setting can be enabled or disabled,
without having the possibility to modify the
value of the set temperature.

GiuliettaX - PL2SVX*
10
9. Warnings
CAUTION: HOT
Danger of burns. The areas marked with
“CAUTION: HOT“ label become very hot. PARTICULAR
CARE IS NEEDED WHEN CLOSE TO THESE AREAS.
9.1 General warning
The manufacturer disclaims all liability for damages to items or persons due to improper use or due
to the coffee machine being used for reasons other than its intended use.
Never operate the espresso machine with wet hands or bare feet.
Do not place hands or other body parts close to the coffee distribution points or near to the steam
and hot water wands.
Ensure that the machine is not handled by children or people that have not been properly instructed
regarding its correct use.
On the cup warmer place just the cups/glasses that need to be used in conjunction with the coffee
machine.
Ensure that the cups/glasses are completely dry before placing them on the cup-warming surface.
No other objects should be placed on the cup warmer.
9.2 Usage discontinuity
When the machine remains unused for a long period of time (at night or during holidays), the following
operations should be performed:
Unplug the machine or switch off the main switch.
Close the main water tap.
If the machine remains unused for more than 4 days, drain the boiler by means of the tap supplied.
NB: upon restart perform the operations described in chapter 6.
Non-compliance with these safety measures exonerates the manufacturer from all liability for
malfunctions or damage to persons or items.
10. Maintenance and repairs
Attention. Maintenance perfomed by unqualied people can compromise the safety and
conformity of the machine. Let only qualied, authorized technicians operate/repair the machine.
To ensure safety during operation, it is absolutely necessary to: follow the manufacturer’s instructions;
have qualied, authorized technicians periodically check that all safety devices are intact and work
properly (the rst inspection must be done after 3 years from the purchase date and, afterwards,
every year).
In case of malfunction, turn off the machine, turn off the main on-off switch and call the service center.
If the power supply cord is damaged, turn off the machine and ask for a replacement cord from the
service center.
Only use original spare parts guaranteed from the manufacturer. The manufacturer warranty will
cease if other non-original parts will be used.
After maintenance always perform the installation CHECK-UP as indicated in the specic section of
this manual.

English
11
EN
The access to the service area is restricted to persons having knowledge and practical experience of
the appliance, in particular as far as safety and hygiene are concerned.
Cleaning and user maintenance shall not be made by children without supervision.
11. Turning the machine ON
Attention. Before setting the machine at work, make sure that: the main electric power switch
is on and that main water tap is open.
ON
OFF
11.1
4
ELECTRIC SWITCH ON
Press the main switch (4) ON (Pic. 11.1). The boiler will be
lled with water until the foreseen level. The “Heating phase”
will start. At the end of the working day, the machine can go
into the Stand by mode (automatically after 240 minutes of
inactivity) or can be turned off by pressing the main switch
(4) OFF.
12. Warming up phase
Attention. Do not put any cloth on the cup warmer..
While waiting for the machine to get ready, x the lterholders (9) in the extraction groups. Do not
cover the cup warmer with cloths to prevent the over-heating of the machine. When the display shows
the exercise temperature, the machine is ready for use.
13. Coffee extraction
K1 K2 K3 K4 K5
13.1
1. Unhook the lterholder (9) from the extraction group.
2. Fill the lter with the desired dose of ground coffee.
3. Press the coffee with a tamper and clean the lter edges from eventual coffee residues/rests.
4. Firmly lock the lterholder (9) to the grouphead and make sure that the group gasket provides a good seal.
5. Place the cup/cups under the lterholder dispensing spouts.
6. PRE-PROGRAMMED DOSES: press one of the switches (K1-K2-K3-K4) and the pre-programmed
dose will be dispensed. Water will stop owing out once the programmed quantity will be reached.
7. CONTINUOUS DISPENSING: to have continuous dispensing, press the continuous/stop switch
K5 (Pic. 13.1).
8. Attention: if the machine is dispensing coffee and you press any of the switches of the same
selection panel, the dose will be interrupted.
9. To brew other coffees, remove the lterholder, clean it from the coffee rests with a wet soft cloth
and repeat the above mentioned operations.

GiuliettaX - PL2SVX*
12
13.1 Coffee dose programming
The machine has a selection/control panel for each extraction group:
K1GR1 K2GR1 K3GR1 K4GR1 K5GR1 K1GR2 K2GR2 K3GR2 K4GR2 K5GR2
13.2 13.3
Through the control panel it’s possible to perform the machine functions:
Button Function Special function
1 espresso +
1 coffee -
2 espressos
2 coffee
Continuous extraction Enter programming/scroll screen/conrm
function
Reference Pic. 13.2
Button Function Special function
1 espresso
1 coffee
2 espressos
2 coffee
Continuous extraction
Reference Pic. 13.3
Before programming the coffee dispensing buttons ll the lterholder with the correct dose
of ground coffee. Don’t use coffee rests for programming the doses. It’s possible to modify
and save the doses (through volumetric control) by following the procedure described below:
1. To enter the programming mode: press one of the K5 buttons of any of the 2 groups and keep it
pressed for more than 5 seconds; the LED of the K5 button will blink on both selection panels (Pic.13.4).
2. Within 30 seconds (after 30 seconds you are out of the programming mode) press any of the 4
switches for the different doses (for example switch K1GRx). The relative led of K1GRx of the dose
you are programming and the LED of K5GRx will stay on (Pic.13.5).

English
13
EN
13.4 13.5
3. Once the desired quantity of coffee for that dose is reached, press the selected button again and
the serving dose will be memorized. The machine will go back to doses programming mode. At the
same time, the LED of the programmed dose will go off and the LED of both K5 buttons will blink; now
it’s possible to program the other doses without repeating the operation described in point 1.
4. To program the other doses (if the time-out of 30 seconds has not elapsed yet) repeat points 2 and 3
consequently.
If the time-out of 30 seconds has already elapsed and you are out of the programming mode, you need to
repeat all the operations of points 1-2-3 to enter in the programming mode again.
To exit the programming mode without modifying any of the parameters just wait for 30 seconds, without
pressing any button.
IMPORTANT: what has been programmed on the FIRST GROUP is ALWAYS automatically
transferred also TO THE OTHER GROUP. This does not mean that you cannot program the other
group independently from group 1, you can do so by repeating the operations in points 1-2-3 also
on the other group.
13.2 Washing cicle
The washing cycle enables the cleaning of the extraction groups and can be performed
as follows:
13.6
A B
Press the continuous/stop button (K5GRx) (A)
and then the switch (K1GRx) (B) of the group
where you want to perform the washing cycle
(Pic.13.6).
The washing cycle will be conrmed by the
synchronic blinking of the relative LEDs of the
2 buttons that you have pressed one after the
other (K5GRx + K1GRx); the blinking will continue during the entire washing cycle and will stop if
any of the other switches of the same panel will be pressed. In this case the washing cycle will be
interrupted and the LEDs will go back to the ON position. It’s possible to undergo the washing cycle
using an appropriate detergent powder (see chapter 15).
The extraction group that undergoes the washing cycle will dispense water 5 times through the group.
Once the cycle is over, the selection panel will go back to the normal functioning mode.
It’s possible to do the washing cycle at the same time on both groups, as many times as desired
during the working day.
In chapter 15. CLEANING AND MAINTENANCE you’ll nd out how to perform the washing cycle with
the recommended detergent powder.

GiuliettaX - PL2SVX*
14
14. Dispensing other hot beverages
14.1
12
10
STEAM DISPENSING
Once the machine is ready, open the steam
knob (12) anticlockwise with the steam wand
(10) directed on the drip tray and let the initial
condense water come out; then close the steam
knob to stop the function (Pic. 14.1).
Completely immerse the steam nozzle (10) into
the jug with the beverage. Gradually open the
steam knob (12) anticlockwise to let the steam come out and turn it clockwise to stop it.
13
11
14.2 HOT WATER DISPENSING
Place the jug under the hot water wand (11).
Open the hot water knob (13) anticlockwise to
let the water come out and turn it clockwise to
stop it (Pic. 14.2).
MILK FROTHING FOR CAPPUCCINO
Use a tall narrow jug and ll it up to about the
half-way mark.
Once the machine is ready, open the steam knob (12) anticlockwise with the steam wand (10) directed
on the drip tray and let the initial condense water come out; then close the steam knob.
Plunge the steam wand (10) into the milk.
Gradually open the steam knob (12) and heat the milk for a few seconds.
When the required amount of froth has been made and the temperature is sufciently warm, stop the
steam ow by turning the steam knob (12) clockwise.
Once the frothing is over, clean the steam wand (10) thoroughly with a sponge or a clean cloth.
NOTE. At the end of each steam dispensing phase, clean the inside of the steam nozzle as
follows: turn the nozzle towards the drip tray and carefully activate the steam dispensing at
least once, clean the steam wand thoroughly with a sponge or a clean cloth.
15. Cleaning and maintenance
Attention. For the correct application of the food safety system HACCP, please follow the
instructions in this chapter.
15.1 Groups cleaning
15.1 15.2
Procedure to be done at the end of each working day, on each grouphead.
Clean the group gasket with a brush (Pic. 15.2).

English
15
EN
Insert the blind lter in the lterholder.
Pour 3-5 gr of detergent powder (or 1 single bag of LELIT PLA9201) in the blind lter (Pic.15.1).
Hook the lterholder onto the grouphead and perform a washing cycle acting as described in
paragraph 13.2.
Remove the lterholder and clean the shower lter with a sponge.
Rinse by letting the hot water come out of each group for 30 seconds.
15.2 Filterholders cleaning
Pour 1 litre of warm water and 10 gr of detergent powder (or 3 single bags of LELIT PLA9201) into
a suitable basin.
Remove the lters from the lterholders.
Immerge and leave the lters and lterholders in the solution for at least 20 minutes.
Remove any residues with a sponge and rinse with plenty of warm water.
Place the lters in the lterholders, making sure that the lter xing spring is in the correct position.
15.3 Cleaning of the steam and hot water wands
Use a clean sponge to wash the wands with hot water and remove any eventual organic residue.
Rinse carefully.
To clean the steam nozzle inside, proceed as follows: turn the nozzle towards the cup tray and
carefully activate the steam dispensing at least once.
15.4 Cleaning of the water drip tray
Remove the drip tray and the relative grate and rinse both with tap water.
15.5 Cleaning of the water discharge tray
At the end of the working day, pour a jug of hot water into the discharge tray, removing any eventual
organic residue.
15.6 Cleaning of the appliance body
Use a soft cloth and cleaning products WITHOUT ammonia or abrasives to remove any eventual
organic residue in the work area. Do not spray liquids into the panel slots.
15.7 Cleaning of the coffee circuits – descaling
The descaling procedure must be performed regularly to ensure a stable performance of the machine
functions.
The frequency of the descaling cycle depends on the used water prole.
Contact your direct reseller/authorized installer for more details to program the correct descaling
frequency.

GiuliettaX - PL2SVX*
16
16. Toubleshooting – Solving the most
common problems
Before calling the service personnel, to avoid useless expenses, check whether the machine problem
corresponds to one of the cases indicated below.
Malfunction Cause Solution
Leaking from the lterholder
edge
Dirty group gasket Clean the group gasket with a brush
and/or replace the gasket with an
original part.
Coffee extraction time too
short
Too coarse coffee grinding degree
The used coffee is too old
Use a ner grinding degree.
Use fresh coffee.
Coffee comes out in drops Filter holes blocked or lter holder
outlet dirty
Too ne coffee grinding degree
Clean the lter/the lterholder.
Use a coarser grinding degree.
Water leak under the
machine
Discharge tray blocked
Discharge tray hole blocked
Empty and clean the discharge tray.
Clean the hole.
Steam pressure higher than
2 bar
Fake pressure inside the boiler Open the steam tap for few minutes.
Steam comes out from
underneath the drip tray
Too much water inside the boiler
Check the steam pressure: if it is
above 2,5 bar, probably there is a
problem with the lling of the boiler
or the heating of the steam boiler
Open the water tap and take out
some litres of water.
Steam pressure lower than
0.8 bar
Check if the machine is in Stand By
mode
Press a button to exit the Stand-by
mode.
Coffee temperature
too hot/cold
Adjust the temperature using the
display
See the following link: https://youtu.
be/5jC4WnZankw
Machine does not heat Check the water mains pressure
(pump manometer)
Check the pressure on the steam
manometer
Turn off and turn on the machine.
RESET1the unit: if the reset does
not work, please contact your
reseller/authorized technician.
If the pressure is at 0, it means
that there may a problem with
the heating, please contact your
reseller/authorized technician.
Water comes out from the
drainage tray
Check the slope of the discharge
tube
If this does not solve the situation,
please contact your reseller/
authorized technician.
No water comes from the
water wand
Check, clean or replace the
distribution lter
If this does not solve the situation,
please contact your reseller/
authorized technician.
The selection panel blinks,
all functions are blocked
Turn off and turn on the machine If this does not solve the situation,
please contact your reseller/
authorized technician.
The machine continues
charging water
Check the water prole: it needs to
be suitable for coffee machines
If this does not solve the situation,
please contact your reseller/
authorized technician.
1. RESET: to perform the RESET of the entire unit, turn the machine off, press the buttons 1-3-5 (K1GR1-K3GR1-K5GR1) at
the same time and afterwards turn the machine on.

English
17
EN
17. Advices – Tips – Useful Images
Attention. This chapter is for the use of qualied and authorized technical staff only. The
access to the service area is restricted to persons having knowledge and practical experience of the
appliance, in particular as far as regards safety and hygiene.
Attention. The machine must be fed with water having a hardness between 3 and 9°F. It is
forbidden the use of tubes and gaskets that have been already used.
1
2
17.1 17.2
It is advisable to install a water softener (1) for the water connection of the machine (Pic.17.1).
Attention. Before connecting the water softener to the machine, perform a rinsing cycle and
wait until the water is clear. Only after this you can connect the water softener to the machine.
Attention. The manometer “PUMP” shows the inlet pressure (the hydraulic mains pressure).
Therefore, even with the pump out of function, the manometer will never show “0” value. When the
pump is off, the pressure does not have to exceed 5 bars. The hydraulic mains pressure we recom-
mend is between 2-3 bars. If you register a higher or lower inlet pressure, please contact a specialist
to adjust the pressure. Anyway, the inlet pressure must not exceed 5 bars to avoid damages.
If the pressure of the mains is above 0.5 Mpa (5 bar), it is recommended to install a balanced pres-
sure reducing valve for high pressure (a device in which any increase in the mains pressure does not
affect the output pressure).
The water draining tube (2) must not bend to avoid water returns to the machine (Pic.17.2).
To complete the installation of the machine and assemble the cup warmer rail proceed as indi-
cated below. Follow the assembling instructions carefully. In case of maintenance / opening the
machine body, act the other way round.
17.3 17.4
Loosen the two side screws using a PH2 Phillips screwdriver (Pic.17.3).
Remove the lateral panels (Pic.17.4).

GiuliettaX - PL2SVX*
18
17.5 17.6
Use a PH2 Phillips screwdriver and remove the 3 xing screws of the cup warmer shelf (Pic.17.5).
Use a PH2 Phillips screwdriver and tighten the 8 M screws (part#MC268/I) present in the package to
x the sides of the cup warmer shelf (Pic.17.6).
Attention. The polished side of the shelf must face outwards (high).
17.7 To adjust/set the pump pressure, act on the screw
(10) after having loosen the locknut. By turning it
clockwise, the pressure increases, anticlockwise,
the pressure decreases. At the end tighten the
locknut (Pic.17.7).

English
19
EN
IMPORTANT INFORMATION
For the correct disposal of the product in accordance with EU DIRECTIVE
2002/96/EC and with Legislative Decree no. 151 of 25 July 2005. At the
end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special authorised differential waste collection centre
or to a dealer providing this service. Disposing of a household appliance
separately avoids possible negative consequences for the environment
and health caused by improper disposal and enables recovery of the
materials it contains, with signicant savings in energy and resources.
The product is marked with a crossed-out wheelie bin as a reminder of the
need to dispose of household appliances separately.
EC DECLARATION OF CONFORMITY
Gemme Italian Producers srl declares under its own responsibility that
the product:
Coffee machine for professional use type: PL2SVX
to which this declaration relates conforms to the following standards:
2006/42/EC EC Machinery Directive
2014/35/UE EC Low Voltage Directive
97/23/EC Pressure Equipment Directive (PED)
IEC 60335/1:2010 - IEC 60335/2/75:2012 Electrical Appliance Safety
EC 55014-1:2017 - EN 55014-2:2015 - IEC 61000-3-2:2018
IEC 61000-3-:2013 Electromagnetic compatibility
NB: This declaration is null and void should the machine be modied
without our specic authorisation.
Castegnato, 02/05/2021 - Managing Director
Gemme Italian Producers srl
25045 Castegnato (Bs)

LELIT.COM
EN/7800056 REV 01
©2021 Gemme Italian Producers Srl.
All Rights Reserved
